Gladius G0975 User manual

Gladius G0975/0975M
9.7” Intel®Celeron®N2930
Rugged Tablet PC
User's Manual
Version 1.2
P/N: 4019097500120P2017.01

- II -
This page is intentionally left blank.

- i -
Revision History
Version Date Descriptions
1.0 2015.03 Initial release
1.1 2016.11
1.3 Specifications: Updated to the latest specications
New sections:
A. Using the Vehicle Cradle (Optional)
B. Using the Desktop Cradle (Optional)
1.2 2017.01 Added new model (G0975M) descriptions

- ii -
Copyright
Copyright © 2016 ARBOR Technology Corp. All Rights Reserved.
This document contains proprietary information protected by copyright. No
part of this manual may be reproduced by any mechanical, electronic, or other
means in any form without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
About This Manual
This user’s manual provides the general information and installation
instructions for the product. The manual is meant for the experienced users
and integrators with hardware knowledge of personal computers. If you are not
sure about any description in this manual, consult your vendor before further
handling.
We recommend that you keep one copy of this manual for the quick reference
for any necessary maintenance in the future. Thank you for choosing ARBOR
products.

- iii -
Contents
Contents
Preface.........................................................................................................vii
Declaration of Conformity .................................................................................... vii
CE................................................................................................................. vii
FCC Class B ................................................................................................. vii
RoHS ........................................................................................................... viii
SVHC / REACH ........................................................................................... viii
Symbols Description.............................................................................................ix
Important Safety Instructions................................................................................ix
Rechargeable Battery Pack Safety.......................................................................xi
General Cleaning Tips ......................................................................................... xii
Cleaning Tools ............................................................................................. xiii
Recommended Cleaning Procedures.......................................................... xiii
Disposing of the Computer ................................................................................. xiv
Additional Information & Technical Support .........................................................xv
Warranty ............................................................................................................. xvi
Chapter 1. Introduction................................................................................1
1.1 Product Highlights............................................................................................2
1.2 Package Contents ...........................................................................................3
1.2.1 Order Information...................................................................................3
1.2.2 Optional Accessories .............................................................................4
1.2.3 Congure-to-Order Service (for G0975 only).........................................4
1.3 Specications...................................................................................................4
1.3.1 G0975 ....................................................................................................4
1.3.2 G0975M .................................................................................................7
1.4 Dimensions....................................................................................................10
1.4.1 G0975 ..................................................................................................10
1.4.2 G0975M ...............................................................................................11
Chapter 2. Getting Started.........................................................................13
2.1 Getting to Know the Computer ......................................................................14
2.1.1 Front Side ............................................................................................14
2.1.2 Left and Right Sides.............................................................................18
2.1.3 Bottom Side .........................................................................................20
2.1.4 Rear Side.............................................................................................20
2.2 Installing Memory Card..................................................................................21
2.3 Installing/Replacing the Extenal Battery Pack ...............................................21
2.4 Charging the Battery Pack.............................................................................24

- iv -
Contents
Important Notice on Charging the Battery.......................................24
2.5 Driver Installation...........................................................................................25
Notice on USB Hub Driver...............................................................28
Chapter 3. Using the Computer.................................................................31
3.1 Using Touch Screen.......................................................................................32
3.1.1 Projected Capacitive Touch ................................................................32
3.1.2 Text Input .............................................................................................32
3.1.2.1 On-screen Keyboard ...........................................................32
3.1.2.2 Handwriting Recognition .....................................................33
3.2 Function Keys................................................................................................34
3.2.1 Using the Function Keys......................................................................34
3.2.2 Customizing the Function Keys ...........................................................34
3.3 Using the Wi-Fi Feature.................................................................................36
3.4 Using the Bluetooth Feature..........................................................................38
3.4.1 Launching the Bluetooth Feature.........................................................38
3.4.2 Pairing/Connecting with Other Bluetooth Devices ...............................39
3.4.3 Bluetooth Device Name .......................................................................40
3.4.4 Hiding/Exposing the Computer ............................................................40
3.5. Using the Camera (for G0975 Only).............................................................42
3.5.1 Launching the Camera.........................................................................42
3.5.2 Taking a Picture ...................................................................................43
3.5.3 Shooting a Video..................................................................................43
3.5.4 Conguring Video Shooting .................................................................43
Chapter 4. Utilities......................................................................................45
4.1 ARBOR System Suite....................................................................................46
4.1.2 Accessing ARBOR System Suite.........................................................46
4.1.3 Using ARBOR System Suite................................................................47
Chapter 5. BIOS ..........................................................................................49
5.1 Accessing the BIOS Setup Utility...................................................................50
5.2 Main Setup.....................................................................................................51
5.3 Advanced Settings .........................................................................................52
5.3.1 Boot Conguration ...............................................................................53
5.3.2 PCI Express Conguration...................................................................53
5.3.3 Miscellaneous Conguration................................................................54
5.3.4 Thermal Conguration ........................................................................54
5.3.5 SATA Conguration .............................................................................55
5.4 Security Settings............................................................................................56
5.5 Power Settings ..............................................................................................57

- v -
Contents
5.6 Boot Settings .................................................................................................58
5.7 Exit Options ...................................................................................................59
Appendix .....................................................................................................61
A. Using the Vehicle Cradle (Optional) ................................................................62
A.1 Overview.................................................................................................62
A.2 Specications .........................................................................................63
A.3 Dimensions.............................................................................................64
A.4 Installing the Vehicle Cradle ...................................................................65
A.4.1 Docking the G0975 to the Vehicle Cradle..............................65
A.4.2 Installing the Vehicle Cradle Driver........................................67
A.4.3 Mounting the Cradle to a Vehicle...........................................72
A.4.4 Connecting the Peripherals to the Cradle..............................73
A.5 Removing the G0975 from the Vehicle Cradle .......................................73
B. Using the Desktop Cradle (Optional)...............................................................75
B.1 Overview.................................................................................................75
B.2 Specications .........................................................................................76
B.3 Dimensions.............................................................................................77
B.4 Installing the Desktop Cradle..................................................................77
B.4.1 Docking the G0975 to the Desktop Cradle ............................78
B.4.2 Installing the Desktop Cradle Driver ......................................78

- vi -
This page is intentionally left blank.

- vii -
Preface
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the
directives of the Union European (EU). A Certicate of Compliance is available
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of
shielded cables. This kind of cable is available from ARBOR. Please contact
your local supplier for ordering information.
FCC Class B
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference
that may cause undesired operation.
Any changes or modications not expressly approved by the guarantee of this
device could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
Preface

- viii -
Preface
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
RoHS
ARBOR Technology Corp. certies that all components in its products are
in compliance and conform to the European Union’s Restriction of Use
of Hazardous Substances in Electrical and Electronic Equipment (RoHS)
Directive 2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose
of the directive is to prohibit the use of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU
are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that
exceed a maximum concentration value of 0.1% by weight or for cadmium
exceed 0.01% by weight, per homogenous material. Homogenous material
is dened as a substance or mixture of substances with uniform composition
(such as solders, resins, plating, etc.). Lead-free solder is used for all
terminations (Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the
earth we live, ARBOR hereby conrms all products comply with the restriction
of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH
--Registration, Evaluation, Authorization, and Restriction of Chemicals)
regulated by the European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)
