Glace Bay Ice Machine Installation, Maintenance and Operation Manual Page 1

Glace Bay Ice Machine Installation, Maintenance and Operation Manual Page 2
Before installing, operating, or maintaining this product, carefully read the entire contents of
this instruction manual.
Become familiar with the equipment’s function and safety precautions prior to operating or
servicing the unit.
Always use tools that are in good condition when servicing the unit.
Always read and follow any safety placards that are located on the unit. These placards contain
specific safety information regarding refrigerant and electrical voltage hazards.
Always follow local environmental regulations when working with refrigerant.
Fill in the information listed below and file away for future reference.
© Glace Bay Enterprises Inc, all rights reserved
© Copyright 2017. Glace Bay Ent, Inc
P
h
o
n
e:
8
8
8
-
3
8
1
-
1
5
5
0
F
Model Number:
____________________________________________
____________________________________________________
_____________________
Serial Number
____________________________________________
Purchased Date:
____________________________________________
___________________________________________________
Install Date:
____________________________________________
___________________________________________________
Preface

Installation, Operation and Maintenance Instructions of
Granular Ice Machine
I. Overview
068-128: vertical granular ice machine with an ice bin.
258-458: modular granular ice machine to be used with the B105 ice bin.
The machine must be installed by or under the guidance of professional
installation personnel.
Please carefully read and understand all the contents of this manual before
installation.
If you have any question, contact the local agent or directly call the hotline
marked on the machine.
II. Installation of Ice Machine
1. Unpacking Precautions
Check the model before unpacking.
Check the outer package before unpacking.
Check the machine and its accessories after unpacking.
2. Environmental Requirements
Use the machine indoors, but not below the freezing point.
Ambient temperature: with the maximum below 40℃and minimum above
3℃
Surrounding spacing: keep the appropriate spacing around the machine
(properly reduce this distance for the water-cooled model), as show below:
Machine Part Spacing (cm)
Side 15
Back 20
Front 30
Keep the front, rear, left and right sides level (via the adjustable feet at the
bottom) after installation.
Glace Bay Ice Machine Installation, Maintenance and Operation Manual Page 4

Water supplied to the ice machine must comply with the local standards of
drinking water.
Pretreatment may be needed for the water supplied to the Ice Machine
(depending on the local water quality).
Do not use hot water in the ice machine!
Refer to the table below for the layout of water supply and drainage pipelines:
Installationdiagram(forreferenceonly):
Water
Temperature
(℃)
Ice-making
Water
Pressure
(Mpa)
Cooling
Water
Pressure
(Mpa)
Inside
Diameter of
WaterInlet
Pipe
(mm)
Inside
Diameter of
DrainPipe
(mm)
>0.6
>0.13
>0.59
>9.5(3/8”)
>15.8(5/8”)
<32
<0.55
<1.17
Headper
meter:>3cm
Drainpipe
Externalpowersupply
Externalwatersource
068-128
Drainageintothesewer
Glace Bay Ice Machine Installation, Maintenance and Operation Manual Page 5
3. Water System Installation

removed!
Check whether the level of the Ice Machine is adjusted!
Check whether the water pipes are properly connected, and whether the water
pressure is within the normal range, and ensure that ice-making water and
coolingwater(onlyforthewater-cooledmodel)aresuppliedtothemachine!
Check whether the plug is reliably connected to the power supply!
Checkwhethertheearthwireofthemachineisreliablygrounded!
Checkwhetherthepowervoltageandfrequencyarethesameasthoseonthe
nameplate!
Checkwhethertheambienttemperatureandwatertemperaturearewithinthe
above ranges!
2.Operationpanel:
Functionzone:
Start button
Operating status
068-128
Glace Bay Ice Machine Installation, Maintenance and Operation Manual Page 7
258-458
Operating status
Start button

