Gefen EXT-HDMI-2-COMPSVIDSN User manual

®
HDMI
to
Composite / S-Video
Scaler
EXT-HDMI-2-COMPSVIDSN
User Manual
www.gefen.com

ASKING FOR ASSISTANCE
Technical Support:
Telephone  (818)772-9100
   (800)545-6900
Fax   (818)772-9120
Technical Support Hours:
8:00AMto5:00PMMondaythroughFriday,PacicTime

Write To:
Gefen,LLC
c/oCustomerService
20600NordhoffSt
Chatsworth,CA91311
www.gefen.com
[email protected]




Notice
Gefen,LLCreservestherighttomakechangesinthehardware,packagingandany
accompanyingdocumentationwithoutpriorwrittennotice.
HDMI to Composite / S-Video Scaler isatrademarkofGefen,LLC


Alltrademarksarethepropertyoftheirrespectivecompanies.
©2013Gefen,LLC,AllRightsReserved
Alltrademarksarethepropertyoftheirrespectivecompanies
Rev A1

CONTENTS
INTRODUCTION....................................................................................................................1
 ImportantOperatingNotes..............................................................................................2
 Features..........................................................................................................................3
 PackageIncludes............................................................................................................3
 PanelLayout...................................................................................................................4
 PanelDescriptions..........................................................................................................5
CONNECTING THE HDMI TO COMPOSITE / S-VIDEO SCALER.......................................6
 Connections....................................................................................................................6
 WiringDiagram...............................................................................................................6
OPERATING THE HDMI TO COMPOSITE / S-VIDEO SCALER..........................................7
 UsingOverscanandUnderscan.....................................................................................7
  OverScan...............................................................................................................7
  UnderScan.............................................................................................................8
 AudioOutputandFormats..............................................................................................9
APPENDIX............................................................................................................................10
 FirmwareUpdateProcedure.........................................................................................10
 Specications................................................................................................................11
WARRANTY............................................................................................................................12


INTRODUCTION
CongratulationsonyourpurchaseoftheHDMItoComposite/S-VideoScaler.Your
completesatisfactionisveryimportanttous.
Gefen
Gefendeliversinnovative,progressivecomputerandelectronicsadd-onsolutionsthat
harnessintegration,extension,distributionandconversiontechnologies.Gefen’sreliable,
plug-and-playproductssupplementcross-platformcomputersystems,professionalaudio/
videoenvironmentsandHDTVsystemsofallsizeswithhard-workingsolutionsthatare
easytoimplementandsimpletooperate.
The GefenTV HDMI to Composite / S-Video Scaler
ConvertanyHi-DefsourcetostandarddenitionNTSC/PALformatwithscaling.TheHDMI
toanalogvideoscaleraccommodatesresolutionsupto1080pFullHDvideoandsupports
scaledoutputsinCompositeandS-Video,whilemaintainingtheoriginalaspectratiofor
optimalviewing.ThecoaxS/PDIFdigitalaudioandleft/rightanalogaudiooutputsallow
theaudioextractedfromtheHDMIsignaltobesenttoanyA/VReceiveroraudioamplier.
Underscan/OverscanandNTSC/PALswitcheshelpassurecompatibilitywithavarietyof
analogtelevisions.ThisscaleralsofeaturesaUSBportforrmwareupgrades.
How It Works
UsingtheincludedHDMIcable,connecttheHi-DefsourcetotheHDMIinput.Usea
compositeorS-videocabletoconnectthescalertotheanalogmonitor.Connectthescaler
toanA/VReceiveroramplierusinganS/PDIFcableorananalogaudiostereopatchcord
withRCAconnectors.Connectthepowersupplytothescalerandtoanavailableelectrical
outlet.Poweronallconnectedcomponents.UsetheNTSC/PALswitchonthescalerto
selectthecorrectoutputformatforyourTV.SelectUnderscanorOverscanusingtheslide
switchonthescalertocompensateforscanningcharacteristicsofyouranalogTVthat
couldresultinover-croppingoftheimageorvisibleblackborders.
NOTE:HDCPencryptedHDMIsourcesarenotsupportedbythisdevice.IfHDCPcontent
isused,thentheoutgoingvideosignalwillresultinablackscreen.
1

