Gigabyte GS-R1160-RH User guide

System Installation Guide
GS-R1160-RH
1U Rack Mount Server
Intel®XeonLGA775 ProcessorServerboard
Rev. 1.0

2
GS-R1160-RH Rack Mount Server
Table of Content
Safety, Care and Regulatory Information................................................4
Introduction..............................................................................................8
Contents Packages ................................................................................8
Chapter 1 Features Summary.................................................................9
Chapter 2 System Hardware Installation ............................................... 11
Step 2-1: Chassis Removal and Installation .................................................................11
Step 2-2: CPU Installation............................................................................................... 12
Step 2-3: Heat Sink Installation....................................................................................... 13
Step 2-4: Memory Installation ........................................................................................ 14
Step 2-5: PCI Expansion Card Installation.................................................................... 15
Step 2-6: Hard Disk Drive Installation ............................................................................ 16
Step 2-7: FAN Duct Removal and Installation.............................................................. 17
Chapter 3 Appearance of GS-R1160-RH .............................................18
3-1: Front View of GS-R1160-RH .................................................................................. 18
3-2: Rear View of GS-R1160-RH................................................................................... 19
3-3: Switch and LED Indicators Introduction ................................................................. 20
3-4: LAN LED Description............................................................................................... 21
3-5: Connector Icon Description..................................................................................... 22
Chapter 4 Motherboard Jumper Setting ...............................................23
4-1: GA-5YXS-RH Motherboard Jumpper Setting ........................................................ 23
Chapter 5 BIOS Setup ..........................................................................25
Main...........................................................................................................27
Advanced Processor Options ........................................................................................ 29
Advanced ...................................................................................................31
Memory Configuration..................................................................................................... 32
PCI Configuration............................................................................................................. 33
I/O Device Configuration................................................................................................. 35
Advanced Chipset Control ............................................................................................. 38
Hardware Monitor ............................................................................................................ 39

3
Table of Content
Security ......................................................................................................41
Server.........................................................................................................43
System Management...................................................................................................... 44
Console Redirection........................................................................................................ 45
Boot............................................................................................................48
Exit .............................................................................................................49

4
GS-R1160-RH Rack Mount Server
Safety, Care and Regulatory Information
/Important safety information
Readandfollowallinstructionsmarkedontheproductandinthedocumentationbeforeyouoperate
yoursystem.Retainallsafetyandoperatinginstructionsforfutureuse.
*Theproductshouldbeoperatedonlyfromthetypeofpowersourceindicatedontheratinglabel.
*Ifyourcomputerhas avoltageselectorswitch,makesure thattheswitchisinthe properpositionfor
yourarea.Thevoltageselectorswitchissetatthefactorytothecorrectvoltage.
*Theplug-socketcombinationmustbeaccessibleatalltimesbecauseitservesasthemaindisconnect-
ingdevice.
*Allproductshippedwithathree-wireelectricalgrounding-typeplugonlyfitsintoagrounding-typepower
outlet.Thisisasafetyfeature.Theequipmentgroundingshouldbeinaccordancewithlocalandnational
electricalcodes.Theequipmentoperatessafelywhenitisusedinaccordancewithitsmarkedelectrical
ratingsandproductusageinstructions
*Donotusethisproductnearwateroraheatsource.
*Setuptheproductonastableworksurface orsoastoensurestability ofthesystem.
*Openingsinthecaseareprovidedforventilation.Donotblockorcovertheseopenings.Makesureyou
provideadequatespacearoundthesystemforventilationwhenyousetupyourworkarea.Neverinsert
objectsofanykindintotheventilationopenings.
*To avoidelectrical shock, alwaysunplug all power cablesand modem cablesfrom the wall outlets
beforeremovingcovers.
*Allowtheproducttocoolbeforeremovingcoversortouchinginternalcomponents.
/Precaution for Product with Laser Devices
Observethefollowingprecautionsforlaserdevices:
*DonotopentheCD-ROMdrive,makeadjustments,orperformprocedures onalaserdeviceotherthan
thosespecifiedintheproduct'sdocumentation.
*Onlyauthorizedservicetechniciansshould repairlaserdevices.
/Precaution for Product with Modems, Telecommunications, ot Local Area
Network Options
Observethefollowingguidelineswhenworkingwithoptions:
*Donotconnectoruseamodemortelephoneduringalightningstorm.Theremaybeariskofelectrical
shockfromlightning.

