Giant TCR ADVANCED 1 User manual

FASTER. ALWAYS FASTER. IF THIS IS YOUR
MANTRA, YOU’RE NOT ALONE. TCR ADVANCED
SUPPORTS YOUR HABIT.
Its Compact Road Design is often imitated, never duplicated. Its frame, a stunning, lightweight
Advanced-grade composite thing of beauty, is obsessively engineered for unmatched precision.
Its stiff, oversize PowerCore bottom bracket area and OverDrive headtube work together to make
the most of every one of your precious watts.
— SRAM Force drivetrain
— SRAM GXP bottom bracket
— Lighter Mavic Ksyrium SL wheelset
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Specifications and availability subject to change without notice.
Key Upgrades (from TCR Advanced 2)
Frame TechnologySpecifications
Actual
Frame Size Part Number Head Angle Seat Angle* Toptube** Headtube Chainstay Wheelbase Standover Height***
centimeters degrees degrees centimeters centimeters centimeters centimeters inches
XS 43.0 386752 71.0 74.5 52.0 12.0 40.5 97.7 28.5
S 46.5 386753 72.0 73.5 53.5 13.5 40.5 97.4 29.2
M 50.0 386754 73.0 73.0 55.5 15.0 40.5 98.0 30.1
M/L 53.5 386755 73.0 72.0 57.0 17.0 40.5 98.6 31.0
L 55.5 386756 73.0 72.0 58.5 18.5 40.5 100.1 31.7
XL 58.5 386757 73.0 72.0 60.5 20.0 40.5 102.1 32.4
frame geometry
FRAME
SIZES XS,S,M,M/L,L,XL
COLORS White/Red
FRAME Advanced-Grade Composite
FORK Advanced-Grade Composite,
Full Composite OverDrive Steerer
SHOCK N / A
COMPONENTS
HANDLEBAR Giant Contact, 31.8
STEM Giant Contact
SEATPOST Giant Vector Composite
SADDLE Fi'zi:k Arione w/ Manganese rails
PEDALS Not Included
DRIVETRAIN
SHIFTERS SRAM Force
FRONT DERAILLEUR SRAM Force
REAR DERAILLEUR SRAM Force
BRAKES SRAM Force
BRAKE LEVERS SRAM Force
CASSETTE SRAM Force 1070 12x25, 10-speed
CHAIN SRAM PC-1090
CRANKSET SRAM Force Composite, 39/53
BOTTOM BRACKET SRAM GXP, Internal Press Fit
WHEELS
RIMS Mavic Ksyrium SL
HUBS Mavic Ksyrium SL
SPOKES Mavic Ksyrium SL
TIRES Michelin Pro3 Race, 700x23, Folding
EXTRAS
TCR
ADVANCED 1
on-road |performance |Competition
22
