Giga-tronics 4506 User manual

Manual 07504506 Model 4506
Page 1
Operation Manual
Model 4506
12(1x4) Multiplexers
90900160

Manual 07504506 Model 4506
Page 2
Operation Manual
All technical data and specifications in this publication are subject to change without prior notice and do
not represent a commitment on the part of Giga-tronics, Incorporated.
© 2011 Giga-tronics Incorporated. All rights reserved. Printed in the U.S.A.
CONTACT INFORMATION
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
Telephone: [phone] (only within the United States)
925.328.4650
Fax: [phone]
On the Internet: www.gigatronics.com
Warranty
Giga-tronics Series 3000 Switching Modules are warranted against
defective materials and workmanship for three yearsfrom date of shipment,
or as detailed in the warranty section of this manual. Giga-tronics will, at its
option, repair or replace products that are proven defective during the
warranty period. This warranty DOES NOT cover damage resulting from
improper use, nor workmanship other than Giga-tronics service. There is no
implied warranty of fitness for a particular purpose, nor is Giga-tronics liable
for any consequential damages. Specification and price change privileges are
reserved by Giga-tronics.

Manual 07504506 Model 4506
Page 3
Operation Manual
Regulatory compliance information
This product complies with the essential requirements of the following applicable European
Directives, and carries the CE mark accordingly.
89/336/EEC and 73/23/EEC
EMC Directive and Low Voltage Directive
EN61010-1 (1993)
Electrical Safety
EN61326-1 (1997)
EMC –Emissions and Immunity
Manufacturer’s Name:
Manufacturer’s Address
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
U.S.A.
Type of Equipment:
Model Series Number
Switching Module
4506
Declaration of Conformity on file. Contact Giga-tronics at the following;
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
Telephone: [phone] (only within the United States)
925.328.4650
Fax: [phone]

Manual 07504506 Model 4506
Page 4
Operation Manual
Record of Changes to This Manual
Use the table below to maintain a permanent record of changes to this document. Corrected
replacement pages are issued as Technical Publication Change Instructions (TPCI). When you
are issued a TPCI, do the following:
1. Insert the TPCI at the front of the manual binder.
2. Remove the pages from the manual binder that are noted in the TPCI.
3. Replace the page(s) removed in the previous step with the corrected page(s).
4. Record the changes in the table below.
TPCI
Number
TPCI Issue
Date
Date Entered
Comments

Manual 07504506 Model 4506
Page 5
Operation Manual
Revision History
Revision
Description of Change
Chg Order #
Approved By
A
Initial Release 10/98
JL
B
Updated
C
Reformatted 3/12
RCW

Manual 07504506 Model 4506
Page 6
Operation Manual
Contents
Contents........................................................................................................................................................ 6
Chapter 1 Introduction ................................................................................................................................. 7
1.1 Safety and Manual Conventions.........................................................................................................7
1.1.1 Product Reference....................................................................................................................... 7
1.1.2 Personal Safety Alert...................................................................................................................7
1.1.3 Equipment Safety Alert ...............................................................................................................7
1.1.4 Notes ........................................................................................................................................... 7
1.1.5 Electrical Safety Precautions ....................................................................................................... 7
Chapter 2 Configuration Table...................................................................................................................... 8
Chapter 3 Functional Description ................................................................................................................. 9
3.1 Introduction........................................................................................................................................9
3.2 General Description............................................................................................................................9
Chapter 4 Block Diagram ............................................................................................................................10
Chapter 6 Specifications .............................................................................................................................11
Chapter 7 Register Map .............................................................................................................................. 12
Chapter 8 Front Panel Connector Pins........................................................................................................17

Manual 07504506 Model 4506
Page 7
Operation Manual
Chapter 1 Introduction
1.1 Safety and Manual Conventions
This manual contains conventions regarding safety and equipment usage as described below.
1.1.1 Product Reference
Throughout this manual, the term “Common Core Switching Platform, Series 8800” refers to all models
of within the series, unless otherwise specified.
1.1.2 Personal Safety Alert
WARNING: Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
1.1.3 Equipment Safety Alert
CAUTION: Indicates a situation which can damage or adversely affect the product or
associated equipment.
1.1.4 Notes
Notes are denoted and used as follows:
NOTE: Highlights or amplifies an essential operating or maintenance procedure, practice, condition or
statement.
1.1.5 Electrical Safety Precautions
Any servicing instructions are for use by service-trained personnel only. To avoid personal injury, do not
perform any service unless you are qualified to do so.
For continued protections against fire hazard, replace the AC line fuse only with a fuse of the same
current rating and type. Do not use repaired fuses or short circuited fuse holders.
WARNING
!
CAUTION

