Installation Manual
Generac PWRcell™ Inverter
009954
(000209b)
WARNING
Loss of life. This product is not intended to
be used in a critical life support application.
Failure to adhere to this warning could result
in death or serious injury.
Register your Generac product at:
https://pwrfleet.generac.com
1-888-GENERAC
(888-436-3722)
Para español, visita: http://www.generac.com/service-support/product-support-lookup
Pour le français, visiter: http://www.generac.com/service-support/product-support-lookup

ii Installation Manual for Generac PWRcell Inverter
Use this page to record important information about your Generac Product
Record the information found on your unit data label on this page. See Serial Number Location.
When contacting an Independent Authorized Service Dealer (IASD) or Generac Customer Service, always supply the complete
model number and serial number of the unit.
Table 1: PWRcell Inverter Important Information
Unit Model Number
Unit Serial Number
Date Purchased
Commissioning Date
(000393a)
WARNING
CANCER AND REPRODUCTIVE HARM
www.P65Warnings.ca.gov.

Installation Manual for Generac PWRcell Inverter iii
Section 1: Safety Rules & General
Information
Introduction ..........................................................1
Safety Rules .........................................................1
General Hazards ..................................................2
Electrical Hazards ................................................3
Section 2: General Information
Specifications ......................................................5
Serial Number Location ......................................6
Unit Dimensions ..................................................6
Component Locations .........................................6
About PWRcell Inverters .....................................6
Inverter Control Panel .........................................7
Section 3: Location and Compliance
Location ................................................................9
Compliance ..........................................................9
Rapid Shutdown ..................................................9
Voltage and Frequency Trip Thresholds .........10
Section 4: Installing PWRcell Inverter
PWRcell Inverter Dimensions and Mounting
Clearances ..........................................................11
Mounting Bracket Dimensions .........................11
Mounting the Inverter ........................................12
Section 5: Electrical Connections
PWRcell Inverter Wiring Compartment ............13
Accessing Wiring Compartment ......................13
Knockout Dimensions and Locations .............14
Wiring Guidelines ..............................................15
Grounding Bar Wiring .......................................15
DC Wiring ...........................................................16
AC Wiring ...........................................................16
Protected Load ...................................................17
Connecting Ethernet .........................................18
Current Transformers (CTs) ............................. 18
Other Accessories ............................................. 23
Section 6: Commissioning and Setup
System Configuration ....................................... 25
General Information .......................................... 25
Commissioning the System ............................. 25
Connect the PWRcell inverter to High Speed
Broadband Internet ........................................... 25
Registration ....................................................... 25
Connecting PWRcell Inverter to AC Power ..... 26
Selecting Inverter System Mode ...................... 26
Configuring Inverter Settings ........................... 27
Adjusting Inverter Settings .............................. 27
Selecting Inverter Compliance Setting
(optional) ............................................................ 28
Selecting ESS Grid Usage Mode (Optional) .... 28
Enabling REbus Devices .................................. 28
REbus Beacon Setup ........................................ 29
Configuring Static IP Settings .......................... 32
Commissioning Multiple Inverter Systems ..... 33
Installer Configuration Tool ............................. 34
Section 7: Maintenance
Service ................................................................ 39
Accessing Wiring Compartment ...................... 39
Replacing Fuses ................................................ 39
Section 8: Troubleshooting
General Troubleshooting .................................. 41

iv Installation Manual for Generac PWRcell Inverter
This page intentionally left blank.

