Giant CITY SPEED - V1.0 User manual

CITY SPEED USER GUIDE VERSION 1.0
CAUTION The battery has polarity (+/- sides), so be
sure to install the battery with the + side upward as
shown in the diagram.
!
How to replace the battery
© 2008 Giant Bicycle, Inc. Giant and its symbol are trademarks of Giant Bicycle, Inc. All rights reserved. Printed in Taiwan.
www.giant-bicycles.com
Congratulations on your purchase of a GIANT CITY SPEED.
GIANT CITY SPEED represents the latest in design and
engineering, and also requires special care. While Giant Bicycle
engineers have used the best quality, most durable and lowest
maintenance materials for this CITY SPEED, you must follow
certain guidelines to attain optimal performance and proper
wear characteristics.
WARNING Failure to follow these Instructions will
void your warranty, and may result in hidden damage to
the CITY SPEED. Damage to the CITY SPEED can cause
loss of structural integrity, which may result in serious
personal injury.
!
Front light
Rear light
Front light
Take out the battery holder
from the stem
CAUTION The battery has polarity (+/- sides), so be
sure to install the battery as shown in the diagram.
!
Loosen the battery holder
fixing bolt with 2.5mm Allen
Key
How to replace the batte
ry
Replace the battery (
AA SIZE)
with a new one.
Step 3 :
Battery holder
+
-
Step 1 :
Step 2 :
Fixing bolt
+
-
Rear light
Warranty
Please refer to the Giant Owner’s Manual for complete
provisions of the warranty.
Step 1 :
Handlebar
Handlebar alignment:
CAUTION An insufficiently tightened handlebar
binder bolt may compromise steering action, which
could cause you to lose control and fall. Place the
front wheel of the bicycle between your legs and
attempt to twist the handlebar/stem assembly. If
you can twist the stem in relation to the front
wheel, the bolts are insufficiently tightened.
.
!
Loosen the handlebar binder bolt
with 6mm Allen key to make sure
the handlebar stem is parallel to
the bike’s center line and
clamped tight eno
ugh so that you
can’t twist it out of alignment
Tightening torque: 11.7-14.7 Nm (104-130 In. lbs.)
Loosen the battery holder fixing
bolt with 2.5mm Allen key
Rear light on
the
rear carrier
:
Loosen the battery holder fixing
bolt with 2.5mm Allen key
Step 1 :
Step 1 :
Rear light
WARNING Full composite seat post is NOT
applicable due to the integrated design of seat clamp.
!
Tightening torque:
9.8
-
1
1.7
Nm (
87
-
103
In. lbs.)
Replace the battery (CR2032) with a new one
Step 2 :
Replace the battery (CR2032)
with a new one
Step 2 :
