Generac Power Systems RV 45 SERIES User manual

Owner’s Manual
Air-cooled Recreational Vehicle Generators
RV 45, 55, and 65
Models: 005410-1, 005412-1
005414-1, 005751-0
005752-0, 005753-0
This manual should remain with the unit.

INTRODUCTION
READ THIS MANUAL THOROUGHLY
If any portion of this manual is not understood, contact the near-
est Authorized Service Dealer for starting, operating and servicing
procedures.
Throughout this publication, and on tags and decals affixed to the
generator, DANGER, WARNING, CAUTION and NOTE blocks are
used to alert personnel to special instructions about a particular
operation that may be hazardous if performed incorrectly or care-
lessly. Observe them carefully. Their definitions are as follows:
DANGER
After this heading, read instructions that, if not
strictly complied with, will result in personal injury,
including death, and property damage.
After this heading, read instructions that, if not
strictly complied with, may result in personal inju-
ry or property damage.
After this heading, read instructions that, if not
strictly complied with, could result in damage to
equipment and/or property.
NOTE:
After this heading, read explanatory statements that
require special emphasis.
These safety warnings cannot eliminate the hazards that they
indicate. Common sense and strict compliance with the special
instructions while performing the service are essential to prevent-
ing accidents.
Four commonly used safety symbols accompany the Danger,
Warning and Caution blocks. The type of information each indi-
cates follows:
This symbol points out important safety informa-
tion that, if not followed, could endanger per-
sonal safety and/or property of others.
This symbol points out potential explosion
hazard.
This symbol points out potential fire hazard.
This symbol points out potential electrical shock
hazard.
The operator (driver) is responsible for proper and safe use of the
vehicle and its equipment, and the safety of all vehicle occupants.
We strongly recommend that the operator read this manual and
thoroughly understand all instructions before using this equipment.
We also strongly recommend instructing other occupants in the
vehicle to properly start and operate the generator. This prepares
them if they need to operate the equipment in an emergency.
CONTENTS
This manual contains pertinent owner’s information, including
warranty, electrical diagrams, exploded views and lists of repair
parts. In addition, the latter portion of this manual contains infor-
mation necessary for the proper installation of these generators.
OPERATION AND MAINTENANCE
It is the operator's responsibility to perform all safety checks, to
make sure that all maintenance for safe operation is performed
promptly, and to have the equipment checked periodically by
an Authorized Service Dealer. Normal maintenance service and
replacement of parts are the responsibility of the owner/operator
and, as such, are not considered defects in materials or workman-
ship within the terms of the warranty. Individual operating habits
and usage contribute to the need for maintenance service.
Proper maintenance and care of the generator ensures a minimum
number of problems and keep operating expenses at a minimum.
See an Authorized Service Dealer for service aids and acces-
sories.
HOW TO OBTAIN SERVICE
When the generator requires servicing or repairs, simply contact
an Authorized Service Dealer for assistance. Service technicians
are factory-trained and are capable of handling all service needs.
When contacting an Authorized Service Dealer about parts and
service, always supply the complete model number and serial
number of the unit as given on its data decal, which is located on
the generator.
Model No. _________________ Serial No.______________
AUTHORIZED SERVICE
DEALER LOCATION
To locate the nearest AUTHORIZED SERVICE
DEALER, please call this number:
1-800-333-1322
ONLY DEALER LOCATION INFORMATION
CAN BE OBTAINED AT THIS NUMBER;
or locate us on the web at
www.guardiangenerators.com.

Table of Contents
Recreational Vehicle Generators
1
Part I — Operating Instructions
Introduction .................................Inside Front Cover
Read This Manual Thoroughly....................................... IFC
Contents ......................................................................... IFC
Operation and Maintenance .......................................... IFC
How to Obtain Service ................................................... IFC
Authorized Service Dealer Locator Number...................... IFC
Safety Rules ............................................................. 2
Section 1 – General Information ............................. 4
1.1 Generator Identification .............................................. 4
1.2 Generator Applicability ............................................... 5
1.3 Installation ................................................................... 5
1.4 Safety .......................................................................... 5
1.5 Generator AC Connection System............................. 5
1.6 Specifications.............................................................. 6
Section 2 – Operation .............................................. 7
2.1 Generator Control Panel............................................. 7
2.2 Optional Remote Start/Stop Panel ............................. 8
2.3 Automatic Choke ........................................................ 8
2.4 Before Starting the Engine ......................................... 8
2.5 Starting the Generator ................................................ 9
2.6 Stopping the Generator.............................................. 9
2.7 Applying Loads to Generator ................................... 10
2.8 Protection Systems................................................... 10
Section 3 – Maintenance........................................ 11
3.1 Checking the Engine Oil Level ................................. 11
3.2 Changing the Engine Oil and/or Oil Filter................ 11
3.3 Maintaining the Engine Air Cleaner.......................... 12
3.4 Checking the Engine Spark Plug ............................. 12
3.5 Fuel Filter (Gasoline Only)........................................ 13
3.6 Clean Spark Arrestor ................................................ 13
3.7 Cleaning the Generator ............................................ 13
3.8 Battery Maintenance ................................................. 13
3.9 Adjusting Valve Clearance........................................ 14
3.10 Major Service Manual ............................................... 15
3.11 Drive Belt................................................................... 15
3.12 Exercising the Generator .......................................... 15
3.13 Out of Service Procedure ......................................... 15
3.14 RV Generator Service Interval .................................. 15
Section 4 – Notes ................................................... 16
Part II — Installation Instructions
Safety Rules ........................................................... 18
Section 1 — General Information.......................... 20
1.1 Purpose and Scope of the Installation
Instructions................................................................ 20
1.2 Safety ........................................................................ 20
1.3 Standards Booklets .................................................. 20
1.4 Equipment Description ............................................. 20
1.5 Generator Engine Operating Speed ........................ 20
1.6 Generator AC Connection System........................... 20
Section 2 — Installation......................................... 22
Major Features and Dimensions .............................. 21
2.1 Location and Support ............................................... 22
2.2 Generator Compartments......................................... 23
2.3 Cooling and Ventilating Air ....................................... 25
2.4 Gasoline Fuel System............................................... 27
2.5 Exhaust System ........................................................ 27
2.6 Electrical Connections .............................................. 29
2.7 Battery Installation .................................................... 30
2.8 Optional Accessories................................................ 32
Section 3 — Post Installation ................................ 33
3.1 Post Installation Tests ............................................... 33
3.2 Before Initial Start-up ................................................ 33
3.3 Initial Start ................................................................. 33
3.4 Testing Under Load................................................... 33
3.5 Installation Checklist ................................................. 34
Section 4 – Troubleshooting.................................. 35
4.1 Troubleshooting Guide ............................................. 35
Section 5 – Notes ................................................... 36
Section 6 – Electrical Data..................................... 38
Section 7 – Exploded Views and Parts Lists ........ 40
Section 8 – Warranty.............................................. 52

