Giant GLORY 0 - DATASHEET 2 User manual

Spec Features
— FOX 40 FIT RC2 20QR fork w/ 203mm travel, FOX DHX RC4 coil shock
— Complete Shimano Saint M810-series component group
— Giant Contact AM handlebar, Contact DH stem & Contact seatpost
— Wheelset: DT Swiss EX 500 rims/ Shimano Saint hubs
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
frame
SIZES S,M,L
COLOUR Smoke
FRAME ALUXX SL-grade aluminum,
8.0” Maestro suspension
FORK FOX 40 FIT RC2, 20QR, 203mm travel
SHOCK FOX DHX RC4
componentS
HANDLEBAR Giant Contact AM 31.8x750mm
STEM Giant Contact DH direct mount
SEATPOST Giant Contact 30.9x400mm
SADDLE Fi'zi:k Tundra2 w/ K:ium rails
PEDALS Not included
DriVetrain
SHIFTERS Shimano Saint
FRONT DERAILLEUR N/A
REAR DERAILLEUR Shimano Saint short cage
BRAKES Shimano Saint F:203mm / R:180mm
hydraulic disc
BRAKE LEVERS Shimano Saint
CASSETTE Shimano HG80 11-28T 9SPD
CHAIN Shimano HG93
CRANKSET Shimano Saint 38T 170mm
BOTTOM BRACKET Shimano Saint external
WHeeLS
RIMS DT Swiss EX 500 32H
HUBS Shimano Saint w/ Center Lock
F:20QR / R:12mm
SPOKES DT Competiton 14/15g
TIRES Maxxis Minion DH 3C 26x2.5”
EXTRAS MRP G2 Chainguide 38T
Specifications and availability subject to change without notice.
Specifications
Actual
Frame Size Part Number Head Angle Seat Angle* Toptube** Headtube Chainstay Wheelbase Standover
Height***
inches degrees degrees inches inches inches inches inches
S 16 2113100 65.5 65.7 21.9 4.5 17.5 45.1 29.8
M 17 2113101 65.5 59.7 23.8 4.5 17.5 45.5 31.0
L 17.5 2113102 65.5 59.0 25.4 5.1 17.5 46.7 32.2
frame geometry
Glory
A B C D E F G H
$
OFF-road | PERFORMANCE | Downhill
99
