GEIGER System INline GSI56.. E12 SMI
with electronic end stop for the facade technology

2Gerhard Geiger GmbH & Co. KG | 100W2507 0220V001en
EN
EN
1. General information
Dear customer,
By purchasing a GEIGER motor you have decided on a quality product from GEIGER.
Thank you very much for your decision and the condence placed in us.
Before you put this drive into operation please observe the following safety instructions. It
serves for the prevention of danger and for the avoidance of personal injury and damage to
property.
The installation and operating instructions contain important information for the installer, the
specialist electrician and the user. Please pass on these instructions if you transfer the product.
These instructions should be kept by the user.
2. Guarantee
In the case of incorrect installation contrary to the installation and operating instructions and/
or constructional modication, the legal and contractual guarantee for property damage and
product liability lapses.
Index
1. General information ............................................................................2
2. Guarantee.............................................................................................2
3. Intended use ........................................................................................3
4. Safety instructions ..............................................................................3
5. Safety instructions for assembly.......................................................4
6. Assembly instructions........................................................................5
7. Identicationnumber..........................................................................6
8. Information for the specialist electrician ..........................................6
9. Conductor assignment for SMI drives for mains voltage................7
10. SMI drives on different AC phases ....................................................8
11. For your notes ….................................................................................9
12. Setting of the end stops ...................................................................10
13. Activate the programming mode ....................................................10
14. Programming/changing the end stops............................................ 11
15. Resetting to factory settings............................................................11
16. Obstacle detection and anti-freeze protection ...............................11
17. What to do if… ...................................................................................11
18. Declaration of conformity.................................................................12
19. Maintenance.......................................................................................13
20. Technical data....................................................................................13
21. Notes on waste disposal ..................................................................13

3
www.geiger.de EN
EN
3. Intended use
The motors of the GSI56.. E12 SMI series with electronic end stop are designed for operation
with Venetian blinds that are within a façade whereas the motor is outside the cavity.
The motors may not be used for the operation of roller grilles, garage doors, furniture and lifting
tools.
GJ 56 xx x
Design options
Torque in Nm
Motor diameter
GEIGER INline System
4. Safety instructions
I ATTENTION: Important safety instructions. For personal safety,
it is important to follow these instructions. Please keep these
instructions for future reference.
fDo not allow children to play with stationary controls. Keep remote controls away
from children.
fThe installation is to be checked regularly for defective balance, signs of wear or
damaged cables and springs, if relevant.
fDo observe the moving sun protection system and keep persons away until it has
closed completely.
fWhen operating the manual release with the sun protection system open, please be
cautious as it can fall down quickly if springs or tapes wear off or are broken.
fDo not operate the device if operations such as, for example, window cleaning are to
be carried out in the vicinity.
fDisconnect the automatic controlled device from the mains power supply if opera-
tions such as, for example, window cleaning are being carried out in the vicinity.
fDuring operation observe the danger zone.
fDo not use the installation if people or objects are in the danger zone.
fUrgently shut down damaged installations until repair.
fUnconditionally shut down the unit during maintenance and cleaning operations.
fPinching and shearing points are to be avoided and must be secured.
fThis appliance can be used by children aged 8 and above and persons whose
physical, sensorial or mental capacities are impaired, or who have no experience or
know-how if they have been supervised or been given instructions on the use of the
appliance and if they understand the possible resulting dangers. Children are not
permitted to play with the device. Cleaning and maintenance should not be carried
out by children.
fThe rated sound pressure level is less than 70 dB(A).
fDisconnect the device from the mains power supply for maintenance and replace-
ment of parts.
If the motor is disconnected via a plug connection the operator must be able to
control - from any place to which it has access – that the plug is removed.
If this is not possible - due to design or installation - the disconnection from the
power supply must be ensured via locking in the disconnected position (e.g. isolator).
fThe motor tube can get very hot during prolonged use.
When working on the unit, do not touch the tube before it has cooled down.

