Gigabyte GS-SR104 User guide

System installation Guide
1-i
GS-SR104
Rack Mount Server
System Installation
Guide

System installation Guide
1-ii
INDEX
1. INTRODUCTION 1-1
1.1. PREFACE 1-1
1.2. FEATURES 1-1
2. HARDWARE INVENTORY 2-1
3. SYSTEM INSTALLATION PROCEDURES 3-1
3.1. CHASSIS COVER REMOVAL 3-1
3.2. CPU INSTALLATION 3-2
3.3. HEAT SINK INSTALLATION 3-2
3.4. MEMORY INSTALLATION 3-3
3.5. HARD DISK DRIVE INSTALLATION 3-3
3.6. PCI EXPANSION CARD INSTALLATION 3-5
3.7. REINSTALL TOP COVER 3-7
3.8. DOCK HANDLES INSTALLATION 3-7
3.9. FRONT PANEL 3-8
3.10. REAR PANEL 3-9
3.10.1. LCD MODULE INSTALLATION ( OPTIONAL ) 3-9
3.10.2. LCD MODULE SETTING INSTRUCTION 3-10
3.10.3. LCD DISPLAY INFORMATION 3-11
3.10.4. USING THE LCD MODULE 3-12
3.11. CONNECTOR ICONS 3-13

System installation Guide
1-1
1. INTRODUCTION
1.1. Preface
Using this manual will help you get the most from
your Rack Mount Server. Keeping the manual with
your Rack Mount Server to refer when you want
information and help.
In order to get the optimal usage out of your Rack
Mount Server and you should Remember the
following:
 Read through all the instruction for your Rack
Mount Server .
 Keep the area free of static electricity and
magnetic fields. These can damage the Serve .
 When cleaning the server or its components, apply
the proper cleaning solutionor sprays only on the
cloth ,not to the server or its components .
1.2. Features
Our Rack Mount Server use 1U Chassis and support
the following features:
Processor Support
 Single Socket 370 for Intel Coppermine ‘ Celeron
( 0.13 u ) and Tualatin processor
 Up to 1 GHz and above
 Optimal CPU Keep Out Zone for Type C
Heat-sink
 100/133MHz FSB

System installation Guide
1-2
 AUTO detect CPU voltage
BIOS
 Award BIOS 2M bit flash ROM
 Auto configure IDE HDD type
 Multiple boot options
 User setting for hardware monitoring
 DMI 2.0 compliant
Chipset
 VIA Apollo Pro Family AGP set
( VT82C694T ,VT82C686B ) Chipset
 ATI Rage XL VGA Chip with 8MB Video
Memory
 Intel 82559 Dual LAN chip
Memory Support
 2 x 168-pin 25 degree DIMM sockets for SDRAM
modules
 Supports PC-100/PC-133 either un-buffered or
registered memory and VCM SDRAM
 Supports up to 2GB SDRAM
 Supports only 3.3V SDRAM DIMM
Storage Controller
 Max 2 IDE ATA channels ( 2 x ATA-100 )
 44MB Floppy Disk Drive
 High Speed IDE CD-ROM Drive ( Slim type )
Networking
 On board dual LAN , Ethernet 10/100 WOL ( Wake
On LAN )
 Adaptive fail over feature
 Load balance feature

System installation Guide
1-3
I/O Expansion Slot
 PCI riser , 1 slot ,support 33MHz & PCI 2.2
compliant
Build-in I/O ports
 1 x PS/2 Keyboard port
 1 x PS/2 Mouse port
 2 x COM port ( 1 x back side and 1 x front side )
 1 x VGA port
 1 x LPT port
 2 x RJ-45 ports
 2 x USB ports
Power
 Total output power 150 W
 Input : Rating switch full range 90V~250V
47~63 Hz
Operating Temperature
 5 to 35 degree C
Thermal Solution
 Special-designed Heat-sink and hi-efficiency
chassis fans for dual 1 GHz plus processor
thermal solution
Chassis Dimensions
 Height 44 mm ( 1.73 In. )
 Width 482.6 mm ( 19.0 In. )
 Depth 495.3 mm ( 19.5 In. )

System installation Guide
2-1
2.Hardware Inventory
When you unpack your GS-SR104 Rack Mount
Server ,Check that all the items that you ordered are
present in good condition. Review the inventory
checklist below to be sure that the components and
optional components that you ordered are included. If
anything is miss or damage ,contact your retailer as
soon as possible.
 Chassis
 Power Supply (Installed)
 Motherboard GA-6VTMR (Installed)
 Power Cord x1
 Manual (M/B User’s Manual & System
Installation)
 Flat Screw # 6-32 * 5L x 12 (For HDD)
 Heat sink x 1
 Case Handle x 2
 Flat Screw M4*10L x 4 (For Handle)
 Support CD x1
 Support Floppy Disk x 2

System installation Guide
3-1
3.System Installation
Procedures
Warning: Please remove the protective thin films
(Top and Bottom) from the system when installing.
3.1. Chassis Cover Removal
a. Unscrew the two thumbscrews from top cover of
the system (Fig-1).
b. Standing at the front of the system. Gently apply
force to the indentures with your thumbs and
push toward the rear of the chassis for about 3/4
of an inch. Top cover may be lifted straight up
(Fig-2).
Fig-1 Fig-2
c. With the top cover removed, you will see a
transparent plastic air duct over the CPU and
Memory. Remove the air duct to install the
CPU and Memory (Fig-3).

