GILMAN gemini GAF1300 User manual

1
MODEL NO.: GAF1300 / GAF1300V
1200-1400W
DIGITAL
ARIA FRYER
A GILMAN GROUP BRAND
電子控制無油煎炸鍋

2
Please read and retain for future reference.
• Ensure the appliance is in placed on a horizontal, even and stable surface.
• Verify that the mains voltage is the same as that indicated on the rating plate
on the appliance before use.
• Make sure that you always use a grounded wall socket to connect the appliance.
• Always remove the plug from the wall socket when the appliance is not in use.
• Remove the plug from the wall socket by pulling the plug, not the power cord.
• Make sure that the appliance, the power cord and plug do not make contact
with water.
• Make sure that the appliance, the power cord and plug do not make contact
with hot surface, such as a hot hob or naked ame.
• Check the appliance’s power cord regularly to make sure it is not damaged.
Do not use the appliance if the power cord is damaged. If the power cord is
damaged, it must be replaced by an electrical technician or a person with
similar qualication, in order to avoid any hazards.
• Never use the appliance in the vicinity of ammable material.
• Certain part of the appliance may get hot, such as air outlet. Do not touch
these part to prevent scalding yourself.
SAFETY INSTRUCTION - GENERAL
SAFETY INSTRUCTION - ELECTRICITY AND HEAT
• Use this appliance solely in accordance with these instructions.
• This appliance is for household use only, not for commercial purpose.
• Remove all packaging material from the appliance before use.
• This appliance shall not be used by children of 0 to 8-year old.
• This appliance can be used by children older than 8-year old and persons
with reduced physical, sensory or mental capabilities or lack of experience
and knowledge, but only if they have been given supervision or instruction
concerning use of the appliance in safe way and understand the hazards
involved.
• Children should be supervised to ensure that they do not play with the appliance.
• Cleaning and maintenance must not be done by children.
• Have any repairs carried out solely by a qualied electrician. Never try to repair
the appliance yourself.
• Do not handle the plug or appliance with wet hands.
• Do not immerse the main body in water.
• Children shall not play with the appliance.
• Do not leave the appliance unattended when connected to the mains supply.
• Keep hair, loose clothing, ngers and all parts of the body away from openings
of the appliance.
• Only use the attachments/accessories supplied with the product.

3
• Do not place the appliance against a wall or against other appliance, it should
be placed with a minimum distance of 10cm away.
• During operation, hot steam is released through the air outlet. Keep your
hands and face at a safe distance away from the steam and the air outlet.
Also be careful of hot steam and air when you remove the frying basket from
the appliance.
• Pay attention to any accessible surfaces that may become hot during use.
• Slight smoke on the rst use is a normal occurrence. It will disappear shortly
afterwards.
SAFETY INSTRUCTION - DURING OPERATION

4
Aira Fryer
Touch screen control panel
1. Touch screen with LCD display panel
2. Upper housing
3. Main cord
4. Body case
5. Window door
6. Air outlet
7. Air inlet
8. Bake tray/ Oil collection tray
9. Mult-functional grill rack
10. Frying basket with detachable handle
11. Food seperator
12. Kebab sticks (4 pieces)
13. Bread toast rack
1. TouchcontrlpanelwithLCDdisplay
2. Temperature(65℃-200℃)/ 
Timersetting(1-30mins)
3. Increasebutton
4. Decreasebutton
5. Start/Stopbutton
6. PowerON/OFF/Cancelbutton
7. Cookingprograms:
 (DIY,Meat,Fries,Toast,Chicken,Fish)
PRODUCT OVERVIEW

5
• Place the appliance on a stable, horizontal and level surface.
Leave at least 10cm free space on the back and sides, and
pay attention away from curtains, wall covering and other
combustible materials.
• Firstly, open the front door, slide the bake tray into the fryer on the inner base.
(See Pic.1 - 4)
• Insert the Multi-functional grill rack in along the guiding groore that built on the sides
of inner wall. (See Pic.5 - 6)
• Please always keep the bake tray stay in the lowest layer for gathering oil from fried
ingredients.
• Choose proper accessories for different cooking.
• Please use the GLOVE to take out the mult-functional grill rack or bake tray after cooking
nished.
NOTE:
ASSEMBLY INSTRUCTION
Side Side
Back
Pic.1 Pic.2
Pic.5 Pic.6
Pic.3 Pic.4
Bake tray/ Oil collection tray :

