gefran 4t-48 User manual

1 • INSTALLATION
• Dimensions and cut-out; panel mounting
Panel mounting:
Fix the device with the bracket provided before making any electrical
connections.
To mount two or more devices side by side, use the cut-out dimensions
shown above.
CE MARKING: The instrument conforms to the European Directives
2004/108/CE and 2006/95/CE with reference to the generic standards:
EN 61000-6-2 (immunity in industrial environment) EN 61000-6-3 (emission
in residential environment) EN 61010-1 (safety).
MAINTENANCE: Repairs must be done out only by trained and specialized
personnel. Cut power to the device before accessing internal parts.
Do not clean the case with hydrocarbon-based solvents (Petrol,
Trichlorethylene, etc.). Use of these solvents can reduce the mechanical
reliability of the device. Use a cloth dampened in ethyl alcohol or water to
clean the external plastic case.
SERVICE: GEFRAN has a service department. The warranty excludes
defects caused by any use not conforming to these instructions.
4T 48
UNIVERSAL TEMPERATURE INDICATOR
SOFTWARE VERSION 3.2x (includes R77 version)
code 81600G / edition 13 - 07/2011
INSTALLATION and
OPERATION MANUAL
99
10
45
45
48
70
70
63
48
For correct and safe
installation, follow
the instructions and
observe the warnings
contained in this
manual.
!
Faceplate protection IP65
Working / Storage temperatures 0...50°C / -20...70°C
Relative humidity 20 to 85%, non-condensing
Installation Panel mounting, extractable from front
Weight 150g
°C / °F selection Faceplate configurable
Linear scale ranges -1999...9999
Configurable decimal point position,
possible 32 segment linearization
Transmitter / Sensor Power
Supply (option)
24V ±10%, 50mA
15V for transmitter, max. 50mA
1,2V for potentiometer > 100Ω
Fuse (inside device, not
operator serviceable)
100...240Vac - tipo T - 500mA - 250V
11...27Vac/dc - tipo T - 1,25A - 250V
Power supply (switching) (std) 100...240Vac/dc ±10%, 50/60Hz, 5,5VA
(opt) 20...27Vac/dc ±10%, 50/60Hz, 5,5VA
Max. non-linearity error See t.P parameter
Resolution
(function of settable
sample time)
120msec, >14bit - 16000 points
60msec, >14bit - 16000 points
(only for linear inputs)
30msec, >13bit - 8000 points
(only for linear inputs)
15msec, >12bit - 4000 points
(only for linear inputs)
Thermocouples J, K, R, S, T, B, E, N
(IEC 584-1, CEI EN 60584-1, 60584-2)
L GOST, U, G, D, C
Custom linearization available on request
Cold junction error 0,1° / °C
RTD type (scale configurable within
indicated range, with or without
decimal point)
Max. RTD line resistance
DIN 43760 (PT100), JPT100
20Ω
PTC type / NTC type 990Ω, 25°C / 1KΩ, 25°C
Display 4 digit red LED’s; digit height 10mm,
Keys 3 mechanical keys (Raise, Lower, F)
Accuracy 0.2% f.s. at 25°C ambient temperature,
ts=120msec
Main input TC, RTD, PTC, NTC
60mV, 1V Ri ≥ 500KΩ; 5V, 10V Ri ≥10KΩ
20mA, Ri = 50Ω
adjustable digital filter
2 • TECHNICAL SPECIFICATIONS
FUNCTION CABLE LENGTH USED
TC input probe 0,8 mm2 compensated 5 m
“PT100” input probe 1 mm2 3 m
Power supply cable 1 mm2 1 m
EMC conformity has been tested with the following connections
Environmental conditions of use for internal use only, altitude up to 2000m
Logic input
(only R77 version)
24V, 5mA (Ri = 47KΩ) isolation 1500V
or voltage-free contact
1
81600G_MHW_4T48_07-2011_ENG
1 / 7

Connections for keylock function through digital input (require selection +VT for the signal on contact 3)
OFF (open): keyboard enable
ON (closed): keyboard disable
23 5 6
+ -
+VT
• Linear input 1V for
potentiometer dc current
linear input
20mA, Ri = 50Ω
• Linear (I) - (V)
4
1
2
-
+
Available thermocouples:
J, K, R, S, T, B, E, N,
L, U, G, D, C
- Respect polarities
- For extensions,
use compensated
cable appropriate for
thermocouple.
dc voltage linear
input
60mV, 1V, 5V, 10V
3 • DESCRIPTION OF FRONT PANEL
2
1
+
-
!
