OWNER’S MANUAL
IMPORTANT: READ OWNER’S MANUAL CAREFULLY
Please fill out and return your warranty card
MODEL 261123 & 261124

CONGRATULATIONS on your purchase of a Global
product. We appreciate your business and will do
everything in our power to keep you happy with your
purchase for many years to come.
Your purchase entitles you to the best protection by
one of the most comprehensive warranties in the
industry.
Thank you for purchasing a GLOBAL product.
TABLE OF CONTENTS
SAFETY PRECAUTIONS 3
MACHINE COMPONENTS 4
MACHINE SET UP AND INSTALLATION 5-6
MACHINE OPERATION 6-9
TANK DRAINING 7
BATTERY CHARGING 7-8
PREVENTATIVE MAINTENANCE 8-9
MACHINE STORAGE 9
BASIC TROUBLESHOOTING 10
PARTS BREAKDOWNS AND LISTS 11-27
WIRING DIAGRAM 28
TABLE OF CONTENTS
2
ORDER YOUR CLEANING CHEMICALS & PADS
Visit www.globalindustrial.com Or Call 1-800-645-1232
PADS (Case of 5)
20" Scrubbing Pad -
Model 261165GN
20" Buffing Pad -
Model 261165RD
CLEANING CHEMICALS
Floor
Cleaner
Model
640404
(Case of 4)
Floor
Stripper
Model
640405
(Case of 6)
Multi
Purpose
Cleaner/
Degreaser
Model
640407
(Case of 4)
Heavy-Duty
Cleaner/
Degreaser
Model
640406
(Case of 4)

This machine is intended for commercial use. It is
constructed for use in an indoor environment and is
not intended for any other use.
• Use with approved accessories only.
• Use of non-approved accessories voids
warranty.
• DO NOT modify machine.
• Modification to the machine voids warranty.
All operators shall read, understand and exercise the
following safety precautions:
1) DO NOT OPERATE MACHINE:
• Unless trained and authorized.
• Unless you have read and understand the
operator’s manual.
• In flammable or explosive areas.
• If not in proper operating condition.
• In outdoor areas.
2) BEFORE OPERATING MACHINE:
• Make sure all safety devices are in place and
operate properly.
3) WHEN USING MACHINE:
• Go slow on inclines and slippery surfaces.
• Follow all safety guidelines.
• Be very careful when using the machine in
reverse.
• Report any damage to your supervisor.
• DO NOT attempt to fix machine by yourself. All
repairs must be made by an authorized
technician.
4) BEFORE LEAVING OR SERVICING MACHINE:
• Stop machine on level ground.
• Turn machine off and remove key.
5) WHEN SERVICING MACHINE:
• Read operator’s manual thoroughly prior to
operating or servicing this machine.
• Use manufacturer supplied or approved
replacement parts.
• Secure machine with wheel chocks prior to
jacking the machine up.
• Any lifting or hoisting of machine should be
done with OSHA approved equipment and
safety precautions.
• Disconnect batteries prior to working on
machine.
• Wear gloves when handling batteries or battery
cables.
• Avoid any contact with battery acid.
• Avoid moving parts. Do not wear loose fitting
clothing while servicing machine.
SAFETY PRECAUTIONS
WARNING
Batteries emit hydrogen gas. Explosion or
fire can result from hydrogen gas. Keep
sparks and open flames away! Keep battery
compartment open when charging.
Flammable materials can cause an
explosion or fire. DO NOT use flammable
materials in tanks as cleaning agent in
machine.
Flammable materials or reactive metals can
cause explosion or fire. DO NOT pick up. DO
NOT use to clean up flammable or
combustible spills.
3
!
WARNING
!
WARNING
!