2
Study these SAFETY RULES carefully before installing, operating
or servicing this equipment. Become familiar with this manual and
with the unit. The generator can operate safely, efficiently and reli-
ably only if it is properly installed, operated and maintained. Many
accidents are caused by failing to follow simple and fundamental
rules or precautions.
The manufacturer cannot anticipate every possible circumstance
that might involve a hazard. The warnings in this manual, and on
tags and decals affixed to the unit, are, therefore, not all-inclusive.
If using a procedure, work method or operating technique the
manufacturer does not specifically recommend, ensure that it is
safe for others. Also make sure the procedure, work method or
operating technique that chosen does not render the generator
unsafe.
DANGER
Despite the safe design of this generator,
operating this equipment imprudently, neglect-
ing its maintenance or being careless can cause
possible injury or death. Permit only responsible
and capable persons to operate or maintain this
equipment.
Potentially lethal voltages are generated by
these machines. Ensure all steps are taken to
render the machine safe before attempting to
work on the generator.
Parts of the generator are rotating and/or hot
during operation. Exercise care near running
generators.
GENERAL HAZARDS 
For safety reasons, the manufacturer recommends that the•
installation, initial start-up and maintenance of this equipment
is carried out by an Authorized Service Dealer.
The generator engine releases DEADLY carbon monoxide gas•
through its exhaust system. This dangerous gas, if breathed
in sufficient concentrations, can cause unconsciousness or
even death. Never operate the generator set with the vehicle
inside any garage or other enclosed area. DO NOT OPERATE
THE GENERATOR IF THE EXHAUST SYSTEM IS LEAKING OR
HAS BEEN DAMAGED. SYMPTOMS OF CARBON MONOXIDE
POISONING ARE (a) inability to think coherently, (b) nausea,
(c) vomiting, (d) twitching muscles, (e) throbbing temples,
(f) dizziness, (g) headaches, (h) weakness, and (i) sleepi-
ness. IF EXPERIENCING ANY OF THESE SYMPTOMS, MOVE
INTO FRESH AIR IMMEDIATELY. IF SYMPTOMS PERSIST, GET
MEDICAL HELP. Shut down the generator and do not operate it
until it has been inspected and repaired.
Never sleep in the vehicle while the genset is running unless the•
vehicle has a working carbon monoxide detector. The exhaust
system must be installed in accordance with the genset instal-
lation manual. Make sure there is ample fresh air when operat-
ing the genset in a confined area.
Keep hands, feet, clothing, etc., away from drive belts, fans,•
and other moving or hot parts. Never remove any drive belt or
fan guard while the unit is operating.
Adequate, unobstructed flow of cooling and ventilating air is•
critical to correct generator operation and is required to expel
toxic fumes and fuel vapors from the generator compartment.
Without sufficient cooling airflow, the engine/generator quickly
overheats, which causes serious damage to the generator. Do
not alter the installation or permit even partial blockage of ven-
tilation provisions, as this can seriously affect safe operation of
the generator.
When working on this equipment, remain alert at all times.•
Never work on the equipment when physically or mentally
fatigued.
Inspect the generator regularly, and contact the nearest•
Authorized Service Dealer immediately for parts needing repair
or replacement.
Before performing any maintenance on the generator, discon-•
nect its battery cables to prevent accidental start up. Disconnect
the cable from the battery post indicated by a NEGATIVE, NEG
or (–) first. Reconnect that cable last.
Never use the generator or any of its parts as a step. Stepping•
on the unit can stress and break parts, and may result in dan-
gerous operating conditions from leaking exhaust gases, fuel
leakage, oil leakage, etc.
Safety Rules
Recreational Vehicle Generators
SAVE THESE INSTRUCTIONS – The manufacturer suggests that these rules for safe operation be copied and posted in
potential hazard areas of the recreational vehicle. Safety should be stressed to all operators and potential operators of
this equipment.

The engine exhaust from this product•
contains chemicals known to the state
of California to cause cancer, birth
defects or other reproductive harm.
WARNING:

This product contains or emits chemicals•
known to the state of California to cause
cancer, birth defects or other reproductive harm.
WARNING:


3
ELECTRICAL HAZARDS 
The generator covered by this manual produces dangerous•
electrical voltages and can cause fatal electrical shock. Avoid
contact with bare wires, terminals, connections, etc., while the
unit is running. Ensure all appropriate covers, guards and bar-
riers are in place before operating the generator. If work must
be done around an operating unit, stand on an insulated, dry
surface to reduce shock hazard.
Do not handle any kind of electrical device while stand-•
ing in water, while barefoot, or while hands or feet are wet.
DANGEROUS ELECTRICAL SHOCK MAY RESULT.
During installation onto the vehicle, have the generator prop-•
erly grounded (bonded) either by solid mounting to the vehicle
frame or chassis, or by means of an approved bonding conduc-
tor. DO NOT disconnect the bonding conductor, if so equipped.
DO NOT reconnect the bonding conductor to any generator part
that might be removed or disassembled during routine mainte-
nance. If the grounding conductor must be replaced, use only a
flexible conductor that is of No. 8 American Wire Gauge (AWG)
copper wire minimum.
In case of accident caused by electric shock, immediately•
shut down the source of electrical power. If this is not pos-
sible, attempt to free the victim from the live conductor. AVOID
DIRECT CONTACT WITH THE VICTIM. Use a nonconducting
implement, such as a rope or board, to free the victim from the
live conductor. If the victim is unconscious, apply first aid and
get immediate medical help.
Never wear jewelry when working on this equipment. Jewelry•
can conduct electricity resulting in electric shock, or may get
caught in moving components causing injury.
FIRE HAZARDS 
For fire safety, the generator must be installed and maintained•
properly. Installation always must comply with applicable
codes, standards, laws and regulations. Adhere strictly to local,
state and national electrical and building codes. Comply with
regulations the Occupational Safety and Health Administration
(OSHA) has established. Also, ensure that the generator is
installed in accordance with the manufacturer’s instructions
and recommendations. Following proper installation, do noth-
ing that might alter a safe installation and render the unit in
noncompliance with the aforementioned codes, standards,
laws and regulations.
Keep a fire extinguisher in the vehicle at all times. Extinguishers•
rated “ABC” by the National Fire Protection Association are
appropriate for use on the recreational vehicle generator elec-
trical system. Keep the extinguisher properly charged and be
familiar with its use. If there are any questions pertaining to fire
extinguishers, consult the local fire department.
EXPLOSION HAZARDS 
Do not smoke around the generator. Wipe up any fuel or oil•
spills immediately. Ensure that no combustible materials are left
in the generator compartment, or on or near the generator, as
FIRE or EXPLOSION may result. Keep the area surrounding the
generator clean and free from debris.
Gasoline is extremely FLAMMABLE and its vapors are•
EXPLOSIVE. Do not permit smoking, open flame, sparks or any
source of heat in the vicinity while handling gasoline. Comply
with all laws governing the storage and handling of gasoline.
This generator may use liquid propane (LP) gas as a fuel. LP•
gas is highly EXPLOSIVE. The gas is heavier than air and tends
to settle in low areas where even the slightest spark can ignite
the gas and cause an explosion.
Safety Rules
Recreational Vehicle Generators

