Girard Systems GC660B User manual

SINGLE CHANNEL WALL SWITCH
GC660B
INSTALLATION AND PAIRING GUIDE
REV.12302015
RV AWNING PRODUCTS
1361 CALLE AVANZADO, SAN CLEMENTE, CA 92673 [phone] FAX [phone]
www.girardrv.com

Page 2of 12
Girard Systems awnings may be operated in light wind and rain
conditions. When periods of heavy rain and or high wind are expected
the awning must be closed. Never leave the awning open and
unattended.
Damage caused by wind and rain is not covered by warranty.
All awnings must be closed prior to moving the vehicle for any reason.
As an extra safety precaution a visual check that every awning is fully
closed is required.
Damage caused by failure to comply with these instructions is
not covered by warranty.
Before using your awning, ensure that the area into which the awning
will be deployed is free of obstructions (Trees, walls, pillars, posts,
other vehicles etc.)
Damage caused by collisions with any of the above or similar is
not covered by warranty.
Before using your awning make sure that all of your electrical circuits
are operating correctly. Recreational Vehicles can generate AC power
from three separate sources. The electrical system transfer switch in
your vehicle will select power for the awning as follows:
Shore Power – if connected;
Generator Power – if the generator is running;
Inverter Power – batteries must be charged for inverter operation.
Girard Systems awnings are supplied with an electric motor appropriate to the
product.

Page 3of 12
CONTENTS
Product Description ……………………………………………………………………….…. 4
Setting time and day ………………………………………………………………………... 5
Installation …………………………………………………………………………………….… 6
Programming………………………………………………………………………………….... 7
GC136 AC Motor Controller ……………………………………………………………….. 7
GC274A / GC274B AC motor Controllers …………………………………………….. 8
98GC74 AC Motor Controller ……………………………………………………………… 9
GC732G DC Motor Controller ……………………………………………………..……. 10
GC1146C DC Motor Controller …………………………………………………………. 11

Page 4of 12
PRODUCT DESCRIPTION
The GC660B is a Single channel RF transmitter, powered by two 3v Lithium batteries
(CR2032) designed to control a single Awning by means of three push buttons. IN,
STOP and OUT, and operate an LED lighting strip by use of the LED button on the
control pad as displayed in the picture below.
The faceplate can be removed easily by holding the module at the left and right edges
firmly in one hand and push the STOP button with two fingers of your other hand. The
picture below shows how the batteries must be inserted.

Page 5of 12
SETTING TIME AND DAY
The GC660B not only controls the awning but functions as a 24 hour clock and a 7 day
calendar.
When the battery tray is inserted the display will light up as in the photograph above,
then it will default to Mon 10:00. Replace the faceplate, then;
1) Press and hold the CH button until the hour starts to flash.
Screw
mounting holes

Page 6of 12
2) Set the hour using the IN and OUT buttons.
3) Press the CH button once and the minute will start to flash.
4) Set the minutes using the IN and OUT buttons.
5) Press the CH button once and the day will begin to flash.
6) Set the day using the IN and OUT buttons.
7) Press and hold the CH button until the selected time and day are displayed but
NOTHING is flashing.
8) Press the CH button one final time and the : between the hours and minutes will
begin to flash, this indicates that the clock is set and running.
The CH button serves no other function on this module than to set the time and day.
INSTALLATION
The screw holes indicated in the picture above are the only ones to be used when
mounting the module. Do NOT drill any other holes in this module as this will damage
the circuit board and render the module useless. Screws are provided with the module
for this purpose. The GC660B has an operating range of 100’ but should be mounted
with as few obstructions as possible between itself and the Motor Controller it is paired
with.

Page 7of 12
PROGRAMMING
The following pages give instructions of how to pair the GC660B with various motor
controllers. Ensure that you select the correct set of instructions for the motor controller
on your vehicle.
GC136 AC Motor Controller
Fig.1 Fig.2
To pair the GC660B Wall switch with a GC136 Motor controller follow the steps below.
Note; When carrying out this part of the procedure each step must be executed
within 10 seconds of the previous one or the module will revert to factory settings.
It is highly recommended that you read and understand the following sequence
before attempting to execute it.
1) Ensure that there is power supplied to the Motor controller.
2) Using an appropriate tool press the Program button on the Motor controller. See
Fig.1 (The Green LED will start blinking)
3) Press the STOP button on the Motor Controller. See Fig.2 ( The Green LED will
remain ON)
4) Press the IN button on the Wall switch. (The Green LED will extinguish)
5) Press the OUT, STOP and IN buttons on the wall switch to ensure that the
Modules have been successfully paired.
Program Button
Stop Button

