Giant TCR COMPOSITE 1 User manual

TCR composite 1
Specifications and availability subject to change without notice.
Specifications
frame
SIZES XS,S,M,M/L,L,XL
COLOUR White / Black / Red
FRAME Composite
FORK Composite w/ OverDrive steerer
SHOCK N/A
componentS
HANDLEBAR Giant Connect SL 31.8mm
STEM Giant Connect SL
SEATPOST Giant Vector Advanced composite
SADDLE Giant Racing
PEDALS Not included
DriVetrain
SHIFTERS Shimano Ultegra
FRONT DERAILLEUR Shimano Ultegra
REAR DERAILLEUR Shimano Ultegra
BRAKES Shimano 105
BRAKE LEVERS Shimano Ultegra
CASSETTE Shimano 105 12-25T 10SPD
CHAIN Shimano 105
CRANKSET Shimano Ultegra 39/52T
BOTTOM BRACKET Shimano internal press fit
WHeeLS
RIMS DT Swiss R 1900
HUBS DT Swiss
SPOKES DT Swiss
TIRES Michelin Dynamic 700x23c
EXTRAS
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Actual
Frame Size Part Number Head Angle Seat Angle* Toptube** Headtube Chainstay Wheelbase Standover
Height***
centimeters degrees degrees centimeters centimeters centimeters centimeters inches
XS 43.0 2115800 71.0 74.5 52.0 12.0 40.5 97.7 28.5
S 46.5 2115801 72.0 73.5 53.5 13.5 40.5 97.4 29.2
M 50.0 2115802 73.0 73.0 55.5 15.0 40.5 98.0 30.1
M/L 53.5 2115803 73.0 72.0 57.0 17.0 40.5 98.6 31.0
L 55.5 2115804 73.0 72.0 58.5 18.5 40.5 100.1 31.7
XL 58.5 2115805 73.0 72.0 60.5 20.0 40.5 102.1 32.4
frame geometry
Spec Features
— Complete Shimano Ultegra & 105 series component group
— Giant Connect SL handlebar & stem, Vector Advanced composite seatpost
— Wheelset: DT Swiss R 1900
$
A B C D E F G H
on-road | performance | Competition