1. Vacuum ON/OFF switch
2. Brush ON/OFF switch
3. Battery level meter
4. Solution ON/OFF switch
5. Solution control knob
6. Recovery tank drain hose
MACHINE COMPONENTS
4
7. Squeegee assembly
8. Brush lift foot pedal
9. Solution tank level sight tube
10. Console adjustment levers
11. Rear solution fill
12. Circuit breakers
13. Squeegee lift lever
14. Control housing
15. Solution tank
16. Transport wheels
17. Scrub head
18. Scrub head skirt
19. Protective rollers
20. Front solution fill
21. Recovery tank
22. Recovery tank lid
23. Operating triggers
24. Main power ON/OFF switch
25. Reverse switch
26. Speed control knob

CONTENTS
• Machine
• 2 Batteries
• Squeegee Assembly
• Battery Charger
• Pad Driver
• Extra Squeegee
BATTERY CONNECTIONS
The batteries and charger are shipped separately and
will need to be installed and connected as shown in the
diagram below.
1. Be sure power switch is in the “off” position.
2.
Open recovery tank to gain access to battery compartment.
3. Carefully place the two batteries into the
compartment as shown in figure below. Place the
battery brace at the rear of the two batteries. DO
NOT DROP BATTERIES INTO COMPARTMENT!
4. Connect battery cables in the following sequence.
1. RED to POSITIVE
2. BLACK to NEGATIVE
5. Apply a coat or protective spray on the cable
connections to prevent battery corrosion.
MACHINE SET UP - PRE-OPERATION CHECKS
1. Check battery meter to make sure batteries are fully
charged. (see BATTERY CHARGING)
2. Check that squeegee is properly installed.
3. Check that brush / pad is properly installed.
INSTALLING PAD DRIVER OR BRUSH
1. Ensure that the machine is turned off
2. Lower brush head assembly to the floor by stepping
on the foot pedal and pushing pedal forward.
3. Tilt the machine backward to access the drive motor
hub.
4. If using a pad driver, first attach the appropriate pad
to the pad driver surface.
5. Mount the pad driver or brush to the drive motor hub
by lining up the three studs with the three holes in the
drive motor hub. Once in the holes, rotate the driver
toward the spring clip to lock driver into place.
MOUNTING THE SQUEEGEE
1. Pull back on the squeegee lift lever to raise the
squeegee bracket up.
2. Loosen the two knobs on the squeegee and slide the
squeegee into the slots at the rear of the squeegee
bracket (the wheels on the squeegee point to the
back).
3. Tighten the knobs securely.
4. Vacuum hose connects securely to squeegee
pick-up tube and rests with metal ring and spring
which connects to recovery tank with suction
when motor is on.
MACHINE SET UP & INSTALLATION
WARNING
Batteries emit hydrogen gas. Explosion or
fire can result from hydrogen gas. Keep
sparks and open flames away! Keep battery
compartment open when charging.
5
!
CAUTION
Remove the squeegee assembly prior to
tilting the machine backwards. It makes the
process faster and easier.
!
WARNING
Do not keep the machine tilted back for
a long time. This could cause battery acid to
leak from the batteries.
!