Manual 07504506 Model 4506
Page 8
Operation Manual
Chapter 2 Configuration Table
PL 90900160 4506 Module
PCB PL85002920
WL WL88101670
SCH SCH85002920

Manual 07504506 Model 4506
Page 9
Operation Manual
Chapter 3 Functional Description
3.1 Introduction
This manual provides the necessary information for the operation and maintenance of the Model 4506
General Purpose VXI Switch Module.
3.2 General Description
This card assembly contains twelve 1x4 single wire high power switch multiplexers (trees). These 1x4
multiplexers is capable of carrying 10 amps of load. In each of the 1x4, there is a default position which
is normally closed. During initial turn on or after a reset to the card, the switch trees will be set to the
default position. This will be pole 1 of each tree to the common will be closed. This card assembly fits in
an ASCOR’s series 4000 VXI host modules which can be a 3 wide to 8 wide VXI module with the capacity
for six to 17 card assemblies. This card occupies two 0.5 inch slots or 1 inch width. This allows of ease in
design of complex switch systems. The Series 4000 host VXI module contains sixteen 2-wire analog back
plane to allow connections between card assemblies without the need of external cabling. This
architecture produces a high performance switch system without the usual custom designs or external
wiring and integration efforts. The interface and mechanical construction of the Series 4000 VXI module
and card assemblies meets the specification of the VXIbus System Specification, rev. 1.2 and 1.3.

Manual 07504506 Model 4506
Page 10
Operation Manual
Chapter 4 Block Diagram
Analog Groundplane

Manual 07504506 Model 4506
Page 11
Operation Manual
Chapter 6 Specifications
Electrical:
Switching Voltage : 220VDC, 250VACpk
Switching Current: 20 Amps
Contact Power Rating (Resistive): 280 W or 5000 VA
Bandwidth 1KHz
Breakdown voltage: 1000 Vrms
Contact Resistance: <1 ohm
Mechanical:
Thickness: 1.0 inches
Width: 7.825 inches
Length: 10.75 inches
Weight: 1 lbs.
Connectors:
Connector: Burndy type MS, 50 pin
Environmental Specifications
Temperature:
Operating: 0º to 55ºC
Storage: - 40º to 75ºC
Relative Humidity:
Operating: 0 to 90% non-condensing
Storage: 0 to 95% non-condensing

Manual 07504506 Model 4506
Page 12
Operation Manual
Chapter 7 Register Map
The Model 4506 is a VXI register based card assembly design to be used with the ASCOR Series 4000
host VXI module. The switch paths are controlled by a high speed interface called VXImax™ is a 16/32
bit data controller. The Model 4506 can be programmed in 16 bit or 32 bit wide data format. Through
your VXI controller, write the data to the appropriate register as shown on the register map for the relay
or relays in the register that is being closed. When the data bit is true, the relay chosen will be closed.
The state of the relays in a register can be determined by reading the desired register. The data read
back represents the value at the coil of the relay. This allows verification that the program register has
correctly controlled the relay coil.
The following register maps are shown in two configurations: 16 bit mode and 32 bit mode. In each
section, 16 bit and 32 bit, the register map is organized to show the relay designation in each register. It
is followed by the register’s functionality and the path connections to the front panel.
A16 Register
Offset Value
00h 7Fb5h
7= Register Based, A16/A24 Module
FB5=VXI Manufacturer ID, ASCOR
02h 7D21h
7=A24 space requirement
xxxx= Model Number for this module
04h FFFCh
06h (assigned by Resource Manager)
Control Bit
3Eh 0 Low true output to enable coil driver IC’s
1 When low enables readback of coil state
2 High true EEPROM write enable (factory only)
3-15 Don’t care

