Genetec Synergis IX User manual

Synergis IX DIN Rail Single Door
Controller
SY-SIX-CTRL-DIN-1D
Installation Manual

SY-SIX-CTRL-DIN-1D | Synergis IX DIN Rail Single Door Controller | Installation Manual
Last Updated August 2018 2
The contents of this guide are furnished for informational use only and are subject to change without notice.
Genetec assumes no responsibility or liability for any errors or inaccuracies that may appear in the
informational content contained in this guide.
Genetec reserves the right to revise and improve its products as it sees fit. This document describes the state
of a product at the time of document’s last revision, and may not reflect the product at all times in the future.
In no event shall Genetec be liable to any person or entity with respect to any loss or damage that is incidental
to or consequential upon the instructions found in this document or the computer software and hardware
products described herein. The use of this document is subject to the disclaimer of liability found in the
end-user license agreement.
This publication may not be copied, modified, or reproduced in any form or for any purpose, nor can any
derivative works be created therefrom without Genetec’s prior written consent.
Copyright © 2018 Genetec.

SY-SIX-CTRL-DIN-1D | Synergis IX DIN Rail Single Door Controller | Installation Manual
Last Updated August 2018 3
Contents
Introduction ............................................................................................................................. 5
Single Door Controller Editions .................................................................................................................... 5
Grounding Requirements ....................................................................................................... 6
Safety Grounding .......................................................................................................................................... 6
Earth Ground Connection ............................................................................................................................. 6
Mounting .................................................................................................................................. 8
Removal ....................................................................................................................................................... 8
Connections ............................................................................................................................ 9
Power Requirements .................................................................................................................................... 9
Power over Ethernet (PoE) ......................................................................................................................... 11
Encrypted Module Network ........................................................................................................................ 12
Module Wiring ..................................................................................................................................... 12
End of Line (EOL) Resistors ............................................................................................................... 13
Backup Battery .................................................................................................................................... 13
Ethernet 10/100 Network Interface ............................................................................................................. 14
Configuration ........................................................................................................................ 15
Setting the IP Address ................................................................................................................................ 15
Setting the IP Address from a Keypad ....................................................................................................... 15
Configuring a Controller via the Synergis Software .................................................................................... 15
Adding a Controller with Default Records ........................................................................................... 16
Adding a Controller Based on an Existing Controller .......................................................................... 1 7 
Configuring a Controller ...................................................................................................................... 17
Addressing Modules ................................................................................................................................... 20
Door Access Control ............................................................................................................ 22
Reader Location ......................................................................................................................................... 22
RS-485 Card Reader Connection (Entry Only) .......................................................................................... 22
RS-485 Card Reader Connection (Entry/Exit) ............................................................................................ 23

SY-SIX-CTRL-DIN-1D | Synergis IX DIN Rail Single Door Controller | Installation Manual
Last Updated August 2018 4
Door Contact Connection ........................................................................................................................... 23
Lock Output Connection ............................................................................................................................. 24
Programming the Onboard Reader ............................................................................................................ 25
Inputs ..................................................................................................................................... 26
Resistor Value Options ............................................................................................................................... 27
Trouble Inputs ............................................................................................................................................. 28
Outputs .................................................................................................................................. 29
Hardware Configuration ....................................................................................................... 3 0 
Defaulting a Controller ................................................................................................................................ 30
Temporarily Defaulting the IP Address ....................................................................................................... 31
LED Indicators ...................................................................................................................... 32
Power Indicator ........................................................................................................................................... 32
Status Indicator ........................................................................................................................................... 32
Fault Indicator ............................................................................................................................................. 32
PoE Power Indicator ................................................................................................................................... 33
Battery Indicator ......................................................................................................................................... 33
Ethernet Link Indicator ................................................................................................................................ 33
Reader Data Indicators ............................................................................................................................... 33
Relay Indicator ............................................................................................................................................ 34
Input Indicators ........................................................................................................................................... 34
Mechanical Diagram ............................................................................................................. 35
Mechanical Layout ................................................................................................................ 36
Technical Specifications ...................................................................................................... 37
New Zealand and Australia .................................................................................................. 38
European Standards ............................................................................................................. 39
FCC Compliance Statements ............................................................................................... 41
Industry Canada Statement ................................................................................................. 42

SY-SIX-CTRL-DIN-1D | Synergis IX DIN Rail Single Door Controller | Installation Manual
Last Updated August 2018 5
Introduction
The Synergis IX DIN Rail Single Door Controller is the central processing unit of the Synergis System. It
communicates with all system modules, stores all configuration and transaction information, processes all
system communication, and reports alarms and system activity to a monitoring station or remote computer.
Flexible module network architecture allows large numbers of modules to be connected to the RS-485 Module
Network. Up to 250 modules can be connected to the Synergis System in any combination to the network up
to a distance of 900M (3000ft). Communication beyond this distance requires the use of a RS-485 Network
Extender
The current features of the Controller include:
 Internal industry-standard 10/100 Ethernet
 32 Bit advanced RISC processor with 2Gb total memory
 2 high security monitored inputs
 NIST Certified AES 128, 192 and 256 Bit Encryption
Single Door Controller Editions
There are two editions of the Synergis IX DIN Rail Single Door Controller:
 The Controller can be supplied power from a 12V DC power supply connected to the N+ and N- terminals.
 The Controller with PoE can be supplied power from a 12V DC power supply connected to the N+ and N-
terminals OR from a PoE Router via the onboard Ethernet terminal.
The features specific to the PoE interface described in this manual are only relevant if you are using the
appropriate edition.