2
INTRODUCTION
Important Operating Notes
READ THESE NOTES BEFORE INSTALLING OR OPERATING
THE HDMI TO COMPOSITE / S-VIDEO SCALER
• TheHDMIToComposite/S-VideoScalerconvertsHDTVinputresolutionsof
480p@50/60Hz,576p@50/60Hz,480i@50/60Hz,576i@50/60Hz,
720p@50/60Hz,1080iand1080pat50/60HztoeitherNTSC480iorPAL576i.
• SupportedPCinputresolutionsinclude640x480@60Hz,800x600@60Hz,
1024x768@60Hz,1280x1024@60Hz,1600x1200@60Hz,and1920x1200@60Hz.
• Boththedigitalandanalogaudiooutputsareactiveatalltimeswhenusing2-channel
LPCM.TheHDMIToComposite/S-VideoScalerwillnotdown-mixmulti-channel
digitalaudioformatsto2channelanalogstereo.Seepage9formoreinformation.
• ThisdevicesupportsbothNTSCandPALvideostandards.Thisdevicemaintainsthe
aspectratiooftheoriginalsignal.
• Pleasebesuretosettheproperoutputformatforyourtelevision.NTSC60Hzis
commonlyusedintheUnitedStatesandJapan,whilePAL50Hziscommonlyusedin
Europeancountries.Usingtheimproperformatwillresultinaunrecognizablepicture
andmaydamageyourTVset.
• TheHDMIToComposite/S-VideoScalerisHDMI1.2Compliant.
• HDCPencryptedHDMIsourcesarenotsupportedbythisdevice.IfHDCPcontentis
used,thentheoutgoingvideosignalwillresultinablackscreen.


3
INTRODUCTION
Features
• HDMItoComposite/S-Videoconversionplusscaling
• HDMIpass-through
• Supports480ito1080pHDMIinputresolutionsat50/60Hz.
• Outputs480i/576isignalforComposite/S-VideoDisplaydevices
• SupportsbothNTSCandPALformats
Package Includes
(1)HDMIToComposite/S-VideoScaler
(1)6ft.HDMICable(M-M)
(1)5VDCPowerSupply
(1)Quick-StartGuide

4
Panel Layout
INTRODUCTION
Top
6
57
8
10
9
Back Front
1 4
3
2

5
INTRODUCTION
Panel Descriptions
1 L/R
ConnecttwoRCA-typecablesfromtheseoutputstothedisplay,audioamplier,or
receiver.Only2channelLPCMfromtheHDMIinputcanbepassedtotheseoutputs.
Multi-channelbit-streamsuchasDolbyDigitalwillnotbepassedtothisoutput.
2 Composite
ConnectanRCA-typecablefromthisoutputtotheCompositeinputonthedisplay
orA/Vreceiver.
3 S-Video
ConnectanS-VideocablebetweenthisoutputandtheS-Videoinputonthedisplay
orA/Vreceiver.
4 CoaxOut
ConnectanRCA-typecablefromthisoutputtotheS/PDIFconnectoronareceiveror
audioamplier.
5 PAL/NTSC
SwitchesbetweenNTSC(60Hz)andPAL(50Hz)output.Makesurethatyouusethe
properoutputforthetelevision.Usingthewrongformatwillresultinaunrecognizable
pictureandmaydamageyourtelevision.
6 UnderScan/OverScan
Mostanalogtelevisionsetsweredesignedtoacceptanover-scannedsignal.Ifthe
resultingvideosignaldisplaysablackborderaroundtheedges,thensetthisswitchto
OverScan.Iftheresultingvideosignalisstretchedbeyondtheedgeofthedisplay,then
setthisswitchtoUnderScan.
7 HDMIIn
ConnectanHDMIcablefromtheHi-Defsourcetothisconnector.
8 USB
Usedtoupgradethermware.Seepage10forinformationonupgradingthermware.
9 5VDC
Connecttheincluded5VDCpowersupplytothisreceptacle.
10 Power
ThisLEDwillglowbrightblueoncetheincludedpowersupplyisconnectedbetweenthe
scalerandanavailableelectricaloutlet.


6
Connections
1. ConnecttheincludedHDMIcablebetweentheHi-DefsourceandtheHDMIIn
connectoronthescaler.
2. ConnectanS-VideocablefromthescalertothedisplayoranA/Vreceiver.
AlternatelyoradditionallyconnectaCompositecable(RCA-type)betweenthescaler
andtheCompositeinputonthedisplayorA/Vreceiver.
3. ConnecttwoRCA-typecables(usuallypartoftheCompositecable)betweenthe
LandRconnectorsonthescalerandtheLandRconnectorsonthedisplayorA/V
receiver.
4. Connecttheincluded5VDCpowersupplytothepowerreceptacleonthescalerand
connectthepowercordtoanavailableelectricaloutlet.
Wiring Diagram for the HDMI to Composite / S-Video Scaler
INTRODUCTION
GTV-HDMI-2-COMPSVIDSN
Audio Receiver
Display
Scaler
Hi-Def Source
HDMI CABLE
S-VIDEO CABLE
COMPOSITE VIDEO CABLE
COAX AUDIO CABLE
L/R RCA AUDIO CABLE
®

7
OPERATING THE HDMI TO COMPOSITE / S-VIDEO SCALER
Using Overscan and Underscan
OncetheHDMI to Composite / S-Video Scalerisconnectedandpowered,thecontentfrom
theHi-Defsourceshouldbedisplayed.
Over Scan
Ifthevideosignaldisplaysablackborderaroundtheedgesofthepicture,thensetthe
Under Scan / Over ScanswitchtotheOver Scanpositiontocorrecttheimage.
Exampleofanimagewithunderscan
Correctedimageusingoverscan

