GIGACLOUD TECHNOLOGY MF309368 User manual

ASSEMBLY INSTRUCTIONS
SKU CODE: MF309368/MF309369
1
Weight Limits: 250 lbs

SAFETY WARNING
2
1. This bed is designed for use only mattress (es) meeting the following specifications on the
upper bunk:
Upper bunk
Bed type Length Width Thickness
Twin Standard 74” - 75” 38 ½'' 6'' max
2. Replacement parts, including additional guardrails, maybe obtained from any of our
(GIGACLOUD TECHNOLOGY (USA) INC. 18961 ARENTH AVENUE CITY OF INDUSTRY, CA,
91748) dealers
3. Follow the information on the warnings appearing on the upper bunk bed end structure and on
the carton. Do not remove warning label from bed.
4. Always use the recommended size mattresses or mattress supports, or both, to help prevent
the likelihood of entrapment or falls.
5. Surface of mattress must be at least 5" (127mm) below the upper edge of guardrails.
6. Do not allow children under 6 years of age to use the upper bunk.
7. Periodically check and ensure that the guardrail, ladder, and other components are in their
proper position, free from damage, and that all connectors are tight.
8. Do not allow horseplay on or under the bed and prohibit jumping on the bed.
9. Always use the ladder for entering and leaving the upper bunk.
10. Do not use substitute part. Contact the manufacture or dealer for replacement part.
11. Use of a night light may provide added safety precaution for a child using the upper bunk.
12. Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed
next to the wall, the guardrail that runs the full length of the bed should be placed against the
wall to prevent entrapment between the bed and wall.
13. The use of water or sleep flotation mattresses is prohibited.
14. STRANGULATION HAZARD - Never attach or hang items to any part of the bunk bed that are
not designed for use with the bed; for example, but not limited to, hook, belts and jump ropes.
15. Keep these instruction for future reference.
16. Prohibit more than one person on upper bunk
17. We recommend assembling your bunk bed on the shipping carton to protect your floor or
carpet.
18. Be certain all staples are out of the box before beginning assembly on the shipping carton.

ASSEMBLY INSTRUCTIONS
Thank you for purchasing this quality product. Be sure to check all packing
material carefully for small parts which may have come loose inside the
carton during shipment. Separate, identify and count all parts and hardware.
Compare with the parts list to be sure all parts are present.
"DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED"
3
HOUSE LOFT BED

IMPORTANT:
PLEASE READ INSTRUCTION BEFORE STARTING THE ASSEMBLY
Detail View
4
HOUSE LOFT BED
1
2
11
10
3
27
4
5
6
8
9
12
13
41
14
15
16
17
18
23
24
25
25
25
26
27
28
29
30
31
32
33
34
35
36
37 38
39
40
40
18
17
19
19
20
21
22

5
PART LIST MF309368
1 Vertical bar
1 pc 1 pc
2 Vertical bar
2 pcs
4 Guard Frame
6 Guard Frame
1 pc
1 pc
1 pc 1 pc
29 Vertical bar
30 Vertical bar 31 Vertical bar 32 Vertical bar 33 Vertical bar
37 Vertical bar 38 Vertical bar
1 pc 1 pc
1 pc
3 Vertical bar
1 pc
1 pc
10 Guard Frame
1 pc
12 Vertical bar
1 pc
14 Horizontal bar
1 pc
15 Horizontal bar 16 Horizontal bar
2 pcs 2 pcs
17 Rooftop 18 Rooftop
2 pcs
2 pcs
19 Shelf Frame 23 Vertical bar 24 Vertical bar
1 pc 1 pc
25 Horizontal Bar
3 pcs
26 Vertical bar 27 Vertical bar
3 pcs
28 Vertical bar
1 pc 1 pc
1 pc