SY-SIX-CTRL-DIN-1D | Synergis IX DIN Rail Single Door Controller | Installation Manual
Last Updated August 2018 6
Grounding Requirements
An effectively grounded product is one that is intentionally connected to earth ground through a ground
connection or connections of sufficiently low impedance and having sufficient current-carrying capacity to
prevent elevated voltages which may result in undue hazard to connected equipment or to persons.
Grounding of the Synergis system is done for three basic reasons:
1. Safety
2. Component protection
3. Noise reduction
Safety Grounding
The object of safety grounding is to ensure that all metalwork is at the same ground (or earth) potential.
Impedance between the Synergis system and the building scheme ground must conform to the requirements
of national and local industrial safety regulations or electrical codes. These will vary based on country, type of
distribution system, and other factors. The integrity of all ground connections should be checked periodically.
General safety dictates that all metal parts are connected to earth with separate copper wire or wires of the
appropriate gauge.
Earth Ground Connection
The DIN Rail enclosure and the DIN Rail modules must be grounded to a suitable single-point earth ground
connection in the installation. A minimum 14AWG solid copper wire (or thicker, in accordance to local
authorities) shall be used from the Synergis system's earth connection points.
The DIN Rail enclosure includes an earth ground single-point link connection via the metallic enclosure. This
single-point link is the Synergis system's earth ground. All modules that have earth ground connections and
that are installed in the same enclosure shall be connected to this single point. A single-point earth ground
connection avoids the creation of ground loops in the system and provides a single reference point to earth
ground.

SY-SIX-CTRL-DIN-1D | Synergis IX DIN Rail Single Door Controller | Installation Manual
Last Updated August 2018 7
Controller
Earth Ground
Link connection
Dialer’s Earth
Ground Connection
PRT-RDM2-DIN
PRT-PSU-DIN
V-
Power Supply
Reader Expander
PRT-PSU-DIN
Input Expander
Output Expander
V-
AC Mains Wiring
DIN Rail Ground Connections (one or more cabinets installed in the same room)
DIN Rail Enclosure
Module Network
(RS-485 N+, N-, NA and NB)
Additional DIN Rail Enclosure (s)
DIN Rail Ground Connections (multiple cabinets in different rooms, sectors, or buildings)
DIN Rail Enclosure
Controller
Earth Ground
Link connection
Dialer’s Earth
Ground Connection
Module Network (RS-485 N+, N-, NA and NB)
PRT-RDM2-DIN
PRT-PSU-DIN
V-
Power Supply
Reader Expander
PRT-PSU-DIN
Input Expander
Output Expander
PRT-RDM2-DIN
Input Expander
PRT-PSU-DIN
Input Expander
Input Expander
V-
DIN Rail Enclosure DIN Rail Enclosure
Sector or Building #1 Sector or Building #2 Sector or Building #3
Note that the DIN Rail enclosure earth terminal is connected to the power supply V- terminal.
There must be only one single earth grounding point per system.

SY-SIX-CTRL-DIN-1D | Synergis IX DIN Rail Single Door Controller | Installation Manual
Last Updated August 2018 8
Mounting
The Controller is designed to mount on standard DIN Rail either in dedicated DIN cabinets or generic DIN Rail
mounting strip.
When installing the Controller ensure that there is adequate clearance around all sides of the device and that
air flow to the vents of the unit is not restricted. It is recommended to install the Controller in a location that will
facilitate easy access for wiring. It is also recommended that the Controller is installed in electrical rooms,
communication equipment rooms, closets or in an accessible area of the ceiling.
1. Hook the lower tabs under the bottom edge of the DIN Rail.
2. Push the Controller against the DIN Rail mount until the upper tab clips over the upper rail.
Removal
The Controller can be removed from the DIN Rail mount using the following steps:
1. Insert a flat blade screwdriver into the hole in the tab at the top of the Controller.
2. Lever the tab up and rotate the unit off the DIN Rail mount.

SY-SIX-CTRL-DIN-1D | Synergis IX DIN Rail Single Door Controller | Installation Manual
Last Updated August 2018 9
Connections
Power Requirements
Power is supplied to the Controller by a 12V DC power supply connected to the N+ and N- terminals. The
Controller does not contain internal regulation or isolation and any clean 12V DC supply is suitable for this
purpose.
Warning: Termination of wiring to the Controller while power is applied or the battery is connected
may cause serious damage to the unit and will VOID ALL WARRANTIES OR GUARANTEES.
Power the unit only after all wiring, configuration and jumper settings are completed.
A battery backup must be connected to the module network to provide a monitored supply. The battery plays
an important role in power conditioning and provides a continuous source of power in the event of a power
outage.
Example 2A Power Supply Connection:
Controller
Power Supply
NAN+ N- NB
+
-
To other modules
on network
Mains Input
NAN+ N- NB AC AC
B+B-
V1-V2+ V- V-
Transformer
Gel Cell Backup Batteries
+
-

SY-SIX-CTRL-DIN-1D | Synergis IX DIN Rail Single Door Controller | Installation Manual
Last Updated August 2018 10
Example 4A Power Supply Connection:
B+
B- LN
Controller
Power Supply
+
-
V1+ V- V1+ V1+ V1+ V1+ V1+ V- V- V- V- V-
To other modules
on network
Mains Input
NAN+ N- NB
NAN+ N- NB
Gel Cell Backup Batteries
+
-
In a small installation this same power supply can be used to supply the module network as well, so long as
the maximum load of the power supply is not exceeded. In larger installations, the power supply may need to
be split to allow for load sharing between several supplies.
In order to comply with EN 50131-1 only one battery can be connected and monitored per system. If
more capacity is required a single, larger battery must be used.
Example Multiple PSU Connection:
Module #3 Module #1 Controller
Module #2
Power Supply #3 Power Supply #2 Power Supply #1
NAN+ N- NB NAN+ N- NB NAN+ N- NB
NAN+ N- NB