Safety Rules & General Information
Installation Manual for Generac PWRCell Inverter 1
Section 1: Safety Rules & General Information
Introduction
Thank you for purchasing a Generac PWRcell™ product.
The Generac PWRcell inverter is a storage-ready
inverter that connects to the PV Link™ optimizers and
PWRcell batteries to form the Generac PWRcell system.
This manual provides instructions for installing the
PWRcell inverter, including mounting, wiring, and battery
integration information. The companion document to this
installation manual is the Generac PWRcell Inverter
Owner’s Manual. See the owner’s manual for complete
information on programming and configuring the
PWRcell inverter.
The information in this manual is accurate based on
products produced at the time of publication. The
manufacturer reserves the right to make technical
updates, corrections, and product revisions at any time
without notice.
Read This Manual Thoroughly
If any section of this manual is not understood, contact
the nearest Independent Authorized Service Dealer
(IASD) or Generac Customer Service at 1-888-436-3722
(1-888-GENERAC), or visit www.generac.com for assis-
tance. The owner is responsible for correct maintenance
and safe use of the unit.
This manual must be used in conjunction with all other
supporting product documentation supplied with the
product.
SAVE THESE INSTRUCTIONS for future reference. This
manual contains important instructions that must be fol-
lowed during placement, operation, and maintenance of
the unit and its components. Always supply this manual
to any individual that will use this unit, and instruct them
on how to correctly start, operate, and stop the unit in
case of emergency. The contents of this manual are
applicable to PWRcell Inverters operating with software
version > 13120.
NOTE: Verify the latest software version is installed to
ensure the most up to date features and functionality are
available. See Verifying Inverter Software Version for
more information on verifying the inverter software. To
get the latest software version go to generac.com/
pwrcell/update and follow the instructions, or call 1-855-
395-7841 for additional help or questions.
Safety Rules
The manufacturer cannot anticipate every possible cir-
cumstance that might involve a hazard. The alerts in this
manual, and on tags and decals affixed to the unit, are
not all inclusive. If using a procedure, work method, or
operating technique that the manufacturer does not spe-
cifically recommend, verify that it is safe for others and
does not render the equipment unsafe.
Throughout this publication, and on tags and decals
affixed to the unit, DANGER, WARNING, CAUTION, and
NOTE blocks are used to alert personnel to special
instructions about a particular operation that may be
hazardous if performed incorrectly or carelessly. Observe
them carefully. Alert definitions are as follows:
NOTE: Notes contain additional information important to
a procedure and will be found within the regular text of
this manual.
These safety alerts cannot eliminate the hazards that
they indicate. Common sense and strict compliance with
the special instructions while performing the action or
service are essential to preventing accidents.
How to Obtain Service
For assistance, contact the nearest Independent Autho-
rized Service Dealer (IASD) or Generac Customer Ser-
vice at 1-888-436-3722 (1-888-GENERAC), or visit
www.generac.com.
When contacting an IASD or Generac Customer Service,
always supply the complete model and serial number of
the unit as given on its data decal located on the unit.
Record the model and serial numbers in the spaces pro-
vided on the front cover of this manual.
(000100a)
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
WARNING
(000001)
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
(000002)
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
(000003)
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.

Safety Rules & General Information
2 Installation Manual for Generac PWRCell Inverter
General Hazards
•Connecting the PWRcell inverter to the electric util-
ity grid must only be done after receiving prior
approval from the utility company.
•Only competent, qualified personnel should install,
operate, and service this equipment. Strictly com-
ply to local, state, and national electrical and build-
ing codes. When using this equipment, comply with
regulations established by the National Electrical
Code (NEC), CSA Standard; the Occupational
Safety and Health Administration (OSHA), or the
local agency for workplace health and safety.
•Protection against lightning surges in accordance
with local electric codes is the responsibility of the
installer.
NOTE: Lightning damage is not covered by warranty.
•Never work on this equipment while physically or
mentally fatigued.
•Any voltage measurements should be performed
with a meter that meets UL3111 safety standards,
and meets or exceeds overvoltage class CAT III.
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
(000191)
DANGER
Automatic start-up. Disconnect utility power and
render unit inoperable before working on unit.
Failure to do so will result in death or serious injury.
(000187)
WARNING
Electrocution. Potentially lethal voltages are generated
by this equipment. Render the equipment safe before
attempting repairs or maintenance. Failure to do so
could result in death or serious injury.
Risk of injury. Do not operate or service this machine
if not fully alert. Fatigue can impair the ability to
operate or service this equipment and could result in
death or serious injury. (000215a)
WARNING
(000209b)
WARNING
Loss of life. This product is not intended to
be used in a critical life support application.
Failure to adhere to this warning could result
in death or serious injury.
(000640)
WARNING
Equipment damage. Connecting inverter to electric utility
grid must only be done after receiving prior approval
from utility company. Failure to do so could result in
equipment or property damage.
(000155a)
WARNING
Electric shock. Only a trained and licensed electrician
should perform wiring and connections to unit. Failure to
follow proper installation requirements could result in death,
serious injury, and equipment or property damage.
(000182a)
WARNING
Equipment damage. Only qualified service personnel may
install, operate, and maintain this equipment. Failure to
follow proper installation requirements could result in death,
serious injury, and equipment or property damage.
Equipment damage. Connect only to REbus-compatible
devices to the DC bus. Never connect to any other DC
power source. Connecting to other DC power sources
could result in equipment damage. (000598a)
CAUTION