4Gerhard Geiger GmbH & Co. KG | 100W2507 0220V001en
EN
EN
5. Safety instructions for assembly
I ATTENTION: Important safety instructions. Follow all installation
instructions, as incorrect installation can lead to serious injuries.
fWhen mounting the motor without any mechanical protection of the driven parts and
of the tube which may become hot, the motor must be installed at a height of at least
2.5 m above the ground or of another level which provides access to the drive.
fBefore the motor is installed, all cables which are not needed are to be removed and
all equipment which is not needed for power-operated actuation is to be put out of
operation.
fThe actuating element of a manual release must be mounted at a height of less than
1.8 m.
fIf the motor is controlled by a switch or pushbutton, the switch or pushbutton must
be mounted within eyeshot of the motor. The switch or pushbutton must not be
located in the vicinity of moving parts. The height of installation must be at least
1.5mabovetheoor.
fPermanently installed control devices must be attached visibly.
fIn case of devices extending horizontally, a horizontal distance of at least 0.4 m must
berespectedbetweenthefullyextendedpartandanyotherxedelement.
fThe rated speed and the rated torque of the motor must be compatible with the
device.
fThe mounting accessories that are used must be designed in accordance with the
selected rated torque.
fGood technical knowledge and good mechanical skills are necessary for the motor
installation. Incorrect installation can lead to serious injury.
Electricalworkmustbecarriedoutbyaqualiedelectricianinaccordancewiththe
regulations in force locally.
fOnly use connecting cables that are suitable with the environmental conditions and
which meet the construction requirements. (see accessories catalogue)
fIf the device is not equipped with a connecting cable and a plug, or other means for
disconnecting from the mains with a contact opening on each pole according to the
conditions of the overvoltage category III for full disconnection, a disconnecting
device of this type must be incorporated into the permanently installed electrical
installation according to the wiring rules.
fDo not mount the connecting cables near hot surfaces.
fA plug for the disconnection of the motor from the power supply must be accessible
after installation.
fDamaged connecting cables must be replaced by GEIGER connecting cables of the
same type.
fThe device must be mounted as described in the installation instructions. Fixations
shall not be made with adhesives since they are regarded as unreliable.

5
www.geiger.de EN
EN
6. Assembly instructions
I A prerequisite for a safe functioning of our system components is
a proper assembly taking into account the relevant standards and
guidelines in the production of element facades.
I The system components supplied by GEIGER may not be repro-
cessed or altered, otherwise the warranty expires.
I Before installation, the motor and the other system parts should be
checked for visible damage.
Connecting element:
The connecting element must be screwed at right angles to the mounting surface. It is important
to ensure that the mounting surface is cleaned and the seal of the connecting element ts
cleanly and evenly on the mounting surface.
Please make sure that the connecting element and the facade element are rmly and durably
connected. Tightening torques depend on the facade element and must be determined by the
facade manufacturer.
The tightness of the connection between the connecting element and the facade element must
be checked on site during installation.
A centering bore optionally used for double-walled proles may not be larger than + 0.3 mm
compared to the centering collar.
Cavity gear:
The cavity gear must be xed within the cavity in such a way that the hexagonal rod of the
connecting element can be inserted without tension into the hexagonal holding of the gear.
The screws must be secured with a screw-lock.
The hexagonal rod of the connecting element must t exactly into the hexagonal housing of the
anged gear and must not be subject to tension during operation.
Motorwithangedgear–Parallelmounting:
Screw mounting
For parallel mounting (radial), the drive is
placed on the 7 mm hexagonal rod of the
connecting element. The drive is attached
to the xing bracket on the angle gear using
2 galvanized countersunk head screws DIN-
EN-ISO 14581 8.8 M5 x 10 and a tightening
torque M = 2Nm.
The screws must be secured with a high-
strength screw-lock.
The hexagonal rod of the connecting element
must t exactly into the hexagonal housing of
the anged gear and must not be subject to
tension during operation.