+
-
• Thermocouples
2
1
4
2
3
1
+
-
+
+
S
-
Ri = 50Ω
to connect for 20mA input
4
2
3
1
+
-
+
+
-
Ri = 50Ω
4 to 20mA
• Linear input with 3-wire transmitter• Linear input with 2-wire transmitter
Standard:
100 to 240Vac/dc
±10%
Optional:
11 to 27Vac/dc ±10%
50/60Hz, 3,5VA max.
• Power supply
23
24
~
~
PWR
4 • CONNECTIONS
“Raise” and “Lower” keys:
These keys are used for any operation that
requires a numerical parameter to be raised or
lowered. •• The speed of change is proportional
to the time the key is pressed. •• The operation
is not cyclic: once the maximum (minimum) limit
is reached, there will be no further increase
(decrease) of the value, even if the key remains
pressed.
The keys can be configured to perform
reset, hold, display of the peak value, etc. as
determined by the ‘t.U.’ and ‘t.d.’ parameters on
the ‘In’ menu.
PV display: Indication of process variable
•• Indication of ‘HI’ or ‘Lo’ out of range
•• Indication of open circuit (br) or short circuit (Er)
•• Display of configuration and calibration
messages
Function key:
Gives access to different configuration stages ••
Confirms any parameter changes
Label with engineering units
4
2
3
1
R >100Ω
- 1,2V
+
+
Use wires
of adequate
thickness
(min. 1mm2)
PT100,
JPT100,
PTC, NTC
• Pt100 / PTC / NTC
3
1
2
3-wire Pt100
2-wire PTC /
NTC / Pt100
T T
1
2
3
4
5
67
8
9
10
11
1213
14
15
16
17
1819
20
21
22
23
24
• Inputs
Digital input
24V, 5mA
or no-voltage contact
(only for R77 version)
+
-
• Digital input
6
5
281600G_MHW_4T48_07-2011_ENG
2 / 7

Software version
Configuration hd
Information display
IF
Ud
xd
INPUT
0 None
6 On Digital (only for R77)
• Information display
5 • PROGRAMMING and CONFIGURATION
Process variable
Password
PA = 99
Custom linearization
User calibration
YES
NO
LEVEL 1 DISPLAY
Protection code
Information display
Input settings
Pressed for
approx. 2 sec.
Keep the F key
pressed to browse
the menus.
Release the F
key to enter the
displayed menu.
Press the F key
to access the
parameters.
Keep the F key
pressed to exit any
menu at any time.
Device structure: identification of boards
DISPLAY
POWER
Power board - Seal side
Select
transmitter
voltage
Select signal at
contact 3
CPU board - Component side
CPU
24V
15V 10V 5V 1,23V
PT100
+VT
IF
In
PA
Pr
Ln
U.(.
P.U.
3
81600G_MHW_4T48_07-2011_ENG
3 / 7

N.B.: for the version R77 are not available the probe codes 0...39, 48...51, 54...58
In case of probe non-availability, maximum and minimum limits are set to 0.
In case of custom linearization, test limits for setting LO and HI errors are given by the calibration values.
If these limits are not exceeded, they are taken into consideration as limits L_S and H_S.
Select sampling time
(resolution). For linear
input 0...1V/POT only.