Safety Rules & General Information
Installation Manual for Generac PWRCell Inverter 3
Electrical Hazards
(000104)
DANGER
Electrocution. Water contact with a power
source, if not avoided, will result in death
or serious injury.
(000604)
Electrocution. PWRcell Battery front cover should
be removed by a qualified technician only.
Removing the front cover could result in death,
serious injury, equipment or property damage.
DANGER
(000145)
DANGER
Electrocution. In the event of electrical accident,
immediately shut power OFF. Use non-conductive
implements to free victim from live conductor. Apply
first aid and get medical help. Failure to do so will
result in death or serious injury.
(000599)
Electrocution. Turn battery disconnect OFF and
de-energize REbus before touching terminals.
Failure to do so will result in death, serious injury,
equipment and property damage.
DANGER
(000152)
DANGER
Electrocution. Verify electrical system is
properly grounded before applying power.
Failure to do so will result in death or serious
injury.

Safety Rules & General Information
4 Installation Manual for Generac PWRCell Inverter
This page intentionally left blank.

Installation Manual for Generac PWRcell Inverter 5
General Information
Section 2: General Information
Specifications
Description Units X7602 X11402
Max. cont. grid-tied AC power @ 122º F (50º C) kW 7.6 11.4
Max. cont. islanded AC power without an external
transfer switch1kW 7.6 7.6
Max. cont. islanded AC power w/ external transfer
switch and single 6 module battery cabinet2kW 9.0 9.0
Max. cont. islanded AC power w/ external transfer
switch and 2 battery cabinets (8 modules minimum)2kW 11.0 Range 9.6 to 11.0*
Peak motor starting current (2 sec) A rms 50
Normal output frequency AC Hz 60
Grid Voltage Line to Neutral (L-N) VAC 120
Grid Voltage Line to Line (L-L) VAC 240 208
Peak efficiency % 97.3 97.7
Allowable split phase imbalance % Up to 30%
CEC weighted efficiency % 96.5 97.5
AC terminals wire size AWG 14 to 6
DC terminals wire size AWG 18 to 6
STOP terminals wire size AWG 30 to 14
Weight lb (kg) 70.9 (32.1)
Thermal management - forced convection
Weatherization rating - NEMA Type 3R
Enclosure material - powder-coated steel
Description Units Min Nominal Max
REbus voltage V 360 380 420
REbus current A 30†
REbus Input short circuit current3A 30
REbus Input source backfeed current to input source A 30
Output power factor rating AC - 1
Operating voltage range AC, X7602 Series (L-N) V rms 106 120 132
Operating voltage range AC, X7602 Series (L-L) V rms 212 240 264
Operating voltage range AC, X11402 Series (L-N) V rms 106 120 132
Operating output voltage range AC, X11402 Series (L-L) V rms 184 208 228
Continuous output current AC grid-tied A rms 32
PCS controlled current grid-tied A rms 32
Continuous output current AC islanded1A rms 42
Output fault current duration A / ms 50 / 2,000
Full Power operating ambient temperature range4°F (°C) -4 (-20) +122 (+50)
Utility interconnection voltage and frequency
trip limits and trip times See Voltage and Frequency Trip Thresholds for more
information.
Trip voltage and frequency limits
Trip voltage accuracy
Trip time accuracy - 2% +/-2 cycles
1 When islanded, continuous power output is restricted to 7.68kW unless backup power is routed through an external transfer
switch.
2 Peak performance, values provided for 104º F (40º C)
3 Rating for one DC input. Four total.
4 Includes ambient temperature rising from inverter operation.
* In Island mode XVT11402 Protected loads only supply 2 phases 120 VAC L-N, 208 L-L which results in lower power than in
grid tied 3 phase mode. The low value of the range is for full L-L loading while high value of the range is full L-N loading.
†Inverter limits its REbus current to adhere to its AC power rating. Total REbus current capability from multiple REbus
sources may safely exceed this value as the inverter safely limits the amount utilized.

