Genius Wireless TwinTouch Optical Office User manual

Hardware Installation
1. You can connect the receiver to a USB port of a PC.
2. Install two AA rechargeable batteries in the mouse and two AA rechargeable
batteries in the keyboard.
3. Turn on your computer.
4. The channel buttons are factory preset. If your keyboard/mouse does not work,
then follow the next step.
5. After you open Windows, to set the ID channel setting, please press the button
on the receiver first (RB) and press the button under the mouse (MB) within six
seconds. Now press the receiver button again and the button under the keyboard
(KB) within six seconds. So you press RB, MB, then the RB, KB to set the chan-
nel setting.
Important: You can use the battery charger receiver to recharge two AA or two
AAA rechargeable batteries each time when you use the PC. Plug the battery
charger receiver USB connector into the PC directly and remember do not put the
batteries in the wrong direction, use the same types of batteries, and do not
recharge via the USB hub, that will make your receiver, main-board and hub burn
or become non-usable easily. Also, keep all drinks away! If any spill occurs on the
receiver, unplug the USB connector first and clean the receiver immediately. Please
remove the batteries if you do not use this device for at least two weeks.
Warning: (Troubleshooting)
1. Please do not use Wireless TwinTouch Optical Office on a desk which is made
of glass, mirror, iron, or black velvet. Also, a flat surface is necessary or the Op-
tical Sensor will error easily. When you use Wireless TwinTouch Optical Office
on a desk that is made of metal, try using a pad or reduce the receiving distance.
2. Before the first installation is completed (channel setting ready), the keyboard
will not work in DOS. If your USB keyboard does not work in BIOS, DOS or
Windows, then use another PS2 keyboard to make the USB controller (USB
function) and USB legacy (USB keyboard) “On” in the BIOS setup. This may
occur with older BIOS versions. Then unplug the PS/2 keyboard and plug in
your USB keyboard and everything should be working properly.
3. The Wireless TwinTouch Optical Office channel provides 256 ID-codes, and it
automatically selects the ID # for your keyboard and mouse. You can only set up
one Wireless TwinTouch Optical Office at a time. But if you have additional
1
ENGLISH

Wireless TwinTouch Optical Office sets in an area of 10 square meters, more
interference may occur between the receiver and your keyboard and mouse.
4. If you feel the mouse does not move smooth as usual or the keyboard does not
work when typing, then the batteries have lost their charge, so please replace
them. Also, the wireless icon will be blinking “red” when there is a battery-low
situation. The LED on the receiver shows the battery-recharging status (from
shining to LED completely “on” for battery full). You should set up the channel
every time you replace the batterires.
5. If you need to buy new batteries, please choose Ni-MH (Nickel-Metal-Hydride)
AA batteries, 1.2V, 1300 to 1600 mAH. Please do not mix or use other types
of batteries (Li-ion, Ni-Cd, Alkaline, etc.).
6. The Wireless TwinTouch Optical Office with radio frequency gives you free
movement and an enjoyable experience. For optimal performance, place the re-
ceiver at least 8 inches (about 20 cm) away from the mouse and other electrical
devices, such as the computer, monitor, and etc.
Software Installation
1. Make sure the mouse and keyboard is connected to the computer.
2. Put the Setup disk (or CD) into the disk drive.
3. Follow the instructions on the screen to finish the software installation.
Factory Setting
1. Mouse:
Button Assignments
The Button Assignment feature lets you work in a more efficient way because you
can assign the most frequently used commands in Windows to the mouse buttons.
Magic-Roller Press the “Magic-Roller” to surf the Internet and Windows docu-
ments
2

Left Button Provides traditional mouse functions such as click, double click and
drag.
Right Button You can assign this button frequently used keyboard and mouse func-
tions in addition to features like EasyJump, Auto-Panning, Zoom, etc.
Roller ButtonYou can assign this button frequently used keyboard and mouse func-
tions in addition to features like EasyJump, Auto-Panning, Zoom, etc.
Side Buttons You can assign certain functions (Application/Document, Horizontal
Scroll, Last/Next Page, and Zoom in/out) to the upper or lower side
button with the roller.
2. Keyboard:
1. Word: Open Word application
2. Excel: Open Excel application
3. Scroll Wheel: For fast browsing and switching
between applications. (If you want to select the
application, please switch the scroll wheel
again.)
4. Vol.-& +: decrease or increase volume
5. Mute:Remove the sound
6. Play & Pause: Play and pause of audio or video
CD’s
7. Rewind: Previous track of audio or video CD’s
8. Forward: Next track of audio or video CD’s
9. Stop: Stop play of audio or video CD’s
10. Media: Controls the playback of music CDs and
PC audio
11. E-mail: Open mail folder
12. Stop: Stop your command when using the browser
13. Refresh: Refresh the page
14. Back: See last page when viewing the Internet
15. www: Open browser in Netscape or IE
16. Forward: Go to next page when viewing the Internet
17. Search: Open the search function when you using browser
18. My favorite: Open my favorite web-site
19. Sleep: Turn system into sleep mode
20. Calculator: Open the calculator from Windows
21. My Computer: Open my computer folder from Windows
MouseMate Software Features
Browsing Speed You can adjust the browsing speed when you surf the
Internet or Windows documents.
Browsing
Direction
Move the “Magic-Roller” forward and the screen will
browse to the top of the document. Move it in reverse and
the document will go in the opposite direction
3
ENGLISH

