GL Racing GLR-GT User manual

www.gl-racing.com
A new benchmark of Low Center Gravity on 1/27 Mini RC –GLR-GT
GL Racing and Development Team conducts a wide research and consulation for 1:27-1:28 scale RC car racing and the GLR-GT
is developed and test intensively on track by GL Team Drivers and group of experienced RC car players.
Performance is always our goal with no compromise for case of drive, adjustment, maintainence and optional upgrade. All levels
of player will be benefited by a proper setup GLR-GT chassis for at least 0.5sec or more faster in average lap-times.
Traction roll is substantially reduced by further lowering down the CG, new suspension design and geometry:
1. “One layered” electronics layout without stacking to achieve the lowest and optimized CG.
2. Micro but most-wanted “Cable Routers” to ensure obstacle-free rear subframe movement.
3. “Roller-Bearing” side shock mechanism for more stroke, sensitivity and centered gravity.
4. New Long Doubled-Wishbone front suspension and geometry for less traction roll.
5. Less traction roll even with lighter springs for more mechanical grip and bumpy track.
6. New optional Front Anti-Roll Bar for fine and most demandable tuning requirement.
7. New Slide Linkage design optimized positioning.
8. Few conversion parts for switching in between 98 to 102mm wheelbase in option.
9. Stock adjustable and optional tuning Front and Rear Tri-Damper.
10. Aluminum Motor Mount for best heat dissipation.
11. Full and high quality ball bearing.
12. Lightened and ultra-smooth rear ball
differential.
GL Racing products are designed and
developed in Hong Kong. Our high-end and
performance product is recommended for player
with age of 14 or over.
Thanks for choosing GL Racing. Page 1
Ver00
90mm Wheelbase

Bag A (1-5)
A-1 A-2
A-3
257014 x1257020 x1
307520 x1357520 x1Lock Nut x1
G1 x1G2 x1
G4 x1
G3 x1
G5 x1
G7 x1
G6 x1
E Pack x1
A Pack x1
B Pack x1D Pack x2
C Pack x1
Page 2
90mm

A-4
A-5 (Pinion Gear from 9T to 14T)
9T x1
14T x1
13T x1
12T x1
11T x1
10T x1
G8a x1G10a x1
G9a x1
S1 Pack x1
S3 Pack x1
S2 Pack x1
Bag A (1-5)
Page 3
90mm

Bag B
B-1
Bag C (1-8)
C-1
F Pack x153T x1
G12 x1G14 x1
G13 x1G15 x1
G16 x1
M3x3 Grub x1
H1 x1
H6a x1
H5 x1
H4 x1
H3 x1
H2 x10
H7 x2
BE-3625 x1
(3x6x2.5)mm
(Ball 2.381mm)
Page 4
90mm
(Alloy) (Alloy)

Bag C (1-8)
C-2 C-3
C-4 C-5
BE-3620 x2
BE-3625 x7
BE-2523 x1
(3x6x2)mm
(3x6x2.5)mm
(2x5x2.3mm with Flanged)
PI-15115 x2
(1.5x11.5mm)
PI-1516 x2
(1.5x16mm)
2x4x1.5 x1
G11 x1
H12 x4
(BS-2502)
H16 x1
(BS-3580)
H15 x5
(BS-3520)
H14 x4
(BS-3540)
H13 x12
(BS-3025)
G17 x1G19 x1
G18 x1
H8 x2
H11 x1
H9a x2
H10 x1
Hard(0.9)
(Black) Soft (0.8)
(Red)
(Ø 1.5x6mm
Threaded Rod)
SP-3 x1SP-4 x1
Page 5
(12mm Length)
90mm
(Alloy) (Alloy)

Bag C (1-8)
C-6 C-7
C-8
SM1 x10
SM2 x10
SM3 x10
SM4 x5
SM7 x5
SM5 x10
1.5 x1
1.3 x10.9 x1
M1x2.5 PM x5M1.2x2.5 PM x3M1.2x4 PB x5M1.5x3.5 PM x3
M2.5x2 Grub x2
M2x3 KM x5M2x3 PM x3
M2x4 KB x22
M2x4 KM x7
M2x4 PB x7
M2x4 PM x3
M2x4 Cup Head x5M2x6 KB x6
SM6 x10
M1.2x3 PB x3
M1.6x4 PM x3
Page 6
(2.3x4.4x0.5)
(3x4.5x0.1)
(5x7x0.2)
(4.2x6.4x0.2)
(2x4x0.1)
(2x4x0.2)
(2x4x0.3)
90mm

Bag D
D-1
GT-S-035 x1
GT-S-036 x1
SP-1 x4SP-2 x1
G20a x1
(GL003 DMG) (Ø 5.3x6.5)mm (Ø 6x11)mm
Page 7
90mm
(Alloy)

Tips: Screw the G19 to
the end. The final
dimension is around
13mm to 13.1mm.
H12 x3 H14 x4
H13 x2 H8 x2
SM5 x10
SM4 x1
BE-3620 x2 SP-3 x1
(Black)
BE-3620
BE-3620
SM4
G19
SP3
G11
H12
G18
G17
H14
H14
H14
H14
H8
H8
H13
H13
SM5
SM5
SM5
SM5
B1
B2
Options: Alloy Steering Hub
GT-OP-008-0
GT-OP-008-1
GT-OP-008-2
GT-OP-008-3
(3x4.5x0.1)
SM5
SM5
Options: Alloy Steering Hub
GT-OP-008-0
GT-OP-008-1
GT-OP-008-2
GT-OP-008-3
Page 8
90mm
13mm

M1.2x3 PB x2
M2x4 PB x2
H13 x2
PI-1516 x2
PI-15115 x2
H13
H13
(M1.5x16)
(M1.5x11.5)
PI-1516 (Long)
PI-15115 (Short)
M2x4 PB
M1.2x3 PB
M1.2x3 PB
G8a
G9a
S1-1
S1-2
S2-1
S2-2
Down Stop Screw
Page 9
Adjusting the Down Stop Screw
to let the front lower arm in horizontal.
M2x4 KB
M2x4 KB x2
90mm

H15 x1
M2x4 KB x2
M2x4 KM x1
M1x2.5 PM x4
H15
G14
C5
C6
M1x2.5 PM
M2x4 KB
M2x4 KM
Page 10
90mm

x2
21.0mm
14mm
257014 x1
H11 x1
(Ø 1.5x6mm
Threaded Rod)
257020 x1
307520 x1
H9a x2
H9a
307520
257020
H11
207514
257020 307520
Counterclockwise
Clockwise
Clockwise
Page 11
90mm

M2x4 KB x2
M2x4 x2
(Cup Head)
M1.5x3.5 PM x1
H12 x1
(BS-2502)
M2x3 PM x2
M2x4 PB x2
H15 x2
(BS-3520)
M2x4 KB
H12
M1.5x3.5 PM
GT-S-035
A1
A3
G13
M2x4
(Cup Head)
M2x4
(Cup Head)
M2x3 PM
M2x3 PM
M2x4 PB
M2x4 PB
H15 H15
G4
G3
B3 B3
G1
G2
Options: GT-OP-009
Alloy servo mount
Options: GL-0820-TG
GL titanium gear servo
Page 12
90mm

M2x4 KM x1
M2x4 KB x6
M2x3 KM x1
M2x4 KB
M2x4 KB
M2x3 KM
M2x4 KM
G16
Options: GT-OP-006
Brass Chassis
Page 13
90mm

G5 G7
G6
M2x4 KB x8
M2x6 KB x2
Options: GT-OP-002-N
Front Anti Roll Bar set
Page 14
M2x4 KB
M2x6 KB
M2x4 KB
90mm
Important notice:
Keeping the alignment
on G3 and G4 once fix
to the chassis board
then to go next step.
G3 G4
Tips: Checking all the ball
joints be moved freely
once snap-in to the arm
then go next step.

