GeoVision GV-BX Series User manual

alarm shop

© 2011 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in
part, without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows and Windows
XP are registered trademarks of Microsoft Corporation.
January 2011
alarm shop

Contents
Introduction .................................................................................iii
Options ........................................................................................vi
Note for Connecting to GV-System ..........................................vii
Note for Adjusting Focus and Zoom .......................................viii
1. Box Camera ..............................................................................1
1.1 Packing List................................................................................. 1
1.2 Overview ..................................................................................... 2
1.3 Accessory Installation ................................................................. 5
1.3.1 C-Mount Lenses ..................................................................5
1.3.2 Infrared Illuminators.............................................................7
1.4 Connecting the Camera .............................................................. 9
2. Mini Fixed Dome.....................................................................13
2.1 Packing List............................................................................... 13
2.2 Overview ................................................................................... 14
2.3 Installation................................................................................. 15
2.4 Adjusting the Focus .................................................................. 16
3. Bullet Camera .........................................................................17
3.1 Packing List............................................................................... 17
3.2 Overview ................................................................................... 18
3.3 Installation................................................................................. 19
3.3.1 Adjusting the Angles..........................................................20
3.3.2 Adjusting Lens and Inserting a Memory Card....................23
3.3.3 Inserting the Sun-Shield Cover..........................................25
3.4 Connecting the Camera ............................................................ 26
3.4.1 Wire Definition ...................................................................26
3.4.2 Connecting the Power Cable.............................................27
3.4.3 Applying Waterproof Treatment.........................................27
i
alarm shop

4. Vandal Proof IP Dome............................................................29
4.1 Packing List............................................................................... 29
4.2 Overview ................................................................................... 31
4.3 Installation................................................................................. 32
4.3.1 Hard-Ceiling Mount ...........................................................32
4.3.2 In-Ceiling Mount ................................................................37
4.3.3 Wall-Pendent Mount..........................................................40
4.4 Connecting the Camera ............................................................ 43
4.4.1 Wire Definition ...................................................................43
4.4.2 Connecting the Power Cable.............................................44
5. Fixed IP Dome ........................................................................45
5.1 Packing List............................................................................... 45
5.2 Overview ................................................................................... 46
5.3 Installation................................................................................. 48
5.3.1 Hard-Ceiling Mount ...........................................................48
5.3.2 Wall-Surface Mount...........................................................52
5.3.3 Wall-Pendent Mount..........................................................53
5.4 Connecting the Camera ............................................................ 55
6. Cube Camera ..........................................................................57
6.1 Packing List............................................................................... 57
6.2 Overview ................................................................................... 58
6.3 Installation................................................................................. 59
6.4 Connecting the Camera ............................................................ 60
7. Accessing the Camera...........................................................61
7.1 System Requirement ................................................................ 61
7.2 Assigning an IP Address........................................................... 62
8. The Web Interface ..................................................................65
9. Upgrading System Firmware.................................................67
10 Restoring to Default Settings...............................................69
10.1 Using the Web Interface ......................................................... 69
10.2 Directly on the Camera ........................................................... 70
ii
alarm shop

Introduction
Welcome to the GV-IPCam H.264 Quick Start Guide. In this quick guide,
you will find information on the installation and basic configurations of the
Box Camera, Mini Fixed Dome, Bullet Camera, Vandal Proof IP Dome,
Fixed IP Dome and Cube Camera.
Model Model No. Description
Fixed
Lens
GV-BX110D Varifocal
Lens
1.3 M H.264 D/N
Box IP Cam
GV-BX120D Varifocal
Lens
1.3 M H.264 Low
Lux D/N Box IP Cam
GV-BX220D-0
2 M H.264 D/N Box
IP Cam, Auto Iris IR,
f: 2.8 ~ 8.5 mm,
F/1.4, 1/3” CS Lens
GV-BX220D-1
2 M H.264 D/N Box
IP Cam, Auto Iris IR,
f: 3.1 ~ 8 mm,
F/1.2, 1/3’’ CS Lens
GV-BX220D-2
2 M H.264 D/N Box
IP Cam, Auto Iris IR,
f: 2.8 ~ 6 mm,
F/1.3, 1/3’’ CS Lens
Box
Camera
GV-BX220D-3
Varifocal
Lens
2 M H.264 D/N Box
IP Cam, Auto Iris IR,
f: 2.8 ~ 12 mm,
F/1.4, 1/3’’ CS Lens
iii
alarm shop