Manual 07504506 Model 4506
Page 13
Operation Manual
16 Bit Register:
REGISTER: 8000h
MODE: 16 bit
FUNCTION: Control Matrix K1 through K15, 1x4 #'s 1-5 (note shield is on J1-60, 39, 31, 20 ),
chassis gnd = J1-1
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
1x4 #1
K1
nc to K2, no to K3
1
1x4 #1
K2
com to K1 nc
2
1x4 #1
K3
com to K1 no
3
1x4 #2
K4
nc to K5, no to K6
4
1x4 #2
K5
com to K4 nc
5
1x4 #2
K6
com to K4 no
6
1x4 #3
K7
nc to K8, no to K9
7
1x4 #3
K8
com to K7 nc
8
1x4 #3
K9
com to K7 no
9
1x4 #4
K10
nc to K11, no to K12
10
1x4 #4
K11
com to K10 nc
11
1x4 #4
K12
com to K10 no
12
1x4 #5
K13
nc to K14, no to K15
13
1x4 #5
K14
com to K13 nc
14
1x4 #5
K15
com to K13 no
15
-
-
-
-
REGISTER: 8002h
MODE: 16 bit
FUNCTION: Control Matrix K16 through K30, 1x4 #'s 6-10 (note shield is on J1-60, 39, 31, 20
), chassis gnd = J1-1
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
1x4 #6
K16
nc to K17, no to K18
1
1x4 #6
K17
com to K16 nc
2
1x4 #6
K18
com to K16 no
3
1x4 #7
K19
nc to K20, no to K21
4
1x4 #7
K20
com to K19 nc
5
1x4 #7
K21
com to K19 no
6
1x4 #8
K22
nc to K23, no to K24
7
1x4 #8
K23
com to K22 nc
8
1x4 #8
K24
com to K22 no
9
1x4 #9
K25
nc to K26, no to K27
10
1x4 #9
K26
com to K25 nc
11
1x4 #9
K27
com to K25 no
12
1x4 #10
K28
nc to K29, no to K30
13
1x4 #10
K29
com to K28 nc
14
1x4 #10
K30
com to K28 no
15
-
-
-

Manual 07504506 Model 4506
Page 14
Operation Manual
REGISTER: 8004h
MODE: 16 bit
FUNCTION: Control Matrix K31 through K45, 1x4 #'s 11-15 (note shield is on J2-60, 39, 31, 20
), chassis gnd = J2-1
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
1x4 #11
K31
nc to K32, no to K33
1
1x4 #11
K32
com to K31 nc
2
1x4 #11
K33
com to K31 no
3
1x4 #12
K34
nc to K35, no to K36
4
1x4 #12
K35
com to K34 nc
5
1x4 #12
K36
com to K34 no
6
-
-
-
7
-
-
-
-
8
-
-
-
-
9
-
-
-
-
10
-
-
-
-
11
-
-
-
-
12
-
-
-
-
13
-
-
-
-
14
-
-
-
-
15
-
-
-
-

Manual 07504506 Model 4506
Page 15
Operation Manual
32 Bit Register:
REGISTER: 8000h
MODE: 32 bit
FUNCTION: Control Matrix K1 through K30, 1x4 #'s 1-10 (note shield is on J1-60, 39, 31, 20 ),
chassis gnd = J1-1
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
1x4 #1
com to J1-29
K1
nc to K2, no to K3
1
1x4 #1
nc to J1-30, no to J1-59
K2
com to K1 nc
2
1x4 #1
nc to J1-58, no to J1-28
K3
com to K1 no
3
1x4 #2
com to J1-56
K4
nc to K5, no to K6
4
1x4 #2
nc to J1-57, no to J1-27
K5
com to K4 nc
5
1x4 #2
nc to J1-26, no to J1-55
K6
com to K4 no
6
1x4 #3
com to J1-24
K7
nc to K8, no to K9
7
1x4 #3
nc to J1-25, no to J1-54
K8
com to K7 nc
8
1x4 #3
nc to J1-53, no to J1-23
K9
com to K7 no
9
1x4 #4
com to J1-51
K10
nc to K11, no to K12
10
1x4 #4
nc to J1-52, no to J1-22
K11
com to K10 nc
11
1x4 #4
nc to J1-21, no to J1-50
K12
com to K10 no
12
1x4 #5
com to J1-48
K13
nc to K14, no to K15
13
1x4 #5
nc to J1-49, no to J1-19
K14
com to K13 nc
14
1x4 #5
nc to J1-18, no to J1-47
K15
com to K13 no
15
-
-
-
-
16
1x4 #6
com to J1-16
K16
nc to K17, no to K18
17
1x4 #6
nc to J1-17, no to J1-46
K17
com to K16 nc
18
1x4 #6
nc to J1-45, no to J1-15
K18
com to K16 no
19
1x4 #7
com to J1-43
K19
nc to K20, no to K21
20
1x4 #7
nc to J1-44, no to J1-14
K20
com to K19 nc
21
1x4 #7
nc to J1-13, no to J1-42
K21
com to K19 no
22
1x4 #8
com to J1-11
K22
nc to K23, no to K24
23
1x4 #8
nc to J1-12, no to J1-41
K23
com to K22 nc
24
1x4 #8
nc to J1-40, no to J1-10
K24
com to K22 no
25
1x4 #9
com to J1-8
K25
nc to K26, no to K27
26
1x4 #9
nc to J1-9, no to J1-38
K26
com to K25 nc
27
1x4 #9
nc to J1-37, no to J1-7
K27
com to K25 no
28
1x4 #10
com to J1-35
K28
nc to K29, no to K30
29
1x4 #10
nc to J1-36, no to J1-6
K29
com to K28 nc
30
1x4 #10
nc to J1-5, no to J1-34
K30
com to K28 no
31
-
-
-
-

