GeoVision GV-BL120D User manual

GV-IP Camera
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Bullet Camera
Ultra Bullet Camera
Target Bullet Camera
ICH265HISI2V10-A
Quick Start Guide

Caution
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Safety Notice
The GV-IPCAM uses a Lithium battery as the power supply for its internal
real-time clock (RTC). The battery should not be replaced unless required!
If the battery does need replacing, please observe the following:
Danger of Explosion if battery is incorrectly replaced
Replace only with the same or equivalent battery, as recommended by
the manufacturer
Dispose of used batteries according to the manufacturer's instructions

© 2017 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in
part, without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice. Note: no memory card slot or local
storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows is the
registered trademark of Microsoft Corporation.
June 2017
i

Contents
Contents ..............................................................................i
Options .............................................................................. v
Note for Adjusting Focus and Zoom.............................. vi
Note for Installing Camera Outdoor.............................. vii
Note for Closing the Bullet Camera Cover .................. viii
Note for Silica Gel Bags ................................................ viii
Note for Waterproofing Failures......................................ix
Note for Recording ............................................................x
Chapter 1 Bullet Camera (Part I)......................................1
1.1 Packing List ..............................................................................3
1.2 Overview ..................................................................................4
1.3 Installation ................................................................................5
1.3.1 Connecting the Camera ...............................................7
1.3.2 Adjusting the Angles ..................................................12
1.3.3 Adjusting Lens and Inserting a Memory Card.............16
1.3.4 Installing the Sun-Shield Cover ..................................19
1.4 Loading Factory Default..........................................................20
1.4.1 Using the Web Interface.............................................20
1.4.2 Directly on the Camera ..............................................21
Chapter 2 Bullet Camera (Part II)...................................22
2.1 Packing List ............................................................................24
2.2 Overview ................................................................................25
2.3 Installation ..............................................................................27
i

2.4 Connecting the Camera..........................................................34
Chapter 3 Bullet Camera (Part III)..................................36
3.1 Packing List ............................................................................37
3.2 Overview ................................................................................38
3.3 Installation ..............................................................................39
3.3.1 Adjusting the Angles ..................................................43
3.3.2 Adjusting Lens ...........................................................45
3.4 Connecting the Camera..........................................................46
3.4.1 Wire Definition ...........................................................46
3.4.2. Power Connection.....................................................47
3.5 Loading Factory Default..........................................................49
3.5.1. Using the Web Interface............................................49
3.5.2. Directly on the Camera .............................................49
Chapter 4 Ultra Bullet Camera.......................................50
4.1 Packing List ............................................................................52
4.2 Overview ................................................................................53
4.3 Installation ..............................................................................55
4.3.1 Waterproofing the Cable ............................................60
4.3.2 Connecting the Camera .............................................62
4.4 Loading Factory Default..........................................................65
4.4.1 Using the Web Interface.............................................65
4.4.2 Directly on the Camera ..............................................65
Chapter 5 Target Bullet Camera (Part I)........................66
5.1 Packing List ............................................................................67
5.2 Overview ................................................................................68
5.3 Installation ..............................................................................69
5.4 Connecting the Camera..........................................................73
5.4.1 Wire Definition ...........................................................73
5.4.2 Power Connection......................................................74
5.5 Loading Factory Default..........................................................75
ii

5.5.1 Using the Web Interface.............................................75
5.5.2 Directly on the Camera ..............................................76
Chapter 6 Target Bullet Camera (Part II).......................77
6.1 Packing List ............................................................................78
6.2 Overview ................................................................................79
6.3 Installation ..............................................................................80
6.3.1 Adjusting the Angles ..................................................85
6.3.2 Adjusting Lens ...........................................................86
6.4 Connecting the Camera..........................................................87
6.4.1 Wire Definition ...........................................................87
6.4.2 Power Connection......................................................88
6.5 Loading Factory Default..........................................................89
6.5.1 Using the Web Interface.............................................89
6.5.2 Directly on the Camera ..............................................89
Chapter 7 Target Bullet Camera (Part III)......................90
7.1 Packing List ............................................................................91
7.2 Overview ................................................................................92
7.3 Installation ..............................................................................93
7.4 Connecting the Camera..........................................................94
7.4.1 Wire Definition ...........................................................94
7.4.2 Power Connection......................................................94
7.5 Loading Factory Default..........................................................95
7.5.1 Using the Web Interface.............................................95
7.5.2 Directly on the Camera ..............................................95
Chapter 8 Accessing the Camera..................................96
8.1 System Requirement ..............................................................96
8.2 Accessing the Live View .........................................................97
8.2.1 Checking the Dynamic IP Address .............................98
8.2.2 Configuring the IP Address ......................................100
8.3 Adjusting Image Clarity.........................................................102
iii

iv
Chapter 9 The Web Interface .......................................105
Chapter 10 Upgrading System Firmware ...................108