GV-BX320D-0
3 M H.264 D/N
Box IP Cam
f: 3.1 ~ 8 mm,
F/1.2, 1/3’’ CS Lens
GV-BX320D-1
Varifocal
Lens 3 M H.264 D/N
Box IP Cam
f: 2.8 ~ 6 mm, F/1.3,
1/3’’ CS Lens
Mini
Fixed
Dome
GV-MFD110 Fixed
Lens
1.3 M H.264 Color
Mini Fixed Dome
GV-BL110D 1.3 M H.264 IR
Bullet IP Cam
GV-BL120D 1.3 M H.264 Low
Lux IR Bullet IP Cam
GV-BL220D 2 M H.264 IR
Bullet IP Cam
Bullet
Camera
GV-BL320D
Varifocal
Lens
3 M H.264 IR
Bullet IP Cam
Vandal
Proof IP
Dome
GV-VD120D
(IK10+, Transparent Cover)
GV-VD121D
(IK10+, Smoked Cover)
GV-VD122D
(Transparent Cover)
GV-VD123D
(Smoked Cover)
Varifocal
Lens
1.3 M H.264 Low
Lux IR Vandal Proof
IP Dome
iv
alarm shop

GV-VD220D
(IK10+, Transparent Cover)
GV-VD221D
(IK10+, Smoked Cover)
GV-VD222D
(Transparent Cover)
GV-VD223D
(Smoked Cover)
2 M H.264 IR
Vandal Proof IP
Dome
Vandal
Proof IP
Dome GV-VD320D
(IK10+, Transparent Cover)
GV-VD321D
(IK10+, Smoked Cover)
GV-VD322D
(Transparent Cover)
GV-VD323D
(Smoked Cover)
Varifocal
Lens
3 M H.264 IR
Vandal Proof IP
Dome
GV-FD120D
1.3 M H.264 Low
Lux IR Fixed IP
Dome
GV-FD220D 2 M H.264 IR
Fixed IP Dome
Fixed IP
Dome
GV-FD320D
Varifocal
Lens
3 M H.264 IR
Fixed IP Dome
GV-CB120 1.3 M H.264
Cube Camera
Cube
Camera
GV-CB220
Fixed
Lens 2 M H.264
Cube Camera
For a detailed user’s manual, see GV-IPCam H.264 User’s Manual on the
software CD.
v
alarm shop

vi
Options
Optional devices can expand your camera’s capabilities and versatility.
Contact your dealer for more information.
Device Description
GV-IR LED
A mountable infrared LED device that improves
image performance of Box Cameras under low
light conditions. Note that the GV-IR LED is only
compatible with GV-BX110D and GV-IR LED T2 is
compatible with GV-BX120D / 220D-0 / 220D-1 /
220D-2 / 220D-3 / 320D-0 / 320D-1.
GV-PA191 PoE
Adapter
The GV-PA191 PoE adapter is designed to
provide power and network connection to the
cameras over a single Ethernet cable.
Wall Mount Bracket An L-shaped bracket designed for wall mount
installation of the Vandal Proof IP Dome and the
Fixed IP Dome.
Housing Cover The housing cover is designed for Vandal Proof IP
Dome to provide shielding to the camera. Two
types are available: transparent and smoked.
alarm shop

Note for Connecting to GV-System
The GV-IPCAM H.264 is designed to work with GV-System, a hybrid or
digital video management system. Note the following when GV-IPCAM
H.264 is connected to GV-System:
1. Normally, the images are recorded to the memory card inserted in the
Box Camera, Bullet Camera, Vandal Proof IP Dome, Fixed IP
Dome and Cube Camera. Once the camera is connected to
GV-System for video management or the camera’s Live View is
accessed through the Web browser (see 7. Accessing the Camera in
the Quick Start Guide), the recording to the memory card will be
stopped and the recording will be taken control by GV-System. When
the connection between the camera and GV-System is interrupted, the
recording to the memory card will be resumed to back up the images
on the camera.
2. Once the camera is connected to GV-System, the resolution set on
GV-System will override the resolution set on the camera’s Web
interface. You can only change the resolution settings through the
Web interface when the connection to GV-System is interrupted.
vii
alarm shop

Note for Adjusting Focus and
Zoom
When adjusting the Focus and Zoom Screws (on Box Camera, Mini Fixed
Dome, Bullet Camera, Vandal Proof IP Dome and Fixed IP Camera),
please do not over tighten the Focus and Zoom screws. The screws only
need to be as tight as your finger can do it; don't bother using any tools to
get them tighter. Doing so can damage the structure of lens.
For example,
Bullet Camera Fixed IP Camera
viii
alarm shop

1. Box Camera
1.1 Packing List
•Box Camera
•Terminal Block
•Fixed Focal or Varifocal Megapixel Lens
•C-mount Lens Adapter (BX110D only)
•Lens Rings (BX120D, BX220D-0 / 220D-1 / 220D-2 / 220D-3,
BX320D-0 / 320D-1 only)
•Video Out Wire (BX120D, BX220D-0 / 220D-1 / 220D-2 / 220D-3,
BX320D-0 / 320D-1 only)
•DC 12V Power Adapter
•GV-IPCAM H.264 Software CD
•GV-IPCAM H.264 Quick Start Guide
•GV-NVR Software DVD
•GV-NVR Quick Start Guide
alarm shop