4
Section 1 – General Information
Recreational Vehicle Generators
Please record the following information from the generator DATA DECAL or information decal.
1. Model Number _____________________ 2. Serial Number__________________
3. kW Rating _________________________ 4. Rated Voltage __________________
5. Phase _____________________________ 6. Hertz __________________________
1
2
345
815
13
1614
6
79, 17 10
12 1110, 17
18
1.1 GENERATOR IDENTIFICATION
REFERENCE NUMBER IDENTIFICATION
1. Generator Air Intake
2. Data Plate
3. Engine Start/Stop Switch
4. 7.5 amp Fuse
5. Circuit Breaker
6. Optional Remote Panel Receptacle
7. Generator AC Output Leads
8. Starter Contactor
9. Fuel Inlet
10. Fuel Pump
11. Oil Filter
12. Oil Drain Plug
13. Oil Dipstick and Filler Tube
14. Air Filter (Behind access panel.)
15. Spark Plugs
16. Exhaust Outlet
17. Fuel Filter
18. Evaporative Port

5
Section 1 – General Information
Recreational Vehicle Generators
1.2 GENERATOR APPLICABILITY
These generators have been designed and manufactured for sup-
plying electrical power for recreational vehicles. DO NOT modify
the generator or use it for any application other than for what it
was designed. If there are any questions pertaining to its applica-
tion, write or call the factory. Do not use the unit until advised by
competent authority.
DANGER
For fire safety, the generator must have been
properly installed in compliance with ANSI
119.2-1975/NFPA 501C-1974, “Standard for
Recreational Vehicles, Part III – Installation of
Electrical Systems.” The generator also must
have been installed in strict compliance with the
manufacturer’s detailed installation instructions.
After installation, do nothing that might render
the unit in noncompliance with such codes,
standards and instructions.
Use the generator set to supply electrical power for operating one
of the following electrical loads:
RV 45 G & LP: 120 and/or 240 volts, single phase, 60 Hz elec-•
trical loads. These loads can require up to 4500 watts (4.5 kW)
of total power, but cannot exceed 37.5 AC amperes of current
at 120 volts or exceed 18.7 AC amperes at 240 volts.
RV 55 G & LP: 120 and/or 240 volts, single phase, 60 Hz elec-•
trical loads. These loads can require up to 5500 watts (5.5 kW)
of total power, but cannot exceed 45.8 AC amperes of current
at 120 volts or exceed 22.9 AC amperes at 240 volts.
RV 65 G & LP: 120 and/or 240 volts, single phase, 60 Hz elec-•
trical loads. These loads can require up to 6500 watts (6.5 kW)
of total power, but cannot exceed 54.1 AC amperes of current
at 120 volts or exceed 27 AC amperes at 240 volts.
Do not overload the generator. Some installa-
tions may require that electrical loads be alter-
nated to avoid overloading. Applying excessive-
ly high electrical loads may damage the genera-
tor and may shorten its life. Add up the rated
watts of all electrical lighting, appliance, tool
and motor loads the generator will power at one
time. This total should not be greater than the
wattage capacity of the generator. If an electri-
cal device nameplate gives only volts and amps,
multiply volts times amps to obtain watts (volts
x amps = watts). Some electric motors require
more watts of power (or amps of current) for
starting than for continuous operation.
1.3 INSTALLATION
This Owner’s Manual has been prepared under the assumption
that a competent, qualified technician installed the generator into
a recreational vehicle. We also assume the installer complied
with all applicable codes, standards and regulations pertaining to
installation.
An INSTALLATION MANUAL was shipped with the generator. That
Manual contains manufacturer’s instructions and recommenda-
tions for installing the unit into an industrial vehicle. After installa-
tion, installers should forward the Installation Manual to Owners/
Operators for their information.
Owners/Operators have the responsibility to make sure that noth-
ing is done that might render the installation unsafe or in non-
compliance with applicable codes, standards and instructions.
1.4 SAFETY
Before using the generator set, carefully read GENERAL SAFETY
RULES inside the cover. Comply with these RULES to prevent
accidents and damage to equipment and/or property. The manu-
facturer suggests copying and posting the GENERAL SAFETY
RULES to potential operators of this equipment.
1.5 GENERATOR AC CONNECTION
SYSTEM
These air-cooled generator sets are equipped with dual stator
AC power windings. These two stator windings supply electrical
power to customer electrical loads by means of a dual 2-wire
connection system.
Generators may be installed to provide the following outputs:
1. 120 VAC loads only — two loads, each with a maximum
total wattage requirement equal to half of the generator’s
rated power output (in watts), and 120V across the generator
output terminals. Figure 1.1 shows the generator lead wire
connections for 120VAC ONLY.
Figure 1.1 – Connection for 120 Volts Only

6
Section 1 – General Information
Recreational Vehicle Generators
2. 120/240 VAC loads — one load with a maximum total watt-
age requirement equal to the generator’s rated power output,
and 240V across the generator output terminals; or two sepa-
rate loads, each with a maximum total wattage requirement
equal to half of the generator’s rated power output (in watts),
and 120V across the generator output terminals. Figure 1.2,
shows the generator lead wire connections for 120/240 VAC
loads. Also refer to the "Line Breakers" section for circuit
breaker ratings.
This procedure should be done by an Authorized Service Dealer or
other qualified installer.
Figure 1.2 - Connection for 120/240 Volts
T1
RED
T2
WHITE
T3
BLACK
GROUNDED NEUTRAL
STATOR POWER
WINDINGS
CB1
CB2
1.6 SPECIFICATIONS
1.6.1 FUEL REQUIREMENTS (GASOLINE)
This generator is equipped with a gasoline fuel system as standard
equipment. Specific installations may provide either a separate fuel
tank for the generator, or the generator may “share” the vehicle
engine’s fuel tank.
1.6.1.1 Fuel Consumption (gph)
Model 10% Load 50% Load 100% Load
RV45G .33 .45 .73
RV55G .35 .55 .89
RV65G .37 .65 .97
NOTE
Some installations using a “shared” fuel tank may
have a generator fuel pickup tube that is shorter than
the vehicle engine’s pickup tube. Such an arrange-
ment causes the generator engine to “run out of gas”
while adequate fuel for the vehicle remains in the
tank.
To reduce lead and carbon deposits use high quality UNLEADED
gasoline with the generator. Leaded REGULAR grade gasoline is an
acceptable substitute.
NOTE:
Using unleaded gasoline contributes to longer engine
valve life by reducing lead and carbon deposits.
The manufacturer does not recommend using
any gasoline containing alcohol (such as “gaso-
hol”). If using any gasoline containing alcohol, it
must not contain more than 10 percent ethanol
(Do not use E85), and it must be removed from
the generator during storage. Do NOT use any
gasoline containing methanol. If using gasoline
with alcohol, inspect more frequently for fuel
leaks and other abnormalities.
1.6.2 ENGINE OIL REQUIREMENTS
All oil should meet minimum American Petroleum Institute (API)
Service Class SJ, SL or better. Use no special additives. Select the
oil's viscosity grade according to the expected operating tempera-
ture (also see chart).
SAE 30• ÎAbove 32° F
10W-30• ÎBetween 40° F and -10° F
Synthetic 5W-30• Î10° F and below
SAE 30
SAE 3 0
Synthetic 5W-30
Synthetic 5W-30
10W-30
10W-30
Crankcase and oil filter capacity is approximately 1.4 L or 1.5 U.S.
quarts. DO NOT use special additives. See sections "Checking the
Engine Oil Level" and "Changing the Engine Oil and/or Oil Filter" for
oil level check and filling procedures.

