Gelmar 6286 User manual

DIY Installation Guide
Larder Unit

Larder Unit
Code Unit Size (U) kg Finish Material
6286 300 100kg CP Steel
6288 450 100kg CP Steel
Top Runner
Bottom Runner
Basket Hanger Clip
Wire Basket
Door Fixing Brackets
max
Unit Size
300 / 450
max
Interior height
1850 - 2100
Basket Hanger Clips
Bottom Runner
Spacer

Installation
STEP 2
Install Top Runner
Draw a centre line on the inside top of the cabinet. Position the runner
along the centre line, with the front xing hole 100mm from the front
edge of the carcass. Secure the front and rear xing holes with screws.
STEP 1
Install Bottom Runner
Draw a centre line on the cabinet bottom. Position the runner along the
centre line, with the front xing hole 130mm from the front edge of the
carcass. Secure the front and rear xing holes with screws.
Cent re lin e
Bottom Runner
32
32
100
353 301
Cent re lin e
Top Runner
36 36
130240
72
To ensure that the
Bottom Runner
runs parallel to
each other, use the
Runner spacer.

STEP 4
Installing the Door
Align the door with the Central Frame. Mark the position of the Frame
Brackets on the door and attach the Door Fixing Brackets in place.
Secure front door of larder in position.
Bear in mind that there needs to be a bracket aligned to where the
handle will be placed on the front of the door.
Close the door to check if it closes ush against the carcass. If not,
adjust by loosening the Fixing Screw and then adjust the Adjustment
Screw.
1850 - 2100
STEP 3
Installing the Central Frame
Secure the frame to the bottom runner. Adjust the height of the frame
to t the cupboard (between 1850mm - 2100mm) and x to the top
runner.
Note: If you extend over 1850mm, drill and mount a 4th xing bracket.
Adjustment screw
Fixing screw
Installation Continued...

STEP 5
Adjust the Depth Alignment
Loosen the Fixing Screw before adjusting the Adjustment Screw. Once
perfect adjustment is made, then tighten the Fixing Screw so that it
doesn’t move out of place.
Adjustment screw
Fixing screw
Adjustment screw
Fixing screw
STEP 6
Adjust the Horizontal Alignment
Loosen the Fixing Screw before adjusting the Adjustment Screw. Once
perfect adjustment is made, then tighten the Fixing Screw so that it
doesn’t move out of place.
Installation Continued...

STEP 7
Attach the Baskets
Insert the Basket Hanger Clips on the Central Frame at regular intivals.
Hang the Wire Baskets on the Basket Hanger Clips.
Basket
Hanger
Clip
Wire
Basket
Installation Continued...
