GENERAL LIFE AC400 User manual

User Manual
www.generallife.com.tr

www.generallife.com.tr

Table of Contents
ABOUT GENERAL Life
WHAT IS SMART AC (AIR CONDITIONER)
CONTROLLER?
RULES TO BE CONSIDERED FOR SAFETY
AC400 AND APPARATUS
TECHNICAL DATA
AC400 SMART AC (AIR CONDITIONER)
CONTROLLER
AC400 SMART AC (AIR CONDITIONER)
CONTROLLER PLACEMENT
AC400 SMART AC (AIR CONDITIONER)
CONTROLLER SETUP
MOBILE APPLICATION-MODES
LED LIGHT COLOR EXPLANATIONS
DECLERATION OF CONFORMITY
WARRANTY CONDITIONS
WARRENTY DOCUMENT
1
2
3
4
5
6
7
8
9
11
12
13
16

ABOUT GENERAL Lıfe
In 2007, ISIPARK started its business life and
created GENERAL LIFE brand which is one of the
leading brand in its sector.
Established and growing with 100% domestic
capital, GENERAL Life presents its products to its
users in many countries of the world with its
exports and represents Turkey in the world.
GENERAL Life; aims to contribute Turkey' s
economy maximum level by doing R&D, P&D and
production in Turkey.
Increases product portfolio by analyze
customers' needs of stylish, user-friendly and
technological products with resources allocated.
The product you purchased is produced with all
this consciousness and presented to the liking of
our valuable users.
Thank you for choosing us.
1

2
WHAT IS SMART AC (AIR CONDITIONER)
CONTROL KIT?
Smart AC Control Kit is the device which allows a
user to control the temperature of air conditioner
via Mobile Application by the internet even if you
are not at home.
HOW DOES SMART AC C ONTROLLER
WORKS?
The AC 400 Smart AC Controller helps your room
stay at the set temperature by communicating
infrared with your air conditioner.
WHAT ARE THE ADVANTAGES OF SMART AC
CONTROLLER?
Control your home temperature, wherever you
are in the World by Mobile App.
Create daily or weekly programs easily by Smart
AC Controller App.
Using Location Mode reduces/increases the
temperature of your home when you move
away/approach.
Depending on the range selected from the Smart
AC Control Kit's Mobile App, you can get a
historical report, the temperature of your home
and the outside air temperature.

RULES TO BE CONSIDERED FOR SAFETY
1- Be sure to read the manual before using the device and
its apparatus.
2-Opening, disassembly or use of the plastic parts of the
product and apparatus other than the intended purpose is
out of warranty.
3-Please note that the voltage of the outlet where you set
up your device and apparatus is the recommended value
in the user manual.
4-Keep away your product and all apparatus from all kinds
of foreign matter such as liquid, dust, heat etc.
5-Do not expose the device cables to any jamming or
pressure. Pay attention to plugging in jacks and sockets as
you can always reach the power connections of the
devices.
6-Disconnect the power supply to prevent damage to your
device and apparatus during thunderstorms and lightning.
7-Disconnect the power supply if your device has not been
used for a long period of time.
8-Your equipment and apparatus should be used with
caution as instructed in the user manual. In case of
damages and malfunctions because of external use, ask
for help from services.
9-Contact our service for maintenance and repair of the
AC400 and its appliances. Maintenance and repair of the
product and apparatus should be performed by ISIPARK
service and authorized services only and accessories and
apparatus specied by company must be used.
3

4
1- AC400 and APPARATUS
AC400 AIR CONDITIONER CONTROLLER
ADAPTER CABLE

5
2-TECHNICAL DATA
Feeding Voltage
Load Current
Temperature Measurement Accuracy
Temperature Setting Accuracy
Operating Temperature
Storage Temperature
5V (DC)
250 mA
o
0.1 C
o
1.0 C
o o
(-10 C) – (+50 C)
o o
(-20 C) – (+60 C)

6
3- AC400 SMART AC CONTROLLER
2 3
4
1-Led:
Provides information about the
mode and status of the device.
2-Wi-Fi Reset Button:
Pressing the button for 4
s e c o n d s r e s e t s W i - F i
connection an d fo r g e t s
connection information. This
allows you to connect new
network.
3-Mode Switch Button:
Allows you to switch between
m o d e s ( H o m e , S l e e p ,
Outside, off) when the button is
pressed for 2 seconds.
4-AC Cable Input
1