0 120ms > 14bit; 16000 divs
1 60ms > 14bit; 16000 divs
2 30ms > 13bit; 8000 divs
3 15ms > 12bit; 4000 divs
TYPE Type 4 DIGIT
PROBE
without dec. point with dec. point
Probe: TC
0 TC J °C 0/1000 0.0/999.9
1 TC J °F 32/1832 32.0/999.9
2 TC K °C 0/1300 0.0/999.9
3 TC K °F 32/2372 32.0/999.9
4 TC R °C 0/1750 0.0/999.9
5 TC R °F 32/3182 32.0/999.9
6 TC S °C 0/1750 0.0/999.9
7 TC S °F 32/3182 32.0/999.9
8 TC T °C -200/400 -199.9/400.0
9 TC T °F -328/752 -199.9/752.0
10 TC B °C 44/1800 44.0/999.9
11 TC B °F 111/3272 111.0/999.9
12 TC E °C -100/750 -100.0/750.0
13 TC E °F -148/1382 -148.0/999.9
14 TC N °C 0/1300 0.0/999.9
15 TC N °F 32/2372 32.0/999.9
16 TC L °C 0/600 0.0/600.0
17 TC L °F 32/1112 32.0/999.9
18 TC U °C -200/400 -199.9/400.0
19 TC U °F -328/752 -199.9/752.0
20 TC G °C 0/2300 0.0/999.9
21 TC G °F 32/4172 32.0/999.9
22 TC D °C 0/2300 0.0/999.9
23 TC D °F 32/4172 32.0/999.9
24 TC C °C 0/2300 0.0/999.9
25 TC C °F 32/4172 32.0/999.9
26 TC °C Custom Custom
27 TC °F Custom Custom
Probe: RTD
28 PT100 °C -200/600 -199.9/600.0
29 PT100 °F -328/1112 -199.9/999.9
30 JPT100 °C -200/600 -199.9/600.0
31 JPT100 °F -328/1112 -199.9/999.9
Probe: PTC - NTC
32 PTC °C -55/120 -55.0/120.0
33 PTC °F -67/248 -67.0/248.0
34 NTC °C -10/70 -10.0/70.0
35 NTC °F 14/158 14.0/158.0
Probe: Voltage + Current
36 0...60mV -1999/9999 -199.9/999.9
37 0...60mV custom linear custom linear
38 12...60mV -1999/9999 -199.9/999.9
39 12...60mV custom linear custom linear
40 0...20mA -1999/9999 -199.9/999.9
41 0...20mA custom linear custom linear
42 4...20mA -1999/9999 -199.9/999.9
43 4...20mA custom linear custom linear
44 0...10V -1999/9999 -199.9/999.9
45 0...10V custom linear custom linear
46 2...10V -1999/9999 -199.9/999.9
47 2...10V custom linear custom linear
48 0...5V -1999/9999 -199.9/999.9
49 0...5V custom linear custom linear
50 1...5V -1999/9999 -199.9/999.9
51 1...5V custom linear custom linear
52 0...1V/Pot -1999/9999 -199.9/999.9
53 0...1V/Pot custom linear custom linear
54 200mV...1V -1999/9999 -199.9/999.9
55 200mV...1V custom linear custom linear
Probe: Custom PT100 - PTC - NTC
56 PT100 custom custom
JPT
57 PTC custom custom
58 NTC custom custom
• TC/LIN input parameters
Input settings
Type of probe,
signal and scale of
main input
+4 to disable filter
(average of the last eight values sampled)
Max. non-linearity error for
thermocouples (TC),
resistors (PT100) and
thermistors (PTC, NTC).
The error is calculated as
deviation from theoretical value
and is expressed as percentage of full
scale (in °C).
S, R range 0...1750°C; error < 0.2% f.s. (t > 300°C) / for other range; error < 0.5% f.s.
T error < 0.2% f.s. (t > -150°C)
B range 44...1800°C; error < 0.5% f.s. (t > 300°C) / range 44,0...999,9; error < 1% f.s. (t > 300°C)
U range -99,9...99,9 and -99...99°C; error < 0.5% f.s. / for other range; error < 0.2% f.s. (t > -150°C)
G error < 0.2% f.s. (t > 300°C)
D error < 0.2% f.s. (t > 200°C)
C range 0...2300; error < 0.2% f.s. / for other range; error < 0.5% f.s.