Options
Optional devices can expand your camera’s capabilities and versatility.
Contact your dealer for more information.
Device Description
The power adapter is available for all Bullet Camera,
Ultra Bullet Camera (except GV-BL2511-E / 5311-E),
and Target Bullet Camera. Contact your sales
representative for the countries and areas supported.
Power Adapter
The GV-PA191 PoE adapter is designed to provide
power and network connection to the cameras over a
single Ethernet cable.
GV-PA191 PoE
Adapter
The GV-Relay V2 is designed to expand the voltage
load of GV IP devices. It provides 4 relay outputs, and
each can be set as normally open (NO) or normally
closed (NC) independently as per your requirement.
GV-Relay V2
The GV-POE Switch is designed to provide power
along with network connection for IP devices. The
GV-POE Switch is available in various models with
different numbers and types of ports.
GV-POE Switch
GV-Mount
Accessories
The GV-Mount Accessories provide a comprehensive
lineup of accessories for installation on ceiling, wall
corner and pole. For details, see GV-Mount
Accessories Installation Guide on the Software DVD.
v

Note for Adjusting Focus and Zoom
When adjusting the Focus and Zoom Screws on Bullet Camera, do not
over tighten the Focus and Zoom screws. The screws only need to be as
tight as your finger can do it. It is not necessary to use any tools to get
them tighter. Doing so can damage the structure of lens.
For example,
Zoom Screw
Focus Screw
The maximum torque value for all the zoom and focus screws is 0.049 N.m
vi

Note for Installing Camera Outdoor
When installing the cameras outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from
entering the camera along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using
waterproof silicon rubber or the like.
vii

Note for Closing the Bullet Camera
Cover
To ensure that the camera performs its full capacity against water and dust,
tightly close and lock the camera cover as indicated below.
Note for Silica Gel Bags
1. The silica gel bag loses its effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel
bag every time you open the camera, and conceal the gel bag in
camera within 2 minutes of exposing to open air.
2. When the camera is shipped, a silica gel bag will be included inside
the camera. For the first-time user, replace the silica gel bag prior to
the installation to avoid foggy live view.
viii

ix
Note for Waterproofing Failures
To avoid waterproofing failures, do not open the screw on the camera body.
The screw on Ultra Bullet
Camera
The screw on Target Bullet
Camera
The screw on GV-EBL2101 /
2111 / 3101 / 5101
The screw on GV-BL3700 /
5700

Note for Recording
1. By default, the images are recorded to the memory card inserted in
the GV-IP Camera (except GV-IR Arctic Box Camera and Target
Series, which are not equipped with a memory card slot). Make sure
the Write recording data into local storage option (see 4.1.1
Video Settings, GV-IPCam Firmware Manual) is enabled. If this
option is disabled, the camera will stop recording to the memory
card while the live view is accessed through Web browsers or other
applications.
2. Mind the following when using a memory card for recording:
Recorded data on the memory card can be damaged or lost if
the data are accessed while the camera is under physical shock,
power interruption, memory card detachment or when the
memory card reaches the end of its lifespan. No guarantee is
provided for such causes.
The stored data can be lost if the memory card is not accessed
for a long period of time. Back up your data periodically if you
seldom access the memory card.
Memory cards are expendable and their durability varies
according to the conditions of the installed site and how they are
used. Back up your data regularly and replace the memory card
annually.
Replace the memory card when its read/write speed is lower
than 6 MB/s or when the memory card is frequently undetected
by the camera.
3. It is recommended to use memory cards of the following setting and
specifications:
Apply a battery backup (UPS) to avoid power outage.
Use Micro SD card of MLC NAND flash, Class 10 for better
performance.
x