5
SafetyInformation
*Toreducetheriskoffire,use onlyNo.26AWGor largertelecommunicationslinecord.
*Donotplugamodemortelephonecableintothenetworkinterfacecontroller(NIC)receptacle.
* Disconnect the modem cable before opening a product enclosure, touching or installing internal
components,ortouchinganuninsulatedmodemcableorjack.
*Donotuse atelephonelinetoreportagasleakwhile youareinthevicinity oftheleak.
/Federal Communications Commission (FCC) Statement
Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterference whentheequipment isoperated ina commercialenvironment. This equipment
generates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewith
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
requiredtocorrecttheinterferenceathisownexpense.
Properlyshieldedandgrounded cablesandconnectorsmustbeused inordertomeetFCC emission
limits.Neithertheprovidernorthemanufacturerareresponsibleforanyradioortelevisioninterference
caused by using other than recommended cables and connectors or by unauthorized changes or
modificationstothisequipment.Unauthorizedchangesormodificationscouldvoidtheuser'sauthorityto
operatetheequipment.
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesired
operation.
/FCC part 68 (applicable to products fitted with USA modems)
ThemodemcomplieswithPart68oftheFCCRules.Onthisequipmentisalabelthatcontains,among
otherinformation,theFCCregistrationnumberandRingerEquivalenceNumber(REN)forthisequipment.
Youmust,uponrequest,providethisinformationtoyourtelephonecompany.
If your telephone equipment causes harm to the telephone network, the Telephone Company may
discontinueyourservicetemporarily.Ifpossible,theywillnotifyinadvance.But,ifadvancenoticeisnot
practical,youwillbenotifiedassoonaspossible.Youwillbeinformedofyourrighttofileacomplaintwith
the FCC.

6
GS-R1160-RH Rack Mount Server
Yourtelephonecompanymaymakechangesinitsfacilities,equipment,operations,orproceduresthat
couldaffectproperoperationofyourequipment.Iftheydo,youwillbenotifiedinadvancetogiveyouan
opportunitytomaintainuninterruptedtelephoneservice.
TheFCCprohibitsthisequipmenttobeconnectedtopartylinesorcoin-telephoneservice.
TheFCCalsorequiresthetransmitterofaFAXtransmissionbeproperlyidentified(perFCCRulesPart
68,Sec. 68.381(c)(3)).
/for Canadianusers only/
/Canadian Department of Communications Compliance Statement
This digital apparatus does not exceed the ClassAlimits for radio noise emissions from digital
apparatusassetoutintheradiointerferenceregulationsofIndustryCanada.
Lepresentappareilnumeriquen'emetpasdebruitsradioelectriquesdepassantleslimitesapplicablesaux
appareilsnumeriquesdeClasseA prescritesdanslereglementsurlebrouillageradioelectriqueedictepar
IndustrieCanada.
/DOC notice (for products fitted with an Industry Canada-compliant modem)
TheCanadianDepartmentofCommunicationslabelidentifiescertifiedequipment.Thiscertification
meansthattheequipmentmeetscertaintelecommunicationsnetworkprotective,operationalandsafety
requirements.TheDepartmentdoesnotguaranteetheequipmentwilloperatetotheusersatisfaction.
Beforeinstallingthisequipment,usersensurethatitispermissibletobeconnectedtothefacilitiesofthe
localTelecommunicationsCompany.Theequipmentmustalsobeinstalledusinganacceptablemethod
ofconnection.Thecustomershouldbeawarethatcompliancewiththeaboveconditionsmightnotprevent
degradationofserviceinsomesituations.
RepairstocertifiedequipmentshouldbemadebyanauthorizedCanadianmaintenancefacilitydesignated
bythesupplier.Anyrepairsoralterationsmadebytheusertothisequipment,orequipmentmalfunctions,
maygivethetelecommunicationscompanycausetorequesttheusertodisconnecttheequipment.
Usersshouldensurefortheirownprotectionthattheelectricalgroundconnectionsofthepowerutility,
telephonelinesandinternalmetallicwaterpipesystem,ifresentareconnectedtogether.Thisprecaution
maybeparticularlyimportantinruralareas.
Caution: Users should not attempt to make such connections themselves, but should contact the
appropriateelectricinspectionauthority,orelectrician,asappropriate.

7
SafetyInformation
NOTICE:TheLoadNumber(LN)assignedtoeachterminaldevicedenotesthepercentageofthetotal
load to be connected to a telephone loop which is used by the device, to prevent overloading. The
terminationonaloopmayconsistofanycombinationofdevicessubjectonlytotherequirementthatthe
sumoftheLoadNumbersofallthe devicesdoesnotexceed100.
/for Europeanusersonly/
CAUTION
Dangerofexplosionifbatteryisincorrectly
replaced.
Replaceonlywiththesameorequivalent
typerecommendedbythemanufacturer.
Disposeofusedbatteriesaccordingtothe
manufacturer’sinstructions.
BSMI Statement
FCC Statemennt
Warning
ThisisaClassAproduct.Indomesticenvironment
thisproductmaycauseradiointerferencein
which case the user may be required to take ad-
equatemeasures.