FILLING THE SOLUTION TANK
1. Auto Scrubber can be filled in two different locations:
a. Front fill area for use with a hose or a bucket.
b. Rear fill area for use with a hose only.
2. Determine which fill area you would like to use to fill the
machine with water.
3. Fill solution tank with up to 13 gallons of water (water
temperature should not exceed 140°F). The clear tube
in the back left of the machine has gallon markers to
help determine the water level in the solution tank
MACHINE OPERATION
1.
Set control housing to a comfortable operating height by
squeezing together the two thumb levers directly underneath
the housing. (see machine components, item #10).
2. Lower squeegee assembly to the floor by releasing the lift
lever from its locked position (see machine components,
item #13).
3. Lower brush head assembly to the floor by stepping on the
foot pedal and pushing pedal forward (see machine
components, item #8).
4. Turn main power to “on” position (see machine components,
item #24).
5. Turn brush motor to “on” position (see machine components,
item #2).
6. Turn vacuum motor switch to “on” position (see machine
components, item #1).
7. Turn the solution switch to “on” position (see machine
components, item #4).
a. Solution will not begin to flow until the operating triggers
are pulled.
8. This machine is self-propelled. The speed can be controlled
by a dial located on the right side of the control housing (see
machine components, item #26).
9. This machine has reverse. In order to activate reverse, there
is a toggle switch located on the left side of the control housing
(see machine components, item #25).
10. To begin scrubbing, pull on one or both of the operating
triggers (see machine components, item #23). When these
triggers are pulled, the brush will begin to spin and the
solution will begin to flow.
11. Begin scrubbing by moving the machine forward.
12. Adjust amount of solution flow by turning the solution control
knob. Turn to the right for more solution, or turn left for less
solution (see machine components, item #5).
WHILE OPERATING MACHINE
1. Occasionally look through the clear recovery tank lid to
see if there is any foam build-up. If excessive foam is
found, add defoamer to the recovery tank.
2. Occasionally view the clear tube at the back left of the
machine to check the amount of cleaning solution that is
left in the machine.
3. Occasionally check the battery level meter (see
machine components, item #3). When meter is in the
red, recharge the batteries.
4. If the squeegee assembly leaves streaks on the floor,
raise the squeegee off the floor and wipe the blades
down with a damp cloth.
5. When the solution tank runs empty, turn off the brush
switch, solution switch and raise the brush head. Keep
the squeegee down and continue to vacuum until all the
dirty water is picked up (see TANK DRAINING section
to learn how to drain recovery and solution tanks).
MACHINE SET UP & INSTALLATION / OPERATION
CAUTION
Do not operate machine unless you
have read and understand this manual.
6
!
CAUTION
Do not keep the machine in the same
position with the pad / brush spinning, or you
could cause damage to the floor.
!
WARNING
Foam must not enter the float shut-off screen, or
damage can occur to the vacuum motor. Foam
will not activate the machines float shut-off device.
!
WARNING
When battery meter is in the red, do not
continue to operate the machine. Battery
damage may result.
!
WARNING
Do not use your fingers to wipe or remove debris
from the blades, as injury may occur.
!
CAUTION
If you are filling the solution tank with a
bucket, make sure the bucket is clean. This
will prevent debris from clogging the lines
or solenoid.
!
WARNING
Do not put any flammable materials into
solution tank. This can cause an explosion
or a fire. Only use approved cleaning
chemicals. Contact Global Equipment
(1-800-645-1232) for recommendations on
proper chemicals.
!

TANK DRAINING
1. Turn the power off on the machine.
2. With the squeegee and brush head in their "up" position,
transport machine to approved area for draining tank(s).
DRAINING THE RECOVERY (DIRTY) TANK
1. Remove the drain hose from the holder, and place the
drain hose over the floor drain. Twist off the drain hose
plug to begin the draining process. In order to
completely empty the recovery tank, hinge open the
recovery tank and let it rest on the support stand.
2. Clean the recovery tank after every use. Use a fresh
water hose to rinse out the recovery tank. Be careful not
to spray water into the float shut-off mechanism.
3. Replace the drain hose plug tightly as soon as you are
done draining the tank.
DRAINING THE SOLUTION (CLEAN) TANK
1. Pull down on the clear tube (back left of the machine) to
remove it from the hose barb. This will allow the solution
to flow freely into a bucket or floor drain.
2. Rinse the solution tank with clean water after every use.
This will help prevent chemical buildup and clogging of
the solution lines.
3. With clean water in solution tank, turn machine power
on, solution switch "on" and pull the operating triggers.
This will allow the clean water to flush through and clean
the solution plumbing.
4. Once tank is rinsed, flushed and drained, reconnect the
clear tube to the hose barb. Be sure the tube is pushed
all the way up on the hose barb.
BATTERY CHARGING
MACHINE OPERATION CONTINUED
CAUTION
The brush motors are circuit breaker
protected to protect them from damage. If a
breaker trips, it can't be reset immediately. You
must first determine what caused the breaker to
trip, and allow the motor to cool down before you
can reset the breaker. The breakers are located on
the back panel of the control housing.
7
!
WARNING
DO NOT lift/flip open recovery tank fully when
filled, may cause spills
!
CAUTION
Any time scrubbing is completed, or when
refilling solution tank, the recovery tank should be
drained and cleaned.
!
CAUTION
If you are storing the machine for any period of time,
always leave the clear recovery tank lid off the tank so
the tank can dry completely and smell fresh.
!
CAUTION
Any time scrubbing operation is completed,
the solution tank should be drained and cleaned.
!
WARNING
If the recovery tank is not drained when the
solution tank has been refilled, foam or water may
enter the float shut-off mechanism and cause
damage to the vacuum motor.
!
WARNING
Use only approved chargers with the following
specifications:
• Automatic shut off circuit
• Deep cycle charging
• Output current of 10 - 20 amps
• Output voltage of 24 volts
!
CAUTION
For the best machine performance, keep
batteries charged at all times. Do not let them sit
in a discharged condition.
!
WARNING
DO NOT place battery charger on wet surface or in
a puddle when operating charger.
!
WARNING
Batteries are dangerous! Batteries emit
hydrogen gas and an explosion or fire can result.
Keep sparks and fire away from batteries at all
times. When charging the machine, make sure the
battery compartment is left open.
!