6 Installation Manual for Generac PWRcell Inverter
General Information
Serial Number Location
Refer to Figure 2-2 to locate unit serial number (A).
Record the information from this tag in Table 1: PWRcell
Inverter Important Information on the inside front cover
of this manual.
Unit Dimensions
Figure 2-1. Unit Dimension
Component Locations
Figure 2-2. Component Locations
About PWRcell Inverters
The PWRcell inverter connects to PV Link™ optimizers
and PWRcell batteries to form the PWRcell system for
grid-interactive solar-plus-storage.
Upon the loss of grid power, PWRcell inverters
disconnect from the grid and provide AC power to
support protected loads when configured to do so. This
capability is referred to as islanding.
All PWRcell products use the REbus™ 380 VDC
nanogrid to connect to each other. The REbus nanogrid
automates the flow of power to enable plug-and-play
setup and operation of PWRcell equipment. For more
information about REbus, visit www.generac.com.
In Figure 2-3 PWRcell inverter (E) is directly connected
to PV Link optimizers (B) and PWRcell battery (C) on DC
(REbus) line (D). To the right of the inverter are AC lines:
120/240 VAC for grid and home loads (G) and protected
loads (H).
.
Figure 2-3. Generac PWRcell System Example
A24-3/4 in (628 mm)
B19-3/8 in (491 mm)
C8-3/8 in (214 mm)
B
A
C
009955
A Control Panel
B Intake Filter
C Exhaust Vent
D Serial Number Tag
009954
A
B
C
D
A Solar Panels D REbus G Loads
B PV Link E PWRcell Inverter H Protected Loads
C PWRcell Battery F Grid
009893
A
C
D
E
F
G
H
B
BB D

Installation Manual for Generac PWRcell Inverter 7
General Information
Inverter Control Panel
Figure 2-4. Inverter Control Panel
See Figure 2-4. The PWRcell system is controlled
through the PWRcell inverter control panel. The inverter
control panel is used for adjusting system settings and for
interacting with devices.
REbus Status LED
REbus Status LED (C) communicates REbus nanogrid
status through LED color.
•Green – all devices are functioning normally and
PV Links are generating power on REbus.
•Yellow – no PV Links are generating power from
PV on REbus.
•Red – one or more REbus device has a fault that
requires attention before operation will continue.
NOTE: A red LED can also indicate a fault with the
REbus nanogrid itself. See display (A) for more
information about the specific fault detected.
Inverter LED
Inverter LED (D) communicates the status of the utility
grid and/or inverter through LED color and state.
•Green – the inverter is enabled and functioning
properly in either state “grid connected” or state
“islanded.”
•Yellow – utility grid is not within normal conditions,
but user intervention typically is not required. The
inverter will restart as soon as the utility grid
returns to normal conditions.
•Red – a serious fault with the utility grid or inverter
has been detected and user attention is required
before the unit will resume operation. See display
(A) for more information about the fault detected.
•No light – the inverter is disabled or powered off.
Internet LED
Internet LED (G) is illuminated when the inverter is
connected to a router and has an IP address.
A blue Internet LED does not mean that the inverter has
connected with the Generac server.
Shutdown Mode
NOTE: A loss of grid power will not de-energize REbus
in a PWRcell system configured to island with enabled
energy storage.
Shutdown button (E) activates a transition to shutdown
system mode. Disabled PWRcell equipment will limit
output voltages to a safe level for servicing. See Rapid
Shutdown for more information.
NOTE: The AC section of the inverter will still be
energized unless the building AC disconnect or main
service breaker is shut off.
To enter shutdown, press and hold shutdown button (E).
In shutdown mode:
•PWRcell inverter will stop sourcing power to
REbus, and immediately disable all communicating
power sources on REbus by sending a system-
wide system mode change signal.
NOTE: Successful signal transmission relies upon
proper configuration of PLM channels across REbus
devices (PV Links and Batteries).
•Shutdown LED (F) will illuminate.
•Inverter screen (A) will display REbus DC bus volt-
age and text indicting shutdown mode has been
initiated.
A LCD Display
B Navigation Keys
C REbus Status LED
D Inverter LED
E Shutdown
F Shutdown LED
G Internet LED
REbus Inverter
Internet
Shutdown
(hold)
009894
A
D
C
B
G
E
F
(000600)
DANGER
Electrocution. Initiate a system-wide shutdown and turn the
PWRcell DC Disconnect Switch OFF on all connected
batteries before performing service. Failure to do so will
result in death, serious injury, or equipment and property
damage.

