GILMAN gemini GMF85T User manual

1
MODEL NO 型號: GMF85T
80W
ULTrasONic MisT FaN
噴霧電風扇
A GILMAN GROUP BRAND

2
IMPORTANT SAFETY INSTRUCTION
Thank you for purchasing this fan. Every care has been taken to ensure that it reaches
you in perfect condition. Please read this manual carefully before operating this product
WARNING: To reduce the risk of re, electrical shock, or injury:
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, if they have been given supervision or instruction concerning the use
of the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be done by
children.
WARNING: To reduce the risk of re, electrical shock, or injury:
This appliance has safety tip-over auto off protection function. But if the fan is
fallen down, please do not connect the appliance to a power supply again to avoid
the risk of short circuit, please disconnect it from the main power supply and take
the fan to our after-sales service center for checking.
WARNING: When using electric tools, basic safety precautions should be followed
to reduce the risk of re, electric shock and personal injury, including the following,
1. Before clean or move the appliance, please unplug the appliance and take out the
water tank. Otherwise there have overow risk and damage this appliance. In order to
avoid any risk, do not take out the water tank before unplug the appliance.
2. Connect the appliance to a power supply of the voltage specied on the rating plate.
This product is designed for a (220-240V~50/60Hz) electric supply. Do not use electrical
extension cord with this fan.
3. When unplug the appliance, do not put any stress on the power cord, as the cord may
fray and break and avoid any Short circuit or an electric shock risk.
4. Do not introduce your ngers through the air inlets or outlets. Do not let children
introduce any foreign body into the air inlet or outlet.
5. Do not let hair, net curtains, tablecloth, clothes or curtains next to the openings of the
fan. They could be aspiring into the fan, causing damaged or injuries.
6. Do not use any fan with a cord or plug damaged, after working default or if the fan is
fallen or have been damaged by any way.
7. Periodically check the electric cable of this fan. If the electric cable is damaged, it must
be replaced by the manufacturer, its after-sales service or by a similar qualied person
in order to avoid a danger.
8. The product is for household use only. Do not use this fan outdoor.
9. Do not use this fan in a damp area such as bathroom.
Please read this manual carefully before operating this product. Keep this manual for
further reference.

3
10. Use the fan in a well-ventilated area. While using, please keep at least 20cm distance
away from wall or corner to ensure the air inlets & outlets openings is not blocked
unexpectedly.
11. Do not use this fan with any semi-conductors speed control.
12. Use the fan on at, dry oor only. The fan should not be operate without a base or
used laying on its side.
13. Do not place the electrical cord under a cover. Do not overlay the cord with little
covers or such element. Place the cord in an area where there is no any risk to
stumble over it.
14. Never leave the fan unattended while it is in use. Always turn the product to the OFF
position and unplug it from the electrical outlet when not in use.
15. Extreme caution is necessary when the fan is used by or near children, invalids or
elderly person and whenever the fan is left operating and unattended.
16. Do not operate the fan in an area where gasoline painting or such ammable liquids
is used or stocked.
17. Do not operate the product if it has a damaged power cord or plug in any machine.
This product has no user-serviceable parts; do not attempt to examine or repair it by
yourself. Only qualied service personnel should perform any servicing. Contact
after-sales service center for support.
18. Use this fan only as it is described in this manual.
19. Children shall be supervised of not to play with the appliance.
20. This unit is intended for household use only. This fan is not suitable for commercial use.
21. Do not plug or unplug the appliance when hand wet.
22. During appliance operating, do not touch ultrasonic atomizer and any internal parts
in appliance.
23. Do not ll the water over 40 oC in this appliance.
24. Metals and chemicals are not allowed to put inside the water tank, which will affect
mist function and danger.
25. To replace a new mosquito tablet (Not included in package) , please turn off the
function and wait for 5 minutes.
26. Any inammables must not cover on the surface of mosquito repellent slot / mosquito
tablet.
27. The elder, weak and baby should not use the Misting function for a long time.

4
PARTS OF FAN
ASSEMABLY INSTRUCTIONS
METHODS OF FILLING WATER TANK
Step 1 : Please balance to lay down the fan;
Step 2 : Please insert the four wheels to the relative position at
fan base to complete the assembly.
Step 3 : After assembled, connect the Power supply and turn on
the fan.
1. Open the water tank compartment door as shown
2. Lift up the water tank vertically and Take out the tank horizontally.
3. Turn over the tank and put bottom up.
4. Loose the tank cap clockrise direction as shown (a), open the cap (b) and ll water.
5. Tighten the cap, put the tank back in machine
6. Close the water tank compartment door.
Put the fan at on the oor and ll water as below:





 
 







 