7
4 - A C 4 0 0 S M A R T A C ( A I R C O N D I T I O N E R )
CONTROLLER PLACEMENT
Your Air Conditioner now controlled by AC400 Smart AC
Controller. You need to place the AC400, considering the
placement of your Air Conditioner and Modem. Make sure
to position of the AC400 faced to the air conditioner. Please
consider that the distance between your AC400 and Air
Conditioner will be effect signal quality. Because of this,
please put the climate control kit as close as possible to the
air conditioner. Remember that you can improve the signal
quality by turning the sloping surface of the device (grille) to
the air conditioner. AC400 uses internet to communicate,
so please make sure that device is in the range of your
wireless modem. Avoid placing the AC 400 where there is a
lot of air circulation (air blowing area of the air conditioner,
door entries, window edges, etc.) so that the temperature
reading can be done correctly. Also, do not place in heat
units (central heating system, replace, etc.) and places
that receive direct sunlight. You can try to place few
locations to nd the most suitable place.

8
5 - A C 4 0 0 S M A R T A C ( A I R C O N D I T I O N E R )
CONTROLLER SETUP
To start setup and mounting, rst scan QR Code below via
your smartphone. You can install the application on your
smartphone with that code (You may need QR Code
Reader App regarding your phone's model and brand)
Note: To get further information about mounting and setup
please visit www.generallife.com.tr/kurulum/ac-400
Plug in adapter to HT400and than wait for the light to come
on. After the light starts blinking purple, the HT 400 smart
setup will be ready.
Smart Setup
Download AC400 mobile app from App Store or Google
Play Store

9
Please open the downloaded App and complete sign-up
and connection.
You will receive a conrmation code mail after you
completed signing up.
If you conrm the incoming mail, the application will
direct you to the Air Conditioner Sync page.
Please select the brand of your air conditioner from
brands list on the Air Conditioner Sync page.
Try remote controllers in the list to determine remote
which controls your Air Conditioner.
After you completing the remote selection, the App
home page will be opened. Select Manual Mode and
control remote functions (heating, cooling, setting
temperature, fan speed and off). Setup is completed If all
functions are operational. If some functions are not
operational, select other remotes from the list under the
name of your air conditioner brand in Sync Air
Conditioner menu. Try other remotes to nd which is
suitable for your air conditioner.
6- MOBILE APPLICATION-MODES
With AC400's Home- Sleep- Outside- Program- Location
and Manual mods, you can control air conditioner anytime
for more comfortable living space.
P.S: If you can't nd controller you required in the list,
please contact our technical department for support.

10
Home Mode, will x temperature on set value.
Recommended to use when you are at home.
Sleep Mode, provides comfy sleep with the set
temperature you desire. You can use this mode
between 11 pm to 7 am which is common
sleeping hours.
Outside Mode is suggested to use when you are
outside of your house for short or long time.
Program Mode allows you to program weekly as
30minute time periods which will automatically
change temperature in your home with your
program.
Location Mode reduces the temperature of your
home when you move away from home or
increases the temperature of your home when you
approach.
Manual Mode allows you to congure working of
air conditioner. You can instantly select heating,
cooling, fan speed and set a timer.

11
7- LED LIGHT COLOR EXPLANATIONS
White
White Flashing
Turquoise
Turquoise Flashing
Orange
Orange Flashing
Blue
Blue Flashing
Yellow
Yellow Flashing
Pink
Pink Flashing
Green
Green Flashing
Purple Flashing
Red
Air Conditioner is off.
Air Conditioner is off, device has
no internet connection.
The device is in Manual Mode.
The device is in Manual mode
but, no internet connection.
The device is in Home Mode.
The device is in Home Mode but,
no internet connection.
The device is in Outside Mode.
The device is in Outside Mode
but, no internet connection.
The device is in Sleep Mode.
The device is in Sleep Mode but,
no internet connection.
The device is in Program Mode.
The device is in Program Mode
but, no internet connection.
The device is in Location Mode.
The device is in Location Mode
but, no internet connection.
The device is ready for setup and
the access point is active.
The device's software is being updated.