6Gerhard Geiger GmbH & Co. KG | 100W2507 0220V001en
EN
EN
7. Identicationnumber
Four removable ID stickers are applied on the connecting cable
of the motor GSI56.. E12 SMI. The printed number SMI-KEY-ID
clearly identies the motor in the bus system.
The stickers and / or the connecting cable must not be
interchanged.
The stickers are useful if you want to note the installation location
for a later bus integration of each motor (see “for your notes”).
8. Information for the specialist electrician
H Caution: Important installation instructions.
Please follow all installation instructions since incorrect installation
can lead to the destruction of the motor and the switching unit.
H Attention! The bus voltage is not a safe low voltage. The bus is not
galvanically isolated from the supply voltage.
H ThemotorcanonlybeoperatedwithSMIcertiedactuators.
• For the operation with a setting switch, a locking switch is necessary (no simultaneous
UP and DOWN commands).
• The operations with the service clamps may be accomplished only by an electrical
specialist.
• The number of motors which can be connected to an actuator depends on the actuator.
Please observe the instructions of the actuator manufacturer.
• In case of parallel connection, the maximum load of the electrical installation must not be
exceeded.
• By push-button operation the switchover must be effected through an off position.
• By push-button operation the switchover time must be at least 0.2 s.
• Connecting cables with plug connectors of the Hirschmann Company are tested and
approved with couplings of the Hirschmann Company.
• A 5-pole connecting cable with continuous power supply must be used for SMI motors.
(GEIGER Flat5 with dark blue ring)
• In order to prevent a malfunction caused by coupling, the supply line (ref. NYM) from the
actuator/switch to the motor must not exceed 100m in case of motors with electronic end
stops.
SMI-KEY-ID: 1114166510
SMI-KEY-ID: 1114166510
SMI-KEY-ID: 1114166510
SMI-KEY-ID: 1114166510
SMI-KEY-ID: 1114166510

7
www.geiger.de EN
EN
9. Conductor assignment for SMI drives for mains voltage
12 34
l+
l+: Control wire +
l-: Control wire -
PE: Protective earth conductor
L: Live
N: Neutral wire
Names
PEl- LN
l+
Ab
Auf
PEl- LN
Drive
12 34
Push button operation
Drive
l+ PEl- LN
12 34
Telegram operation
Drive
Changing the operating mode from telegram operation to pushbutton operation is done by
switching the power supply off and on.
Connector on drive cables The STAS4 connector from Hirschmann
is recommended.
Cable connections and connector
assignment for the STAS4/STAK4
connection system with cables
having black, grey, brown, blue
and yellow-green wires
STAS 4 / STAK 4 Wire colour Name
1
2
3
4
5 (PE)
black
grey
brown
blue
green-yellow
I+
I-
L
N
PE
Cable connections and connector
assignment for the STAS4/STAK4
connector system with cables
having 2 black wires
STAS 4 / STAK 4 Wire colour Name
1
2
3
4
5 (PE)
black 1
black 2
brown
blue
green-yellow
I+
I-
L
N
PE
Definition of the black wires:
black 1: between blue and green-yellow
black 2: between brown and green-yellow
Note on laying SMI wires in
custom cables
The I+ and I- SMI wires can be laid in the motor connec-
tion line of the SMI drive (as above) or in their own cable.
It is not permitted to lay SMI wires together with wires
carrying other signals in one cable.
If SMI drives wired in parallel are supplied with electrical
power from different phases, the SMI I+ and I- wires
must be laid in a separate cable.

8Gerhard Geiger GmbH & Co. KG | 100W2507 0220V001en
EN
EN
10. SMI drives on different AC phases
Parallel connection to the control lines I+ and I- while supplying power to the drives from
different phases, is only permissible in telegram operating mode.
Drive
l+ PEl- NL1
L1
L2
L3
l+
l-
l+
l-
l+
l-
Actuator
(Telegram operation)
N
PE
Drive
l+ PEl- NL2
Drive
l+ PEl- NL3
Drive
l+ PEl- NL1
L1
L2
L3
N
PE
Drive
l+ PEl- NL2
Drive
l+ PEl- NL3
Drive
l+ PEl- NL
L
N
PE
Drive
l+ PEl- NL
Drive
l+ PEl- NL
Telegram operation with power supply from different phases
permitted
permitted Push button operation with power supply from one phase
Push button operation with power supply from different phases
not
permitted

9
www.geiger.de EN
EN
11. For your notes …
SMI-KEY-ID (sticker) Place of installation
e.g.: 1st floor, left side, third room, 1st window etc.

