Geist SpaceCooling RAC10 User manual

RAC10 Small SpaceCooling®
Effective room airow control and monitoring solution for servers,
network switches and phone systems in small spaces.
10001901
The RAC10 system evacuates heat load from the small space and sends it to the outside corridor or ceiling plenum return.
Maintain a perfectly controlled environment for your small computer and network rooms using building air while providing the
needed visibility to cooling capacity and environment information and alarms. Email alerts and the web interface provides remote
alarms and management for superior visibility and control of the room environment.
• Continually deliver cool air to your IT equipment.
• Real-time plus historical cooling capacity and environment monitoring.
• Early alarm notication to email account/s through a secure Ethernet connection.
• Allow multiple email or SNMP trap recipients with escalation.
• Quickly deploy into ceiling or attach to wall in minutes. Web browse to device, set-up
email and/or communicate with existing management software.
Wall Mount
Ceiling Mount
• With RAC10 unit installed and temperature sensors located at air
entry to space and IT equipment air intake vent, connect to AC
power using attached 10FT cord.
• During start-up the RAC10 system will perform a self check.
• Access the web interface using the supplied default web address.
• Adjust factory default settings as desired.
• Refer to the User Manual for details.
Thermal Control & Monitoring Software
Wall Mount
The dimensions of the RAC10 fan enclosure is 14 1/4” x 21 1/4”.
The RAC10 ts between the standard 16” center studs. Mounting as
close the ceiling will maximize the heat exhausted. Use 2”, #10 wood
screws to attach the unit to the wood studs. A power receptacle is
required within close proximity to the RAC10.
Ceiling Mount
To install the RAC10 in a drop ceiling, 18 gauge hanger wire must be
used to support the unit. Attach the hanger wires to the four eyelets
on the backside of the RAC10. Place the RAC10 across the ceiling
grid using the hanger wire to support the weight. Plug the RAC10
into the power receptacle which is required to be out of the ceiling
plenum. Option Duct Kit can be ordered if required.
System Start-up

Geist Americas Geist Europe Geist Asia
Geist DCiM China Hong Kong
800.432.3219 1.877.449.4150 [phone] +86.755.86639505 [phone]
geistglobal.com geistglobal.com geistglobal.com geistglobal.com geistglobal.com
Installation Procedures
The RAC10 relies on the building installation for protection from overcurrent. A Listed circuit breaker is required in the building
installation. The circuit breaker should be rated at 15 or 20 Amps. Install the RAC10 so the input plug may be disconnected
for service.
18 ga.
hanger
wire




Four #10 2”
wood screws
Installation Precaution Guidelines
• Read and save these installation instructions.
• Install the equipment such that the amount of airow required for safe operation of
equipment is not restricted.
• The equipment relies on the building installation for over current protection.
• A listed 20 amp circuit breaker is required in the building installation.
• Model RAC10 is equipped with a grounded pin plug, reliable earth ground should
be maintained.
• Install the equipment so the input plug or appliance coupler may be disconnected
for service.
• Caution: Disconnect all power before performing any type of maintenance such as
cleaning and dusting.
• Contact Geist Customer Service for any service issue at 800-432-3219.
Specications
Input: 120 VAC, 50/60 Hz, 10FT
Cord, NEMA 5-15P
Fan Speed Regulation: Automatic
temperature control with Ethernet
remote adjustment
Airow:
1100 CFM Maximum
Environmental Monitoring: Ethernet
remote access and alarms, up to
four RJ12 Temperature sensors with
20 FT cords (two included)
Regulation: Temperature based,
range: 60 to 120F
Physical: 23.75 L x 14.00 W x
3.52 H
Network: HTTP / HTTPS / SNMP
/ DHCP
Regulatory: UL, cUL 507, FCC
Part 15 Class A
Warranty
2 Years
System Components
Wall or ceiling mount for automated heat exhaust and critical monitoring / alerts.
Optional SC System for room air supply required for some room and load conditions.
Ceiling Mount Wire Hanger Loop Optional Ducting Kit Temp Sensor Port (4) Internal Temp Sensor
Wall Stud
Mounting Flange Cable Tie Loop Power Input
Ethernet RJ45
Redundant Fan
Cartridges
