Genesis CCTV ID-650VDN User manual

Product Manual
ID-650VDN

Dome Series Color Camera
IR Dome Color Camera
Specification
Packing List
No Name Manual Number
1. Vandal proof IR Dome Color Camera 1
2. User Guide 1
Dome Series
USER MANUAL
Notes: Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
Genesis CCTV for technical support.
Model
Pick up Element 1/3"SONY
Effective Picture
Elements (H×V) PAL:752(H)×582(V)
NTSC:768(H)×494(V)
Horizontal Resolu-
tion 650TV Line
Minimum Illumina-
tion
0.001Lux
0Lux (with IR LED ON)
S/N Ratio More than 48dB
Scanning System 2:1 interface
Synchronous
System Internal, Negative sync.
Auto Electronic
Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama
Characteristic 0.45
IR Distance 30 Meters (with ￠5X24PCS Infrared LED)
IR Status Under 10Lux by CDS
IR Power On CDS AUTO Control
Video Output 1Vpp, 75Ω
Auto Gain Control Auto
Power/Current DC12V/500mA
Lens 3.6mm Lens(6mm/8mm optional)
Dimension (mm) ￠131 x 93(H)
Weight (g) 800g
Storage Tempera-
ture -30~+60℃
Operating Tempera-
ture -10~+45℃
6923 Narcoossee Rd Orlando, FL 32822
www.genesiscctv.com
ID-650VDN

INTRODUCTION
Congratulations on your purchase of this product.
This User Guide is for the ID-650VDN. We adopt the
latest SONY/SHARP sensors and drivers. The
most attractive characteristics are small and easily hidden,
in the elevator and corridor. In addition, it owns the
characteristics of high definition and stability, strong anti-
jamming, rich and real color. Setup and use of this model
is convenient too.Making it a great faddition to your
CCTV system.
Please read this instruction manual carefully to en-
sure proper use of the product.
CONNECTING
BRIEF OF PRODUCT
•1/3” Sony Color Super HAD CCD
•High Resolution :420/540/600/680TVLines
•Simple Installation Adjustment
•Cable Managed
•22pcs IR Led
•Elegant design
•Intelligent LED Power
•2.8mm - 12mm Lens
•IR Distance 25m
•Day/night function w/ Infrared
•Power supply: DC12V
.
DC12V Power Supply
Monitor
TROUBLE AND SOLUTION
Link wire rule：
Power
Video
 Note
●Please note the camera’s operating temperature and its using
environment requirement. Avoid using the camera at too high or
too low temperatures. The operating temperature is -30~+60℃.
(Recommendatory operating temperature is -10~+45℃.)
●Never make the camera face the sun or bright object. Otherwise,
it will damage the CCD.
●Do not mount the camera near by the radiator or heater.
1. No Picture after providing power
. May be the power supply voltage abnormity, please check the power
supply voltage and pole whether exactitude.
. Please check all the connecting cableand monitors whether be connected
correctly or not.
2. The picture level direction have flowing interference ripples
. May be caused by the power supply AC ripples, it need filter the wave of the
power supply.
. Check the monitor and peripheral equipments used.
3. The picture background color changes continuously
. The fluorescent lamp’s electromagnetic field cause color roll. This is proper
phenomenon of the cameras.
. Reduce the fluorescent lamp numbers or increase the distance between the
camera and the fluorescent lamps can improve it.
. Use power supply external sync. camera can solve it.
4. The picture smear too mass
. The power supply’s voltage unstable.
. Connecting cables not connect correctly or have high impedance.
To prevent fire or shock hazard. Do not expose the unit
The symbol is intended to alert the user to the presence of
The symbol is intended to alert the user to the presence of
to rain or moisture.
important operating and maintenance (servicing)
Instructions in the literature accompanying the appliance.
uninsulated ‘dangerous voltage’ within the product’s
enclosure that may be of sufficient Magnitude to constitute
a risk of electric shock to persons.
Notes：
●The power supply must through safe attestation. Its output voltage,
current, voltage polarity and operating temperature must match the
camera’s requirement.
●When using the camera in the thunderbolt condition,please note to
mount Anti-thunder device or put off the power supply plug and cable.
●In order to capture high quality pictures, the power supply’s cable and
Video
DC12V
CAUTION:
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK
DO NOT REMOVE COVER OR BACK NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
RISK OF ELECTRIC. DO NOT OPEN
CAUTION: TO PREVENT ELECTRIC SHOCKS AND RISK OF
FIRE HAZARDS, DO NOT USE OTHER THAN
SPECIFIED POWER SOURCE.
Genesis CCTV - 6923 Narcoossee Rd, Suite 610 Orlando FL, 32822 Phone: [phone] Fax: [phone]
