GEM EASIPROX-ANSI Technical manual

Copyright © Gianni Industries, Inc. All Rights Reserved.
P-MU-EASIPROX Ver. B Published on 2008.02.12 Page: 1/ 4
EASIPROX
Waterproof Standalone Proximity Reader
EASIPROX EASIPROX-ANSI
I. Product Characteristic:
Easiprox has a 2000 cards capacity and a reading time of 0.5-second max.
Fully Programmable via Master card
Electronics potted with epoxy compound applications
Aesthetic and inconspicuous design
Suitable for fully weatherized indoor/outdoor
Non-volatile memory stores all programmed information for at least 10 years, even in the
event of total power failure.
II. Specifications:
Operating Voltage 12Vdc or ac
Current Draw Average 45mA, Peak 70mA @ 12Vdc
Transmitting Frequency 125 KHz
Memory Volume 2000 Proximity cards/tokens and PIN codes
Read Range 10~15 cm (Depending on local installation conditions)
Relay Electric Current 3A MAX @24Vdc
Relocking timer Strike Time: 0.7~42 seconds (adjustable)
Format Em-400x 64-bit standard R/O or compatible
Case Material ABS (UL94V0)
Color Dark gray
Operating Temperature -20~+70℃
Ambient Humidity 5~95% relative humidity non-condensing
Visual Signals 3 LED display with audible indication (Red/Yellow/Green)
EMC Meet CE requirement

Copyright © Gianni Industries, Inc. All Rights Reserved.
P-MU-EASIPROX Ver. B Published on 2008.02.12 Page: 2/ 4
III. The indicator signal chart:
Signal Condition
Yellow Power on, Stand-by
Green Lock relay active
User Signals
Red Invalid Card
Yellow、Green Flashing The memory is empty
Green Flashing Into the ADD CARDS MODE
Red Flashing Into the DELETE CARDS MODE
Yellow、Red Flashing Into the CLEAR MEMORY MODE
Yellow Flashing Into the TIME ADJUST MODE
Programming
Signals
Green Blinking Clearing Memory
IV. Wiring diagram:
Push Button
(N.O./Com.)
Power Supply
Electric Strike
(Fail-Secure Typical)
Electric magnet
(Fail-safe Typical)
Note:
1. The suggested wire gauge is #22~26 AWG.
2. The varistor or diode must be connected across the lock terminal (electromagnet...)
operated by the device. The vartistor controls the overload produced by the strike coil
(EMP).
3. Using a Linear supply power recommended, to prevent power reduction at the card
reader.

Copyright © Gianni Industries, Inc. All Rights Reserved.
P-MU-EASIPROX Ver. B Published on 2008.02.12 Page: 3/ 4
V. Operation Instruction
WARNING: Please read all of operation instruction before proceeding.
Setting Master Card
If the GREEN and YELLOW lamps are flashing, it indicates that the memory is empty and
that there is no Master Card. All programming is done by using this Master Card.
Add Cards
Read the Master Card once→Only the GREEN lamp wills light→Wait for the GREEN
lamp to start flashing→The Easiprox is now in the ADD state.
In this state every Card presented to the Easiprox will operate the relay and be added to
memory. Read the Master Card to return to the Stand-by state.
Delete Cards
Read the Master Card twice with a time between reads of less than 2 seconds→The
RED lamp will light→Wait for the RED lamp to start flashing→The Easiprox is now in
the DELETE state.
In this state every Card that is presented to the reader will be deleted from the system
memory. (Cards can now also be deleted by using the optional Card Simulator.). Once
the Card or a group of Cards have been deleted, read the Master Card to return to the
Stand-by state.
Clear Memory
Read the Master Card three times with a time between reads of less than 2 seconds→
The YELLOW and RED lamps will light→Wait for the YELLOW and RED lamps to start
flashing→The Easiprox is now in the CLEAR MEMORY state.
Now present any Card except the Master Card to the reader and all memory will be
cleared. Alternatively, read the Master Card to abort this function. Once the memory is
cleared the YELLOW and GREEN lamps will flash to indicate that the memory is empty.
Totally reset
Power off→Shorted the Clear Memory （Black cable）→Power on→Wait for the
YELLOW and RED lamps to start flashing（remove the black cable）→Once the
memory is cleared the YELLOW and GREEN lamps will flash to indicate that the memory
is empty.
Time Adjust
This function sets the relay operating time for a push-button input and a valid card read.
Read the Master Card 4 times with a time between reads of less than 2 seconds→All
the lamps will go off→Wait for the YELLOW lamp to start flashing→The Easiprox is
now in the TIME ADJUST state and each flash of the YELLOW lamp equates to 0.7
second of relay operation time.
Once the desired time is reached (max 42 seconds), read the Master Card to store the
time and return to the Stand-by state. If programming mode is required simply allow the
YELLOW lamp to flash until it stops automatically (after 61 flashes). The unit will now be
in programming mode.

Copyright © Gianni Industries, Inc. All Rights Reserved.
P-MU-EASIPROX Ver. B Published on 2008.02.12 Page: 4/ 4
Card Simulator / Programmer (optional)
The Card Simulator allows adding and removing any card/card number from the reader
memory when the card is lost or not available. One unit can be utilized at different sites
but for security reasons it will operate only in conjunction with the Master Card.
The Card Simulator / Programmer cannot be used to gain access. It will only operate
together with the reader's MASTER card
¾Setting Card Number
Hold the On/Off button down.
Use the RIGHT ARROW key to move the cursor to the digit to be changed.
Use the UP ARROW key to change the number at the cursor.
Repeat the above until all the digits of the number are correct.
This number is stored in memory and the On/Off button may now be released.
¾Battery
The unit is powered by a PP3 9V battery. Undo the 2 screws at the back of the unit to
gain access to the battery.
¾Deleting Cards
The MASTER card must be used to put the reader into the Delete mode.
RED lamp flashes
Place the Card Simulator close to the reader
Hold down the On/Off button and check the displayed number
Press the Send button
The GREEN lamp will flash to verify that the selected number is deleted and then the
RED lamp will continue flashing.
Once the card or a group of cards have been deleted, read the Master Card to return to
the RUN state.
¾Adding Cards
The MASTER card must be used to put the reader into the Add mode.
GREEN lamp flashes
Place the Card Simulator close to the reader
Hold down the On/Off button and check the displayed number
Press the Send button
The GREEN lamp will go steady and the relay will operate to verify that the selected
number is added. The GREEN lamp will then continue flashing.
Once the card or a group of cards have been added, read the Master Card to return to
the stand-by state.