1 pc
PART LIST MF309369
34 Stair Frame 35 Stair Frame 36 Stair Frame
39 Plank 40 Plank
1 pc 1 pc
1 pc
6
HARDWARE LIST MF309368
1/4*32
32 pcs
B Bolts D Bolts
1/4*50
10 pcs
C Bolts
E Screws
#8*10
18 pcs
A Bolts
1/4*55
40 pcs
1/4*18
27 pcs
F Bolts
2 pcs
41 Window Frame
1 pc
22 Shelf Frame
1 pc
1 pc
5 Guard Frame
1 pc
7 Guard Frame
16 pcs
8 Slats 9 Slats
4 pcs
1 pc
11 Guard Frame
1 pc
13 Window Frame 20 Shelf Frame
1 pc 1 pc
21 Plank
G Allen Key
4*59
1 pc
1/4*25
10 pcs

STEP 1
STEP 2
ASSEMBLY INSTRUCTIONS
ITEM: MF309368/MF309369
HOUSE LOFT BED
7
D1/4*18 8 pcs
A11 pcs
1/4*55
A
A
A
7
1
11
11
7
1
2
3
2
5
E
E
9
8
8
8
8
8
8
6
6
8
8
9
8
4

STEP 4
STEP 3
8
A13 pcs
1/4*55
C2 pcs
1/4*32
A1 pc
1/4*55
ASSEMBLY INSTRUCTIONS
HOUSE LOFT BED
ITEM: MF309368/MF309369
11
2
A
A
A
1
7
4
5
3
2
10
6
2
10
4
2
A
A
C
C
6
6
12 12

9
STEP 5
STEP 6
ASSEMBLY INSTRUCTIONS
B4 pcs
1/4*50
D4 pcs 1/4*18
A4 pcs
1/4*55
B4 pcs
1/4*50
18
17
14
15
16
D
A
A
B
B
A
B
D
16
14
15
HOUSE LOFT BED
ITEM: MF309368/MF309369
B
13
41
6
B
13
6
41
18
17
18
17

STEP 7
10
STEP 8
ASSEMBLY INSTRUCTIONS
D8pcs
1/4*18
HOUSE LOFT BED
C1/4*32 4 pcs
ITEM: MF309368/MF309369
C
D
D
D
3
2
1
2
13
41
12
14
17 18
12
13
14
1
2
D
C
18
17
18
17
41
B1 pc
1/4*50
B
B
E#8*10 6 pcs
E
E
20
21
20
21

1 pcs
1/4*25
D3 pcs
1/4*18
F
C
38
37
5
5
37
38
19
19
22
20 20
19
19
22
66
D
ASSEMBLY INSTRUCTIONS
F9 pcs
1/4*25
19
19
22
20
F
19
22
F
22
HOUSE LOFT BED
ITEM: MF309368/MF309369
STEP 9
STEP 10
11
20
2 pcs
1/4*32C
F

12
ASSEMBLY INSTRUCTIONS
STEP 12
A1/4*55 2 pcs
1/4*18
D4 pcs
A8 pcs
1/4*55
C1/4*32 4 pcs
HOUSE LOFT BED
ITEM: MF309368/MF309369
25
A
D
2
24
25
24
2
A
D
D
CA
A
23 3
37 38
36
35
34
AC
36
35
34
3
23
24 237 38
24
2
25
25
STEP 11
25
25

13
ASSEMBLY INSTRUCTIONS
STEP 13
STEP 14
11 pcs
1/4*32
C
A1pc
1/4*55
B1/4*50 1pc
9 pcs
1/4*32
C
27 28 29 30 31
33
34
35
36
C
C
HOUSE LOFT BED
31
32
33
28
29
30
27
B
AC
ITEM: MF309368/MF309369
34
35
36
31
32
33
28
29
30
27
C
26
26
31
32
33
28
29
30
27
23
23
24
24
B
A
C
32

14
ASSEMBLY INSTRUCTIONS
STEP 15
STEP 16
E#8*10 12 pcs
E
31
28
23
3
37
38
39
40
40
HOUSE LOFT BED
ITEM: MF309368/MF309369
39
40
40
E
40
28
31
39
40
37 38
3
23

15
ASSEMBLY INSTRUCTIONS
COMPLETE
HOUSE LOFT BED
ITEM: MF309368/MF309369