5
“ON/SPEED” Button: When the fan is stationary, press the “ON/
SPEED” button on touch control panel or remote controller the buzzer
will beep once and the fan will start to work at wind Level 1. You also
can choose the wind speed either by pressing the “ON/ SPEED”
button on the touch control panel or on the remote controller. The
relative wind circulation can be set from the Level. 1 means Low, Level
2 means Medium and Level 3 means High. The LED display screen
will show the selected speed – 1, 2 or 3.
“OFF” Button: Press this button once to switch off the fan. All functions will be
stopped immediately. If press and hold 3 seconds on the “OFF” button, the LED
display screen will be switch off but the preset function keep operating. (Including
Ionizer, Mosquito Repellent and Misting). You can turn on the LED display or
choose the speed mode again either by pressing the “ON/SPEED” button on the
touch control panel or on the remote controller.
“SWING” Button: Press the “SWING” button on the touch control panel or
remote controller, the fan grille will start auto swing ON and move in circular
direction so that the air can be circulated better. Press the “SWING” button again to
switch off this function.
INSTRUCTION OF TOUCH CONTROL PANEL
AND REMOTE CONTROLLER


 


   






 



REMOTE CONTROLLER
LED DISPLAY AND TOUCH CONTROL PANEL
Please connect the plug into main power supply, the power light
indicator will be displayed on LED screen continuously and the
buzzer will beep.



6
”TIMER” Button: Press “TIMER” button on the remote controller. This function will
work in all of fan mode (Normal or Sleep or Natural mode). The timer function
allows you to set the operation time from 1 to 8 hours. To set the timer, press the
“TIMER” button. The LED display screen shows 1 H Timer as default. Press once
“TIMER” button to increase 1 hour each time. The Fan will operate for 1 hour
before shutting down to standby mode. The Timer light indicator will be on when
the Timer function have been set. To cancel the timer function press the button
until LED display timer indicator light goes off. Without timer setting, the Fan
operates continuous.
“MODE” Button: While the fan is working, lightly press the “Mode” Button on the
remote controller or touch control panel to set different wind modes, it can be set
to the mode of Normal, Natural or Sleep circulation setting. After selected, LED
display screen shows the relative wind mode light indicator. The Normal wind
mode is set by default.
“IONIZER” Button: When the fan is at power ON mode, lightly press the “IONIZER”
button on the touch control panel or remote controller to switch ON the function.
The Ionizer light indicator will be displayed on the LED screen. Press the button
again to switch OFF the function. The Ionizer function can work independently
when the Wind function is off.
“MISTING” Button: Press the “MISTING” button on Touch control panel or
on remote controller. The LED display screen will show the humidification pattern.
The “MISTING” light indicator will be ON during normal humidifier function. Press
the button again to turn off the Misting function. The “waterless” light indicator
will be ON and have three “Bi” alarm sound when there is not enough water in the
tank. It needs to be refilled. The Misting function will be auto-off when there is not
enough water. Please refer to the section “Method of refilling water tank” in page 4.
Press the button again to turn on the mist function after relled. The Misting function
can work independently when the Wind function is off.
“MOSQUITO REPELLENT” Button: Please insert a mosquito repellent tablet (to
be purchased separately) into the Mosquito repellent slot at the back of the
Fan. Press “MOSQUITO REPELLENT” button on the touch control panel or remote
controller, the LED display screen will show Mosquito repellent light indicator that
the Mosquito repellent function is switched ON. Press the button again to switch
off the function. This Mosquito repellent function can work independently when the
Wind function is off.

7
GUIDELINES FOR USING THE REMOTE CONTROLLER
• The remote controller must be pointed towards the receiver on the fan for function
selection.
• Do not block the line of sight between the remote controller and the receiver.
• Handle the remote controller with care. Do not drop the remote controller on the oor or
bang it against hard objects.
GUIDELINES FOR THE USE OF BATTERIES
• If the remote controller will not be used for a long period of time, remove the batteries
from the battery compartment.
• The remote controller uses two AAA batteries, both of them should be new and
replaced at the same time when they discharge (Battery not included)
• Clean battery contacts and also those of the device prior to battery installation
• Ensure the batteries are installed correctly with regard to polarity, matching +/- sides of
the battery to the corresponding indications on the remote controller.
• Remove used and dead/discharged batteries promptly.
MAINTENANCE AND CLEANING






Pour out water from water tank
Step 1 - Prepare a dry towel and put near the outlet.
Step 2 - To open the outlet lock in anti-clockrise direction and pull out
the outlet silica stopper. Pour out all the water left inside and dry the
tank completely.
Step 3 - Put back the outlet silica stopper until closed perfectly. To
close the outlet lock clockrise direction.
• Always remove the plug from the socket-outlet and ensure the fan is stopped
before cleaning.
• To clean enclosure, use a clean, soft and lightly clamp cloth to gently wipe off the
dirt from the surface of the fan.
• Interior dust or dust on fan grille can often be removed by using a vacuum cleaner
with a crevice tool attachment.
• Do not use water spray to clean on the fan.
• Do not use thinner, benzene, acidic detergent, oil, harsh cleaners or materials to
clean the fan. It will damage the housing or its color.
• After cleaning, use the original packaging material to repack the fan and store in
a dry place.
• A few drops of mild citric acid and water to water tank for 5 – 10 minutes to remove the
dirt on the water tank
• If the fan will not be used for a period of time. Please pour out water of the water tank
and water left in the base. Dry it before storage.

