Gefen EXT-USB-MIDI User manual

CAT-5 Cables
Optional
Accessories
USB MIDI Extende
r
Extends any USB device up to 150 feet away from the computer.
The USB MIDI extender extends any USB device up to 150 feet from the location of your computer,
eliminating the 16 feet distance limitation of USB. The USB MIDI sender and receiver units use one
CAT-5 cable for extension. It is optimized for applications where two devices, such as the keyboard
and mouse, must be operated remotely. The USB MIDI extender can even be used to extend
surveillance cameras for security purposes. The USB MIDI Extender extends any MIDI device.
How It Works
The USB MIDI extender sender unit is connected to the computer using the supplied USB cable.
The remote peripheral(s) are connected to the receiver unit. A category-5 (CAT-5) cable is used to
link the sender to the receiver.
Features:
zExtends any USB device up to 150 feet (45 meters) using CAT-5 cable
zRequires no external power adapter
zProvides support for any full-speed 12 Mb/s or low-speed 1.5Mb/s USB device
zUse either PC or Mac with USB keyboard/mouse
zIdeal for USB MIDI interface devices
Specifications:
zUSB device support: full-speed 12 Mb/s Low-speed 1.5 Mb/s
zUSB Input Connectors: type B
zUSB Output Connectors: type A
zLink Connector: RJ-45
zShipping Weight: 2 lbs.
Package Includes:
zUSB MIDI extender send unit
zUSB MIDI extender receive unit
z6.6' USB cable (A-B)
zUser Manual
EXT-USB-MIDI
Dystrybucja i sprzedaż: Meditronik Sp. z o.o.
02-952 Warszawa, ul. Wiertnicza 129, tel. [phone], fax [phone]
http://www.meditronik.com.pl e-mail: [email protected]

USB MIDI
Extender
USER MANUAL
www.gefen.com

ASKING FOR ASSISTANCE
Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00am to 5:00pm
Monday thru Friday
Write To:
Gefen, Inc.
c/o Customer Service
20600 Nordhoff Street
Chatsworth, CA 91311
www.gefen.com
[email protected]
© 2007 Gefen Inc., All Rights Reserved
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
USB MIDI is a trademark of Gefen Inc.

TABLE OF CONTENTS
Introduction / How It Works
Operation Notes / Features
USB MIDI Extender Installation
Panel Description
CAT-5 Cable Diagram
Warranty
1
2
3
4
5
6

Thank you for purchasing the USB MIDI Extender. Extending your USB peripherals
(i.e. computer keyboard, mouse or trackball) up to 150 feet away from the location of
your Macintosh or PC computer are done easily with the USB MIDI Extender.
The USB MIDI extender extends any USB device up to 150 feet from the location of
your computer, eliminating the 16 feet distance limitation of USB. The USB MIDI sender
and receiver units use one CAT-5 cable for extension. It is optimized for applications
where two devices, such as the keyboard and mouse, must be operated remotely.
The USB MIDI extender can even be used to extend surveillance cameras for security
purposes. The USB MIDI Extender extends any MIDI device.
How It Works
The USB MIDI extender sender unit is connected to the computer using the supplied
USB cable. The remote peripheral(s) are connected to the receiver unit.A category-5
(CAT-5) cable is used to link the sender to the receiver.
The USB MIDI Extender Package Includes:
(1) USB MIDI extender send unit
(1) USB MIDI extender receive unit
(1) 6.6’ USB cable (A-B)
(1) User Manual
INTRODUCTION
1

NOTES
READ THESE NOTES AND FEATURES BEFORE INSTALLING
OROPERATING THE USB MIDI EXTENDER.
• The USB MIDI sender and receiver were designed to operate on USB enabled
computers and systems. DO NOT attempt to use this equipment with any other type of
computer.
• Only dedicated Category 5 UTP type cable (CAT-5) is recommended for this
application (pin to pin). Shielded CAT-5 cables are recommended for long distances to
protect your signal from EMI.
• The length of cable used to connect the USB MIDI Extender MUST NOT EXCEED 150
2
FEATURES
• Extends any usb device up to 150 feet (45 meters) using CAT-5 cable
• Requires no external power supply
• Provides support for any full-speed 12 MB/S or low-speed 1.5 MB/S USB device
• Use either PC or MAC with USB keyboard/mouse
• Ideal for USB MIDI interface devices

USB MIDI EXTENDER INSTALLATION
3
1. Place the USB MIDI Reciever unit close to the USB devices at the remote end.
2. Connect the USB devices to the USB MIDI Reciever unit.
3. Place the USB MIDI Sender unit close to the host computer.
4. Connect the USB MIDI Sender unit to the USB MIDI Reciever unit using the desired
length of CAT5 cable.
5. Connect the USB•100S unit to the host computer using the USB cable supplied with
the unit. This connection should be made last.

PANEL DESCRIPTION
4
Sender
Reciever
USB cable connects to computer

LINK CABLE - WIRING DIAGRAM
White/Blue
Blue
White/Green
Brown
White/Brown
Green
White/Orange
Orange
RJ-45 Jack
2 3 4 5
6
7 8 1
2 3 4 5
6
7 8 1
1818
5

WARRANTY
Gefen Inc. warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen Inc. is notified within two (2) year
from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment,
provided that the equipment has not been subjected to mechanical, electrical, or other
abuse or modifications.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the time of repair. Such repairs are warranted
for ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fitness for any particular purpose, all
of which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cable must be free from any
scratches, markings, and neatly coiled.
The information in this manual has been carefully checked and is believed to be accurate.
However,Gefen, Inc. assumesno responsibilityforany inaccuraciesthatmay becontained
in this manual. In no event will Gefen, Inc., be liable for direct, indirect, special, incidental,
or consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information contained herein
regarding USB MIDI Extender features and specifications is subject to change without
notice.
