Gemmy PLC-01 User manual

1
TABLE TOP CENTRIFUGE
PLC-01,PLC-02,PLC-03,PLC-04,PLC-05
USER’S MANUAL
OPERATION / MAINTENANCE
AND PARTS LIST
! Safety Information
This manual contains important and safety information.
The user must carefully read and understand the contents of this
manual prior to using this equipment.
2013.0115.2000

TABLE TOP CENTRIFUGE
PLC-01,PLC-02,PLC-03,PLC-04,PLC-05
USER’S MANUAL
OPERATION / MAINTENANCE
AND PARTS LIST
Content
Safety information, product information …………………………… 1
Intended use, installation, definition ……………………………. 2
Tubes information ……………………………………………….. 3
Grounding ……………………………………………………… 4
How to install testing tubes …………………………………………. 5
Operation ……………………………………………………………. 6
Recalibration procedure for speed ……………………………. 7
Speed and RCF indication ………………………………………… 8
Disassembly ……………………………………………………… 9
Maintenance & Servicing …………………………………………. 10
Troubleshooting ………………………………………………………. 11
Direction and environmental condition for clean, operation………. 12
Diagram of components …………………………………………. 13
Parts list …………………………………………………………….. 14
Wiring diagram ………………………………………………………. 15
Gemmy Industrial Corp.
Certified: ISO9001, ISO13485,
CE Marking, GMP, FDA

Safety information
Your GEMMY Table Top Centrifuge has been designed with functions,
reliability, and safety in mind. This manual contains important operation
and safety information. The users must carefully read and understand
the contents of this manual prior to installing your centrifuge in
conformance with your local electrical codes.
Classification: This Centrifuge is classified as “Class I” equipment.
Thermal cutout operation temperature
：
105ºC
CE marking
：
The manufacturer also declares the conformity with the
actual required safety standards in accordance with
LVD 73/23 EEC.
Standard:
This equipment complies with EC Electromagnetic Compatibility
requirement of EN60601-1-2. EMI filter is designed in conformity
with 89/336 EEC-EMC Directive.
ISO9001+13485,
GMP (Good Manufacturing Practice)
FDA registered (USA)
Product’s briefing
：
This equipment is a Class 1 tabletop centrifuge with timers of 60
minutes maximum and a speed control knob. The motor has a max
speed of 4000 –4500 rpm and fitted with a thermal cut-off to cut the
power in abnormal temperature condition. There is no heating
element. The power cord is non-detachable. Two PC boards are
installed, one is for power filtering, one is for the speed control. There
is no applied part for patients and not suitable for the use in special
environment.
Motor
：
AC, carbon brush, your choice of 67W or 90W
power
：
110V/60HZ or 220V/50HZ
rotor
：
45º fixed angle rotor
Suggested Tubes:
5ml:12 x 75mm
10ml: 16 x 100mm Length
15ml:17 x 117mm (or120mm)
1

Intended use:
This equipment is to provide a laboratory test within the range of
1000 –4500 rpm for test tubes containing in vitro diagnostic
specimens for qualitative or quantitative test procedures. Refer to the
clinic laboratory method specified by the reagent manufacturer or
established by medical technology for products applications.
Installation:
1
、
Strip the packing materials
2
、
Open the cover of the carton box and remove the artificial form
3
、
Carry the centrifuge carefully from the carton box;
4
、
Remove the plastic bag from the centrifuge;
5
、
Place centrifuge onto a sturdy and flat table.
6
、
Don’t drop the equipment and don’t place the equipment
upside down.
Content
：
-Rotor :1
-Carbon brush :1 pair spare carbon brush
-Fuse : 1
-Adaptor : Corresponding to the rotor.
-Power Cord
：
3-wire
（
CSA type, SVT 105ºC, 18AWG x 2 C
）
Definition
：
g Force
The measurement for samples undergoing the stress of
acceleration in a centrifuge.
RCF
（
Relative Centrifugal Force
）
RCF is the centrifugal force that the samples undergoes which
relies on the speed of rotation
（
N
）
in rpm and the rotating radius
(cm)
（
R
）
. The rotating radius is measured from the center axis of
rotor to the extreme end of the centrifuge tubes.
Formula:RCF = 11.18 x R x ( N / 1000)²
A-0815: Ø 21.1cm;
A-1215:Ø 22.7cm
2