7
Section 2 – Operation
Recreational Vehicle Generators
1.6.4 ENGINE SPECIFICATIONS
Type of Engine ........................................................................GT-530
Cooling Method ................................................................ Air-cooled
Rated Horsepower ...................................................18 at 3600 rpm
Displacement ........................................................................... 530cc
Compression Ratio................................................................8.5 to 1
Cylinder Block.................................. Aluminum w/Cast Iron Sleeve
Type of Governor ....................................... Electronic, Fixed Speed
Engine Governor Speed ................................................... 2571 rpm
Air Cleaner................................................................. Paper Element
Starter .................................................................. 12-volt DC Electric
Ignition System ............................ Solid-state w/Flywheel Magneto
Recommended Spark Plug
NGK ....................................................................................BPR6HS
Spark Plug Gap ............................................. 0.030 inch (0.76 mm)
Recommended Min. Battery.................. 400 Cold Cranking Amps
Class II Emission Certified
2.1 GENERATOR CONTROL PANEL
The following features are mounted on the generator control panel
(Figure 2.1):
2.1.1 START/STOP SWITCH
This generator is started with a "One Touch" starting sequence.
Push up on the top half of the momentary switch. Hold for one
(1) second and release. Note flashing indicator light on the switch.
Fuel pump engages automatically for a three (3) to five (5) second
delay before starter motor cranks the engine for 16 seconds or
until the engine starts. If the engine does not start, the starter
will cool for seven (7) seconds and crank the engine again for 16
seconds. If the engine does not start, the starter will cool for seven
(7) seconds before cranking for seven (7) seconds to a maximum
cycle total of 90 seconds. Once started, the light on the switch
stays on continuously. If the generator does not start at the end
of the start sequence, a fault code will flash on the switch (see
Diagnostics).
The switch center position is the RUN position.
To stop a running engine, press momentarily the bottom half of the
switch to kill the ignition.
Figure 2.1 – Typical Control Panel
Indicator Light
TO START GENERATOR:
Push up oncontrol switch. Hold for 1 second
and release. Note flashing indicator.
Generator will start automatically.
TO STOP GENERATOR:
Push down then release control switch.
Generator will shut down.
DIAGNOSTICS:
If the generator shuts down due to a fault, the
indicator will flash a code to identify the
problem. See chart to the right.
2 FLASHES = LOW BATTERY
3 FLASHES = OVERCRANK
4 FLASHES = OVERSPEED
5 FLASHES = LOW OIL PRES.
6 FLASHES = HIGH OIL TEMP.
7 FLASHES = UNDERSPEED
1.6.3GENERATOR SPECIFICATIONS
SERIES RV45G RV55G RV65G
Rotor RPM 3600 3600 3600
Rotor Poles 2 2 2
Engine RPM 2571 2571 2571
Rated Max. Continuous AC Output Watts* 4500 5500 6500
Voltage* 120 120 120
Rated Max. Continuous Current Amps (240V) 37.5 (18.7) 45.8 (22.9) 54.1 (27)
Phase 1 1 1
Frequency 60 Hertz 60 Hertz 60 Hertz
Weight 278 lbs. 285 lbs. 293 lbs.
Length 33.7 in. 33.7 in. 33.7 in.
Width 21.5 in. 21.5 in. 21.5 in.
Height 16.8 in. 16.8 in. 16.8 in.
* All units are re-connectable to 120 and/or 240 volts, dual voltage output. Units are not listed per RVIA/ANSI when reconnected for dual voltage output
** Maximum wattage and current are subject to, and limited by, such factors as fuel Btu content, ambient temperature, altitude, engine condition, etc.. Maximum power
decreases about 3.5% for each 1,000 feet above sea level; and will also decrease about 1% for each 6° C (10° F) above 16° C (60° F) ambient temperature.

8
Section 2 – Operation
Recreational Vehicle Generators
2.1.2 7.5 AMP FUSE
The fuse protects the engine’s DC control circuit against electrical
overload. If the fuse element has melted open due to overloading,
the engine cannot be cranked. If the fuse must be replaced, use
only an identical 7.5 amp replacement fuse.
2.1.3 LINE BREAKERS
Protects generator’s AC output circuit against overload, i.e., pre-
vents unit from exceeding wattage/amperage capacity. The circuit
breaker ratings are as follows:
Model Cir. Breaker 1 Cir. Breaker 2 240 Volt
RV45 20A 20A 20A 2P
RV55 20A 30A 25A 2P
RV65 30A 30A 30A 2P
NOTE:
If this generator has been reconnected for dual volt-
age AC output (120/240 volts), install line breakers
having an amperage rating equal to that stated in the
preceding chart. The replacement line breakers con-
sist of two separate breakers with a connecting piece
between the breaker handles (so that both breakers
will operate at the same time). If the unit is recon-
nected for dual voltage, it is no longer RVIA listed.
2.1.4 DIAGNOSTICS
If the generator shuts down due to a fault, the indicator will flash a
code to identify the problem.
2 Flashes = Low Battery (Voltage falls below 11.0 VDC for one•
minute)
NOTE:
Alarm will clear automatically if voltage rises over
11.0 VDC. Battery voltage is not monitored during
crank cycle.
3 Flashes = Overcrank (Unit does not start through entire start•
cycle)
4 Flashes = Overspeed (Alternator spins at 4200 rpm/72 Hz•
or greater)
5 Flashes = Low Oil Pressure (Drops below the 5 psi threshold•
of the switch)
NOTE:
There is a five second delay of the alarm when the
engine is first started up.
6 Flashes = High Oil Temperature (Unit shuts down when tem-•
perature switch limit is reached)
NOTE:
As the unit cools down it will attempt to restart auto-
matically when the temperature switch opens again.
7 Flashes = Underspeed (Alternator spins less than 3240•
rpm/54 Hz for three (3) seconds)
NOTE:
After a fault is indicated, press stop momentarily to
clear the alarm once the problem is fixed.
2.2 OPTIONAL REMOTE
START/STOP PANEL
A remote mounted Start/Stop Panel is available that allows start-
ing and stopping the generator engine conveniently from inside the
vehicle. The remote panel includes a Start/Stop switch, hourmeter,
generator run lamp, and a wire harness.
2.3 AUTOMATIC CHOKE
This engine is equipped with an automatic choke that consists of
two main components: a choke solenoid and prechoke (Gasoline
only.).
2.3.1 CHOKE SOLENOID
During engine cranking (Start/Stop switch at START), a solid-state
choke module signals the choke solenoid to activate and cycle
(choke on/choke off) until the engine starts. The choke solenoid
thus opens and closes the carburetor choke valve only when
the engine is cranking. When the engine starts, the choke stops
cycling (Gasoline only.).
2.3.2 PRECHOKE
The choke system also has a temperature-sensitive metal strip that
adjusts choke valve angle according to ambient temperatures (i.e.,
in cold ambient temperatures, choke valve closes more). Once the
engine starts, an element heats the temperature-sensitive strip to
a normal operating condition, opening the choke valve. This may
take about three minutes in cooler weather (Gasoline only.).
2.4 BEFORE STARTING THE
ENGINE
NOTE:
Instructions and information in this manual assume
the generator has been properly installed, con-
nected, serviced, tested and adjusted by a qualified
installation technician or installation contractor.
2.4.1 INSTALLATION
Generator installation must have been properly completed so it
complies with all applicable codes, standards and regulations
and with the manufacturer's recommendations. (See Part II -
Installation Instructions.)