6
Basket with detachable handle:
Basket :
The handle should always be used when taking the basket in and out of the unit. The
metal locking hook needs to be in place before lifting the basket. (See Pic. 7 - 8)
After ll ingredients into the well-assembled Basket with its handle, put the basket into
the inner chamber, then dismantle the handle from basket and close the front door.
(See Pic.12 - 15)
To place the handle on the basket, squeeze the handle together in the open position
(See Pic.9). Then attach it to the basket with the hooks facing down and bottom-up
installation (See Pic.10), lock in place with metal hook securely before hold up the basket.
(See Pic.11)
Open hook Locked hook
Pic.9
Pic.7
Pic.10
Pic.8
Pic.13 Pic.14
Pic.11
Pic.12 Pic.15
(Metal locking
hook must be
locked in place)

7
Pic.16
Pic.17
Food separator :
Bread toast rack :
Insert a food separator in the middle of the frying basket to separate the different
ingredients. (See Pic.16)
Place the slide breads into the toast rack on the bake tray (Max 6 slices); Then put the
bake tray together with breads and toast rack into the inner chamber; And then close the
front door before toasting.
• Please always keep the bake tray stay in the lowest layer for gathering oil from fried
ingredients.
• Do not let food exceed the basket. If the ingredients may be expansion after heating,
count the amount according to the heated volume.
•
There is a safety switch for operating safety. (See Pic.17)
• When the front door closed properly, and machine can only start operation.
NOTE:

8
Kebab sticks :
Mode Choosing
Place meat or vegetable on the skewers then place them on top of the mult-functional
grill rack inside the unit, slide the bake tray into the fryer on its inner base.
• Connet the the unit to the wall socket, the Power button will light twinkly with a long
“beep” sound at same time.
• Press the Power button slightly, the digital panel will light all, and the screen show
the default time and temperature alternately, “30:00 ” 200ºC ”
• At this time, there are two kinds of operating modes for users to choose. The rst is
Menu mode, the second is Manual mode.
• Menu mode: The appliance has been set in ve common foods menu for users to
choose.
• Manual mode: Choose DIY menu, allows the users to set according to different foods,
set temperature and frying time. Set the temperature from 65ºC to 200ºC and time up
from 1 to 30 minutes manually.
OPERATING INSTRUCTION
• If you want to stop the program for a while and continue later, you can press the “Start/
Stop” button to pause the process, and can press the “ start/ stop” button again to
continue the program.
• If you press the “Start/ Stop” button during cooking and then open the door, the operation
will be pause. When you close the door within 3 minutes, the program will continue
with your previous setting. The program will stop if door keeps opening more than 3
minutes and need to reset your menu again.
• If you need pre-heat, choose DIY menu, adjust the required time manually.
NOTE:

9
Cooking setting
Cooking nish
• Menu mode: In the menu recipes, there are SIX kinds of function menu, respectively:
DIY, Meat, Fries, Fish, Chicken, Toast.
• Press “MENU” button once, the rst recipes of “DIY” start ashing, click the “MENU”
button once more, the next recipe light ashing, and press the “MENU” button one by
one. The recipe will ash one by one.
• While a recipe is ashing, press the START/STOP button, the appliance begins to
work under the default temperature and time. The preset cooking time and timperature
are listed in the table below.
• When the appliance is nished cooking, it will be heard 5 “BEEP” sounds, its heater
has stopped heats up, but its fan need to work continuously until the temperature of
center of the Inner Chamber drop to 120ºC.
• Open the front door, then assemble and lock the handle on the basket, and make
sure the handle and basket are fastened tightly together with the metal hook. Hold the
handle, take out the basket.
DIY Meat Fries Toast Chicken Fish
Times(Minutes) 3 10 20 6 20 14
Temperature(°C) 180 160 180 190 180 180
• Manual mode: When you need to set different temperature and time to cook different
foods, recommend to use the manual mode. i.e. DIY menu setting.
• Press the (time/temperature) switch button ,
,
,
, the default time/tempsetting ashes,
when the time indicator lights on, press the or button to adjust the time. After
adjusting time and then press the ,
,
,
button again to set the temp, the temperature
display is blinking, the temperature indicator lights on, press the or button to
increase or decrease the temperature.
• After time and temperature setting done, press “START/STOP”button to start the
cooking process.
• In the process of cooking, regular or irregular ip food, to help to cooking more evenly.
• Press the or button for a long time, can quickly adjust the time and temperature.
• As ingredients differ in origin, size, shape and brand, please adjust the best cooking
time and temperature accordingly for your ingredients.
• During cooking, the basket, toast rack, grill rack, sticks and tray’s temperatures are
very high. Pay attention to the hot surface and do not touch them with bare hands;
• Every time when you pull out the basket to ip the foods need to use handle, then push
the Basket into the Inner chamber again, and press “START/STOP” button to continue
working.
• When take out the basket from the appliances, never try to
unlock the Handle and the Basket. It’s dangerous.
CAUTION:
DANGER:

10
• The Basket may be high temperature, never try to touch it with bare hand to avoid
injuries.
• If the ingredients are not well cook yet after cooking, simply put the basket back into
the appliance and add few more minutes of extra cooking time again.Certain part of
the appliance may get hot, such as air outlet. Do not touch these part to prevent scald-
ing yourself.
• Remove the cooked ingredients on a plate or tableware. (See Pic.18)
• Ater cooking nished, unplug the power cord from wall to wait the unit chill down for
safety cleaning and storage.
• To prolong the service life of the Aria fryer and its components, please let the fryer cool
down when operate continuously for around 30 minutes and start another cook work.
• All accessories are dishwasher-proof.
• Unplug the appliance and let it cool down completely before storage
• Make sure all parts are cleaned and dry before storage.
CAUTION:
TIP:
NOTE:
Pic.18
Clean the appliance after every use. Do not clean the frying basket and the interior of the
appliance by metal kitchen utensils or abrasive cleaning materials, as this may damage
their non-stick coating.
• Remove the plug from the socket and let the appliance cool down completely.
• Wipe the exterior of the appliance with a moist cloth.
• Clean the accessories with hot water, some detergent and a non-abrasive sponge.
• Remove any remaining dirt by degreasing liquid.
CLEANING AND STORAGE

11
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The Digital Aria Fryer does
not work
The appliance is not plugged in Put the main plug in an
earthed wall socket
The ingredients fried
with the Digital Aria
Fryer are not well
cooked
The amount of ingredients in the
frying basket is too big
Put smaller batches of ingredients
into the frying basket. Smaller
batches can be fried move
evenly
The set temperature is too low Adjust the temperature to the
required temperature setting
The ingredients are fried
unevenly in the Digital Aria
Fryer
Certain types of ingredients
need to be shaked halfway
through the preparation time
Ingredients that lie on top of or
across each other (e.g. fries)
need to be shaked halfway
through the preparation time
Fried snacks are not
crispy
The type of snacksmeant to
be prepared in a traditional
deep fryer
Use oven snacks or lightly
brush some oil onto the
snacks for a crisper result
White smoke comes out
from the appliance
You are preparing greasy
ingredients
When you fry greasy ingredients in
the Aria fryer, a large amount
of oil will leak into the plate.
The oil produces white smoke
and the plate may heat up
more than usual.
This does not affect the
appliance or the end result
The bake tray still contains
grease residues from previous
use
White smoke is caused by
grease heating up in the bake
tray. Make sure you clean the
bake tray properly after every
use
Fresh fries are fried
unevenly in the Digital
Aria Fryer
You did not use the right type
of potato
Use frozen froes from super
market and make sure that
they stay firm during frying
You did not rinse the potato
sticks properly before you fried
them
Rinse the potato sticks properly
to remove starch from the
surface of the sticks
Fresh fries are not crispy The crispiness of the fries
depends on the amount of oil
and water in the fries
Make sure you dry the potato
sticks properly before you add
the oil
Cut the potato sticks smaller
for a crispier result
Add little olive oil for a crisper
result

12
PRODUCT SPECIFICATIONS
Model no.: GAF1300 / GAF1300V
Voltage: 220-240V~
Frequency: 50/60Hz
Output power: 1200 - 1400W
Product dimensions: 259(W) x 325(H) x 283(D) mm
* The nal product specication may be varied according to a different lot of
material and actual input voltage power of the usage area.