8 Installation Manual for Generac PWRcell Inverter
General Information
This page intentionally left blank.

Location and Compliance
Installation Manual for Generac PWRcell Inverter 9
Section 3: Location and Compliance
Location
When installing the PWRcell inverter, consider the follow-
ing:
•The unit can be installed in indoor or outdoor loca-
tions.
•The inverter installation location must meet the
working space requirements in NEC Article 110.26.
Compliance
Follow all instructions included in this manual and use
appropriate practices for all product wiring and installa-
tion.
Note on DC Wiring and the NEC
Some electricians or installers may be unfamiliar with DC
wiring in a residential setting. Note the following:
•NEC 690.31(G) for DC PV circuits in buildings.
•NEC 215.12(C)(2) for correct DC wiring identifica-
tion.
Always adhere to applicable codes when marking and
installing DC conductors. See Table 3-1: REbus DC Wir-
ing Coloring Convention. Mark or flag all conductors as
appropriate.
•It is recommended that REbus (+) conductors NOT
be green, white, gray, blue, or black.
•It is recommended REbus (-) conductors NOT be
green, white, gray, or red.
Rapid Shutdown
The PWRcell Inverter is equipped with four DC discon-
nects to initiate the Photovoltaic Rapid Shutdown System
(PVRSS). Each disconnect switch can be used to initiate
Rapid Shutdown in compliance with NEC 690.12 for all
PV Link and SnapRS units connected to that disconnect.
NOTE: If an additional DC disconnect is added, ensure
the disconnect switch is rated for a minimum of 30
amperes, 450 volts.
To initiate the PVRSS:
•Open the inverter lid.
•Locate the four DC disconnects to the left of the
Generac Power Core.
•Turn all disconnects with connected PV sources to
the “off” position.
•PV Links will open all SnapRS devices within 30
seconds controlling all PV conductors within the
array to less than 80V, and all conductors leaving
the array to below 30V.
NOTE: Where the DC disconnect(s) in the inverter are
used as the Rapid Shutdown initiation device, proper
labeling is required for the exterior of the inverter lid to
indicate to first responders where to initiate Rapid Shut-
down.
(000190)
DANGER
Loss of life. Property damage. Installation must
always comply with applicable codes, standards, laws
and regulations. Failure to do so will result in death
or serious injury.
WARNING
Electrocution. Refer to local codes and standards for
safety equipment required when working with a live
electrical system. Failure to use required safety
equipment could result in death or serious injury.
(000257)
(000182a)
WARNING
Equipment damage. Only qualified service personnel may
install, operate, and maintain this equipment. Failure to
follow proper installation requirements could result in death,
serious injury, and equipment or property damage.
Table 3-1. REbus DC Wiring Coloring Convention
Wire Color
REbus + (RE+) Red
REbus - (RE-) Black
Ground (GND) Green

Location and Compliance
10 Installation Manual for Generac PWRcell Inverter
Voltage and Frequency Trip Thresholds
This unit or system is provided with fixed trip limits and
shall not be aggregated above 30 kW on a single point of
common connection.
All PWRcell inverters are shipped from the factory in
compliance with all UL1741 requirements, including
IEEE1547. If permission to operate (PTO) is dependent
on compliance to a specific utility standard, follow the
steps covered in Installer Configuration Tool section in
this manual.
Voltage Trip Thresholds
See Table 3-2 for the default fixed voltage trip setpoints.
All over voltage and under voltage trip conditions result in
a 300-second restart delay time after the trip threshold
has been exceeded for the listed number of cycles.
Frequency Trip Thresholds
See Table 3-2 for the default fixed frequency trip set-
points. All over frequency and under frequency trip condi-
tions result in a 300-second restart delay time after the
trip threshold has been exceeded for the listed number of
cycles.
*Value of 999 indicates a disabled threshold for voltage trips
**Value of zero indicates a disabled threshold for frequency trips
Table 3-2. Voltage Trip and Frequency Thresholds
Voltage Trip Thresholds Frequency Trip Thresholds
Threshold Threshold
(% of nominal) No. of Cycles Threshold Hz Over/ Under Nominal No. of Cycles
OV1 110 120 OF1 0.5 120
OV2 120 10 OF2 2 6
OV3 130 1 OF3 1.3 0
OV4 999* 1 OF4 0** 1
UV1 88 120 UF1 0.5 120
UV2 50 10 UF2 2 10
UV3 999* 1 UF3 0** 1
UV4 999* 1 UF4 0** 1