9
Section 2 – Operation
Recreational Vehicle Generators
2.4.2 ENGINE LUBRICATION
Have the engine crankcase properly serviced with the recommend-
ed oil before starting. Refer to sections "Engine Specifications",
"Checking the Engine Oil Level" and "Changing the Engine Oil and/
or Oil Filter" for oil servicing procedures and recommendations.
Any attempt to crank or start the engine before
it has been properly serviced it with the recom-
mended oil may result in an engine failure.
2.4.3 FUEL SUPPLY
The engine must have an adequate supply of proper fuel to oper-
ate. Before starting it, check that sufficient fuel is available.
NOTE:
Depending on the installation, the generator may
have either a separate fuel tank, or it may “share” the
vehicle engine’s fuel tank.
2.4.4 COOLING AND VENTILATING AIR
Air inlet and outlet openings in the generator compartment must
be open and unobstructed for continued proper operation. Without
sufficient cooling and ventilating airflow, the engine/generator
quickly overheats, which causes it to shut down and may damage
the generator.
2.4.5 ENGINE EXHAUST GAS
Before starting the generator engine, be sure there is no way for
exhaust gases to enter the vehicle interior and endanger people or
animals. Close windows, doors and other openings in the vehicle
that, if open, might permit exhaust gases to enter the vehicle.
DANGER
The generator engine releases DEADLY carbon
monoxide gas through its exhaust system. This
dangerous gas, if breathed in sufficient concen-
trations, can cause unconsciousness or even
death. Never operate the generator set with the
vehicle inside any garage or other enclosed
area. DO NOT OPERATE THE GENERATOR IF
THE EXHAUST SYSTEM IS LEAKING OR HAS
BEEN DAMAGED. SYMPTOMS OF CARBON
MONOXIDE POISONING ARE (a) inability to
think coherently, (b) nausea, (c) vomiting, (d)
twitching muscles, (e) throbbing temples, (f)
dizziness, (g) headaches, (h) weakness, and
(i) sleepiness. IF EXPERIENCING ANY OF
THESE SYMPTOMS, MOVE INTO FRESH AIR
IMMEDIATELY. IF SYMPTOMS PERSIST, GET
MEDICAL HELP. Shut down the generator and
do not operate it until it has been inspected and
repaired.
DANGER
Never sleep in the vehicle while the genset is
running unless the vehicle has a working carbon
monoxide detector. The exhaust system must be
installed in accordance with the genset installa-
tion manual. Make sure there is ample fresh air
when operating the genset in a confined area.
2.5 STARTING THE GENERATOR
NOTE:
Read the vehicle manufacturer’s instructions. The
owner/operator should become familiar with the vehi-
cle in which this generator is installed. Differences
exist between vehicles. For example, some vehicles
may use a transfer switch to isolate dockside power
from the generator, while other vehicles may use an
isolating receptacle. Some vehicles may be equipped
with a DC converter which allows the generator to
power certain DC lighting and other DC loads.
To crank and start the generator engine, proceed as follows:
1. Turn OFF electrical loads using the means provided in the
vehicle (such as a main line circuit breaker or transfer
switch).
NOTE:
If starting from the generator control panel, turn OFF
loads by setting the generator’s main circuit breaker
to the OFF (or open) position. If starting from a
remote panel, turn OFF loads using the means pro-
vided in the vehicle (such as a main circuit breaker).
Electrical load circuits should be turned ON after the
generator has started, stabilized and warmed up.
2. To crank and start the engine, push up on the Start/Stop
switch momentarily and release. There is a delay as the fuel
pump primes and the generator automatically begins the start
sequence (Note the flashing light on the switch.).
3. Let the engine run at no-load for a few minutes to stabilize and
warm up.
4. Turn ON electrical loads using the means provided (such as a
main circuit breaker or transfer switch).
2.6 STOPPING THE GENERATOR
1. Turn OFF all electrical loads using the means provided (such
as a main circuit breaker or transfer switch).
2. Let generator run at no-load for a few minutes, to stabilize
internal engine generator temperatures.
3. Place the Start/Stop switch in its STOP position. The engine
will come to a complete stop.

10
Section 2 – Operation
Recreational Vehicle Generators
2.7 APPLYING LOADS TO
GENERATOR
When applying electrical loads to the generator, observe these
guidelines:
Before applying electrical loads, let the generator stabilize and•
warm up for a minute or two.
DO NOT overload the generator.•
2.7.1 LETTING THE ENGINE STABILIZE
The generator supplies correct rated voltage only at the proper
governed speed. Some electrical appliances may be extremely
sensitive to voltage. Incorrect voltages can damage such appli-
ances.
If electrical loads are applied at reduced operating speeds, such
loads imposed on the engine when sufficient power is not available
may shorten engine life. Never turn ON electrical loads until after
the generator engine has started and stabilized at no-load.
2.7.2 DO NOT OVERLOAD THE GENERATOR
Read the rated wattage/amperage capacity of the generator on the
generator data label (See the "Generator Identification" section.).
Applying electrical loads in excess of the unit’s rated capacity will
cause the engine/generator to automatically shut down.
To avoid overloading, add up the wattage of all connected electrical
lighting, appliance, tool and motor loads. This total should not be
greater than the generator’s rated wattage capacity.
Most lighting, appliance, tool and motor loads indicate their•
required watts on their nameplate or data plate. For light bulbs,
simply note the wattage rating of the bulb.
If a load does not show its rated wattage, multiply that load’s•
rated VOLTS times AMPS to obtain WATTS.
Induction type motors (such as those that run the vehicle’s•
furnace fan, refrigerator, air conditioner, etc.) need about 2-1/2
times more watts of power for starting than for running (for a
few seconds during motor starting). Be sure to allow for this
when connecting electrical loads to the generator. First, figure
the watts needed to start electric motors in the system. To that
figure, add the running wattages of other items that will be oper-
ated by the generator.
Do not apply heavy electrical loads for the first two or three•
hours of operation.
2.8 PROTECTION SYSTEMS
2.8.1 LOW OIL PRESSURE SWITCH
This switch (Figure 2.2) has normally closed (N.C.) contacts that
are held open by engine oil pressure during cranking and operat-
ing. Should oil pressure drop below a preset level, switch contacts
close, and the engine automatically shuts down. The unit should
not be restarted until oil is added.
2.8.2 HIGH TEMPERATURE SWITCH
This switch (Figure 2.2), which has normally open (N.O.) contacts,
is mounted near the oil filter. The contacts close if the temperature
should exceed approximately 270º F (132º C) for gasoline mod-
els.
Figure 2.2 – Low Oil Pressure and
High Temperature Switches
2.8.3 FIELD BOOST
The Controller Circuit Board houses a field boost diode and resistor
that are not part of the automatic choke circuit. These two compo-
nents are part of a “field boost” circuit (Figure 2.3). During engine
cranking only, a positive DC (battery) voltage is delivered through
a diode, resistor, brushes, slip rings, and the generator rotor.
Application of this voltage to the rotor “flashes the field” whenever
it is started. Flashing of the field each time the generator starts
makes sure that a sufficiently strong magnetic field is available to
produce “pickup” voltage in the stator windings.
Figure 2.3 – Field Boost Circuit