13
安全指引 - 一般安全
安全指引 - 電子和熱能產品
- 請按照這些說明事項, 使用本產品。
- 本產品僅供家用，不作商業用途。
- 使用前，請將所有包裝材料拆除。
- 0至8歲的兒童不應使用本產品。
- 超過8歲的兒童可使用本產品，但請勿由肢體不健全、感覺或精神上有障礙或
缺乏相關經驗和知識的人使用，除非有負責他們安全的人對他們使用本產品進
行監督或指導。
- 請務必看顧好兒童，以確保他們不玩耍本產品。
- 兒童不應清潔或維修本產品。
- 當需進行任何維修，必須由專業維修人員進行維修。永遠不要嘗試自己修理本
產品。
- 手濕時不可以接觸電源插頭或本機。
- 主機不可以浸入水中。
- 兒童不可以把玩本機。
- 本機開著後不可以無人監管。
- 當本機開著時，頭髮、鬆身衣物、手指和身體其他部份都要離開本機。
- 只使用隨機附送的配件。
- 請把本產品放置在平穩的表面上使用。
- 使用相符的電源和電壓，以防止觸電。
- 本產品只能使用帶接地線的電源插座。
- 當本產品不使用時，請從牆上的插座中拔掉插頭。
- 從牆上插座中拔掉插頭時，應拿著插頭而不是電源線。
- 確保本產品、電源線和插頭不與水接觸。
- 確保本產品、電源線和插頭不接觸發熱表面，如明火。
- 定期檢查本產品的電源線以確保其沒有損壞。如果電源線損壞，請勿使用其產
品，並須由專業維修人員來更換，以避免出現任何危險。
- 切勿在易燃材料附近使用本產品。
-
本產品的某部分可能會發熱。不要觸摸這些部分，以防止燙傷自己。
閱讀下列說明事項並請妥善保管，以供日後參考。

14
安全指引 - 操作期間
- 不要把產品貼近牆身或其他電器，保持距離至少10厘米以上。
- 使用產品時，熱空氣和熱蒸氣通過出風口釋放。勿把手和臉貼近本產品。當你拿
出籃子時要小心被熱蒸氣和熱空氣弄傷。
- 使用時，請注意碰到熱表面。
- 在第一次使用本產品時，會有輕微的煙霧，均屬正常的。不久後，將會消失。

15
部件示意圖
1. 輕觸式顯示屏
2. 上殼
3. 電源線
4. 機身
5. 主機門
6. 出風口
7. 進風口
8. 烤盤/盛油盤
9. 多功能烤架
10.炸籃連可拆式手柄
11.食物分隔器
12.串燒捧(共4支)
13.麵包多士架
1. 輕觸式控制面板及LCD顯示屏
2. 時間/溫度設定鍵 
(時間設定範圍:1-30分鐘;溫度
設定範圍:65℃-200℃)
3. 增加鍵
4. 減少鍵
5. 開始/暫停
6. 電源開關/取消鍵
7. 烹調程式:
 DIY自選程式、肉類、薯條、
 多士、雞肉、魚類
無油煎炸鍋
控制面板

16
安裝說明
- 將產品放置在平坦的表面上。 在背面和側面預留至
少10厘米空間，並註意遠離窗簾，牆布和其他可燃
材料。
- 打開機門後，將烤盤/盛油盤推進入機裡，請沿著內壁兩側的引導凸位推進。
(參閱圖1 - 4)
- 放入多功能烤架。請沿著內壁兩側的引導凹位推進。(參閱圖5 - 6)
- 請將烤盤/盛油盤放在最低層，以便從油炸食材中收集油份。
- 為不同的烹飪選擇合適的配件。
- 烹飪完成後，請使用隔熱手套取出炸籃或烤盤/盛油盤。
烤盤/ 盛油盤
多功能烤架
注意：
側面 側面
背面
圖1 圖2
圖5 圖6
圖3 圖4

17
鎖鈎打開 鎖鈎關閉
- 放入或取出炸籃時，應使用手柄。在提起籃子之前，必須將鎖鈎固定到位。
(參閱圖7 - 8)
- 將食材放進炸籃及裝上手柄後，放入機內，然後移除手柄並把機門關上。
(參閱圖12 - 15)
- 將手柄安裝在炸籃上。首先把鈎子向下(圖9)，從下移上裝上於炸籃扣位內
(圖10)，再將鎖鈎固定扣緊使不能鬆掉，才可提起炸籃。(圖11)
(手柄的鎖鈎
必需安裝扣緊)
炸籃子配可拆式手柄
炸籃
圖7
圖9 圖10 圖11
圖12 圖13 圖14 圖15
圖8