Installing PWRcell Inverter
Installation Manual for Generac PWRcell Inverter 11
Section 4: Installing PWRcell Inverter
PWRcell Inverter Dimensions and Mounting Clearances
Figure 4-1. PWRcell Inverter Dimensions and Mounting Clearances
Mounting Bracket Dimensions
Figure 4-2. Mounting Bracket Dimensions
4 in
(10.16 cm)
28 in
(71.15 cm)
8 in
(20.32 cm)
28-1/2 in
(72.4 cm)
36 in
(91.44 cm)
8 in
(20.32 cm)
19-1/4 in
(48.9 cm)
8-1/2 in
(21.6 cm)
20 in
(50.8 cm)
8 in
(20.32 cm )
24-1/2 in
(62.23 cm)
010508
16 in
(40.64 cm)
1-1/2 in
(3.81 cm)
2-3/8 in
(6.03 cm)
009990

Installing PWRcell Inverter
12 Installation Manual for Generac PWRcell Inverter
Mounting the Inverter
1. Verify mounting location adheres to the following
requirements:
•Location must meet all PWRcell inverter
requirements listed in Section 3 of this manual.See
Location and Compliance for more information.
•Inverter must be mounted upright on a vertical wall.
•Never obstruct intake or exhaust vents.
•Never allow water to enter intake or exhaust vents.
•Observe all mounting clearances. See PWRcell
Inverter Dimensions and Mounting Clearances.
2. Secure mounting bracket mounting surface
through mounting holes.
•Fasteners must adequately secure the 70.9 lbs
(32.1 kg) inverter weight to the wall.
•Fasteners must be suitable for the mounting
surface.
•Fasteners must engage at least two studs or other
structural members.
•Mounting bracket has clearance holes for 1/4”
fasteners with slots to accommodate different stud
spacings.
3. See Figure 4-3. Insert mounting bracket tabs (A)
into inverter body slot (B).
NOTE: Figure 4-3 is for illustration purposes only.
Figure 4-3. Mounting Inverter onto Bracket
4. See Figure 4-4. Secure the bottom of the inverter
to wall with two fasteners through mounting holes
(C). Holes are spaced at 11 1/4 in from each other.
Use anchors or blocking as needed.
Figure 4-4. Mounting Holes
(000641a)
CAUTION
Equipment damage. Mount inverter to a strong, stable surface.
Never mount to drywall, plaster, or other non-structural wall
treatments. Failure to mount inverter to a strong, stable surface
could result in equipment or property damage.
A
B
009991
C
011237

