GLOBAL FURNITURE ALLIANCE Palmera Swivel Recliner Operating and installation instructions

Palmera Swivel Recliner
DESCRIPTION
TV Chair With Footstool
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

This product is designed to seat people up to a maximum of 115kgs (18 stone)
Check and re-tighten parts/nuts & bolts every three months
For any assistance with assembly, please contact Global Furniture Alliance on 01291 645080
Option 2or email [email protected]
Alternatively you can go to the following websites:-
www.youtube.com (YouTube Channel - Global Furniture Alliance)
www.gfa.uk.com (Product Ranges - Assembly instruction Videos)
For any missing/damaged parts, please contact your retailer.
Please retain these instructions for future reference and in case of any queries, please quote the
following batch number to your retailer. (The batch number is also located on the underside of
the seat pad or footstool pad)
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

IMPORTANT: Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
Identify all the parts and hardware.
Do not discard of the packaging until you have checked that you have all of the parts and hardware
required. Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by children and pets. Keep
children and pets away during assembly. To avoid danger of suffocation, always keep plastic bags
away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid scratches. We do not
recommend the use of power tools for assembly as this could damage the unit. Only use manual
tools.
Requires 2 people for ease of assembly.
SAFETY INFORMATION
CARE and MAINTENANCE
Wipe regularly with clean water and a damp, clean, soft white cloth
General cleaning can be done as needed with a mild detergent and water solution. Always rinse
with clean water and dry.
For heavy soiling, dampen a soft white cloth or soft bristle brush. Use care as scrubbing can damage
the surface.
More difficult stains can be treated, but this should be occasional, not daily, cleaning.
ANY cleaning solution used must be removed with clean water and a clean white cloth. Cleaning
residue left on the material can cause it to dry out and crack, or affect the color.
DO NOT use any cleaners with corrosive ingredients (lye, acids or ammonia).
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

PRE-ASSEMBLY INFORMATION
PARTS DESCRIPTION
BA C
ED
Back Cushion
Qty 1
Seat Cushion
Qty 1
Footstool Pad
Qty 1
Chair Round Base
Qty 1
Footstool
Round Base
Qty 1
Fa/b
Chair Spindle with
Large Metal Plate
Qty 1
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

PRE-ASSEMBLY INFORMATION
PARTS DESCRIPTION
H
Ga/b
Footstool Spindle
with Small Metal
Plate
Qty 1
Handle
Qty 1
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
JI K
ML
Allen Key Screw
M8*55mm
Qty 7
Allen Key Screw
with Locking Nut
M8*25mm
Qty 2
Small Washer
6.5*18*1.5mm
Qty 7
N
Allen Key Screw
M6*40mm
Qty 3
Medium Washer
8.5*17*1.5mm
Qty 2
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com
Allen Key Screw
M6*16mm
Qty 4

PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
Pa/bO Q
R
Chrome Cap
Qty 2
Large Allen
Wrench
Qty 1
Large Washer
8.5*22*2mm
Qty 5
M6 Allen Key
Qty 1
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

ASSEMBLY
STEP 1
Attach the chair spindle (Fa) on the center of the Base (D) with a metal plate (Fb).
Use five screws (I) and five large washers (O) and the Allen key (Q) to tighten as per above
diagram.
After the round base is well assembled , align the hole in the metal frame of seat cushion
(B) with the spindle (Fa).
Press the seat cushion down so that it rests firmly.
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

ASSEMBLY
STEP 2
Insert the handle (H) into the hole on the metal frame of the seat cushion(B) with clockwise
rotation.
Position back cushion (A) as shown and align the two holes at two sides of seat cushion
cuhsion (B) and back cushion (A) together, connecting the seat cushion (B) and back cushion (A)
by using two chrome caps (Pa/b) and two allen key screws (I) and two medium washers(N).
(This step can be easily done by placing the screws (I) through the side of caps with hole(Pb) and washers (N) first,
tighten using M6 allen key (Q), then use the chrome side of the caps (Pa) to cover the screw with a rotation as per
above arrows)
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

ASSEMBLY
STEP 3
Come to the back of the chair, align two holes on the seat cushion (B) and back cushion (A)
together.
Use two allen key screws with locking nuts (J) to tighten, use large wrench (R) and M6 allen key
(Q) as detailed drawing.
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

ASSEMBLY
STEP 4
Attach footstool spindle(Ga) on the bottom of the footstool pad(C) as shown, align four holes on
the spindle and footstool pad together.
Place the screws (K) and small washers (M) accoring to the holes location, use the M6 allen key
(Q) to tighten.
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

ASSEMBLY
STEP 5
Align three holes on the footstool round base(E) with footstool spindle (Gb), put the small metal
plate (Gb) between them, then use three Allen screws(L) and three small washers(M) according to
the holes location as diagram shown.
Then tighten with M6 Allen key(Q).
Flip footstool over and place in front chair .
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

ASSEMBLY
STEP 6
All the assembly steps have been completed, please check if all the screws have been tighten
enough before sitting down .
Recliner Handle function - Twist clockwise to tighten the tilt tension OR twist counter clockwise to
loose tilt tension .
GLOBAL FURNITURE ALLIANCE LTD
t. 01291 645080
f. 01291 645099
e. [email protected]
www.gfa.uk.com

Thank you for purchasing a product from Global Furniture Alliance. These products have been made
to demanding, high-quality standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty does not affect your
statutory rights.
We reserve the right to repair or replace the defective product, at its discretion.
This product is guaranteed for 12 months if used for normal purposes. Any warranty is invalid if the
product has been overloaded or subject to neglect, improper use or an attempted repair by other
than an authorized agent. Heavy-duty or daily professional/commercial usage are not guaranteed.
Due to continuous product improvement, we reserve the right to change the product specifications
without prior notice.
WARRANTY