3. Operation process and status description:
Startup: properly connect the power supply and water source, and press the
button (ON/OFF) on the panel to start normal operation. The power indicator
will be ON. The machine will automatically operate in an unattended manner
(note: shut down the power supply in case of thunderstorm or no use in a long
time).
Shutdown: press the button (ON/OFF) on the panel to stop the operation of
the machine.
Automatic shutdown with full ice: with ice accumulated in the bin to a certain
height in the operating process, the full ice switch will be triggered, the
machine will confirm that the ice bin is full of ice after some time (about 60s)
and then automatically stop operating, and the full ice indicator will be ON.
When ice is removed, the full ice switch will be reset, the full ice indicator
will be OFF, and the machine will automatically start normal operation.
4. Other special shutdown statuses:
When water shortage is detected, the machine will automatically stop
operating, and the water shortage indicator will be ON. After this fault is
eliminated, the water shortage indicator will be OFF, and the machine will
Glace Bay Ice Machine Installation, Maintenance and Operation Manual Page 8
automatically start normal operation.
When the condenser temperature is too high, the machine will automatically
stop operating, and the condenser temperature fault indicator will be ON.
After this fault is eliminated, the condenser temperature fault indicator will be
OFF, and the machine will automatically start normal operation.
When the reducer speed is abnormal, the machine will automatically stop
operating, and the speed fault indicator will be ON. After this fault is
eliminated, the speed fault indicator will be OFF, and the machine will
automatically start normal operation.

IV. Maintenance and Common Faults
1. Maintenance:
Shut down the power supply before maintenance and repair!
Maintenance and repair must be performed by the qualified professionals.
Please carefully read this manual before maintenance and repair.
The manufacturer is exempted from liabilities for consequences related to
water sanitation and violations of the operating instructions.
Regularly clean the dust on the surface of the machine.
Clean the filter (only for the air-cooled model) on a regular basis
(recommendation: once a month).
Clean the condenser fins on a regular basis (at least once every six months) by
gently brushing up and down with a soft brush. Do not brush the fins right
and left in order to avoid damage to the fins and influence on cooling effects!
2. Common faults and troubleshooting:
Fault
Possible Cause
Inspection and Troubleshooting
Failure in startup of
the ice machine
1. No power supply is
available.
2. The bin is full of ice.
1. Check the power switch
and cable.
2. Remove ice.
Glace Bay Ice Machine Installation, Maintenance and Operation Manual Page9
Automatic shutdown
about 3 min after
each startup
1. The ambient temperature is
too high.
2. The condenser is too dirty.
3. The high-voltage switch is
damaged.
4. The fan is damaged.
5. There is no cooling water in
the water-cooled
machine.
1. Reduce the ambient
temperature, and keep the
specified spacing around
the machine.
2. Clean the filter and
condenser.
3. Replace the high-voltage
switch.
4. Replace the fan.
5. Supply cooling water.
Water shortage
1. There is no water in the
external water source.
2. The water level sensor does
not send the signal.
3. The water level sensor is
damaged.
1. Ensure that there is water
in the external water
source, and open the
corresponding valve.
2. Check the connection and
contact of the water level
sensor.
3. Replace the water level
sensor.

3. Conditions excluded from warranty:
The following conditions and items are excluded from the warranty of the ice
machine:
A. Normal maintenance, adjustment and cleaning.
B. Modification or use of non-original parts without the written approval of the
company.
C. Damage caused by improper installation, power supply, water supply and
drainage.
Too high
temperature of the
condenser or too
slow making of ice
1. The condenser is dirty.
2. The ambient temperature is
high.
3. Ventilation is in poor
conditions.
1. Regularly clean the filter
and condenser.
2. Reduce the ambient
temperature.
3. Keep the specified spacing
around the machine.
Speed fault
1. The speed sensor at the tail
end of the motor is in poor
conditions.
2. The speed sensor at the tail
end of the motor is
damaged.
3. The reducer is damaged.
1. Check whether the speed
sensor is damaged or and
whether the magnet has a
significant deviation.
2. Replace the speed sensor.
3. Replace the reducer.
Glace Bay Ice Machine Installation, Maintenance and Operation Manual Page 10
D. Labor costs increased for work on holidays or overtime, travel time, travel
expenses, non-meaningful request for repair, additional costs arising from
inconveniences in maintenance on the installation site.
E. Damage caused by misuse, abuse or negligence.
F. Damage or failure caused by installation, cleaning or maintenance
nonconforming to the technical requirements of this manual.
G. Other damage caused by human factors.
V. Accessories
See the attached list.

VI. Appendix
Circuit diagram:
Display panel
Reducer motor For 068-128
speed input
Condenser temperature sensor
Evaporator temperature sensor
Full ice sensor
Water level sensor
Reducer motor speed
sensor
Defrosting valve
Master control panel
Display panel
For 258-458
Power plug
Power ON/OFF
Compressor
Fan
Glace Bay Ice Machine Installation, Maintenance and Operation Manual Page 11
Rev
Description of Change
Date
1
Initial Release
September-2017
2
1st Revision
December-2018
Revision Hisory:
