GeoVision GV-IPCam Series User manual

Hardware Manual
GV-IPCam H.264
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Target Camera Series
ICH264TIV301

© 2015 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in
part, without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice. Note: no memory card slot or local
storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows and Windows
XP are registered trademarks of Microsoft Corporation.
April 2015

Content
Content ................................................................................i
Options ..............................................................................iii
Note for Installing Camera Outdoor............................... iv
Chapter 1 Target Box Camera .........................................1
1.1 Packing List ..............................................................................1
1.2 Features ...................................................................................2
1.3 Overview ..................................................................................3
1.4 Installation ................................................................................4
1.5 Connecting the Camera............................................................6
1.6 Loading Factory Default............................................................7
Chapter 2 Target Bullet Camera ......................................8
2.1 Packing List ..............................................................................8
2.2 Features ...................................................................................9
2.3 Overview ................................................................................10
2.4 Installation ..............................................................................12
2.5 Connecting the Camera..........................................................15
2.6 Loading Factory Default..........................................................17
Chapter 3 Target Mini Fixed Dome................................18
3.1 Packing List ............................................................................18
3.2 Features .................................................................................19
i

3.3 Overview ................................................................................20
3.4 Installation ..............................................................................21
3.5 Connecting the Camera..........................................................24
3.6 Loading Factory Default..........................................................25
Chapter 4 Target Mini Fixed Rugged Dome .................26
4.1 Packing List ............................................................................27
4.2 Features .................................................................................29
4.3 Overview ................................................................................31
4.4 Installation ..............................................................................32
4.5 Connecting the Camera..........................................................39
4.6Loading Factory Default ..........................................................40
ii

Options
Optional devices can expand your camera’s capabilities and versatility.
Contact your dealer for more information.
Device Description
Power Adapter
The power adapter is available for Target Box
Camera, Target Bullet Camera, Target Mini Fixed
Dome, and Target Mini Fixed Rugged Dome. The
supported regions include:
•GV-EBL: Australia, Brazil, Europe, U.K., and
U.S
•GV-EBX, GV-EFD, GV-EDR: Australia, Europe,
U.K, U.S.A
GV-PA191 PoE
Adapter
The GV-PA191 PoE adapter is designed to provide
power and network connection to the cameras over
a single Ethernet cable.
GV-POE Switch
The GV-POE Switch is designed to provide power
along with network connection for IP devices. The
GV-POE Switch is available in various models with
different numbers and types of ports.
GV-Mount
Accessories
The GV-Mount Accessories provide a
comprehensive lineup of accessories for installation
on ceiling, wall corner and pole. For details, see GV-
Mount Accessories Installation Guide on the
Software DVD.
Plastic PG21
Conduit
Connector
The plastic PG21 conduit connector is used for
running the wires of Target Mini Fixed Rugged
Dome through a 1/2” conduit pipe.
iii

iv
Note for Installing Camera Outdoor
When installing the Target Mini Fixed Rugged Dome outdoor, be sure
that:
1. The camera is set up above the junction box to prevent water from
entering the camera along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using
waterproof silicon rubber or the like.
3. The silica gel bag loses its effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel bag
every time you open the camera, and conceal the gel bag in camera
within 2 minutes of exposing to open air.

Target Box Camera
1
Chapter 1 Target Box Camera
The Target Box Camera (GV-EBX) is a series of light-weighted cameras
designed for indoor usage. Equipped with IRcut filter and builtin IR LEDs,
the camera is an entry-level surveillance solution with all the essential
features and excellent image quality. The camera supports PoE and can
be installed intuitively.
Model No. Specifications Description
GV-EBX1100-0F
Fixed Iris, f: 2.8
mm, F/2.0, 1/2.7’’
M12 Mount
GV-EBX1100-2F
Fixed
Lens Fixed Iris, f: 3.8
mm, F/1.8, 1/2.7’’
M12 Mount
1.3 MP, H.264,
Low Lux, D/N
1.1 Packing List
•Target Box Camera
•Supporting Rack
•Screw x 3
•Screw Anchor x 3
•GV-IPCAM H.264 Software DVD
•GV-IPCAM H.264 Quick Start Guide
•GV-NVR Software DVD
•GV-NVR Quick Start Guide
Note: Power adapter can be purchased upon request.
1

1.2 Features
•1/3” progressive scan low lux CMOS for GV-EBX1100 Series
•Dual streams from H.264 or MJPEG
Up to 30 fps at 1280 x 1024 for GV-EBX1100 Series
•Intelligent IR
•Day and night function (with removable IR-cut filter)
•Built-in microphone
•Wide Dynamic Range (WDR)
•Defog
•Motion detection
•Tampering alarm
•Text overlay
•Privacy mask
•IP address filtering
•DC 12V / PoE (IEEE 802.3af)
•Megapixel lens
•NAS Recording
•Recording assigned by GV-Edge Recording Manager (Windows &
Mac)
•Support for iPhone, iPad, Android and 3GPP
•31 languages on Web interface
•ONVIF (Profile S) conformant
Note: For optimal performance and compatibility, it is highly
recommended to use a GV-NAS System.
2

Target Box Camera
1
1.3 Overview
1
4
2
3
Figure 1-1
No. Name Description
1 Default Resets the camera to factory default. For
details, see 1.6 Loading Factory Default.
2 LAN / PoE Connects to a 10/100 Ethernet or PoE.
3 Microphone Records sounds.
4 DC 12V Terminal
Block Connects to power.
LED Indicator Description
Status LED The status LED turns on (green) when the
system is ready for use.
Power LED The power LED turns on (green) when
power is supplied to the camera.
3

1.4 Installation
You can stand the Target Box Camera on a plain surface or install it to wall
and ceiling. Follow the steps below to install, connect and adjust your
Target Box Camera.
1. To install the device on the wall/ceiling, put the supporting rack on the
desired location and make marks for screw anchors.
Figure 1-2
2. Drill the marks and insert the screw anchors.
3. Secure the supporting rack onto the wall/ceiling using the supplied
screws.
4. Secure the camera onto the supporting rack and fasten the indicated
screw.
Figure 1-3
4

Target Box Camera
1
5. Connect the network and power cables to the camera. See 1.5
Connecting the Camera.
6. Access the live view. See 2.1 Accessing the Live View, GV-IPCam
H.264 Firmware Manual.
7. Adjust the angle of the camera based on live view and fasten the
indicated screw.
Figure 1-4
5

1.5 Connecting the Camera
1
2
Figure 1-5
1. Connect power using one of the following methods:
•Plug the power adapter to the 12V terminal block. The power
adapter is an optional device. For detail, see Options in the
manual.
•Use the Power over Ethernet (PoE) function and the power will be
provided over the network cable.
The power and status LEDs shall turn on (green).
2. Use a standard network cable to connect the camera to your network.
3. You are ready to access the live view, adjust the image clarity and
configure the basics. See Getting Started, Chapter 2, GV-IPCam
H.264 Firmware Manual.
6

Target Box Camera
7
1
1.6 Loading Factory Default
1. Keep the power and network cables connected to the camera.
2. Use a pin to press and hold the default button on the back panel of
the camera.
Default button
Figure 1-6
3. Release the default button when the status LED blinks. This shall
take about 8 seconds.
Status LED
Figure 1-7
4. When the status LED fades, the process of loading default settings is
completed and the camera reboots automatically. When the status
LED turns on (green), the camera is ready for use.

Chapter 2 Target Bullet Camera
The Target Bullet Camera (GV-EBL) is a series of light-weighted cameras
designed for outdoor environments. The camera adheres to the IP67
standard and has full protection against dust and jets of water. The camera
offers an entrylevel surveillance solution with all the essential features and
excellent image quality.
Model No. Specifications Description
GV-EBL1100-1F
GV-EBL2100-1F
Fixed Iris, f: 6 mm,
F/1.8, 1/2.7” M12 Mount
GV-EBL1100-2F
GV-EBL2100-2F
Fixed
Lens Fixed Iris, f: 3.8 mm,
F/1.8, 1/2.7” M12 Mount
1.3 MP / 2 MP,
H.264, Low Lux,
D/N
2.1 Packing List
•Target Bullet Camera
•Sun-Shield Cover
•Silica Gel Tape x 2
•Supporting Rack
•Screw x 4
•Screw Anchor x 3
•GV-IPCAM H.264 Software DVD
•GV-IPCAM H.264 Quick Start Guide
•GV-NVR Software DVD
•GV-NVR Quick Start Guide
Note: Power adapter can be purchased upon request.
8

Target Bullet Camera
2
2.2 Features
•1/3” progressive scan low lux CMOS for GV-EBL1100 Series
1/2.8’’ progressive scan low lux CMOS for GV-EBL2100 Series
•Dual streams from H.264 or MJPEG
•Up to 30 fps at 1280 x 1024
Up to 25 fps at 1920 x 1080
•Intelligent IR
•Day and night function (with removable IR-cut filter)
•Wide Dynamic Range (WDR)
•Defog
•Vandal resistance (IK10 for metal casing)
•Ingress protection (IP67)
•Motion detection
•Tampering alarm
•Text overlay
•Privacy mask
•IP address filtering
•DC 12V / PoE (IEEE 802.3af)
•Megapixel lens
•NAS Recording
•Recording assigned by GV-Edge Recording Manager (Windows &
Mac)
•Support for iPhone, iPad, Android and 3GPP
•31 languages on Web interface
•ONVIF (Profile S) conformant
Note: For optimal performance and compatibility, it is highly
recommended to use a GV-NAS System.
9

2.3 Overview
Panel
2
1
Figure 2-1
No. Name Description
1 Power
Connector
Connects to the data cable. For details, see
2.5 Connecting the Camera.
2 Default Button Resets the camera to factory default. For
details, see 2.6 Loading Factory Default.
10

Target Bullet Camera
2
IMPORTANT: The silica gel loses its effectiveness when the camera
cover is opened. If you open the camera to access the load default
button, replace the silica gel tape by taping the new silica gel tape to
the inside of the camera cover. Make sure you conceal the silica gel
tape in the camera within two minutes of exposing to the open air.
11

2.4 Installation
You can install the camera to the ceiling or wall. Follow the steps below.
IMPORTANT: To avoid foggy live view, please replace Silica Gel Tape
prior to installation and use waterproof tape to seal the RJ45 connector.
1. Slide the sun-shield cover onto the top of the camera.
Figure 2-2
Note: The GeoVision logo on the sun-shield cover should be
closer to the front of the camera.
2. Line up the screw hole on the camera with the opening on the sun-
shield cover.
Figure 2-3
12

Target Bullet Camera
2
3. Ceiling Mount:
Secure the supporting rack to the opening on the sun-shield cover
Figure 2-4
4. Wall Mount:
A. Insert and tighten the supplied screw on the sun-shield cover.
B. Secure the supporting rack to the bottom.
Figure 2-5
13

5. Install the camera to the wall or ceiling using the screw anchors and
self-tapping screws. You can also stand the camera on a plain
surface.
Figure 2-6
6. Remove the protection sticker from the camera’s cover.
7. Connect the wires and cable connector to the camera. See 2.5
Connecting the Camera.
8. Access the live view. For details, see 3.1. Accessing the Live View,
GV-IPCam H.264 Firmware Manual.
9. Adjust angles of the camera body based on the live view.
14