Bullet Camera (Part I)
1
Chapter 1 Bullet Camera (Part I)
The Bullet Cameras are specifically designed for outdoors and are
weatherproof (IP66 or IP67). They are equipped with IR LEDs for infrared
illumination in night vision applications. The models described in this
chapter use auto iris, which allows for automatic control of exposure.
The WDR Pro models enhance the image by processing contrasting
intensity of light. The super low lux models can produce color live view in
near darkness. The motorized varifocal lens models allow the user to
adjust the focus and zoom through the Web interface.
1

Model No. Specifications Description
GV-BL120D 1.3 MP, H.264, Low Lux
GV-BL130D 1.3 MP, H.264
GV-BL220D 2 MP, H.264
GV-BL320D 3 MP, H.264
GV-BL1500 1.3 MP, H.264, Super
Low Lux
GV-BL2400 2 MP, H.264, WDR Pro
Varifocal
lens
Auto Iris, f: 3 ~ 9
mm, F/1.2, 1/2.7’’
ø 14 mm Lens
Mount
2 MP, H.264, Super Low
Lux
GV-BL2500
GV-BL3400 3 MP, H.264, WDR Pro
1.3 MP, H.264, Low Lux,
3X Optical Zoom
GV-BL1210
GV-BL2410 2 MP, H.264, WDR Pro,
3X Optical Zoom
Auto Iris,
f: 3 ~ 9 mm,
F/1.2, 1/2.7’’
ø 14 mm Lens
Mount
GV-BL3410 3 MP, H.264, WDR Pro,
3X Optical Zoom
Motorized
varifocal
lens
Auto Iris,
f: 4.5 ~ 9 mm,
F/1.2, 1/2.7’’
ø 14 mm Lens
Mount
5 MP, H.264, 2X Optical
Zoom
GV-BL5310
2

Bullet Camera (Part I)
1
1.1 Packing List
Bullet Camera
Self Tapping Screw x 3
Plastic Screw Anchor x 3
Torx Wrench x 2
Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screw x 2,
Plastic Screw Spacer x 2 and Hexagon Screw x 2)
Silica Gel Bag x 2
2-Pin Terminal Block
Power Adapter
GV-IPCAM Software DVD
GV-NVR Software DVD
Warranty Card
Note: The power adapter can be excluded upon request.
3

1.2 Overview
12 3 4
Figure 1-1
No. Name Description
Receives a micro SD card (SD/SDHC,
version 2.0 only, Class 10).
1 Memory Card Slot
2 Zoom Screw Holds the zoom lens in place.
3 Focus Screw Holds the focus lens in place
4 Default Button Resets all configurations to factory default.
For details, see 1.4 Loading Factory Default.
4

Bullet Camera (Part I)
1
1.3 Installation
These instructions describe the basic installation of the Bullet Camera.
1. Slide the cable clamp to the camera base.
Cable Clamp
Figure 1-2
2. Install the Bullet Camera to the wall.
Figure 1-3
3. Remove the protection sticker from the camera’s cover
4. Connect the power, network and other wires to the Bullet Camera.
See 1.3.1 Connecting the Camera.
5

5. Access the live view. For details, see 8.2Accessing the Live View.
6. Adjust angles of the camera body based on the live view. Three
shafts can be adjusted. See 1.3.2 Adjusting the Angles.
7. Loosen the camera’s cover, adjust the focus of the camera and
optionally insert a micro SD card (SD/SDHC, version 2.0, Class 10)
into the SD card slot. See 1.3.3 Adjusting Lens and Inserting a
Memory Card.
8. Fasten the camera’s cover.
9. Install the sun-shield cover to the Bullet Camera. For details, see
1.3.4 Installing the Sun-Shield Cover.
6

Bullet Camera (Part I)
1
1.3.1 Connecting the Camera
Wire Definition for Auto Iris Models
The 7-Pin Data Cable provides connections for power, ground, 1 sensor
input, 1 alarm output, audio input and audio output. The wires are
illustrated and defined below:
Ethernet (PoE)
Digital In (Red)
DC 12V+ / AC 24V + (Brown)
Digital Out (Orange)
DC 12V- / AC 24V - (Black)
GND (Yellow)
Audio In (Red)
Audio Out (Green)
Figure 1-4
No. Wire Color Definition
1 Red Digital In
2 Brown DC 12V+ / AC 24V+
3 Orange Digital Out
4 Black DC 12V- / AC 24V-
5 Yellow Ground
6 Red RCA Audio in
7 Green RCA Audio out
7