Electrical Connections
Installation Manual for Generac PWRCell Inverter 13
Section 5: Electrical Connections
PWRcell Inverter Wiring Compartment
Figure 5-1. PWRcell Inverter Wiring Compartment
Accessing Wiring Compartment
See Figure 5-2 . To access the wiring compartment:
1. Initiate an inverter shutdown.
2. Open all PWRcell DC disconnects (A). Verify DC
voltage reported on LCD screen has dropped to
below 10VDC.
3. Disconnect AC Grid source from inverter. Wait for
Inverter LCD screen to turn off.
4. Open inverter front cover by lifting the bottom to
horizontal (B) and pushing inward (C).
5. Locate wiring compartment cover (D).
6. Remove five M4X10 screws (E) and wiring
compartment cover.
7. Verify all PWRcell DC and AC terminals are below
10V, using a multi-meter.
APWRcell DC Disconnects ISTOP Terminals
BREbus Bi-directional DC Terminals JProtected Loads Disconnect
CInternet Connection KAC Grid Connection Terminals
DDC Main Fuses LProtected Loads Terminals
ECurrent Transformers (CTs) Accessory Ports MGrounding Bar
FAutomatic Transfer Switch (ATS) Accessory Port NGen Sense
GREbus Beacon Port OGen Start
HAuthorized Generac Personnel Only
BC
D
M
L
K
J
I
H
G
F
E
A
009993
NO
(000600)
DANGER
Electrocution. Initiate a system-wide shutdown and turn the
PWRcell DC Disconnect Switch OFF on all connected
batteries before performing service. Failure to do so will
result in death, serious injury, or equipment and property
damage.
(000642)
DANGER
Electrocution. Verify all system voltages are safe before
wiring. Disconnect all AC and DC sources of power before
touching terminals. Failure to ensure no dangerous
voltages are present on conductors and terminals before
wiring will result in death or serious injury.

Electrical Connections
14 Installation Manual for Generac PWRCell Inverter
Figure 5-2. Wiring Compartment
Knockout Dimensions and Locations
NOTE: All knockouts are combination knockouts.
See Figure 5-3 for knockout locations, sizes, and
quantities.
When using knockouts:
•Install reducing washers to accommodate smaller
conduit sizes.
•Install rain-tight or wet locations hubs in
compliance with UL514B.
Figure 5-3. Knockout Locations
C
010238
B
ED
A
Table 5-3. Combination Knockout Size and Quantity
Combination Knockout Size Quantity
3/4 in X 1 in 6
1/2 in X 3/4 in 7
5-1/2 in
140 mm
5-29/32 in
150 mm
2-5/8 in
67 mm
1-21/32 in
42 mm
1-31/32 in
50 mm
2-13/16 in
72 mm
2-7/32 in
56 mm
1-3/8 in
34 mm
1-1/16 in
27 mm
2-3/16 in
55 mm
1-15/16 in
49 mm
1-7/8 in
47 mm
1-13/16 in
46 mm
1/8 in
3.01 mm
1-5/8 in
41 mm
2-7/16 in
62 mm
2-3/16 in
56 mm
2-9/32 in
58 mm
1-13/32 in
36 mm
2-3/16 in
56 mm
2-3/16 in
56 mm
009995

Electrical Connections
Installation Manual for Generac PWRCell Inverter 15
Wiring Guidelines
•The inverter shall be installed in accordance with
NEC Article 705.
•Proper installation techniques must be employed to
restrain service loops and to separate AC, DC and
isolated circuits.
•All conductors must be rated for at least 420 V.
•Always use wiring methods in accordance with
National Electrical Code (ANSI/NFPA 70) or other
applicable codes.
•Field terminals are for copper conductors only.
•Do not use field wiring leads smaller than 18 AWG.
•All permanently installed conductors within the unit
are sized in compliance with NEC Table
310.15(B)(16) (formerly Table 310.16).
•Torque all terminals as specified in Table 5-4.
Grounding Bar Wiring
•Bond the inverter enclosure to the equipment
grounding conductor of the normal power source
power feeder.
•The grounding bar provides central grounding for
up to 8 conductors.
•Input and output circuits are isolated from the
enclosure.
•The neutral conductor is not bonded to the
equipment ground terminal bar within the
enclosure.
•The inverter and its connected PV and battery
sources are not separately derived systems.
•DC system grounding is critical for REbus
communications. REbus grounding wires are used
as communications wires. Ensure the following
REbus devices have a low resistance wired
connection back to the inverter grounding terminal
bar:
– PV Link
– PWRcell batteries
•Torque all terminals as specified in Table 5-5.
Table 5-4. Terminal Toques
Wiring Terminal Torque
AC terminals 13.3 to 15.9 in-lb (1.5 to 1.8 Nm)
DC terminals 12 in-lb (1.35 Nm)
Ground terminals 4 to 6 AWG: 45 in-lb (5 Nm)
8 AWG: 40 in-lb (4.5 Nm)
10 to 14 AWG: 35 in-lb (4 Nm)
STOP terminals 1.9 to 2.2 in-lb (0.22 to 0.25 Nm)
(000642)
DANGER
Electrocution. Verify all system voltages are safe before
wiring. Disconnect all AC and DC sources of power before
touching terminals. Failure to ensure no dangerous
voltages are present on conductors and terminals before
wiring will result in death or serious injury.
(000599)
Electrocution. Turn battery disconnect OFF and
de-energize REbus before touching terminals.
Failure to do so will result in death, serious injury,
equipment and property damage.
DANGER
Table 5-5. Grounding Bar Wiring Terminal
Specifications
Wire Size (AWG) Torque
4 – 6 45 in-lb (5 Nm)
8 40 in-lb (4.5 Nm)
10 30 in-lb (4 Nm)
(000607a)
Equipment damage. Never connect REbus conductors
to ground. Connecting REbus conductors to ground
could result in equipment or property damage.
CAUTION