8
OPERATING THE HDMI TO COMPOSITE / S-VIDEO SCALER
Under Scan
Ifthevideosignalextendsbeyondtheedgeofthedisplay(showninred),thensetthe
Under Scan / Over ScanswitchtotheUnder Scanpositiontocorrecttheimage.
Over-scannedimage(exaggerated)
Correctedimageusingunderscan

9
OPERATING THE HDMI TO COMPOSITE / S-VIDEO SCALER
Audio Output and Formats
Boththedigital(CoaxOut)andanalog(L/R)audiooutputsareactiveatalltimes.
Only2-channelLPCMissupportedontheoutput.Seethetable,below.
Output
CoaxOut L/ROut
Input
Format
DolbyDigital/
DTS
YES NO
Multichannel
LPCM
NO NO
2-Channel
LPCM
YES YES


10
APPENDIX
Firmware Update Procedure
1. DownloadthermwareupdatefromtheSupportsectionoftheGefenWebsite.
2. Power-OFFtheHDMI to Composite / S-Video Scaler.

ItisunnecessarytodisconnectanycablesfromtheHDMI to Composite / S-Video
Scalerduringtheupdateprocess.





3. ConnectaUSBcablebetweenthecomputerandtheHDMI to Composite / S-Video
Scaler.
4. Power-ONtheHDMI to Composite / S-Video Scalerbyconnectingthepower.
5. OncethecomputerisabletoconnecttotheHDMI to Composite / S-Video Scaler,
aRemoveablediskiconwillbedisplayed
6. Extractthermwarelefromthe.ZIPleanddragthe.binletotheRemovableDisk.
7. DisconnecttheUSBcablefromthecomputer.
8. Thermwareupdateprocessiscomplete.
IMPORTANT: TheHDMI to Composite / S-Video Scaler mustbe
POWEREDOFFbeforeconnectingtheUSBcabletothecomputer.

11
APPENDIX
Specications
HorizontalFrequencyRange................................................................................31-70kHz
VerticalFrequencyRange....................................................................................50-60kHz
A/VInput................................................................................(1)HDMITypeA,19-pinfemale
VideoOutputs.....................................................................(1)CompositeRCA/(1)S-Video
AudioOutputs.................................................................................(2)RCA-type,(1)S/PDIF
PowerConsumption......................................................................................7.5Watts(max.)
PowerSupply......................................................................................................5V/2.6ADC
ShippingWeight.................................................................................................4lbs(1.8kg)

12
WARRANTY
Gefenwarrantstheequipmentitmanufacturestobefreefromdefectsinmaterialand
workmanship.
IfequipmentfailsbecauseofsuchdefectsandGefenisnotiedwithintwo(2)yearsfrom
thedateofshipment,Gefenwill,atitsoption,repairorreplacetheequipment,provided
thattheequipmenthasnotbeensubjectedtomechanical,electrical,orotherabuseor
modications.Equipmentthatfailsunderconditionsotherthanthosecoveredwillbe
repairedatthecurrentpriceofpartsandlaborineffectatthetimeofrepair.Suchrepairs
arewarrantedforninety(90)daysfromthedayofreshipmenttotheBuyer.
Thiswarrantyisinlieuofallotherwarrantiesexpressedorimplied,includingwithout
limitation,anyimpliedwarrantyormerchantabilityortnessforanyparticularpurpose,allof
whichareexpresslydisclaimed.
1. Proofofsalemayberequiredinordertoclaimwarranty.
2. CustomersoutsidetheUSareresponsibleforshippingchargestoandfromGefen.
3. Coppercablesarelimitedtoa30daywarrantyandcablesmustbeintheiroriginal
condition.
Theinformationinthismanualhasbeencarefullycheckedandisbelievedtobeaccurate.
However,Gefenassumesnoresponsibilityforanyinaccuraciesthatmaybecontained
inthismanual.InnoeventwillGefenbeliablefordirect,indirect,special,incidental,or
consequentialdamagesresultingfromanydefectoromissioninthismanual,evenif
advisedofthepossibilityofsuchdamages.Thetechnicalinformationcontainedherein
regardingthefeaturesandspecicationsissubjecttochangewithoutnotice.
Forthelatestwarrantycoverageinformation,refertotheWarrantyandReturnPolicyunder
theSupportsectionoftheGefenWebsiteatwww.gefen.com.
PRODUCT REGISTRATION
Please register your product online by visiting the Register Product page under the
Support section of the Gefen Web site.

Rev A1
20600 Nordhoff St., Chatsworth CA 91311
1-800-545-6900 818-772-9100 fax: [phone]
www.gefen.com [email protected]
Pb
ThisproductusesULorCElistedpowersupplies.