BATTERY CHARGING (cont.)
1. Place charger and machine in a well ventilated area.
2. Turn machine off.
3. Open recovery tank up, exposing battery compartment
4. Check fluid level in each battery cell. DO NOT charge
batteries unless fluid is slightly covering the battery
plates. Do not overfill the batteries. Overfilling may
cause the batteries to overflow during charging due to
expansion. Replace the caps prior to charging.
5. Plug approved charger into grounded wall outlet
before plugging the charger into the machine.
6. Plug charger into red charger receptacle located in the
front left of the battery compartment.
7. Flip up the recovery tank "kick stand" and gently lay the
recovery tank down until it rests on the stand.
8. The charger will automatically begin to charge the
batteries, and it will automatically shut down once the
batteries are fully charged.
9. Upon completion of charging, first unplug the charger
from the wall outlet, and then disconnect the charger
from the machine.
10. Check the battery level after charging is complete. If
fluid level is low, add distilled water to bring the fluid
level up to the bottom of the sight tubes. Replace the
caps and wipe the batteries down with a towel.
PREVENTATIVE MAINTENANCE
DAILY MAINTENANCE
1. Remove pad driver / brush and clean with approved
cleaner.
2. Drain recovery and solution tanks completely and rinse
out with clean water. Visually check the recovery tank for
debris and clean out as necessary.
3. Raise squeegee assembly off floor and wipe it down
with a damp towel. Be sure to store the squeegee in the
up position.
4. Remove the float shut-off assembly and rinse it out with
clean water.
5. Clean machine with an approved cleaner and a damp
towel.
6. Recharge batteries.
WEEKLY MAINTENANCE
1. Check fluid level in batteries.
2. Check batteries for loose or corroded cables.
3. Keep battery tops clean from corrosion.
MONTHLY MAINTENANCE
1. Check machine for leaks and loose fasteners.
2. Lubricate all grease points and pivot points with silicon
spray and approved grease.
3. Place machine over a floor drain. Flush solution system
by pouring 3 gallons of hot water and approved alkaline
detergent into the solution tank and running machine
(with solution control on) for 45 seconds. Turn machine
off and let it sit overnight. The next day, drain the
remaining solution and rinse the solution tank out with
clean water.
MACHINE OPERATION CONTINUED
8
WARNING
Before performing any maintenance on
the machine, be sure that the power is turned off,
or the batteries are disconnected!
!
WARNING
Repairs are to be completed by
Authorized Service Centers only. Any repairs
completed by unauthorized persons will void the
warranty.
!