11
Section 3 – Maintenance
Recreational Vehicle Generators
2.8.4 OVERVOLTAGE PROTECTION
A solid-state voltage regulator (Figure 2.4) controls the generator’s
AC output voltage. This regulator supplies an excitation current to
the rotor. By regulating the rotor’s excitation current, the strength
of its magnetic field is regulated and, in turn, the voltage delivered
to connected electrical loads is controlled. When the AC frequency
is 60 Hertz, voltage is regulated at 125 to 120 volts.
Figure 2.4 – Solid State Voltage Regulator
2.8.5 OPERATION IN HIGH GRASS
OR BRUSH
Never operate the generator while the vehicle is
parked over high grass, weeds, brush, leaves or
any other combustible substance. Such mate-
rials can ignite and burn from the heat of the
exhaust system. The generator exhaust system
becomes extremely hot during operation and
remains hot for a long time after it has shut
down.
3.1 CHECKING THE ENGINE OIL
LEVEL
For oil capacities and requirements, see the “Engine Oil
Requirements” section. Check the engine crankcase oil level at
least every eight hours of operation, or before it is used. To check
the engine oil level, proceed as follows (see Figure 3.1):
1. Be sure the generator is as level as possible.
2. Remove the dipstick and wipe it dry with a clean, lint-free
cloth.
3. Install and tighten the dipstick cap; then, remove it again. The
oil level should be at the dipstick “Full” mark.
4. If necessary, remove the oil fill cap on the rocker cover and
slowly add oil until it reaches the dipstick “Full” mark. DO NOT
FILL ABOVE THE “FULL” MARK.
Never operate the engine with the oil level
below the “Add” mark on the dipstick. Doing this
could damage the engine.
5. Install and tighten the oil fill cap and the dipstick before oper-
ating the engine.
Figure 3.1 — Oil Dipstick/Fill Tube and
Location of Oil Drain Plug
Oil DipstickOil Drain HoseOil Fill
3.2 CHANGING THE ENGINE OIL
AND/OR OIL FILTER
Oil Change Intervals – see Section “RV Generator Service
Interval”.
To change the oil and oil filter, proceed as follows:
1. Run the engine until it is thoroughly warmed up (at least five
minutes) then shut off the engine.
2. With the engine still warm from running, remove the round
access grommet from underneath the front of the generator.
Place a suitable container underneath to catch all the drain
oil.
3. Use the 0G4818 tool (supplied with the generator) to turn the
old filter counter-clockwise and remove. Let oil drain into the
container located directly below.
4. Locate the oil drain hose inside and pull the yellow drain plug
out of the access hole (Figure 3.1).
5. Turn the yellow cap counter-clockwise to remove and finish
draining the old oil.
6. After the oil has been drained, replace the oil drain plug by
tightening it clockwise and return.
7. Clean off the oil filter bracket and any old oil that may have
spilled while draining.
8. Apply a light coating of clean engine oil the gasket of the new
oil filter (Figure 3.2).
9. Screw the new oil filter on by hand until its gasket lightly con-
tacts the oil filter adapter. Then, tighten the filter an additional
¾ to one turn. Replace and secure the round access grom-
met.

12
Section 3 – Maintenance
Recreational Vehicle Generators
Figure 3.2 — Engine Oil Filter
Engine
Oil Filter
Twist Counter-clockwise to Loosen
10. Remove the dipstick, valve cover plug and add new oil (see
“Engine Oil Requirements”) to engine. DO NOT FILL ABOVE
THE “FULL” MARK.
11. Install and tighten plug and dipstick before starting the
engine.
12. Start engine and check for leaks.
NOTE:
Check the oil level and fill to the “FULL” mark after
checking for leaks. The filter will retain some oil.
3.3 MAINTAINING THE ENGINE
AIR CLEANER
Replace the paper air filter element after every 200 hours of opera-
tion. (Perform more often when operating in dusty conditions)
1. At the Air Cleaner Cover, turn the yellow plastic knob ¼ turn
counter-clockwise.
2. Pull the top of the Cover out as it hinges on the bottom of the
Air Cleaner Base.
3. Separate the Cover by lifting up and out from the Base.
4. Pull the old filter out and discard safely.
5. Install the new filter in place on the Air Cleaner Base (Figure
3.3).
6. Interlock the Air Cleaner Cover to hinge with the Air Cleaner
Base.
7. Align the Cover and gently push the top closed.
8. Engage the yellow plastic knob and turn ¼ turn clockwise to
secure.
Figure 3.3 – Engine Air Cleaner
Air Cleaner Base
Air Cleaner
Air Cleaner Cover
Knob
3.4 CHECKING THE ENGINE
SPARK PLUG
Reset the spark plug gap or replace the spark plugs as necessary.
See the Service Schedule section for maintenance requirements.
1. Clean the area around the base of the spark plugs to keep dirt
and debris out of the engine.
2. Remove the spark plugs and check the condition. Replace the
spark plugs if worn or if reuse is questionable. See the Service
Schedule section for recommended interval. Clean by scrap-
ing or washing using a wire brush and commercial solvent.
Do not blast the spark plugs to clean.
3. Check the spark plug gap using a wire feeler gauge. Adjust the
gap to 0.76mm (0.030 inch) by carefully bending the ground
electrode if necessary (Figure 3.4).
Figure 3.4 – Setting the Spark Plug Gap
Sparking can occur if the wire terminal does
not fit firmly on the spark plug terminal end. If
necessary, re-form the wire terminal to obtain a
tight fit.
SET PLUG GAP AT 0.030 in.
(.076 MM)