Manual 07504506 Model 4506
Page 16
Operation Manual
REGISTER: 8004h
MODE: 32 bit
FUNCTION: Control Matrix K31 through K60, 1x4 #'s 11-20 (note shield is on J2-60, 39, 31, 20
), chassis gnd = J2-1
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
1x4 #11
com to J1-3
K31
nc to K32, no to K33
1
1x4 #11
nc to J1-4, no to J1-33
K32
com to K31 nc
2
1x4 #11
nc to J1-32, no to J1-2
K33
com to K31 no
3
1x4 #12
com to J2-29
K34
nc to K35, no to K36
4
1x4 #12
nc to J2-30, no to J2-59
K35
com to K34 nc
5
1x4 #12
nc to J2-58, no to J2-28
K36
com to K34 no
6
-
-
-
-
7
-
-
-
-
8
-
-
-
-
9
-
-
-
-
10
-
-
-
-
11
-
-
-
-
12
-
-
-
-
13
-
-
-
-
14
-
-
-
-
15
-
-
-
-
16
-
-
-
-
17
-
-
-
-
18
-
-
-
-
19
-
-
-
-
20
-
-
-
-
21
-
-
-
-
22
-
-
-
-
23
-
-
-
-
24
-
-
-
-
25
-
-
-
-
26
-
-
-
-
27
-
-
-
-
28
-
-
-
-
29
-
-
-
-
30
-
-
-
-
31
-
-
-
-

Manual 07504506 Model 4506
Page 17
Operation Manual
Chapter 8 Front Panel Connector Pins
J1 J2
PIN
CONTACTS
PIN
CONTACTS
A
K2-NO
A
K20-NO
B
K2-NC
B
K20-NC
C
K3-NO
C
K21-NO
D
K3-NC
D
K21-NC
E
(SPARE)
E
(SPARE)
F
K1-C
F
K19-C
H
(SPARE)
H
(SPARE)
J
(SPARE)
J
(SPARE)
K
K5-NO
K
K23-NO
L
K5-NC
L
K23-NC
M
K6-NO
M
K24-NO
N
K6-NC
N
K24-NC
P
(SPARE)
P
(SPARE)
R
K4-C
R
K224-C
S
(SPARE)
S
(SPARE)
T
(SPARE)
T
(SPARE)
U
K8-NO
U
K26-NO
V
K8-NC
V
K26-NC
W
K9-NO
W
K27-NO
X
K9-NC
X
K27-NC
Y
(SPARE)
Y
(SPARE)
Z
K7-C
Z
K257-C
a
CHASSIS GROUND
a
CHASSIS GROUND
b
(SPARE)
b
(SPARE)
c
K11-NO
c
K29-NO
d
K11-NC
d
K29-NC
e
K12-NO
e
K30-NO
f
K12-NC
f
K30-NC
h
(SPARE)
h
(SPARE)
j
K10-C
j
K28-C
k
(SPARE)
k
(SPARE)
m
(SPARE)
m
(SPARE)
n
K14-NO
n
K32-NO
p
K14-NC
p
K32-NC
r
K15-NO
r
K33-NO
s
K15-NC
s
K33-NC
t
(SPARE)
t
(SPARE)
u
K13-C
u
K31-C
v
(SPARE)
v
(SPARE)
w
(SPARE)
w
(SPARE)
x
K17-NO
x
K35-NO
y
K17-NC
y
K35-NC
z
K18-NO
z
K36-NO
AA
K18-NC
AA
K36-NC
BB
(SPARE)
BB
(SPARE)
CC
K16-C
CC
K34-C
DD
(SPARE)
DD
(SPARE)
EE
(SPARE)
EE
(SPARE)
FF
CHASSIS GROUND
FF
CHASSIS GROUND
HH
(SPARE)
HH
(SPARE)