System installation Guide
3-2
Fig-3
3.2. CPU Installation
Lift the ZIF (Zero Insertion Force) socket lever
up 90 degree. Insert CPU into the socket. Make
sure CPU is seated properly, then push the level
back to the original locked position. (Fig-4 and
Fig-5 )
Fig-4 Fig-5
3.3. Heat Sink Installation
Place the heat sink on top of the CPU with the clip
handle on the same side as DIMM slot . Clip one side
(without handle) onto the CPU socket’s hook and
gently push the other side of the clip (with handle) on to
the opposite side of the CPU socket’s hook. (Fig-6 )

System installation Guide
3-3
Fig-6
3.4. Memory Installation
The motherboard contains four slanted DIMM
(Dual Inline Memory Module) sockets. The
system BIOS will auto detect the size of the
memory. To install memory simply push the
memory modules into the DIMM sockets. (Fig-7)
After that re-install a plastic air duct into
system .( Fig-8 )
Fig-7 Fig-8
3.5. Hard Disk Drive Installation
a. First, remove the screw on the top of the

System installation Guide
3-4
cable plate.(Fig-9)
b. And then remove the screw from Hard Disk
Plate.( Fig-10 )
Fig-9 Fig-10
c. Carefully remove the Hard Disk Plate from
system . (Fig-11).
d. Put Hard Disk Drive on to Hard Disk Plate
and secure each hard disk drive with
screws . ( Fig-12 )
e. Re-install the Hard Disk plate with Hard
Drive into system and secure each hard disk
plate with screw . ( Fig-13 )
f. Connect the Power cable to Hard Drive.
( Fig-14 )
Fig-11 Fig-12

System installation Guide
3-5
Fig-13 Fig-14
g. Connect signal cable to Hard Drive .
( Fig-15 )
h. After connect the power and signal cable to
each hard drive , please re-install the cable
plate with screw . ( Fig-16 )
Fig-15 Fig-16
3.6. PCI Expansion Card Installation
GS-SR104 provides two PCI slot on the one
expansion raiser card for a peripheral card . One
PCI slot supports standard PCI card and other
slot for low profile PCI card .

System installation Guide
3-6
Attention : GS-SR104 low profile slot only
provides MD1 form factor [ length : 121.79mm
( 4.795 inch ) and width : 58.09mm( 2.287inch ) ]
a. First, remove the screws located at the rear .
( Fig-17 & Fig-18 )
Fig-17 Fig-18
b. And then install the PCI card into place and
secure the card with screw .( Fig-19 &
Fig-20 )
Fig-19 Fig-20

System installation Guide
3-7
3.7. Reinstall Top Cover
When you are finish installing all the essential
components from above step , re-install the top
cover to the system .( Fig-21 )
And then secure with screws from top side .
( Fig-22 )
Fig-21 Fig-22
3.8. Dock Handles Installation
Remove dock handles from the package. Put two
on each side of the chassis, secure with screws
provided (Fig-23).
Fig-23

System installation Guide
3-8
3.9. Front Panel
Fig-24
LED Panel
Fig-25
Power LED：Green－Online
Off－Offline
LAN LED ：Green－Online
Off－Offline
Flashing－LAN Activity
Fan LED ：Orange－Fan fail
Off－Normal
HDD LED ：Flashing – Data Access
Off-Normal
Slim CD
-
ROM
3.5” FDD COM 2
LCD Module
Connector
LAN 1
Status
LAN 2 Status
FAN Status
HDD Status

System installation Guide
3-9
3.10. Rear Panel
Fig-26
3.10.1. LCD Module Installation (Optional )
LCD module including LCD module ‘ locker and
screw . Fig-27
First , put locker into the case . Fig-28
PS/2 Mouse
PS/2 K/B
USB
COM 1
VGA
LAN 1 LAN 2
Parallel Port
32bit/33MHz PCI
Slot ( Low Profile )
32bit/33MHz PCI
Slot ( Full Size )

System installation Guide
3-10
Fig-27 Fig-28
And then LCD module cable connect to system
connector . ( Fig- 29 )
After that install the LCD module and secure with
screw . ( Fig-30 )
Fig-29 Fig-30
3.10.2. LCD Module Setting Instruction
The Up arrow button for menu selection and
increase the digit number and character located at
the cursor position .

System installation Guide
3-11
The Down arrow button for menu selection and
decreases the digit number and character located
at the cursor position .
The Right arrow button moves the cursor to the
right .
The Left arrow button moves the cursor to the
left .
The Enter accepts the selection.
3.10.3. LCD Display Information
LCD screen will show the following information:
( 1 ) Host Name
( 2 ) LAN 1 IP address
( 3 ) LAN 2 IP address
( 4 ) FAN speed
( 5 ) CPU temperature
( 6 ) Hard Disk space
( 7 ) Virtual Memory capacity
( 8 ) Physical Memory capacity
( 9 ) System time
Enter

System installation Guide
3-12
3.10.4. Using the LCD module
LCD module serves following purposes ;
( 1 ) Configure the LAN 1 IP address ‘ Netmask
and Gateway .
( 2 ) Configure the LAN 2 IP address ‘ Netmask
and Gateway .
( 3 ) Display time setting ( Default 2 sec )
( 4 ) Display information menu : user can setting
which information will be show or not .
( 5 ) Reboot system .
( 6 ) Power off system .
( 7 ) Return to display information
( 8 ) System time setting
