Glacier LS42DB User manual

LIBRARY SHELVING UNIT
LS42DB LS48DB
LS60DB LS72DB
LS84DB
DOUBLE BASE UNIT
01/05
BY
IMPORTANT!
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a
carpeted surface.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX [phone].

PARTS DIAGRAM
HARDWARE
C
E
LS42DB
LS48DB
LS60DB
LS72DB
LS84DB
01300141
01300241
01300341
01300441
01300541
2 ea.
2 ea.
2 ea.
2 ea.
2 ea.
LS42DB - 6 ea.
LS48DB - 6 ea.
LS60DB - 8 ea.
LS72DB - 10 ea.
LS84DB - 12 ea.
412226
H2 Book Stop
H5 Varianta Screw 988060 16 ea.
H4 Tab-V Metal
Flange 909931 16 ea.
LS42DB - 16 ea.
LS48DB - 16 ea.
LS60DB - 24 ea.
LS72DB - 32 ea.
LS84DB - 40 ea.
909932
H7 Tab-V Metal
Shelf Clip
LS42DB - 40 ea.
LS48DB - 40 ea.
LS60DB - 50 ea.
LS72DB - 60 ea.
LS84DB - 70 ea.
988056
H3 # 8 x 5/8"
Panhead
Screw
H6 Metal Frame 412026 1 ea.
Top 01300101 1 ea.
Fixed/
Adjustable
Shelf 01200124
6 ea.
6 ea.
8 ea.
10 ea.
12 ea.
A
LS42DB - 32 ea.
LS48DB - 32 ea.
LS60DB - 40 ea.
LS72DB - 48 ea.
LS84DB - 56 ea.
909930
H1 Tab-V
Plastic
Housing
Side
LS42DB
LS48DB
LS60DB
LS72DB
LS84DB
The diagram show one size for ease of viewing. Any differences will be indicated in each part’s description.

it is important to read all the way through the Adder instructions
(enclosed in the Adder carton) before beginning. It will be necessary
to substitute a Divider (J) for a Right Side (B) during assembly.
NOTE:
The diagrams show one size for ease of viewing.
Any differences will be indicated in each step
’ s text.
If you have purchased an Adder unit
to be assembled in conjunction with this Base unit,
it is important to read through the Back option
and/or Toe Space option directions before beginning.
If you have purchased the Back option or the Toe Space option
to be assembled in conjunction with this Base unit,

Using a plastic mallet, tap in the
plastic housings with the flat
edge facing outwards until flush
with the surface.
IMPORTANT! The flat
edge of the plastic
housing must be
aligned with the shelf
edge. Plastic Housings
cannot be repositioned
once installed.
For a Fixed Shelf or Top,
install the metal flange using a
System (Varianta) Screw as
shown. DO NOT over tighten!
For an Adjustable Shelf, use
the Metal Shelf Clip.
Slide the shelf into place over
the Metal Flanges and push
down until fully seated.
Turn the rotating portion (Cam)
1/2 turn to lock in place.
To remove, simply turn the
Cam counter clockwise 1/2
turn and lift the shelf off of the
Metal Flanges.
ALIGNED
FLAT
EDGE
USING THE TAB-V SYSTEM:
ADJUSTABLE
FIXED

ASSEMBLED DISASSEMBLED
Using the Minifix System:
Insert the Minifix Cams into the
appropriate holes with the arrow
facing outwards as shown.
Using the #2 Phillips screwdriver,
rotate the Cam Devices a half turn
clockwise until snug.
To disassemble, turn the Cam
Devices counter-clockwise and
remove panels.
When screwing post into hole, Do
Not over tighten. Screw post down
until bottom face of post flange just
touches board surface.
H2
H3
E
H1
H1
Install four Plastic
Housings (H1) into
each shelf. Attach a
Book Stop (H2) to
each Fixed/Adjustable
Shelf (E) using five
Panhead Screws (H3)
in the pre-drilled holes.
#1
#2
Install eight Plastic
Housings (H1) into the
Top Panel (C) as shown.
H1
C
H1
H1
H1
H1
H1
H1
H1
H1

#3 Place both Side (A)’s on a clean, carpeted surface as shown. Install Metal
Flanges (H4) using Varianta Screws (H5) in each Side Panel into the selected
pre-drilled holes as indicated.
SIDE
PANELS
FOURTH SET
OF HOLES
FROM BOTTOM
TOP SET OF HOLES
H4/H5
H4/H5
H4/H5
H4/H5
H4/H5
H4/H5
H4/H5
H4/H5
H4 H5
For a 3/4" Back, follow the directions for a
Back Panel. Attach the Back Panel (D) to the
Side (A) as shown. Tighten the Rafix Cams
(H8) 1/2 turn.
#4
H3
H8
H6 D
METAL FRAME 3/4" BACK
For a Metal Frame, attach the Frame (H6) as
shown using five #8 x 5/8" Panhead Screws.
NOTE: If you are installing an Adder, follow the instructions for an Adder unit at this time.

#5
METAL FRAME: 3/4" BACK :
NOTE: If you are installing the Toe Space option, it is recommended to install the Toe
Space at this time. Follow the directions included with the Toe Space option.
With the assistance of another person, stand the assembly
upright and attach the other Side Panel.
METAL FRAME: 3/4" BACK :
C
H1 H1 C H1 H1
#6 Attach the Top Panel (C) using the Tab-V System. Turn the
eight Tab-V Cams (H1) 1/2 turn clockwise to secure.

#7
E
E
METAL FRAME: 3/4" BACK :
E
E
Attach two Fixed Shelves (E) in the same manner.
Placement of the Adjustable
Shelves is optional. The diagram
below shows a recommended
placement for the spacing of the
shelves.
NOTE: The diagram shows the
LS84DB. The shorter bookcases
will use the appropriate sets of
placements.
#8
TOP
TOP
55TH SET OF HOLES
FROM THE BOTTOM
44TH SET OF HOLES
FROM THE BOTTOM
34TH SET OF HOLES
FROM THE BOTTOM
24TH SET OF HOLES
FROM THE BOTTOM
14TH SET OF HOLES
FROM THE BOTTOM

#9
Insert Metal Shelf Pins (H7)
into both Sides at the
preferred heights for the
Adjustable Shelves.
H7
Place the Adjustable
Shelves (E) into each side
of the unit, and lock the
Tab-V cams to secure.
#10
FINISHED
EDGE
E
H7
H7

#11
Your Glacier Library Shelving
unit is now assembled and
ready for use.