10 Gerhard Geiger GmbH & Co. KG | 100W2507 0220V001en
EN
EN
12. Setting of the end stops
General information
In order to set the end positions of the GSI56.. E07 SMI motors, any setting switch – with
continuous power supply – can be used that has a programming key or that allows a
simultaneous UP/DOWN command. In this case, the UP/DOWN keys must be activated
simultaneously instead of the programming key.
Article number / GEIGER setting switch
M56F152 with service terminal (D), 5 wires, SMI compatible
M56F153 with service terminal (CH), 5 wires, SMI compatible
I Important: please observe the connecting diagram on the back of the
setting switch.
Factory setting
• The motor is set on the upper end position at the factory. The lower end stop is at the very
other end. (at least lower end stop + 200 motor rotations).
• The motor command is in normal operation.
I If the factory setting has been carried out and if the programming
mode is activated, max. 100 revolutions can be done downwards.
Reset to factory settings for a further run downwards.
13. Activate the programming mode
I Prerequisite: The motor is positioned between the upper and the
lower end position.
I The GSI56.. E12 SMI can be set with any SMI setting switch that
ensures a continuous power supply and has a programming key
or that allows a simultaneous UP/DOWN command. If there is no
programming key, the UP/DOWN keys must be simultaneously
pressed.
Activate the programming mode
via limit stop switch
In order to activate the programming mode, the motor
must be connected according to the diagram “push
button operation” (see point 8).
Press the programming key of the limit stop switch or the
UP/DOWN keys simultaneously until, after about 3 seconds,
the motor conrms “end position programming activated”
with 1 x click-clack. Then release the key.
1 x
Press programming
key for about
3 seconds
Click-clack
PROG
PROG

11
www.geiger.de EN
EN
14. Programming/changing the end stops
The upper and lower end stops can be programmed and changed independently
of each other.
• Activate the programming mode.
• Run the motor in the direction of the desired end
position. The motor interrupts its run just to show that it
is in the programming mode:
• The direction in which the motor moves after the break*
determines the end stop to be programmed.
(UP = upper end stop, DOWN = lower end stop)
• When the desired end position is reached, move the
motor in the opposite direction until 2 short breaks*
show the last saved position.
• The programming is completed.
* As long as the interruption of movement has not yet
occurred, corrections can be done.
Start the setting process again to adjust another end position.
Cancel the programming mode:
In order to cancel the programming mode, press the PROG key or press simultaneously the
UP/DOWN keys until the motor conrms the cancellation of the programming mode after about
3 seconds with 2 x click-clack.
15. Resetting to factory settings
Press the programming keys (PROG key, /UP/DOWN keys) about 10 seconds until the motor
jerks 1 x after 3 seconds, 1 x after 6 seconds and 4 x after 10 seconds. Then the motor is reset
to factory settings.
Note: the position at which the drive has been reset to the factory setting is now dened as the
upper end position and can be adjusted by activating the learning mode.
16. Obstacle detection and anti-freeze protection
For an optimal operation of the obstacle detection function, move the blind from bottom to top
without interruption, after the programming has been completed.
After an obstacle detection (e.g. obstacle or blind frozen to the window sill), the UP direction is
blocked.
A short command in the DOWN direction releases the UP direction.
17. What to do if…
Problem Solution
Motor does not run. • Motor not plugged in.
Please check the plug connection.
• Check connecting cable for possible
damage.
• Check the mains voltage and allow the
cause of the voltage breakdown to be
tested by a specialist
electrician.
Instead of in the downwards direction,
motor runs upwards.
• The control leads are interchanged.
Exchange black/grey control leads.
Motor only runs in one
direction.
• Motor in the end position.
Run motor in the opposite direction.
Readjust the end positions, if necessary.
After running several times,
the motor breaks down and
no longer responds.
• The motor became too hot and has
switched off.
Try it again after a cooling time of about
15 min.
PROG
PROG