Section 3 – Maintenance
Recreational Vehicle Generators
3.5 FUEL FILTER (GASOLINE ONLY)
Remove and replace the fuel filter (Figure 3.5) every 400 hours of
operation.
Figure 3.5 – Fuel Filter
3.6 CLEAN SPARK ARRESTOR
The engine exhaust muffler has a spark arrestor screen. Inspect and
clean the screen every 200 hours of operation or once each year,
whichever comes first.
NOTE:
If using the generator on any forest-covered, brush-
covered or grass-covered unimproved land, it must
equipped with a spark arrestor. The spark arrestor
must be maintained in good condition by the owner/
operator.
Clean and inspect the spark arrestor as follows:
Remove the screen by removing the screw.•
Slide the spark arrestor screen out from the tail pipe.•
Inspect screen and replace if torn, perforated or otherwise•
damaged. DO NOT USE a defective screen. If screen is not
damaged, clean it with commercial solvent.
Replace the screen and the screw.•
Figure 3.6 - Spark Arrestor
RETAINING
SCREW P/N 056892
SPARK ARRRESTOR
SCREEN P/N 089680
TAILPIPE
P/N 0G5857
3.7 CLEANING THE GENERATOR
Keep the generator set as clean and dry as possible. Protect the
unit against excessive dust, dirt, corrosive vapors, road splash,
etc. Permitting dirt and moisture to accumulate on generator
windings will have an adverse effect on the insulation resistance
of those windings.
When moisture is allowed to remain in contact with windings,
some of the moisture will be retained in voids and cracks in the
insulation. This causes a reduced insulation resistance and will
eventually cause problems. Dirt will make the problem worse,
since dirt tends to hold moisture in contact with windings. Salt (as
from sea air) also will worsen the problem since it tends to absorb
moisture from the air. Salt and moisture, when combined, form a
good electrical conductor which is detrimental to the generator.
Do NOT use a forceful spray of water to clean
the generator. Water will enter the generator
interior and cause problems, and may also con-
taminate the generator fuel system.
3.8 BATTERY MAINTENANCE
NOTE:
This generator is not equipped with an internal bat-
tery charger. It is intended for use in systems where
an external battery charger is installed by the RV
O.E.M. or an aftermarket installer.
All lead-acid batteries will discharge when not in use. The generator
battery should be inspected as follows:
3.8.1 WEEKLY
Inspect the battery posts and cables for tightness and corro-•
sion. Tighten and clean as necessary.
Check the battery fluid level of unsealed batteries and, if nec-•
essary, fill with Distilled Water Only. Do not use tap water in
batteries.
3.8.2 EVERY SIX MONTHS
Have the state of charge and condition checked. This should be•
done with an automotive-type battery hydrometer.
NOTE:
Servicing of the battery is to be performed or super-
vised by personnel knowledgeable of batteries and
the required precautions. Keep unauthorized person-
nel away from batteries.
Damage will result if the battery connections are
made in reverse.
13
TO FUEL PUMP
CUSTOMER FUEL CONNECTION
FUEL FILTER

14
DANGER
Do not dispose of the battery in a fire. The
battery is capable of exploding. Storage batter-
ies give off explosive hydrogen gas. This gas
can form an explosive mixture around the bat-
tery for several hours after charging. The slight-
est spark can ignite the gas and cause an explo-
sion. Such an explosion can shatter the battery
and cause blindness or other injury. Any area
that houses a storage battery must be properly
ventilated. Do not allow smoking, open flame,
sparks, or any spark producing tools or equip-
ment near the battery. Discharge static electric-
ity from body before touching the battery by first
touching a grounded metal surface.
A battery presents a risk of electrical shock
and high short circuit current. The following pre-
cautions are to be observed when working on
batteries:
• Remove watches, rings or other metal objects;
• Use tools with insulated handles;
• Wear rubber gloves and boots;
• Do not lay tools or metal parts on top of the
battery;
• Disconnect any charging source prior to connecting
or disconnecting battery terminals; and
• Do not use any jumper cables or booster battery to
crank and start the generator engine. If any battery
has discharged, remove it for recharging.
Do not open or mutilate the battery. Released
electrolyte has been known to be harmful to the
skin and eyes, and to be toxic.
The electrolyte is a dilute sulfuric acid that is
harmful to the skin and eyes. It is electrically
conductive and corrosive. The following
procedures are to be observed:
• Wear full eye protection and protective clothing;
• Where electrolyte contacts the skin, wash it off
immediately with water;
• Where electrolyte contacts the eyes, flush
thoroughly and immediately with water and seek
medical attention; and
• Spilled electrolyte is to be washed down with an
acid neutralizing agent. A common practice is to
use a solution of 1 pound (500 grams) bicarbonate
of soda to 1 gallon (4 liters) or water. The bicar-
bonate of soda solution is to be added until the
evidence of reaction (foaming) has ceased. The
resulting liquid is to be flushed with water and the
area dried.
3.9 ADJUSTING VALVE CLEARANCE
After the first 50 hours of operation, check the valve
clearance in the engine, adjust if necessary.
Important: If feeling uncomfortable about doing this procedure or
the proper tools are not available, please contact the Authorized
Dealer for service assistance. This is a very important step to
insure longest life for the engine.
To check valve clearance:
The engine should be cool before checking. If valve clearance is•
0.002" - 0.004" (0.05 - 0.1mm), adjustment is not needed.
Remove spark plug wires and position wires away from plugs.•
Remove spark plugs.•
Make sure the piston is at Top Dead Center (TDC) of its com-•
pression stroke (both valves closed). To get the piston at TDC,
remove the intake screen at the front of the engine to gain
access to the flywheel nut. Use a large socket and socket
wrench to rotate the nut and hence the engine in a clockwise
direction. While watching the piston through the spark plug
hole. The piston should move up and down. The piston is at
TDC when it is at its highest point of travel.
To adjust valve clearance (if necessary):
Make sure the engine is at 60° to 80° F.•
Make sure that the spark plug wire is removed from the spark•
plug and out of the way.
Remove the four screws attaching the valve cover with a #2 or•
#3 Phillips screwdriver.
Loosen the rocker jam nut. Use an 10mm allen wrench to turn•
the pivot ball stud while checking clearance between the rocker
arm and the valve stem with a feeler gauge. Correct clearance
is 0.002-0.004 inch (0.05-0.1 mm). (Figure 3.7).
Figure 3.7 - Valve Clearance Adjustment
Jam Nut
Pivot Ball
Stud
Rocker
Arm
Valve
Stem
NOTE:
Hold the rocker arm jam nut in place as the pivot ball
stud is turned.
Section 3 – Maintenance
Recreational Vehicle Generators