TUBES
Round bottom
：
Have a uniform wall thickness and provides a better fit in a rotor
than conical bottom tubes. Round tubes withstand higher
g-forces.
Conical bottom
：
Ideal for cell culturing and ammonium sulfate precipitations.
1. All centrifuges have come with the tube holders, in which a rubber
cushion is installed inside the tubes.
2. The tube adaptor is applied to the volume either 10ml or 15ml.
3. Do not place the cushion upside down or in a slant position.
4. Replace the cushion once the glass tube is broken.
5. Be sure the tube adaptors are placed into the rotor completely.
3

Grounding
This centrifuge is installed with a 3-pin electric cable. Be sure to well
connect the grounding wire to the terminal.
WARNING:
Do not connect the grounding pin to the following areas:
1. Gas piping or faucet
Explosion or fire may occur
2. Other wires of lighting
Electric shock or fire may occur
3. Other electrical applicants.
4

HOW TO INSTALL TESTING TUBES
The balance of rotor has been well calibrated in house thoroughly
before delivery, the user is again requested to install the testing tubes
in the correct way carefully prior to spinning this centrifuge as depicted
below:
1. Place the testing tubes into the tube adaptors diagonally and
symmetrically to balance the rotor. Please refer to the figure.
2. Place the testing tubes gathering on one single side will create
imbalance of rotor, which will possibly cause vibration of rotor.
3. If odd number of testing tube is used, supplement another dummy
tube to remedy the problem.
5

OPERATION:
-Check the specification label located on back of this equipment.
-Plug cord in a properly grounded outlet.
-Place the test tubes into the tube adaptors. Be sure to place the
tubes diagonally and symmetrically to keep the rotor balanced.
-Close the cover completely. NOTE, Locking latch is optional.
-Dial preset your desired time by turning the control knob for any
spin interval from 0 –60 minutes. This equipment is working by
timer-activated operation.
-When turn clockwise the timer, the pilot lamp will light up at the
same time, which indicates the power up.
-Adjust the control knob of speed regulator to bring speed to your
desired operation speed and centrifugal force.
-This centrifuge does not include the speed indicator, the reference
of speed and RCF is depicted below. Nevertheless, the user is
recommended to measure the speed by a hand held LCD
tachometer in order to achieve a correct speed and RCF.
-Speed and RCF varies slightly centrifuge to centrifuge.
-The bell rings and power will shut out automatically when the set
time has elapsed and the pilot lamp will distinguish simultaneously.
WARNING
：
-Do not open the lid only until the rotor has stopped completely.
-Do not stop the rotor by hand. There is possibility of personal injury.
-Gemmy will not ensure the responsibility if user violate the above
regulation.
6

Recalibration Procedure for Speed:
This centrifuge was initially set by its speed from 1000 –4500 rpm (or
4000 rpm for PLC-05) in house. Supposed that the min/max speed is
varied, the control can be recalibrated as depicted below:
1
、
Remove the bottom plate, switch power on by turning control knob
of timer. CAUTION:Electrical Shock
2
、
Turn knob of speed regulator to the extreme LOW position. Adjust
part of SVR P2/204 (for the low 1000 rpm control) right/left to get
the desired speed of 1000rpm.
3
、
To recalibrate the speed for 4000 or 4500rpm, turn speed regulator
to the extreme HIGH position, then adjust SVR (P1/104) right/left
slightly until it reaches 4000 or 4500 rpm.
4
、
The calibration of LOW or HIGH speed can influence each other;
thus the user is recommended to use the digital speed indicator
and measure the result of the recalibration. Repeat the above
procedure until the final speed indication meets your requirement.
5
、
Switch off the power and assemble the bottom plate.
6
、
Glue the parts of SVR (P1/104 and P2/204) after the speed
recalibration is finished. The transportation and vibration may
probably loosen the electronic parts and fasteners.
WARNING:
Electric shock and Personal injury. Always proceed with caution.
7