Page 8of 12
GC274A / GC274B AC motor Controllers
Fig.3
To pair the GC660B Wall Switch with a GC274A or GC274B first remove the lid of the
motor control module by pressing on the Lid release catches as shown in Fig.3
Note; When carrying out this part of the procedure each step must be executed
within 10 seconds of the previous one or the module will revert to factory settings.
It is highly recommended that you read and understand the following sequence
before attempting to execute it.
1) Ensure that there is power supplied to the Motor controller.
2) Press the Program button on the Motor controller. (The Green LED will start
blinking)
3) Press the STOP button on the Motor Controller. ( The Green LED will remain ON)
4) Press the IN button on the Wall switch. (The Green LED will extinguish)
5) Press the OUT, STOP and IN buttons alternately on the wall switch to ensure
that the Modules have been successfully paired.
Lid Release
Lid Release
Program Button

Page 9of 12
98GC74 AC Motor Controller
When pairing with the 98GC74 it is advised that the awning to be controlled is manually
extended couple of feet to enable the programmer to see if the awning is responding in
the correct direction when the buttons on the wall switch are pressed.
The programming window for this module is only 6 seconds so please ensure
that the programming instructions are read and understood before
attempting to execute them.
1) Supply power to the motor control module. (It will beep ONCE )
2) Press the P2 button on the wall switch TWICE. (The motor controller will beep
with each press)
3) Press the IN button on the wall switch. (The awning should retract)
If the awning extends at this point instead of retracting, press the STOP button
immediately, then remove the power supply to the motor controller for at least 10
seconds.
Next repeat steps 1 and 2 above then press the OUT button on the wall switch to
complete the programming procedure.
Ensure that the awning responds correctly to the wall switch by pressing the OUT,
STOP and IN buttons alternately.

Page 10 of 12
GC732G DC Motor Controller
Fig.4
To pair the GC660B Wall switch with a GC732G Motor controller follow the steps below.
Note; When carrying out this part of the procedure each step must be executed
within 10 seconds of the previous one or the module will revert to factory settings.
It is highly recommended that you read and understand the following sequence
before attempting to execute it.
1) Ensure that there is power supplied to the Motor controller.
2) Press the Program button on the Motor controller. (The Red LED will start
blinking)
3) Press the STOP button on the Motor Controller. ( The Red LED will remain ON)
4) Press the IN button on the Wall switch. (The Red LED will extinguish)
5) Press the OUT, STOP and IN buttons alternately on the wall switch to ensure
that the Modules have been successfully paired.
Program Button

Page 11 of 12
GC1146C DC Motor Controller
To pair the GC660B Wall switch with a GC1146C Motor controller follow the steps
below.
•Identify the Remote handset which operates the DC Motor controller for the
awning that the wall switch is to operate. This is likely to be either a 98GC1063
Single channel, or a 98GC1029 Multi channel handset.
•Fully extend the awning to ensure smooth operation, and then retract the
awning leaving it partially open (about 3 feet).
•Locate the P2 Button on the back of the handset.
P2 Button

Page 12 of 12
Note; When carrying out this part of the procedure each step must be executed
within 10 seconds of the previous one or the module will revert to factory settings.
It is highly recommended that you read and understand the following sequence
before attempting to execute it.
1) Supply power to the Motor controller. (The GC1146C will emit a soft beep)
2) Using an appropriate tool press the P2 button on the back of the Handset
TWICE. ( The GC1146C will Beep with each press)
3) Press the P2 button on the wall switch ONCE (The GC1146C will beep again)
4) Press the IN button on the wall switch and verify that the awning moves in the
desired direction.
If the awning extends at this point instead of retracting, press the STOP button
immediately, then remove the power supply to the motor controller for at least 10
seconds.
Next repeat steps 1, 2 and 3 above then press the OUT button on the wall switch to
complete the programming procedure.
Ensure that the awning responds correctly to the wall switch by pressing the OUT,
STOP and IN buttons alternately.
For queries or assistance with programming any of your G-Link devices
please call Girard Systems TOLL FREE on 800–382–8442 between 7:30am
and 3:30pm P.S.T.
