Genius GP560 User manual

USB Tablet
Installation Guide

2
USB TABLET
Table of Contents
Introduction ...............................................................3
Features .....................................................................3
Safety Notice .............................................................4
Check Your Package Contents ..................................4
Chapter 1: Installation ...........................................5
Software .................................................................5
Installation procedure: ...........................................5
Hardware ...............................................................5
Step 1 Connecting the tablet to your PC .......5
Step 2 Checking the power indicator ............5
Step 3 Installing the battery ..........................5
Chapter 2: Getting Started ....................................6
Using the Pen .........................................................6
Using the Tablet .....................................................7
Chapter 3: Q & A ....................................................8
System Requirements ...........................................9
Specifications .......................................................9

3
USB TABLET
EN
Introduction
This USB Tablet provides you with excellent writing and drawing
convenience, making it easier for you to interact with your PC and be
very creative. To make the best use of this USB Tablet, please read this
manual carefully.
- function keys
Quick and easy for users to select tablet functions.
Features
- High-quality handwriting resolution
Large area tablet gives higher resolution.
- Wireless pen
Convenient for handwriting input.

4
USB TABLET
Avoid
- Dampening the product
- Using volatile chemicals to clean the
product
- Dropping the product off the table or to the ground
- Severe impact or vibration
- Stepping on the product
- Placing heavy objects on the product
- Disassembling the product
- Placing the product close to a CRT monitor*
* may cause interference to the monitor
If any problems are occurred, please contact your dealer. Please
do not attempt to disassemble this product by yourself.
Safety Notice
No. Checklist Quantity
1. Tablet 1
2. Pen 1
3. Pen Tip Refills 2
4. AAA Batteries 1
5. USB Cable 1
6. CD 3
7. User’s Manual 1
Check Your Package Contents

5
USB TABLET
EN
Chapter 1: Installation
Software
Installation procedure:
Insert the installation CD into your CD-ROM drive.
After the setup appears, click on the first item to install.
Follow the on-screen instructions to complete the installation.
Note: If the installation does not start automatically, it may be
manually started by double-clinking on:
[My Computer] → [CD-ROM Drive] → [Setup.exe].
Hardware
Step 1 Connecting the tablet to your PC
Plug the USB cable into the USB port of your PC, and
a tablet icon will appear in the system tray.
Step 2 Checking the power indicator
Check the LED indicator on the tablet. If the indicator
light is flashing green, then your tablet is successfully
powered.
Step 3 Installing the battery
Unscrew the pen cap and insert one AAA battery into
the battery compartment, positioning the + and - ends
as shown below. Then replace the cap.
Note:
1. The battery life span is around one year.
2. If the pen tip is worn out after long period of usage, please use the
tweezers to pull out the old pen tip and install a new one.

6
USB TABLET
Chapter 2: Getting Started
Click on the tablet icon in the bottom-right
system tray. (The tablet icon will appear when
the USB cable is plugged in.)
Check the LED indicator on
the tablet. If the indicator
light is flashing green, then
your tablet is successfully
powered.
Using the Pen
Side buttons
Click on the “Buttons” tab to customize
side buttons.
Click Pressure
Move the slider up and down to adjust the pen pressure. You can
also press “Test” to set the value for pen tip pressure.
Mouse
The pen is used as a normal handwriting
pen or mouse. To change mode, select
“Pen” or “Mouse”.
Please put your pen on the hollow area of
the tablet while idle. If you place the pen
on the tablet, the mouse may be seriously affected.
Step 1
Step 2
Default settings
Side Button 1 = right click
Side Button 2 = double-click
The Pen Point = left click

7
USB TABLET
EN
Using the Tablet
Select the function keys
Your tablet offers default settings for function keys (shortcut keys).
To bring up the configuration window, click on the tablet icon in
the system tray.
1. Click the Function Key icon
on the tool bar.
2. Browse or key in the path of
URL.
3. Click “OK”.
Steps

8
USB TABLET
Chapter 3: Q & A
No. Question Answer
1. Is the USB Tablet compatible with
MAC system?
Only for OS 10.2.5~10.4 versions now.
2. Standard mouse cursor does not
move on the screen.
Do not put the wireless pen or mouse on
the tablet.
3. The tablet cannot work with other
PC peripherals.
Please go to upgrade new driver.
4. What is proximity?
It is the height between the wireless pen
and the tablet. You can determine by
checking the LED:
Flashing green: Normal power-on status.
Steady green: The pen is within the
sensible range of the tablet.
No light: The pen tip is pressing on the
tablet.
5. Which items should not be placed
on the tablet?
Heavy objects or devices emitting RF
frequency.
6. PC monitor shows interference
when the tablet is situated nearby.
Move the tablet away from the PC
monitor.
7. After using the pen for about
one year, the pen shows signs of
leaking.
1. Please check the battery power.
2. Enter the tablet configuration panel and
click on the “Buttons” tab, Then select
the “Pen offset value” item to test the
pen.
3. If method 2 does not solve the problem,
please reinstall or update the driver.
8. The tablet disconnects from the
PC.
Reconnect the USB cable.

9
USB TABLET
EN
Active area (W x D) 6” x 4.5” (152 x 110mm)
Physical size (W x D x H) 9.25” x 9.64” x 4.72” (235 x 245 x 12mm)
Technology Electromagnetic
Power Supply USB port (DC 5V ± 5% regulated)
Weight 0.85 lbs. (388g)
Resolution Max 2000 lpi
Accuracy (overall with pen) 0.42mm
Max. Pressure Level 1024 levels
Maximum reading height 0.32” (8mm)
Communication interface USB BUS
Cable length 6 Feet (1.8 Meters)
Connector USB Plug
Certification FCC, CE
System Requirements
OS Microsoft Windows XP/2000 & Mac OS 10.2.5~10.4 versions
CPU speed Pentium 200MHz or compatible CPU
Interface An available USB port
Memory 32MB system memory
Drive CD-ROM or DVD-ROM
Specifications