M2x4 KB x3
M2x6 KB x2
M2x4 KM x1
SM4 x1
M2x4 KB
M2x4 KB
H13 x1
(3x4.5x0.1)
M2x4 KM
M2x6 KB
H13
SM4
G12
A2
Options: GT-OP-013
Transponder Case Pro
Only fit for
Mini Z Nano
Transponder
Unit GP0005M
sale separated.
Page 15
90mm

M1.2x2.5 PM x2
H13 x2
(2x5x2.3mm with Flanged)
BE-2523 x1
M1.2x2.5 PM
BE-2523
H13
H13
S3-2
F2
F1
H6a
H7
H4
H5
BE-3625 x1
(3x6x2.5)mm
BE-3625
H2 x10
(Ball 2.381mm)
H2
H1
53T x1
Spur Gear
53T
F Pack x1
Note: Apply Team
KYOSHO Ball Diff.
Grease around the
ball before assembly.
Page 16
90mm

M1.2x4 PB
M1.2x4 PB x2
M1.5x3.5 PM x2
M2x3 KM x2
M2x4 KM x4
M2x4 KB x1
BE-3625 x2
(3x6x2.5)mm
H13 x3
(BS-3025)
SM2 x1
(2x4x0.2)
BE-3625
BE-3625
G10a
S3-3
H13
H13
SM2
E1
E1
G20a
G15
H15 x2
(BS-3520) M2x4 KM M2x3 KM
M1.5x3.5 PM
H15
H15
M1.2x4 PB
Refer to setup
tips point 2 on
page 21 then to
proceed.
E1
E2 E2
**Rear Ride High Adjustment**
Page 17
90mm
M2x3 KM
M2x4 KB

H16 x1
(BS-3580)
H13 x2
(BS-3025)
2x4x1.5 x1
M1.6x4 TM x2
M3x3 Grub x1
H16
2x4x1.5
M3x3 Grub
H13
M1.6x4 TM S3-1
H3
Options: GT-OP-007-N
T6 Alum. Front Shock Tower
Page 18
90mm

SP-1 x4 SP-2 x1
(Ø 5.3x6.5)mm (Ø 6x11)mm
M2.5x2
Grub x1
H10 x1 357520 x1
357520D1
D2
D1
D2
D3D4
D3
SP-1
SP-1
M2.5x2 Grub
SM7 x4
(5x7x0.2)
SM7
SP-2
C4
C2
C3
C1
H10
Options: GT-OP003-C
Soft
Hard
Spring Set -CS
Options: GT-OP-001
Spring Set –F/R
Soft
Hard
Options: GT-OP-003
Adjustable central shock
Options: GT-OP-004
Adjustable screw Shock
SM6
SM6 x8
(4.2x6.4x0.2) SM6
SM6
Note: Apply Team
KYOSHO #15000 Ball
Diff. Grease (not
included) around ALL
damper pins before
assembly.
Page 19
D4
90mm

BE-3625 x5
(3x6x2.5)mm
M2x4 Cup Head x2
Lock Nut x1
BE-3625
BE-3625
BE-3625
Lock Nut
Lock Nut
M2x4 Cup Head
RX Receiver is NOT INCLUDED
Available at GL Online Shop
GL Mini ESC
12T
Pinion Gear
GLR-GT Gear Ratios
51 52 53 54
95.67 5.78 5.89 6.00
10 5.67 5.20 5.30 5.40
11 4.64 4.73 4.82 4.91
12 4.25 4.33 4.42 4.50
13 3.92 4.00 4.08 4.15
14 3.64 3.71 3.79 3.86
Tire & Rims are NOT INCLUDED
Available at GL Online Shop
Brushless Motor is NOT INCLUDED
Recommended 2500KV or 3500KV motor
Available at GL Online Shop
Options: GL-SD-ESC-010T
Brushless Sensored ESC
Lock Nut
Tips: Apply Superglue on F/R
rubber tires during assembly.
Page 20
A 4