Electrical Connections
16 Installation Manual for Generac PWRCell Inverter
DC Wiring
NOTE: Disable REbus before turning PWRcell DC
disconnects to ON position.
•Connect all REbus devices to the REbus bi-
directional DC terminals.
•Each terminal is protected by a 30 A two-pole
circuit disconnect.
•PWRcell DC disconnects indicate state and may
be used to disconnect DC circuits.
•PWRcell DC disconnects disconnect both
ungrounded DC conductors simultaneously.
•Torque all terminals as specified in Table 5-6.
AC Wiring
NOTE: The installer is responsible for providing sufficient
overcurrent protection for the AC grid wiring terminals.
The conductors and overcurrent protection device shall
be sized in accordance with NEC Article 705 for the utility
power connection. All other conductors shall be sized in
accordance with NEC Table 310.15 and all other
applicable NEC Articles.This system is equipped with a
power control system (PCS). The PCS controlled AC grid
conductors shall be protected with a suitably rated
overcurrent device appropriately sized for the conductor
ampacity.
•See Figure 5-4. The PWRcell inverter is equipped
with four AC grid connection terminals and three
protected loads terminals.
•Use the top four terminals (A) for connection to the
utility grid.
NOTE: Use L3 terminal (B) with 3-phase inverters only.
•Use the bottom three terminals (C) for protected
loads output. See Protected Load.
Figure 5-4. AC Wiring Terminals
(000686a)
DANGER
Electrocution. Never touch terminals when
inverter and PWRcell DC disconnects are ON.
Doing so will result in death or serious injury.
(000646)
Equipment damage. Obey polarity markings when
connecting REbus devices. Reverse-polarizing DC
circuits could result in equipment or property damage.
WARNING
(000645)
WARNING
Equipment damage. Do not connect raw, unregulated
battery output to inverter. Connect only REbus-compatible
batteries. Connecting batteries that are not REbus-
compatible could result in equipment or property damage.
Equipment damage. Do not connect PV string output
directly to inverter. PV must be connected via Generac
PWRcell PV Link. Connecting PV output directly to inverter
could result in equipment or property damage.
CAUTION
(000644a)
(000647a)
CAUTION
Equipment damage. Connect only one wire to each
DC wiring terminal. Doubling wires on a terminal
could result in equipment or property damage.
Equipment damage. Connect only to REbus-compatible
devices to the DC bus. Never connect to any other DC
power source. Connecting to other DC power sources
could result in equipment damage. (000598a)
CAUTION
Table 5-6. DC Wiring Terminal Specifications
Wire Size Terminal
Temp Range
Wire Min
Temp Rating Torque
18 – 6 AWG
(.75 – 10 mm)
-40 to 266ºF
(-40 to 130ºC)
194ºF
90ºC
12 in-lb
(1.35 Nm)
•Torque all terminals as specified in Table 5-7.
Table 5-7. AC Wiring Terminal Specifications
Wire Size 10 to 6 AWG
(2.08 mm2 to 16 mm2)
Terminal Temp Range Up to 248ºF (120ºC)
Wire Min Temp Rating 194ºF (90ºC)
Torque 13.3 in-lb to 15.9 in-lb
(1.5 Nm to 1.8 Nm)
C
009996
A
B
N1
L1
L2
N
Protcd.
L3
(3p)
L1
Protcd.
L2
Protcd.