DECLARATION OF CONFORMITY
ISIPARK A.Ş which Head Ofce and production site is
located on Fatih Mah. 1188 Sk. No:13/A Sarnıç - Gaziemir -
İZMİR – TÜRKİYE conrms and declares that the product
marked with CE and its specications below is covered by
the provisions of the mentioned directive.
Brand
Product Name
Product Type
The product manufactured by ISIPARK and mentioned
above is connected wirelessly at 2.4 Ghz internet and
periodically shares the temperature and status information
with the server on the internet.
Compatible Directives:
The Radio Equipment Directive 2014/53/EU (EN 301 489-1
V2.1.1: 2017, EN 301 489-17 V3.1.1: 2017, EN 220-1
V3.1.1: 2017, EN 62311: 2008, EN 301 489-3 V2.1.1: 2017,
EN300 220-2 V3.1.1:2017 & EN 62368-1: 2014)
Electromagnetic Compatibility Regulation 2004/108/EU
(EMC EN 301 489-1-3-17 v1.9.2)
Low Voltage Directive 2006/95/EU (LVD EN 60950-
1:2006/A2:2013)
Supplementary Information: Mentioned product can be
used with all air conditioner brands and models and
compatibility with the directive only covers the product.
ISIPARK is not responsible for the compliance of the entire
system with the directive. This declaration does not apply
when changes are made to the product without obtaining
our consent.
: GENERAL Life
: AC 400
: Smart Air Conditioner Controller
12

WARRANTY CONDITIONS
1- Warranty starts at the delivery date and warranted
against manufacturing defect for 2 years.
2- Device is delivered to customers in operation.
Mounting and other connections will be additional fee for
service.
3- Devices will maintenance and repair in our factory and
should send by contracted transportation company. For
out services, transportation and accommodation of
service personnel are covered by customers. Overtime is
added on service charge and is received as cash
proceeds.
4- Maintenance of devices and apparatus will be in our
factory. For device maintenance, the round travel fares are
covered by customers.
5- If devices are malfunction in warranty duration, devices
will be inspected in our factory to nd out whose
responsibility (manufacturer or customer) and will
announce to user by report.
6- Devices, which malfunctioned in warranty duration and
found out it is responsibility of manufacturer, customer
can demand new product or repair which all costs will
fullled by manufacturer regarding to cost is not higher
than device.
7- After inspection of malfunction and detected that, it is
customer's fault, repair cost of the device which still in
warranty duration will be customer's responsibility.
13

8- Customers should be aware of damages (if there is
any) of product and warn manufacturer since the day
warranty duration starts. If customer do not warn
manufacturer with knowledge of damage, customer lose
the rights of article 6.
9- Devices and apparatus should be used as specied in
User's Manual if not used as specied, products are out of
warranty.
10- If products damaged, scratched or cracked by
customer. The products will be out of warranty conditions.
11- Damages/Malfunctions because of using other brand'
s and model' s devices and apparatus without knowledge
of manufacturer are out of warranty.
12- The arising depredation owing to working in humid
and acidic places and result of rusting, oxidation is out of
warranty.
13- The transport damage is out of warranty. Customers
can take a transportation insurance.
14- Damages by virtue of grid voltage are out of warranty.
15- Damages because of force majeure like ood,
earthquake, re etc. are out of warranty.
16- All parts of the product are under warranty of our
company.
17- If product breaks down and gets xed in warranty
duration, duration of maintenance adds to the warranty
duration. Products repairment can't exceed 20 work days.
This duration starts when the product's problems are
reported to the seller, agency, producer or the importer if
14

there is no service station. Consumer can report the
problem by; fax, e-mail, registered and reply-paid letter or
a similar way. If a conict happens, the consumer has the
responsibility of proong it. If the problem can't be solved
more than 10 days the producer or importer has to supply
a similar device until end of the reparation. If the product
breaks down because of material, label or mounting faults
in the warranty duration, rm won't demand label costs,
changing parts or any other kind of charge for repairment.
18- Despite consumers rights of maintenance;
-If the product breaks down for 4 times in a year or 6 times
in warranty duration and these problems effects main
purpose of the product. (starting from delivery time during
warranty.),
-Exceeding the maximum repairing term,
-In the case of not existing service station, determining
that repairment is not possible with the report compiled by
respectively service station's seller, dealer, agency,
legation, importer or manufacturer.
19- You may apply for Ministry of Custom and Trade and
General Directorate of Protection of Costumers and
Market Surveillance in case of the problems about
certicate of warranty.
20- Warranty document should be kept by customer until
warranty duration is nished. If warranty is lost there will be
no replacement. All maintenance and repair cost are
responsibility of customer in case of warranty document
lost.
15

www.generallife.com.tr

ISIPARK reserves the right to change and develop product
specications and user manual.
*For all the changes, you can visit www.generallife.com.tr
