Glasdon Automate FIREXPIRE Installation instructions

1.
Automate™
FIREXPIRE™RE-ASSEMBLY INSTRUCTIONS
IMPORTANT NOTE: ENSURE THAT ALL RELEVANT PERSONNEL READ THESE INSTRUCTIONS PRIOR TO USE
1.
2.
DO NOT DESTROY - IMPORTANT SAFETY INSTRUCTIONS
FIREXPIRE IS AN EFFECTIVE LOW COST AUXILIARY DEVICE AND MUST NEVER REPLACE PRIMARY FIRE
PREVENTION MEASURES. OBSTRUCTIONS PREVENTING THE PLATE FROM DROPPING MAY ADVERSELY
AFFECT THE FUNCTION OF THE UNIT AND AS MANY FIREXPIRE DEVICES ARE USED IN UNSUPERVISED
LOCATIONS, REGULAR INSPECTION AND IMMEDIATE REPLACEMENT OF ANY DAMAGED OR DISTORTED
COMPONENTS IS ESSENTIAL.
REQUIRED
• Replacement Thermoplastic Trigger Washer
• Screw Driver
HOW TO REPLACE THE PLATE FOLLOWING A FIRE
HOW IT WORKS
The Firexpire system includes four important
components.
1. Central Spacer
2. Firexpire Extinguishing Plate
3. Thermoplastic Trigger Washer
4. Panhead Screw
Firexpire works by having a plate suspended
above aperture height secured by a
Panhead Screw and a Thermoplastic Trigger
Washer.
When a re occurs inside the liner, the
Thermoplastic Washer responds by releasing
the Firexpire Plate.
This then drops onto the liner sealing and
starving the re of oxygen, thus snufng out
the re.
After rst ensuring the Firexpire Plate is cool
and the contents of the Liner compartment
have been extinguished, remove the top
section of the litter bin and turn the Hood
upside down.
Using a screwdriver, unscrew the Panhead
Screw and Thermoplastic Trigger Washer
(which will now be deformed) from the
Central Spacer. Remove and discard the
deformed Thermoplastic Trigger Washer
from the Panhead Screw.
Extinguishing Plate
Thermoplastic Trigger Washer
Panhead Screw
Central Spacer

2.
HOW TO REPLACE THE PLATE FOLLOWING A FIRE (Continued)
IMPORTANT NOTE: PLEASE ENSURE THAT ALL RELEVANT PERSONNEL READ THE POINTS LISTED WITHIN THIS LEAFLET AND
THAT A COPY IS GIVEN TO STAFF INVOLVED WITH THE INSTALLATION AND MAINTENANCE OF THIS PRODUCT
SAFETY NOTE: PLEASE REFER TO ‘THE MANUAL HANDLING OPERATIONS REGULATIONS 1992’ DURING HANDLING.
.
Stock No. C000/0512 - DWG No. 07B-315-42 Issue 1 - November 2017
AND FIREXPIRE ARE TRADEMARKS OR REGISTERED TRADEMARKS OF GLASDON GROUP OR ITS
SUBSIDIARIES IN THE U.K. AND OTHER COUNTRIES
A planned maintenance schedule or regular inspection is
recommended, replacing components as necessary.
Replacement components are available direct from GLASDON.
GLASDON cannot be held responsible for claims arising from incorrect
installation, unauthorised modications or misuse of the product.
© Copyright NOVEMBER/2017 OF 1ST ISSUE
Glasdon UK Ltd reserve the right to alter specications without prior notice.
Glasdon U.K. Limited
Preston New Road
BLACKPOOL
Lancashire FY4 4UL
Tel. : [phone]
Fax : [phone]
e-mail: [email protected]
web: www.glasdon.com
Assemble the Panhead Screw and a
replacement Thermoplastic Trigger Washer.
Locate the Extinguishing Plate and position
over the Central Spacer.
Locate the assembled Panhead Screw and
Thermoplastic Trigger Washer and position
onto Central Spacer.
Secure by screwing the Panhead Screw
and Trigger Washer into the Central Spacer.
NOTE. ENSURE THE PLATE IS CENTRAL BEFORE
TIGHTENING.
Thermoplastic
Washer
Panhead Screw
3. 4.
5.