8
GS-R1160-RH Rack Mount Server
;Chassis ;GA-5YXS-RHMotherboard(Installed)
;PowerSupply(Installed) ;FAN Duct x 1
;CPU Heat Sink x 1 ;Silm type CD-ROM drive (Installed)
;Cables(RJ45) ;Case Handle Kit x 2
;GS-R1160-RHQuickReferneceGuide
;DriverCDfor motherboarddriver&utility
Introduction
WelcometoGigabyteGS-R1160-RHRackmountServerSystemInstallationGuide.Theguide
providesinstructionsforconfigurationhardwarefortheGS-R1160-RHyoursystem.
Thisinstallationguidewillassistyouininstallingalltheessentialcomponentsfortheseversystem.
Foryourprotection,pleasereadandundertandallofthesafetyandoperatinginstructionsregardingyour
GigabyteServerandretainforfuturereference.Theproceduresinthisguidebookassumethatyourare
asystemornetworkadministratorexperiencedininstallingsimilarhardware.
Contents Packages
Whenopeningthepackage,pleaseensure thesystemcomponentsarenotdamagedduringtheshipping.
Using the following checklist to verify the contents. If any component is missing or damaged in the
system,pleasecontactyourvendorimmediately.
*Theitemslistedaboveareforreferenceonly,andaresubjecttochange withoutnotice.

9
FeatureSummary
Motherboard yGA-5YXS-RH
Processor Supported ySupportssingleIntel®Xeon®processor
yIntelXeon®Dual-Core/Quad-CoreprocessorinLGA775socket
ySupports 800/1066/1333MHzFSB
Chipset yIntel®3200Chipset
yIntel®ICH9R
SystemMemory:
Memory Capacity y4 x DDR2 DIMM sockets up to 8GB
MemoryType yUn-buffered667/800memory
DIMM Size ySupport 256MB, 512MB, 1GB, and 2GB memory
ErrorCorrection: ySingle-bitErrorsCorrection,MultipleBitErrorsDetection
Expansion Slot y1Risercardsupports1PCI-Ex8and 1 PCI-Ex8(x1bandwidth)
add-oncards
y1 SO-DIMM add-on card
SATA RAID controller yICH9R
ySupportsLSI Software SW RAID 0/1/10 (Windowsonly)
Cooling Fans: y5 X System Fan
IntegratedLANs:
Controller yIntel®82566DC&82573VGbEcontrollers
IntegratedGraphics:
Controller yXGIVolariZ9s
GraphicsMemory y32MB DDR2
MassStorageSystem y3 x Hot-Swap SATAHDDs
y1 x slim type CD-ROM
y1x DVDCombo(optional)
Super I/O
Controller yITEIT8718F Super I/O
Built-in I/O y1 x Serial port (COM)
y4xUSB 2.0dual-portconnector(2 atfrontpanel)
y1 x VGA connector
y2 x RJ45 LAN ports
yP/S2 Keyboard andMouseConnectors
Chapter 1 Features Summary

10
GS-R1160-RH Rack Mount Server
System BIOS:
BIOS Type yPhoenix BIOS on 8Mb flash ROM
Server Management Functions: (Optional device)
BMC Chip yH8S IPMI 2.0 controller
FailureDetection yIPMI2.0specificationofServermanagement
EventLogging y32KB Nonvolatile Memory to Log System Failure Events
RemoteManagement yFollow theIPMI2.0specification ofServermanagement
Environment
AmbientTemperature yOperatingTemperature:5oCto35oC
yNon-operatingTemperature:0oCto50oC
RelativeHumidity y10-80% operatingHumidity at30o C
System Dimention: y427.5mm x 567.5mm x 43.5 mm
Electrical Power Supply ySinglePower Supply 300W

11
Hardware Installation Process
Pleaseobservethesafetyinformationinchapter“ImportantSafetyInformation”
Donot exposethe serverto extremeenvironmental conditions.Protectit fromdust,
humidity,andheat.
Step 2-1: Chassis Removal and Installation
Step1 Pushdowntheindentationlocatedattwosidesofthechassis.
Step2 Slidetowardthetopchassis cover.
Step3 Liftuptoremovethetopchassiscover.
Step4 ReverseStep1, ,2,3 toreplacethechassis cover
Chapter 2 System Hardware Installation
1
32
1