15
When valve clearance is correct, hold the pivot ball stud in place
with the allen wrench and tighten the rocker arm jam nut. Tighten
the jam nut to 174 in/lbs. torque. After tightening the jam nut,
recheck valve clearance to make sure it did not change.
Install new valve cover gasket.•
Re-attach the valve cover.•
NOTE:
Start all four screws before tightening or it will not be
possible to get all the screws in place. Make sure the
valve cover gasket is in place.
Install spark plugs.•
Re-attach the spark plug wire to the spark plug.•
On the GT-530, repeat the process for the other cylinder.•
3.10 MAJOR SERVICE MANUAL
To obtain a service manual for the generator, contact the near-
est Authorized Service Dealer. Make sure to identify the MODEL
NUMBER and SERIES. Manuals can be obtained from the internet
website or a service dealer.
3.11 DRIVE BELT
The engine drives the generator rotor by means of a pulley and
drive belt arrangement. Drive belt tension was properly adjusted
before the unit was shipped from the factory. If suspect that drive
belt tension is incorrect, contact an Authorized Service Dealer.
3.12 EXERCISING THE GENERATOR
The manufacturer recommends starting and operating the genera-
tor at least once every seven days. Let the unit run for at least 30
minutes to “exercise” the engine.
3.13 OUT OF SERVICE PROCEDURE
3.13.1 REMOVAL FROM SERVICE
If the generator cannot be exercised every seven days, and it is to
be out of service longer than 30 days, prepare the generator for
storage as follows:
1. Start the engine and let it warm up.
2. Close the fuel shutoff valve in the fuel supply line and allow
the unit to shut down.
3. While the engine is still warm from running, drain the oil
completely. Refill the crankcase with SAE 5W-30 oil having
API classification “For Service SJ/SL.”
4. Attach a tag to the engine indicating the viscosity and clas-
sification of the oil in the crankcase.
5. Remove the spark plug and pour two or three tablespoons of
clean, fresh engine oil into the spark plug threaded openings.
Reinstall and tighten the spark plug.
6. Remove the battery and store it in a cool, dry room on a
wooden board. Never store the battery on any concrete or
earthen floor.
7. Clean and wipe the entire generator.
3.13.2 RETURN TO SERVICE
To return the unit to service after storage, proceed as follows:
1. Check the tag on the engine for oil viscosity and classification.
Verify that the correct recommended oil is used in the engine
(see "Engine Oil Requirements"). If necessary, drain and refill
with the proper oil.
2. Check the state of the battery. Fill all cells of unsealed batter-
ies to the proper level with distilled water. DO NOT USE TAP
WATER IN THE BATTERY. Recharge the battery to 100 percent
state of charge, or, if defective, replace the battery.
3. Clean and wipe the entire generator.
4. Reconnect the battery. Observe battery polarity. Damage may
occur if the battery is connected incorrectly.
5. Turn OFF all electrical loads. Add fuel if necessary and then
start the engine.
6. Allow the unit to warm up thoroughly.
7. Apply electrical loads to at least 50 percent of the unit’s rated
wattage capacity.
8. When the engine is thoroughly warmed up, shut it down.
9. The generator is now ready for service.
3.14 RV GENERATOR SERVICE
INTERVAL
1st 8 Hours,
then every 200 Hours ......................... Change Engine Oil/Filter
1st 50 Hours,
then every 500 Hours .................................. Adjust Valve Lash
200 Hours ..................................................Clean Spark Arrestor
200 Hours .................................Replace Paper Air Filter Element
400 Hours ......................................................Replace Fuel Filter
500 Hours ..................................................Replace Spark Plugs
Section 3 – Maintenance
Recreational Vehicle Generators

16
Section 4 – Notes
Recreational Vehicle Generators

PART II –
INSTALLATION
INSTRUCTIONS
DANGER
ONLY QUALIFIED ELECTRICIANS OR CONTRACTORS
SHOULD ATTEMPT INSTALLATION!

18
Safety Rules
Recreational Vehicle Generators
NOTICE TO INSTALLER
These Installation Instructions have been published by the manu-
facturer to aid in the installation of the products described in this
manual. The manufacturer assumes that installation personnel
are familiar with the procedures for installing such products, or
similar products manufactured. The manufacturer also assumes
that personnel have been trained in the recommended installation
procedures for these products and that such training includes (a)
use of common hand tools, (b) use of special tools, and (c) use of
any tools and/or equipment from other suppliers.
The manufacturer cannot possibly know of and advise the rec-
reational vehicle trade of all conceivable methods, procedures or
techniques by which to perform an installation. Nor can the manu-
facturer anticipate every possible hazard that might result from
each installation method, procedure or technique. The manufactur-
er has not undertaken any such wide evaluation. Therefore, people
who use a method, procedure or technique that the manufacturer
does not specifically recommend must first completely satisfy
themselves that their safety, the safety of the vehicle's occupants
and the product's safety is not endangered by the method, proce-
dure or technique selected.
Information, illustrations, specifications, etc., contained in these
Installation Instructions are based on the latest information avail-
able at the time of publication. Every effort has been expended
to be sure that such data is both accurate and current. However,
the manufacturer reserves the right to change, alter or otherwise
improve this product at any time without prior notice.
DANGER
Despite the safe design of this generator,
operating this equipment imprudently, neglecting
its maintenance or being careless can cause
possible injury or death. Permit only responsible
and capable persons to operate or maintain this
equipment.
Potentially lethal voltages are generated by
these machines. Ensure all steps are taken to
render the machine safe before attempting to
work on the generator.
Parts of the generator are rotating and/or hot
during operation. Exercise care near running
generators.
GENERAL HAZARDS 
For safety reasons, the manufacturer recommends that the•
installation, initial start-up and maintenance of this equipment
is carried out by an Authorized Service Dealer.
The generator engine releases DEADLY carbon monoxide gas•
through its exhaust system. This dangerous gas, if breathed
in sufficient concentrations, can cause unconsciousness or
even death. Never operate the generator set with the vehicle
inside any garage or other enclosed area. DO NOT OPERATE
THE GENERATOR IF THE EXHAUST SYSTEM IS LEAKING OR
HAS BEEN DAMAGED. SYMPTOMS OF CARBON MONOXIDE
POISONING ARE (a) inability to think coherently, (b) nausea,
(c) vomiting, (d) twitching muscles, (e) throbbing temples,
(f) dizziness, (g) headaches, (h) weakness, and (i) sleepi-
ness. IF EXPERIENCING ANY OF THESE SYMPTOMS, MOVE
INTO FRESH AIR IMMEDIATELY. IF SYMPTOMS PERSIST, GET
MEDICAL HELP. Shut down the generator and do not operate it
until it has been inspected and repaired.
Never sleep in the vehicle while the genset is running unless the•
vehicle has a working carbon monoxide detector. The exhaust
system must be installed in accordance with the genset instal-
lation manual. Make sure there is ample fresh air when operat-
ing the genset in a confined area.
Keep hands, feet, clothing, etc., away from drive belts, fans,•
and other moving or hot parts. Never remove any drive belt or
fan guard while the unit is operating.
Adequate, unobstructed flow of cooling and ventilating air is•
critical to correct generator operation and is required to expel
toxic fumes and fuel vapors from the generator compartment.
Without sufficient cooling airflow, the engine/generator quickly
overheats, which causes serious damage to the generator. Do
not alter the installation or permit even partial blockage of ven-
tilation provisions, as this can seriously affect safe operation of
the generator.
When working on this equipment, remain alert at all times.•
Never work on the equipment when physically or mentally
fatigued.
Before performing any maintenance on the generator, discon-•
nect its battery cables to prevent accidental start up. Disconnect
the cable from the battery post indicated by a NEGATIVE, NEG
or (–) first. Reconnect that cable last.
DANGER: For fire safety, installation of a generator into a recreational vehicle must comply strictly with article 551, NFPA 70;
ANSI C1-1975; AND, ANSI A119.2-1975/NFPA 501C “Standard for Recreational Vehicles” (Part 3, “Installation of Electrical
Systems”). In addition, installation must comply with the manufacturer’s instructions and recommendations.