NTC error < 0.5% f.s.
Tc J, K, E, N, L error < 0.2% f.s.
PT100, JPT100 e PTC error < 0.2% f.s.
In
t.P
(.1.
481600G_MHW_4T48_07-2011_ENG
4 / 7

0 None
1 Zero
2 Hold
3 Flash
4 Max. peak display
5 Min. peak display
6 Delta peak display
7 Peak memory reset
8 Zero + peak memory reset
18 Potentiometer calibration
19 Offset
• Protection
0 None
1 Zero
2 Hold
3 Flash
4 Max. peak display
5 Min. peak display
6 Delta peak display
7 Peak memory reset
8 Zero + peak memory reset
17 Keylock (d.I. only)
18 Potentiometer calibration
(t.U. and t.d. only)
19 OFFSET (t.U. and t.d. only)
d.I. - t. u. - t. d.
• User Calibration
.......
• Custom Linearization
min…max scale
of input selected in t.P
Decimal point position for
main input scale
Minimum limit of main
input scale
Maximum limit of main
input scale
Offset correction of main
input
-999 to 999
scale points
min…max scale
of input selected in t.P
Select function of
digital input
(R77 only)
dP Format
0 XXXX
1 XXX.X
2 * XX.XX
3 * X.XXX
(*) not available for TC,
RTD, PTC and NTC scales
Raise key function
(active only in
P.V.selection)
Custom Linearization of
main input
Step 0
(beginning of scale value)
Display limits
(-1999 to 9999)
Step 32
(full scale value)
Display limits
(-1999 to 9999)
Step 33 mV beginning
of scale
Step 34 mV full scale
Step 35 mV at 50°C
(*)
(*)
(*)
(*) only for CPU, TC_LIN and tP = TC CUSTOM
U.C. CPU T Function
2 Custom RTD sensor
3 Custom PTC sensor
4 Custom NTC sensor
5 Potentiometer (0 to 1V)
Digital filter on main input
Digital filter on process
variable display
0.0 to 20.0 sec
0.0 to 9.9
scale points
Calibration of
minimum
Calibration of
maximum
the n step value corresponds to input:
mV beginning scale + n * ΔmV
ΔmV = (mV full scale - mV beginning scale) / 32
Protection code
Value
0 Display and setting
of all parameters
+4 to disable In pages
+16 to enable maintenance of reset latch at power-off (for linear inputs only)
+32 base configuration (the following parameters will not be displayed:
In: Ft, Fd, Of
+128 disabled of all the menu except PA
f.t
f.d
dP
L.s
x.s
o.f
d.I.
t.U.
Ln
0.0.
3.2.
3.3.
3.4.
3.5.
Pr U.(.
(.L.
(.x.
Lower key function
(active only in
P.V.selection)
t.d.
5
81600G_MHW_4T48_07-2011_ENG
• Interface for GEFRAN instrument configuration
KIT PC USB / RS485 o TTL
• ORDERING CODE
Kit for PC via the USB port (Windows environment) for GEFRAN instruments conguration:
Lets you read or write all of the parameters
• A single software for all models
• Easy and rapid conguration
• Saving and management of parameter recipes
• On-line trend and saving of historical data
Component Kit:
- Connection cable PC USB ... port TTL
- Connection cable PC USB ... RS485 port
- Serial line converter
- CD SW GF Express installation
GF_eXK-2-0-0 cod F049095
5 / 7

• WARNINGS
ORDER CODE
Read the following warnings before installing, connecting or using the device:
• follow instructions precisely when connecting the device.
• always use cables that are suitable for the voltage and current levels indicated in the technical specifications.
• the device has no ON/OFF switch: it switches on immediately when power is turned on. For safety reasons, devices permanently connected to the
power supply require a two-phase disconnecting switch with proper marking. Such switch must be located near the device and must be easily reachable
by the user. A single switch can control several units.
