Glatz Sombrano S+ User manual

Sunshade
Sombrano S+
Maintenance
manual
Sombrano S+

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en
Path:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
The following works are described in this maintenance manual:
1. Replacing the gear / car cord ........................................................................... 3
1.1. Dismount ...................................................................................................... 3
1.2. Gear change ................................................................................................ 4
1.3. Replacing the transmission part ................................................................... 6
1.4. Assembly...................................................................................................... 6
1.5. Final check ................................................................................................... 7
2. Replacing the support shaft cord .................................................................... 7
2.1. Dismount ...................................................................................................... 7
2.2. Inserting a new support shaft cord into the car............................................. 8
2.3. Correct adjustment of the support shaft cord…………………………………..9
3. Replacing the screen, canopy or inner shaft ................................................ 10
3.1. Dismounting the screen.............................................................................. 10
3.2. Replacing the inner shaft............................................................................ 10
3.3. Exchanging the canopy .............................................................................. 11
3.4. Mounting the screen with new canopy below the support shaft head......... 11
4. Replacing the ribs ........................................................................................... 12
5. Replacing the locking clip .............................................................................. 13
6. Replacing hand grip........................................................................................ 13
7. Replacing the steering link........................................................................ 17-18
8. Replacing the top notch / runner (2 people required) .................................. 19
8.1. Preparation for replacing the runner........................................................... 19
8.2. Preparation for replacing the top notch ...................................................... 20
8.3. Dismounting the top notch / runner: ......................................................... 221
9. Closing the sunshade ..................................................................................... 22
ØIf you are interested in the workshop equipment / installation aid (see points 4
and 7), please contact our repair centre at [email protected]
Remark
Screws that are not secured with female screws with plastic inserts are secured originally ex works
with an adhesive (e.g. Loctite Ô) (difficult to retract after implementation).
An adhesive is also to be used after repair works so that a permanently stable connection is created.
Technical changes remain reserved.
© Glatz AG 11/2013
GLATZ AG . Neuhofstrasse 12 . 8500 Frauenfeld . Switzerland . www.glatz.ch

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 3
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
Preparation: prepare a clean base to place the sunshade on
Tool: pin spanner 6-point 2 mm, 3 mm, 4 mm, 5 mm, 6 mm
Spanner with adjustable spanner length
1. Replacing the gear / car cord
1.1.Dismount
Proceed as follows with the upright or lying sunshade:
·Remove the screws on the pole shaft and remove the pole from the turning foot

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 4
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
1.2.Gear change
·Unscrew gearbox, remove 2 countersink screws M5 x 30
·Hold and pull out the axis on the hexagonal nut

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 5
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
·In order to remove the upper link, countersink screw M6 x12 must be released and
removed from the masthead.
·Pull out the masthead. Subsequently, take out the gear and insert the new gear
accordingly.
In order to open the car (due to the cord guide), proceed as follows:

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 6
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
·Remove the upper half of the car (at the side of the female screw)
·Lay the sunshade down so that all screws on the car can be released from below
with the pin spanner. Important: do not pull out the screws!
1.3.Replacing the transmission part
·Undo the knot in the cord, tie a knot in the new transmission part and insert it. The
cord must be in the pole rabbet.
1.4.Assembly
·Lay the sunshade down so that the crank is underneath so that all screws of the
slide can be tightened from below with the pin spanner.
·Carefully replace the upper half of the slide and screw it on from below.
·Make sure that the cord does not get jammed in.
·Put the crank in place and turn it, while the other end of the cord is also pulled at.
·The cord must move in accordance with the direction of turning.
·No clicking sound should be heard.
·If the cranking is continued when the cord is fully unravelled, the cord coils itself up
again.

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 7
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
1.5.Final check
·After a successful function check, completely roll out the cord.
·Place the sunshade on the base again.
·Reassemble the gear, axis and gearbox, analogous to the previous step.
2. Replacing the support shaft cord
Preparation: prepare a clean base to place the sunshade on
Tool: pin spanner 6-point 4 mm, 6 mm
Spanner with adjustable spanner length
2.1.Dismount
Proceed as follows with the upright or lying sunshade:
·Unscrew the support shaft cord buckle from the foot of the mast and tie a knot in
the new cord.
·Remove the screws at the foot of the mast and lift and lift the mast off the rotary
base
·Lay the sunshade down and position it so that the
crank is on top
·Release the support shaft head screws, remove the
top half and remove the screen
Make a knot in the shape
of an 8 and pull it tight

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 8
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
2.2.Inserting a new support shaft cord into the car
·Lay down the sunshade so that all screws of the car can be released from below
with the pin spanner. Important: do not pull out the screws!
·Put the sunshade back on the base.
·Remove the top half of the car (at the side of the female screw).
·Place a new cord (from the support shaft cord buckle) around the snatch blocks of
the car and push it through the support shaft pipe. Use a passage aid (e.g. a wire)
or
lift up the mast at the bottom so that it is standing slightly diagonally and so that
the cord can be conducted more easily.
·Pull out the tope at the support shaft head conduct it over the snatch block
·Carefully replace the top half of the car and screw it on using female screws –
warning: do not jam the cord!
·Carefully replace the top support shaft bowl and screw it on using the female
screws.