8
Model No.: GMF85T
Voltage: 220-240V
Frequency: 50/60Hz
Power: 80W
Product Dimension: 390(W) x 240(D) x 840(H) mm (with wheels)
SPECIFICATION
CAUTION: DO NOT ALLOW WATER TO RUN INTO THE INTERIOR OF THE
FAN AS THIS COULD CREATE A FIRE OR ELECTRIC SHOCK HAZARD. THE
FAN MOTOR IS FACTORY LUBRICATED FOR LIFE AND DO NOT REQUIRE
FURTHER LUBRICATION. NO OTHER USER MAINTENANCE IS REQUIRED
OR RECOMMENDED. IF SERVICE IS REQUIRED, PLEASE CONTACT OUR
AFTER-SALES SERVICE CENTER.
CAUTION! DO NOT IMMERSE THE UNIT IN WATER OR ALLOW WATER TO
DRIP INTO THE INTERIOR OF THE FAN HOUSING AS THIS COULD CREATE A
FIRE OR ELECTRIC SHOCK HAZARD.
WARNING! DO NOT ATTEMPT TO OPEN OR REPAIR THE UNIT YOURSELF.
DOING SO COULD VOID THE WARRANTY AND CAUSE DAMAGE OR
PERSONAL INJURY.

9
為了更好的使用本產品，請在使用前詳細閱讀本手冊。
多謝閣下選購本系列產品為使閣下對此產品有更深入的瞭解及正確地使用，敬請在
使用前詳細閱讀此說明書。
󰙬󰙩
󰙬󰙩

󰂤󰁟󰃏󰗫󰎮󰜽󰜻
󰗫󰆳󰂐󰁟

󰌀󰔺󰘐󰌀󰈼
󰐎󰌀󰖀󰈼󰑲󰒷󰎮
󰏶󰎓󰙩
󰎮
1. 清潔或移動本機時，應先切斷電源並取出水箱，否則水有機會溢出並流入機體
產生故障。未切斷電源前，不得隨意取出水箱，以免發生意外。
2. 本產品只可以接上和銘牌上標示的電壓一樣的電源，這個產品被設計在
（220-240V~50/60Hz）的電力供應中使用，並不要使用電源延長線。
3. 當拔除插頭時，請不要直接拉扯電源線，以免發生短路或觸電危險。
4. 不要把你的手指穿過前方出風口及噴霧口。不要讓孩子把任何異物插進入前方
的出風口。
5. 不要讓頭髮、窗簾、桌布、衣服或窗簾旁邊的物件放在的風扇的開口。他們可
能被吸入風扇，造成損壞或人身傷害。
6. 如風扇的電源線或插頭，工作後或風扇跌落地或以任何方式損壞，不要使用
7. 定期檢查該風扇的電源線。如果電源線損壞，必須由售後服務合格的人員替
換，以避免危險。
8. 本產品只可以在室內使用，不要在戶外使用這風扇。
9. 不要在潮濕的地方，如浴室使用這風扇。
10.風扇需在空氣流通的地放使用，風扇需距離牆邊約20CM以確保有足夠空氣流
通，不會阻擋入風和出風口，但不要在窗口附近使用這風扇。
11.不要使用任何半導體速度控制器來控制這風扇。
12.在平坦和乾的地面上使用，如沒有地座或橫放都不應操作。


10
13.請勿將電源線蓋著。將電源線放在一個地方不會有任何絆倒風險。
14.風扇不工作時，請把插頭拔出。在拔走插頭前，所有的開關必須是在“OFF”
位置，然後才把插頭拔除。
15.保持本產品不可被兒童或體弱者接觸。不要讓他們在沒有監督下使用本產品。
16.不要在有汽油使用或儲存油漆或易燃液體的地方使用。
17.電源線、插頭損壞、功能有問題或機身有損壞都不可以使用，本機沒有需要自
行修理的零件，請不要自行打開機身，只有合資格人仕才可以維修本機，有問
題請聯絡客戶服務中心。
18.只使用本說明書中描述的方法使用這風扇。
19.本機不是玩具，兒童不可以把玩本機。
20.本機只可作家庭式使用，不可作商業用途。
21.手濕時不可以插拔電源插頭，以免發生觸電危險。
22.開機時，請勿用手摸水槽內的內部零件，否則可能發生危險。
23.切不可向水箱和水槽加40oC以上的熱水。
24.不可將金屬或化學藥品等放進水槽，否則會出現霧化不良現象或導致危險。
25.如需更換蚊香片時，請關閉驅蚊功能後等待5分鐘以便蚊片冷卻，然後再更換蚊
香片。
26.不可在驅蚊片位置的表面覆蓋任何易燃物品。
27.嬰兒老人或體弱者不宜長時間直接吹風。