1.2 Overview
GV-BX110D
2
alarm shop

Box Camera
1
No. Name Description
1 Audio Out Connects a speaker for audio output.
2 Audio In Connects a microphone for audio input.
3 Default
Resets all configurations to factory default.
See 10. Restoring to Default Settings later
in the Quick Start Guide.
4 Memory Card Slot Inserts a micro SD/SDHC card to store
recording data.
5 Video Out
Connects to a portable monitor for setting
the focus and angle of Box Camera during
initial installation.
6 I/O Terminal Block
Connects I/O devices. For details, see I/O
Terminal Block, Box Camera chapter
GV-IPCam H.264 User’s Manual on the
software CD.
7 LAN / PoE Connects to a 10/100 Ethernet or PoE.
8 DC 12V Connector Connects to power.
9 Status LED Reflects system status of the camera. See
the table below.
10 Microphone Records the sounds.
11 Auto Iris Connector If the varifocal lens is in use, plug the iris
control cable to the connector.
Status LED Description
Red Light ON The system powers on and succeeds to
boot up.
Flashing Red and Green
Lights
The camera is ready for use with network
connectivity.
Green Light ON Error occurs on the system.
3
alarm shop

GV-BX120D / 220D-0 / 220D-1 / 220D-2 / 220D-3 / 320D-0 /
320D-1
11
12
No. Name Description
1 Video Out
Connects to a portable monitor for setting
the focus and angle of Box Camera during
initial installation.
2 Memory Card Slot Inserts a micro SD/SDHC card to store
recording data.
3 Audio Out Connects a speaker for audio output.
4 Audio In Connects a microphone for audio input.
5 I/O Terminal Block
Connects I/O devices. For details, see I/O
Terminal Block, Box Camera chapter,
GV-IPCam H.264 User’s Manual on the
software CD.
6 Power LED Indicates the power is supplied.
7 Default
Resets all configurations to factory default.
See 10. Restoring to Default Settings later
in the Quick Start Guide.
8 LAN / PoE Connects to a 10/100 Ethernet or PoE.
9 DC 12V Port Connects to power.
10 Auto Iris Connector Plug the iris control cable to the connector.
11 Microphone Records the sounds.
12 Status LED Turns on when the unit is ready for use.
4
alarm shop

Box Camera
1
1.3 Accessory Installation
1.3.1 C-Mount Lenses
When you use a C-mount lens, it requires a certain distance from the
camera’s imaging chip; otherwise it will not be possible to focus the lens.
Mount the supplied C-mount lens adapter / lens ring to the camera, and
then attach the lens onto the camera body.
GV-BX110D
Install the supplied C-mount lens adapter to extend focal length for
GV-BX110D as illustrated below.
5
alarm shop

GV-BX120D / 220D-0 / 220D-1 / 220D-2 / 220D-3 / 320D-0 / 320D-1
The supplied lens rings for GV-BX120D / 220D-0 / 220D-1 / 220D-2 /
220D-3 / 320D-0 / 320D-1 include 3 sizes in thickness:
•0.188 mm (transparent color) x 2
•0.125 mm (black color with a glossy surface) x 2
•0.254 mm (black color with a matt surface) x 2
Note: These lens rings are specially designed for varifocal models of
GV-BX120D / 220D-0 / 220D-1 / 220D-2 / 220D-3 / 320D-0 / 320D-1.
Besides the supplied 6 units, each varifocal model has already been
installed with a 0.188 mm lens ring.
6
alarm shop

Box Camera
1
1.3.2 Infrared Illuminators (GV-IR LED / GV-IR LED T2)
1. Connect the infrared illuminator to the terminal block on the camera.
See I/O Terminal Block, Box Camera chapter, GV-IPCam H.264
User’s Manual on the software CD, or GV-IR LED User’s Manual.
2. Access the Web interface of the camera.
3. Select Video and Motion, select Video Settings, select Streaming 1
and set the IR Check Function option to be Trigger by Input (for
GV-IR LED) or Trigger IR by D/N (for GV-IR LED T2).
GV-IR LED
7
alarm shop

GV-IR LED T2
4. Click Apply.
For Trigger by Input and Trigger IR by D/N functions, see the Video
Settings section, Administrator Mode chapter in the GV-IPCam H.264
User’s Manual in the software CD.
8
alarm shop

Box Camera
1
1.4 Connecting the Camera
The Box Camera is designed for indoor use. Please make sure the
installing site is shielded from rain and moisture.
GV-BX110D
1. If you are using the varifocal lens model, plug the iris control cable to
the Auto Iris Connector on the camera.
2. Use a standard network cable to connect the camera to your network.
3. Optionally connect a speaker and an external microphone.
9
alarm shop

4. Optionally connect a monitor using an RCA video-out wire. If your
signal format is PAL, configure the TV Out setting on its Web interface.
See TV Out setting, in the Video Settings section, Administrator Mode
chapter, GV-IPCam H.264 User’s Manual on the software CD.
5. Connect power using one of the following methods:
•plugging the supplied power adapter to the DC jack.
•using the Power over Ethernet (PoE) function and the power will be
provided over the network cable.
6. The status LED of the camera will be red. Then you can set the IP
address for the unit. See 7. Accessing the Camera in the Quick Start
Guide.
10
alarm shop