Speed and RCF Indication
The speed and RCF may be varied centrifuge to centrifuge caused by
its surrounding power consumption, which will result in a fluctuation of
speed. To assure an accurate rpm and its corresponding RCF, do not
place this equipment in the draft, sunlight or near a piece of equipment
that emits heat as well as Electromagnetic conduction emission.
1. Motor 67W (Average values from 5 random samplings)
2. Motor 90 W (Average values from 5 random samplings)
-Confidence interval: ± 95%
-User is recommended to measure speed and RCF by digital speed
indicator to achieve the practical values.
8
TIMER
PLC-01 ~ PLC-03
PLC-04~PLC05
Speed
RCF
Speed
RCF
LOW
1026
124 x g
1018
132 x g
1
1130
150
1123
160
2
1242
182
1262
202
3
1355
216
1603
326
4
1553
285
1810
416
5
1855
406
2055
536
6
2350
651
2280
660
7
3024
1079
2760
967
8
3447
1401
3100
1220
9
4030
1916
3585
1631
HIGH
4460
2346
3960
1990
TIMER
PLC-01 ~ PLC-03
PLC-04 ~ PLC-05
Speed
RCF
Speed
RCF
LOW
1000
118 x g
1000
127 x g
1
1056
132
1080
148
2
1165
160
1170
174
3
1305
201
1270
205
4
1485
260
1390
245
5
1672
330
1543
302
6
1940
445
1770
398
7
2405
682
2016
516
8
2863
967
2628
876
9
3815
1717
3550
1600
HIGH
4500
2390
4003
2033

DISASSEMBLY:
WARNING
：
For sake of safety, the disassembly must be done the qualified
personnel or licensed engineers only. GEMMY will not ensure the
responsibility if user violates this regulation.
Remove the bottom plate by loosening the set-screw.
Loosen the nuts from rubber supports attached to the base to
remove the rack of motor
Unscrew the motor from the rack
Disconnect wires from assembly prior to disassemble the
electronic parts.
Loosen the bolt to remove the rotor.
Remove the control knobs of timer and speed regulator by
loosening the screws on it.
The front control panel is glued.
Unscrew the set bolts to remove timer and speed regulator.
Loosen screws for chamber removal.
Always disconnect from power supply prior to disassembly.
WARNING
：
-Disconnect from power supply prior to disassembly of this
equipment.
-People other than the qualified personnel or licensed engineers
are strictly prohibited for disassembly.
9

MAINTENANCE & SERVICING
：
To avoid electrical shock, always disconnect from power supply
prior to maintenance & Servicing.
People other than the qualified personnel or licensed engineers
are strictly prohibited from maintenance and servicing.
Always use a properly grounded electrical outlet of correct voltage
and current handling capacity.
Always inspect the rubber supports, replace the new one when
required in order to keep the balanced rotor.
Clean the chamber and rotor after use of this equipment.
Do not drop this equipment. Do not place this equipment upside
down.
The drive motor and linkage assembly do not require lubrication.
Always inspect the balance and speed at least once a month.
Inspect and replace the carbon brushes yearly or according to the
operation frequency or whenever it needs.
Use compressor to clean the dust inside the chamber that is
generated by the carbon brushes. Wearing the musk while
cleaning the dust to protect your respiratory system.
Carbon brushes are required from the origin of supplier. The
nature of carbon brushes, such as hardness and dimension, is
connection with the motor design. The carbon brushes out of the
origin of supplier will damage the motor.
The life of carbon brushes depends on the using frequency.
Always inspect the carbon brushes status and replace new ones
when required.
Inspect micro-switch and see if the function of automatic shutout
safety device is working.
A 5A.-fuse is equipped inside the circuit board to encounter the
abuse of voltage, so as to protect the electronic parts and motor
from burnout.
Inspect the speed indicator and see if its variable is accurate or not.
Calibrate the speed indicator if it can’t match the practical value.
(see Page 7:Recalibration Procedure for Speed)
10