Button Find Automatically positions the cursor on the default button,
usually the OK button, when the dialog box appears on
your screen.
Trails This option makes it easier to find the cursor when using
an LCD monitor. This option cannot be used if your
monitor does not support it.
Loop When you move the cursor to the top (or bottom) of the
screen, it will automatically move the cursor to the bot-
tom (or top) of the screen.
Mouse Speed This function lets you adjust the speed at which the
pointer moves across the screen.
Double Click
Speed
Use this function to set the double click speed of the
mouse.
Swap Left/Right Select this option if you want to have the mouse operate
with the right mouse button as the primary button.
Pointers Folders This lets you change the shape of the cursor.
Office Mode Only supports Microsoft Office along with some new ap-
plications. Features include zoom, scrolling and Auto-
scrolling features. It’s similar to Microsoft’s IntelliM-
ouse.
Genius Mode Supports all applications that use scrollbars, including Of-
fice, with zoom, Auto-panning, and scrolling functions.
About Click here to open the Genius Homepage “www.genius-
net.com.tw”
Orientation This function lets you set the angle when you move the
mouse upward. It gives you a more comfortable angle
when holding the mouse. This function works best with a
portable trackball.
EasyJump
“EasyJump” now has two working modes: Office Easy-
Jump mode and Traditional EasyJump mode.
“Office EasyJump” lets you use eight commonly used
applications and 16 Cyber functions more easily and
quickly.
Once you press the button you assigned, “Office Easy-
Jump” will be displayed on a Frisbee. Note that the func-
tions are only available in the applications they belong
to.
4

Click this application button to show the mouse control panel. You can check
or modify the mouse properties.
Click this function and the pan icon appears. You can move the mouse
in any direction in a document or a spreadsheet. The farther you move
the pointer from the pan icon, the faster you can pan in that direction.
Click this function and Office EasyJump Frisbee will always be on the
screen and the button will change to . Click it again to cancel this
effect.
This is a programmable application button. Press the right button on this icon
and a dialog box will display for you to select an executable program. Click
on this button to launch your specific application.
Click this function to implement the “replace” function in the current
application.
Click on this application to launch Microsoft Word.
Click this function to perform the “cut” function in Word.
Click this function to implement the “paste” function in Word.
Click on this application to launch Microsoft Excel.
Click this function to implement the “select all” function in Excel.
Click this function to perform the “undo” function in Excel.
Click on this application to launch Microsoft Power Point.
Click this function to implement the “zoom in” function in PowerPoint.
Click this function to implement the “zoom out” function in Power-
Point.
Click on this application to launch Outlook Express or any other email client
application installed in your system.
Click this function to open a new email.
Click this function to forward a selected email in your mailbox.
Click on this application to open Microsoft Internet Explore or any other
Internet browser installed in your system.
5
ENGLISH

Click this function to return to the previous web page in your open
Internet browser.
Click this function to more forward to the next web page in your open
Internet browser.
Click on this application to launch Windows media player or any other multi-
media player installed in your system.
Click this function to play/pause the current running media player.
Click this function to stop the current running media player.
Note: All the functions related to Office applications are programmable. Place the
cursor on the function icon you want to change, and click the right button to select or
reset the unit from the popup menu. From the dialog box, you can choose another
function to use in the EasyJump Frisbee.
To change from Office EasyJump mode to Traditional Easy-
Jump mode, just click the right button on the Genius logo in
the center of the EasyJump Frisbee.
The “Traditional EasyJump” lets you use eight Cyber func-
tions more easily and quickly.
Once you press the button you assigned, the “EasyJump”
Frisbee will pop up and eight functions will be displayed on
Frisbee.
Click this button to close the current window.
Click this button and the cursor will jump to the horizontal scrollbar. When
you move your mouse, the open document or spreadsheet will scroll horizon-
tally.
Click this button and the cursor will jump to the vertical scrollbar. When you
move your mouse, the open document or spreadsheet will scroll vertically.
Click this button to open the Start Menu.
Click this button to open the Help button.
Click this button to open the Genius Mouse Control Panel.
Click the button and you can move the mouse in any direction in a document
or a spreadsheet. The farther you move the pointer from the pan icon, the
faster you can pan in that direction.
The buttons in “EasyJump Options” are especially used for Internet. The default func-
tion is “Open Browser” (button like ). You can select other functions from
“EasyJump Options” in the “Settings” folder of the Genius Mouse Con-
trol Panel. The functions in “EasyJump Options” are:
6

“Add to Favorite [IE] ” “Organize Favorite [IE] ”
“Add Bookmark [NetScape] ” “Edit Bookmark [NetScape] ”
“Go Next [Forward] ” “Go Previous [Back] ”
“Run Application”
Switch Applications
When the right-button or Magic-Roller is set to “Switch AP”, you can quickly switch
from one open application to another without moving the mouse. To switch to a spe-
cific application, press the right button or the Magic-Roller to select the application.
Zoom function for Office and IE Applications
Press the “Ctrl” key and move the “Magic-Roller” forward (or backward) to set the
Zoom In/Out function. You can also use just one hand to Zoom In/Out: set the right
button to be the “Ctrl” function, press the right button and move the “Magic-Roller”
forward (or backward) to enlarge (or decrease) the document window.
Auto-Panning
You can set this function in the Button Assignment menu. Move the mouse, and the
document moves in the direction you just moved.
Uninstall the Software
Follow these instructions to remove the software from your hard disk. In Windows,
click on the Start button, select Programs and move to the mouse software. Then click
on Uninstall software.
Customize the Software
This section shows you how to customize the software. To open the software control
panel, you can double-click on the icon in the task bar or select the “Software” icon
from the program group.
Close the Software
Click the right button on the taskbar, and select “Close Software” to close the soft-
ware.
7