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 9
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
2.3.Correct adjustment of the support shaft cord
To ensure that the fabric and the rope are well stretched, the distance between the pole
head and the car must be as follows:
350x350cm & 400cm -> 49cm
300x300cm & 350cm -> 47.5 - 48cm

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 10
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
3. Replacing the screen, canopy or inner shaft
3.1.Dismounting the screen
·Remove the hexagonal nut, hold the framework and pull out the
cylinder cross bolt
·At the top, remove 2 countersink screws
·Remove material fastening screws and remove the material from the framework
3.2. Replacing the inner shaft
·Remove 3 screws at the top notch and pull out the inside rod. Warning: establish
whether the new inside rod is for a round screen or an angled one.
3.3.Exchanging the coat
·Mount new coat and screw on the corner eyes with rib ends
·Screw on the top disc again
Warning: the top disc must lie directly on the level surface of the
screen top notch so that the so that the screen does not sway when the sunshade
is open.

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 11
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
3.4.Mounting the screen with new canopy below the support shaft head
·Conduct the cord further through the inside rod
Use a passage aid (wire or previous cord)
·Turn the plastic screw cover out of the screen runner
·Conduct the new cord through runner and spring
·Conduct the end of the new cord into the hole of the shackle and wrap the shackle
with the cord 2x. Put the cord, spring and clip in the runner and replace the screw
cover

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 12
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
4. Replacing the ribs
Tool: small and medium cross recess screw driver
Can be carried out on a closed or upright sunshade or placed on a clean base.
1. Remove the cross recess screws at the corner fastenings of the material from
each defect rib and at each rib left and right of each rib affected
·Stave off the material and uncover the framework/screen
2. Unscrew the screws of the top notch to the extent that defective ribs can be
released
·Attach the replacement rib in top notch
·Screw the top notch together again
3. Undo the screws of the runner to the extent that defective ribs can be pulled
out of the slider
·Attach replacement ribs in runner
·Screw runner together again
4. Reinsert cross recess screws into corner fastenings of the material
1.+4. 2. 3.
Note on 2. + 3.
A mounting aid was used here > mounting plate with standpipe and wooden holder (see
7.1). In each of the places where screws are to be undone (top notch and runner), this
is found below on the standpipe. Thus, the framework is turned upside down in step 2.

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 13
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
5. Replacing the locking clip
Remove the dowel by Ø 5 x 57mm with a drift. Insert a new clip and install the dowel.
6. Replacing hand grip
Release the locking clip from the pole.
The hand grip is attached to the steering link with two blind rivets.

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 14
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
The rivets must be drilled out with a drill.
After drilling out the rivets, the old hand grip can be pulled out.

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 15
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
With the new hande grip two rivets are shipped with, which are needed for the
attachment.
Insert the new hand grip into the steering link.
¨

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 16
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
The blind rivets must be fixed with the machine.

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 17
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
7. Replacing the steering link
·First, the screen needs to be dismounted ( see chapter 3.1 )
·Subsequently, the two screws of the tilting rod are removed
·Further, the 3 screws at the plastic part are undone and removed

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 18
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
1. Pull the cord out of the support shaft and install a new tilting rod
2. If the holes of the tilting rod screws are enlarged, the linkage must be completely
replaced (see image 3). In this case, the thread is worn and only new screws
would not hold.
1. 2.
Newly installed steering link

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 19
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
8. Replacing the crown / runner (2 people required)
8.1.Preparation for replacing the runner
Preparation; put the wooden holder in the standpipe and remove runner cover.
Turn the framework upside down so that the runner is underneath and can be put on the
wooden holder. Place aluminium pipe between top notch and runner so that the
framework stays open.
Preparation; see point 3.1 Dismounting the screen (1 person).
Tools; cordless screwdriver, screwdriver
Mounting aid > steel socket with standpipe and wooden holder
Wooden holder
Is available on request from us
for a charge.
However, can also be self-made.
Requirement; must fit into the
standpipe and on the opposite
side into the hole of the slider.
Steel socket with
s
tand
pipe

Sunshade
Sombrano S+
Glatz AG Service Manual_Sombrano S+_en 20
Pfad:K:\Marketing\Drucksachen\Service Manual\Sombrano S+\Word Dateien\Service Manual_Sombrano S+_en.docx
Created: Dino Aeschbacher/29.09.2013 Updated: Mattea Pelusi/06.03.2018 Released: hon_mg/22.11.2013
8.2.Preparation for replacing the top notch
Preparation; turn framework completely upside down and place upside down on the
wooden holder so that at the top notch the screws are exposed at the top. Position the
aluminium pipe between the top notch and the runner so that the framework stays open.
Aluminium pipe
from an aluminium understaff,
shortened to an appropriate
length
Serves as a holder for the
framework. It is put between the
crown and the slider so that the
framework stays open.
Can be self-made or can be
obtained from us on request for a
charge.