12
GS-R1160-RH Rack Mount Server
Step 2-2: CPU Installation
PleasemakesuretheCPUtypeandspeedthat aresupportedbythemotherboard.
Step1 Raise themetallockinglever onthesocket. Insert theCPUwiththecorrectorientation.
Step2 TheCPU onlyfitsinoneorientation.
Step3 Pushthemetalleverbackintolockedposition.
1
2
3

13
Hardware Installation Process
Step 2-3: Heat Sink Installation
Step1 PlacetheHeat Sinkon theCPU.Before puttingthe heatsink ontheCPU, pleasewell
remember toapplythethermalconductivitycompound ontheCPU.
Step2 Seattheheatsinkintheretentionmoduleswiththefourscrews.Installationcompleted.
1
2
2
22

14
GS-R1160-RH Rack Mount Server
Step 2-4: Memory Installation
Step1. Insert the DIMM memory module vertically intothe DIMM slot,and push it down.
Step2. Closetheplastic clipatboth edgesofthe DIMMslotsto locktheDIMM module.
NOTE! DIMM must be populated in order starting from DIMM6 socket. For dual-channel
operation, DIMMs must be installed in matched pairs.
Step3. Reversetheinstallation stepswhenyou wishtoremove theDIMMmodule.
2
2
1

15
GS-R1160-RH Rack Mount Server
Step 2-5: PCI Expansion Card Installation
GS-R1160-RHprovides expansionriserslots foronePCI-Ex8 slot;andone withPCI-Ex8 slot(atx1
bandwidth).Toinstalltheperipheral,pleasegothroughthefollowingsteps.
Note!!Beforeinstalling theexpansioncard, pleasecheck thecard sizelimitation. Sizelimitationfor
standardrisercardis182mm; andthesizelimitationforlowprofilerisercardis182mm.
Step1 Loosentheriserbracket screws.
Step2 Lifttheriserbracketslightly,thenpullitoutfromtheserverchassis.
Step3 Aligntheexpansioncardwiththeguidinggroove.Slidetheexpansioncardintotheslotuntilthe
cardfirmlyseats.
Step4 Aligntheriserbrackettothesystemmodule.
1
2
2

16
Hardware Installation Process
Step 2-6: Hard Disk Drive Installation
z Pleaseturnoffthecomputerandunplugitspowercordbeforeremovingandinstallingharddrives.
Step1 Pressthereleasebutton.
Step2 Pulltheblankoutofthe drivebay.
Step3 Slideharddiskintoblank.
Step4 Secure it with screws.
Step5 Slidetheblankintothebayuntilitlocksintoplace.Connectcableandpower.
1
23
4
4
4
4
Warning
!
!

17
Hardware Installation Process
Step 2-7: FAN Duct Removal and Installation
Step1 Alignthefanductwiththeguidinggroove.Pushdownthefanductintosystemntilthe
itsfirmlyseats.
Guiding groove

18
GS-R1160-RH Rack Mount Server
3-1:FrontViewof GS-R1160-RH
Chapter 3 Appearance of GS-R1160-RH
X
Y
Z[
X
Y
Z
[
Slim Type CD-ROM (DVD-COMBO Optional)
Hot-Swap SATA HDDs
USB connectors
Front panel switch and LEDs

SystemAppearance
19
3-2:RearViewofGS-R1160-RH
XY
Z
[
\] ^
_`
^
X
Y
Z
[
\
]
^
_
`
Power
Mouse connector
Keyboard connector
COM port
VGAport
USB connectors
RJ45 LAN ports
Low-profile riser slot
Low-profile riser slot

20
GS-R1160-RH Rack Mount Server
3-3: Switch and LED Indicators Introduction
Power Button
Error
HDD
Status Buzzer Stop
Reset
RESET
ERROR
STATUS
BUZZER
STOP
ID Switch
Name
Power
Status
HDD
ID
(Identification)
Error
Color Condition Description
Green On Power On
Green Blink Sleep(S1)
-- Off Power Off (S4/S5)
Green On System Ready On/Alarm
Amber Blink SystemReady butdeqraded,DIMM Killed.
Amber On CriticalAlarm:CriticalFANsFailure
-- Off System Not Ready/ Post error/NMI event/
No Power
Green Blink Hard Disk DriveAccess
-- Off NoAccess and No HDD Fault
Blue On Untiselectedforidentification
-- Off Noidentification
Yellow On IPMI shows the event log.
- Off No event log in IPMI