• if the device is connected to electrically NON-ISOLATED equipment (e.g. thermocouples), a grounding wire must be applied to assure that this
connection is not made directly through the machine structure.
• if the device is used in applications where there is risk of injury to persons and/or damage to machines or materials, it MUST be used with auxiliary alarm
units. You should be able to check the correct operation of such units during normal operation of the device.
• before using the device, the user must check that all device parameters are correctly set in order to avoid injury to persons and/or damage to property.
• the device must NOT be used in inflammable or explosive environments. It may be connected to units operating in such environments only by means of
suitable interfaces in conformity to local safety regulations.
• the device contains components that are sensitive to static electrical discharges. Therefore, take appropriate precautions when handling electronic circuit
boards in order to prevent permanent damage to these components.
Installation: installation category II, pollution level 2, double isolation
The equipment is intended for permanent indoor installations within their own enclosure or panel mounted enclosing the rear housing and exposed terminals on the back.
• power supply lines must be separated from device input and output lines; always check that the supply voltage matches the voltage indicated on the
device label.
• install the instrumentation separately from the relays and power switching devices
• do not install high-power remote switches, contactors, relays, thyristor power units (particularly if “phase angle” type), motors, etc... in the same cabinet.
• avoid dust, humidity, corrosive gases and heat sources.
• do not close the ventilation holes; working temperature must be in the range of 0...50°C.
If the device has faston terminals, they must be protected and isolated; if the device has screw terminals, wires should be attached at least in pairs.
• Power: supplied from a disconnecting switch with fuse for the device section; path of wires from switch to devices should be as straight as possible; the
same supply should not be used to power relays, contactors, solenoid valves, etc.; if the voltage waveform is strongly distorted by thyristor switching units
or by electric motors, it is recommended that an isolation transformer be used only for the devices, connecting the screen to ground; it is important for the
electrical system to have a good ground connection; voltage between neutral and ground must not exceed 1V and resistance must be less than 6Ohm;
if the supply voltage is highly variable, use a voltage stabilizer for the device; use line filters in the vicinity of high frequency generators or arc welders;
power supply lines must be separated from device input and output lines; always check that the supply voltage matches the voltage indicated on the
device label.
• Input and output connections: external connected circuits must have double insulation; to connect analog inputs (TC, RTD) you have to: physically
separate input wiring from power supply wiring, from output wiring, and from power connections; use twisted and screened cables, with screen connected
to ground at only one point; to connect adjustment and alarm outputs (contactors, solenoid valves, motors, fans, etc.), install RC groups (resistor and
capacitor in series) in parallel with inductive loads that work in AC (Note: all capacitors must conform to VDE standards (class x2) and support at least 220
VAC. Resistors must be at least 2W); fit a 1N4007 diode in parallel with the coil of inductive loads that operate in DC.
GEFRAN spa will not be held liable for any injury to persons and/or damage to property deriving from tampering, from any incorrect or
erroneous use, or from any use not conforming to the device specifications.
!WARNING: this symbol indicates danger.
It is seen near the power supply circuit and near high-voltage relay contacts.
Please, contact GEFRAN sales people for the codes availability.
For T input (alternative to RTD, PTC, NTC)
1,2Vdc for potentiometer (*)0 1
15Vdc for transmitter1 5
TRANSMITTER POWER SUPPLY
None0 0
100 to 240Vac/dc1
POWER SUPPLY
11 to 27Vac/dc0
24Vdc, 50mA2 4
(*) R77 for version with potentiometer input (Rinput > 10MΩ)
4T 48 4
NR. DIGITS
4 4
681600G_MHW_4T48_07-2011_ENG
6 / 7

Gefran 4T 48 Installation
Manual: Temperature Indicator
Tel: [phone]
[email protected]
91 Currie Street
Quigney
East London
5200
Powered by TCPDF (www.tcpdf.org) 7 / 7