12 Gerhard Geiger GmbH & Co. KG | 100W2507 0220V001en
EN
EN
18. Declaration of conformity
Current declarations of conformity are available under www.geiger.de
Schleifmühle 6 |D-74321 Bietigheim-Bissingen
Phone [phone] |Fax [phone] |[e-mail] |www.geiger.de
Sitz Bietigheim-Bissingen |Amtsgericht Stuttgart HRA 300591 | USt-IdNr. DE145002146
Komplementär: Geiger Verwaltungs-GmbH |Sitz Bietigheim-Bissingen |Amtsgericht Stuttgart HRB 300481
Geschäftsführer: Roland Kraus |WEEE-Reg.-Nr. DE47902323
Gerhard Geiger GmbH & Co. KG
300H0204
EU Declaration of Conformity
Bietigheim-Bissingen, 25.06.2019 Roland Kraus (General Manager)
Product designation:
Venetian blinds motor, motor for rolling shutters, motor for awnings
Type designation:
GR45.. GJ56..
GS45.. GS56..
GU45.. GSI56..
GB45..
Applied directives:
2006/42/EC
2014/30/EU
2014/53/EU
2011/65/EU + (EU)2015/863 + (EU)2017/2102
Applied standards:
DIN EN 60335-1 (VDE 0700-1):2012-10; EN 60335-1:2012
DIN EN 60335-1 Ber.1 (VDE 0700-1 Ber.1):2014-04; EN 60335-1:2012/AC:2014
EN 60335-1:2012/A11:2014
DIN EN 60335-2-97 (VDE 0700-97):2017-05; EN 60335-2-97:2006+A11:2008+A2:2010
+A12:2015
DIN EN 62233 (VDE 0700-366):2008-11; EN 62233:2008
DIN EN 62233 Ber.1 (VDE 0700-366 Ber.1):2009-04; EN 62233 Ber.1:2008
DIN EN ISO 12100:2011-03; EN ISO 12100:2010
DIN EN 55014-1:2012-05; EN 55014-1:2006 + A1:2009 + A2:2011
DIN EN 55014-2:2016-01; EN55014-2:2015
DIN EN 61000-3-2:2015-03; EN 61000-3-2:2014
DIN EN 61000-3-3:2014-03; EN 61000-3-3:2013
ETSI EN 301 489-1 V1.9.2(2011-09)
ETSI EN 301 489-3 V1.6.1(2013-08)
ETSI EN 300 220-2 V3.1.1(2017-02)
Authorized representative for technical data:
Gerhard Geiger GmbH & Co. KG
Address:
Schleifmühle 6, D-74321 Bietigheim-Bissingen
en
Gerhard Geiger GmbH & Co. KG
Antriebstechnik
Schleifmühle 6
D-74321 Bietigheim-Bissingen
0619100W1518

13
www.geiger.de EN
EN
19. Maintenance
The drive is maintenance-free.
20. Technical data
Technical data GSI56.. E12 SMI with electronic end stop
GSI5606 GSI5610
Voltage 230 V~/50 Hz
Current 0,40 A 0,60 A
Cos Phi (cosj)> 0,95
Inrush current (factor) x 1,2
Power 90 W 135 W
Torque 6 Nm 10 Nm
Speed 26 rpm
Protection class IP 54
Limit switch range 200 rotations
Operating mode S2 6 min. S2 4 min.
Length1) 324,5 mm 329,5 mm
Diameter 55 mm
Weight1) ca. 1,60 kg ca. 1,70 kg
Storage temperature/
Humidity
T = -15°C .. +70°C / dry and non-condensing place
1) With angel gear GSI1…: total length + 52 mm / weight + 0,4 kg
Subject to technical modifications. Please find information to the ambient
temperature range of our GEIGER motors under www.geiger.de
21. Notes on waste disposal
Recycling of packaging materials
In the interest of environmental protection, please contact your local government’s recycling or
solid waste management department to learn more about the services it provides.
Waste disposal of electric and electronic equipment
Electrical and electronic equipment must be collected and disposed of separately in accordance
with EU regulations.

14 Gerhard Geiger GmbH & Co. KG | 100W2507 0220V001en
EN
EN

15
www.geiger.de EN
EN

16 Gerhard Geiger GmbH & Co. KG | 100W2507 0220V001en
EN
EN
For technical questions, please call our service team at: [phone].
They will be happy to assist you.
Gerhard Geiger GmbH & Co. KG
Schleifmühle 6 | D-74321 Bietigheim-Bissingen
T [phone] | F [phone]
[e-mail] | www.geiger.de
