Genie CAP-REX-1G User manual
Quick Start Guide
Please read these instructions carefully before operating the unit
and keep for further reference.
Contactless Request To Exit
Button
CAP-REX-1G
Quick Start Guide Contactless Request To Exit Button
2
The Genie CAP-REX-1G is a sleek contactless request to exit button and works
using capacitive technology. It has a blue LED back light which turns green on
activation. The CAP-REX-1G is 1G in size making it perfect for most access control
applications.
1. Product Features
• When triggered, the back light will change colour with an audible tone
• Provides a dry contact output to interface with any access control controller
• Built-in mechanical override in case of power failure or electronic failure
• Built-in a digital timer to control the relay output timing from 1 to 15 sec
• Back lit design and built-in buzzer (buzzer selectable)
• Capacitance proximity technology has been used instead of infrared
technology – environmental independent design
2. Specifications
Request To Exit Indication Colour changes from Blue to Green with a beep
Request To Exit Output Dry contact output
REX Relay NC / NO jumper selectable rated @ DC30V, 1A
Mechanical Override Available
Output Timer From 1 sec to 15 sec
Typical Read Range ~2.5 cm
Operating Voltage DC12–24V
Operating Current 150mA (Max. @ DC12V)
Operating Temperature -20°C ~ +60°C
Operating Humidity 10% – 90% RH
Case PC, ABS (Black and white colour)
Dimensions 92 × 92 × 8.5 mm
3. Product Dimensions
92mm
92mm
Quick Start Guide Contactless Request To Exit Button
3
4. PCB Setting Diagram
5. Wiring
For door open
duration setting
from 1 to 15 sec.
Label Description
+VDD Power input (+12V ~ +24VDC)
RTE_COM
Exit button output (dry contact)RTE_NO
RTE_NC
MO External device to trigger the door open, active low
GND Signal ground (0 VDC)
Quick Start Guide Contactless Request To Exit Button
4
6. Functions
7. DIP Switch Setting
• As you put your hand near the exit button the capacitive technology will
trigger the device without the need to actually touch it. The colour of the exit
button will change from blue to green in colour when triggered. At the same
time, the relay inside the exit button device will trigger for 1 second and the
built-in buzzer will beep once.
• To adjust the door open duration, please power off the exit button. Change
the DIP Switch setting to alter the door open duration from the table below,
adjustable from 1 to 15 seconds, re-apply power again for the change to take
place.
• Support mechanical override.
• Support an external device/switch to trigger the unit.
• Remote Control is an option (Special order item)
1
ON 1 No. 1,2,3,4 are used for adjusting door open duration.
ON = Valid
OFF = Invalid
Door open duration = To add all the ON position
switch numbers
Example:
If we set 1 and 4 to “ON”, the door open during will be:
1+8=9 the decimal number is 9 seconds (decimal
number)
*Setting all DIP switch to OFF position means door
duration = 1 sec.
OFF 0
2ON 2
OFF 0
3ON 4
OFF 0
4 ON 8
OFF 0
5 ON Turn off (buzzer) Turn off the buzzer
OFF Turn on (buzzer) Turn on the buzzer (default)
6 ON N /A N /A
OFF N /A
7 ON N /A N /A
OFF N /A
8 ON Trigger distance
(near)
2~3cm
OFF Trigger distance
(far)
5cm (default)
NOTE:
Change the DIP Switch, please power off for changes to take place.
Quick Start Guide Contactless Request To Exit Button
5
8. Installation
1. Confirm the size of back box fits CAP REX-1G as shown in 3. Product
Dimensions.
2. Confirm all wiring is correct. Set the jumpers to the required positions.
3. Secure the exit button to the back box with correct screws as shown below.
4. There are 2 M-type buckles at the bottom of the cover as shown in the below
left image. Align them into the slot at the bottom of the module and then push
the upper part of the cover up (as shown below in right image) to secure exit
button cover. Unit is now ready to use.
M-Type buckles
