Global Industrial UB Series User manual

1
User Manual Manual de Usuario Manuel de l'Utilisateur
Customer Service
US: 1-800-645-2986
Servicio de atención al Cliente
US: 1-800-645-2986
Service à la clientèle
Canada: 888-645-2986
PRODUCT DESCRIPTION Model _______.....
UB/UD series
242080/242081

2
Product Description
THANK YOU FOR CHOOSING OUR UTILITY CARTS, FOR YOUR SAFETY AND
CORRECT OPERATION, PLEASE CAREFULLY READ THE MANUAL BEFORE USE.
NOTE:Alloftheinformationreportedhereinisbasedondataavailableatthetime
ofprinting.Thefactoryreservestherighttomodifyitsownproductsatanytime
without notice or incurring in any sanction. Please verify withthefactoryfor
possibleupdates.
WARNING
！ 
• eviewallinstructionsbeforeassemblingthecart.
• Imp operassemblycancausepersonalinjuryand/orpropertydamage.
• M ximumloadis550lbs.distributedevenly.Donotoverloadcart.
• Donot tepintooronthecart,oruseitasatoy.
INSTALLATION
Toassemblethecart,followtheillustrationsbelow.Youwillneedacross‐pointscrewdriver
andarubberorwoodmallet.Usethemallettotapdownthepartstoensuretheyareseated
properlybeforefasteningthemwithscrews. 
(NOTE:Numeralsrefertopartslistonreversesideofthissheet.)

3
Product Description
Specifications
UD252 UB252
MaximumCapacity(lbs.) 550 550
PlatformSize(in.)(LxWxH) 31x17x4⅜ 37⅜x25½x4⅜
UpperPlatformHeight(in.) 33½ 33½
HeightbetweenPlatforms(in.) 19⅝ 19⅝
LowPlatformHeight(in.). 6 6
CasterSize(in.)(O.D.xW) 5x1 5x1
OverallSize(in.)(LxWxH) 39¾x17x33½ 46x25½x33½
Approx.NetWeight(lbs.) 35 45
Approx.ShippingWeight(lbs.) 40 50
Exploded Fig. & Part List
ExplodedFigure PartList
No.# Description Q’tity
1
PlatformUpper(formodelUB252) 1
PlatformUpper(formodelUD252) 1
2 Handle(formodelUB252) 1
Handle(forModelUD252) 1
3 LegA 2
4 CrossHeadScrew.M6x25 12
5 LegB 2
6
PlatformBottom(formodelUB252) 1
PlatformBottom(formodelUD252) 1
7 SpecialScrew  M8x45 16
8 SwivelCasterBracket 2
9 Self‐lockingNutM8 4
10 Caster 4
11 AlexBoltM8x45 4
12 FixedCasterBracket 2
13 SpringWasherM8 16
14 NutM8 16