18
- 在炸籃中間插入食物分隔器, 可供隔開不同食材。
食物分隔器
- 請將烤盤/盛油盤放在最低層，以便從油炸食材中收集油份。
- 不要讓食材超過籃子。如果加熱後食材會膨脹，請預計加熱後的體積。
- 有一個安全開關在機門左上方，以確保操作安全。 (參閱圖17)
- 當機門關上時，產品才能操作。
- 將烤麵包多士架放在烤盤/盛油盤上（最多可放6塊）; 然後將烤麵包架連同
烤盤/盛油盤盤放入機內 ; 然後關上機門。
注意：
麵包多士架
圖16
圖17

19
- 將肉類或蔬菜串在串燒捧上，並將它們放烤架上，然後將烤架連同盛油盤盤
放入機內 ; 然後關上機門。
- 如果您想暫停程序一段短時間並稍後繼續，可以按“開始/停止”鍵暫停該過
程，然後再次按“開始/按下”鍵繼續該程序。
- 如果在烹調途中按下“開始/停止”鍵之後開門，當三分鐘內關門，之前的烹
調程序會繼續，過了三分鐘後關門，烹調程序會取消，變回最初的設定，需自
行重新設定。
- 如果需要預熱時間，請選擇DIY手動模式，調節時間。
串燒捧
注意：
使用說明-模式選擇
- 把本機連接電源，電源鍵 會同時閃爍一聲“be”聲。
- 輕按電源鍵 ，控制面板全部點亮，屏幕交替顯示默認時間和溫度，
“30：00 ”及“200°C ”
- 此時，有兩種操作模式供用戶選擇。第一種為菜單模式，第二種為手動模式。
- 菜單模式：設備已設置在5個常用食物菜單中供用戶選擇。
- 手動模式：用戶可以根據不同的食物，在DIY手動設定溫度和煎炸時間進行設
置。可調溫度從65℃到200℃，時間從１到30分鐘。

20
- 菜單模式：有六種功能菜單，分別為：DIY，肉類，薯條，魚類，雞肉，多士。
- 按“MENU”鍵一次，第一種菜單“DIY”開始閃爍，再次按“MENU”鍵，
下個種菜單燈閃爍，然後逐個按下“MENU”按鈕。菜單將逐一閃爍。
- 當菜單閃爍時，按START / STOP鍵，便開始於以下默認的烹調時間及温度工
作。以下是6款MENU的默認預設內容只供參照或自行按實際食材調節。
- 手動模式：當您需要設置不同的溫度和時間來烹飪不同的食物時，建議使用手
動模式，即DIY自行設定菜單。
- 按“時間/溫度”設定鍵 ,
,
,
，顯示屏顯示時間閃爍，時間指示燈 亮起，按
或按 鍵 調節時間。調整完時間後再按“時間/溫度”設定鍵 ,
,
,
一次，
溫度閃爍，溫度指示燈 亮起，按增加 或 減少鍵調節所需溫度。
- 完成時間和溫度設置後，按“START / STOP”鍵，便可以開始工作。
- 在烹飪食物的過程中，不時翻轉食物，以確保食物平均煮熟。
- 長按 或 鍵，可以快速調整時間和溫度。
烹飪設置
DIY 肉類 薯條 多士 雞肉 魚類
時間 (分鐘) 3 10 20 6 20 14
温度 (°C) 180 160 180 190 180 180
- 這些設定只供參考，當食材的產地、大小、形狀和品牌不同時，設定亦需作出
調校。
- 在烹飪過程中，炸籃，烤麵包架，烤盤/盛油盤和串燒捧的溫度非常高，切勿
用手觸摸。
- 每次需先裝上手柄才拉出籃子翻轉食物，再將籃子推入機內，然後按
“START / STOP”鍵繼續工作。
- 從機上取出炸籃時，切勿嘗試解開手柄。 這是非常危險。
- 炸籃外殼很燙，切勿用手觸摸，以免受損。
- 當設定的烹調工作完成後，將發出5次“BEEP”聲，表示會停止加熱功能，
但風扇會繼續工作，直到機內溫度降至120°C。
- 打開機門，然後將手柄裝到炸籃上，確保把手柄鎖鈎和炸籃扣緊。握著手柄，
取出籃子。
注意：
危險：
注意：
烹飪完成