Troubleshooting:
Problem
Possible cause
Corrective action
Vibration
-Rotor imbalance
-Defective rubber support
-Place tubes symmetrically
-Replace new one
Erratic speed
-Worn out carbon brushes
-Defective triac or VR
-Replace new ones
-Replace parts
Failure of
operation
-Worn out brushes
-Defective motor or PCB
-Blowout fuse
-Disengaged linkage
-Replace carbon brushes
-Replace parts
-Replace fuse
-Connect linkage
Burnout motor &
PCB
-Wrong power supply
-Overload current
Use the right power
source
Change of MAX
and MIN rpm
-Loose SVR of PCB
-Calibrate speed. See Page
7 for correction
Timer can’t work
-Counting failure
-Turn timer to 60min, then
turn to 0 before set time.
Tilted rotor
-Loose fastener attached to
motor
-Broken rubber support
-Fix and glue the fastener
-Replace new one
Failure of motor
spinning
-Worn out carbon brushes
-Malfunction of PCB
-Burnout motor
-Disengaged wiring
-Replace carbon brushes
-Replace PCB
-Replace motor
-Connect wirings
NOTE
：
Troubleshooting must be done by the qualified personnel only.
The drive motor and linkage assembly do not require lubrication
Immerse the centrifuge in water is strictly prohibited
Disassembly must be performed under the supervision of licensed
engineers
Tip the equipment up or place upside down or vibrate the
equipment may damage the equipment
Take care of the electrical shock for troubleshooting.
Always refer troubleshooting to your local distributors.
Unstable voltage and current can shorten the lifespan of this
centrifuge. We recommend you use the voltage stabilizer.
11

Direction to Clean:
Disconnect from power supply prior to clean.
Clean the equipment after every use.
Use a moist cleaning cloth to clean the case, rotor and tube
holders
Dry the equipment thoroughly before operation.
Do not immerse this equipment in water.
Never use benzine or paint thinner for cleaning.
Transportation
Fragile, Handle with Care
Use no hook
Do not drop this equipment
Do not place this equipment upside down.
Pack this equipment in carton box for transportation.
Prevent this equipment from vibrating.
Storage:
Do not place this equipment in the draft, sunlight or near a piece of
equipment that emits heat and electromagnetic conduction
emission.
Disconnect power supply while store this equipment.
This equipment shall be stored under the condition of room
temperature
Do not place any heavy load on this equipment.
Environmental Conditions for Operation & Storage:
Temperature 10º C –40ºC
Humidity 40 % –90 %
Sea level altitude ≤4000 meters
Atmospherics pressure range of 700hPa to 1060hPa
NOTE:
This equipment complies with EC Electromagnetic Compatibility
requirement of EN60601-1-2
EMI filter is designed in conformity with 89/336 EEC-EMC
Directive
This equipment complies with IEC801 series regulations.
12

Diagram of Components
13

Part List
No.
Description
No.
Description
1
Lid
19
Control knob, speed
2
Plastic gasket
20
Pilot lamp
3
Chamber, upper
21
Speed regulator, VR
4
Fastener, rotor
22
Brass connector, rotor+motor
5
Rotor, alloyed aluminum
23
Motor, AC (67W or 90W)
6
Bolt, 3 required
24
Washer
7
Bolt, 3 required
25
Nut
8
Chamber, lower
26
Rack, motor
9
Screw, 3 required
27
Fastener
10
Rubber gasket
28
Fastener
11
Power cord
29
Fastener
12
Control panel
30
Circuit board
13
Base
31
Fastener
14
Fastener
32
EMI
15
Timer, 60 minutes
33
Rubber support, 3 required
16
Washer
34
Fastener
17
Fastener, timer
35
Bottom plate
18
Control knob, timer
36
Fastener
37
Suction feet, 3 required
NOTE
：
When ordering for replacement, be sure to order by its part number
and description.
14

Wiring diagram
A: With Safety Shutout Locking Lid
15
B: Natural Braking Device
15

One Year Limited Warranty
Your GEMMY product is guaranteed to be free from defects in
materials and workmanship for one (1) year under normal use from the
date of purchase.
This WARRANTY does not apply to any product damaged by accident,
misuse, abuse, neglect, improper line voltage, drop, fire, flood or if the
products were altered or repaired by anyone other than the qualified
service personnel.
The liability of Gemmy Industrial Corp. is limited to repair or
replacement and under no circumstances shall GEMMY be liable for
any collateral consequential damages or losses. This guarantee
specifically excludes the expendables and consumables.
All warranty claims must be directed to the distributors or agents
authorized by Gemmy Industrial Corp. responsible for the sale of this
equipment. The users are responsible for shipping expenses.
Purchase Record
Company name:
Address :
Phone No. :
Fax No. :
Email address :
Date of purchase:
Product Model :
Serial No. :
Distributor :
Manufacturer: EU Representative:
Gemmy Industrial Corp. GEMMY EUROPE
Taipei, Taiwan 23 rue de Rotterdam
4000 Liege, Belgium
Tel: [phone]
Fax: [phone]
ISO9001, ISO13485
GMP, FDA, CE MARKING