VACUUM MOTOR MAINTENANCE
1. Contact Customer Service (1-800-645-2986) for any
motor maintenance.
2. Vacuum motor brushes should be checked every 250
hours. Brushes should be replaced when they are worn
to a length of 10mm or less.
BATTERY MAINTENANCE
1. Always follow the battery charging directions as outlined
in the BATTERY CHARGING section of this manual.
2. Keep battery tops and terminals free from corrosion. A
strong solution of baking soda and water is the best way
to keep the batteries corrosion free. DO NOT ALLOW
THE BAKING SODA / WATER SOLUTION TO ENTER
THE BATTERY CELLS.
3. Use a wire brush with the baking soda solution to
properly clean the battery posts and connections.
4. Check battery connections for wear and loose
terminals. Replace if necessary.
MACHINE STORAGE
1. Always store the machine indoors.
2. Always store the machine in a dry area.
3. Always store the machine in its upright position.
4. Always store the machine with the pad driver / brush
raised off the floor.
5. Always store the machine with the squeegee assembly
raised off the floor.
6. If storing in an area which may reach freezing
temperatures, be sure to drain all fluids from the
machine prior to storage. Any damage caused by
freezing temperatures will not be covered by the
warranty.
7. Drain the recovery tank and remove the clear lid on the
top of the recovery tank so that it can "breathe" during
storage.
8. Drain the solution tank of all fluid.
MACHINE OPERATION CONTINUED
9
WARNING
Batteries are dangerous! Batteries emit hydrogen
gas and an explosion or fire can result. Keep
sparks and fire away from batteries at all times.
!
CAUTION
For the best machine performance, keep
batteries charged at all times. Do not let them sit
in a discharged condition.
!
WARNING
Whenever servicing batteries, be sure
to wear protective gloves. Avoid contact with
battery acid at all times!
!

PROBLEM CAUSE SOLUTION
No power Bad batteries Replace batteries
Batteries need to be charged Charge batteries (see Battery Charging)
Loose battery cable Tighten loose cable(s)
Batteries not connected properly Follow battery installation instructions
Brush motor does Bad brush switch Call Customer Service 1-800-645-2986
not run Brush circuit breaker has tripped Check brush motor for obstructions and reset
breaker
Rectifier has burned out Call Customer Service 1-800-645-2986
Bad wiring Call Customer Service 1-800-645-2986
Bad brush motor Call Customer Service 1-800-645-2986
Carbon brushes worn out Call Customer Service 1-800-645-2986
Bad solenoid Call Customer Service 1-800-645-2986
Vacuum motor does Bad vacuum switch Call Customer Service 1-800-645-2986
not run Bad wiring Call Customer Service 1-800-645-2986
Bad vacuum motor Call Customer Service 1-800-645-2986
Carbon brushes worn out Call Customer Service 1-800-645-2986
Short run time Batteries need to be charged Charge batteries (see Battery Charging)
Batteries need maintenance See Battery Maintenance in this manual
Bad cell in battery(s) Replace batteries
Bad charger Replace charger
Little or no solution Bad solution switch Call Customer Service 1-800-645-2986
flow Clogged solution solenoid Call Customer Service 1-800-645-2986
Clogged solution filter Remove filter and clean
Solution line obstructed Remove solution line and clean
Solution flow adjustment knob in need Increase flow by twisting solution adjustment knob
of adjustment to the right. Decrease flow by twisting solution
adjustment knob to the left.
Poor water pick up Squeegee clogged Clean debris off squeegee with damp towel
Squeegee blades worn Install new squeegee blades
Squeegee not mounted correctly Confirm that the squeegee assembly is securely
fastened to the machine and not loose fitting .
Vacuum hoses have a hole or are loose Check hose connections and make sure they are
firm. Replace hose if damaged.
Vacuum hose may be clogged Check hose for debris and remove any clog.
Drain hose stopper is loose Tighten drain plug.
Batteries need to be charged Charge batteries (see Battery Charging)
Vacuum motor is loose Tighten vac motor mounting screws. Do not over
tighten or damage will occur.
Recovery tank lid is loose Confirm the clear recovery tank lid is securely in
place.
Recovery tank inlet hole is clogged Drain recovery tank and tilt tank on side. Check
the inlet hole for debris and remove debris.
Recovery tank is full Drain recovery tank.
Float shut off is clogged Remove float shut off from inside recovery tank
and remove any debris.
BASIC TROUBLESHOOTING
10

MODEL 261123 & 261124 - CONTROL HOUSING
11
PARTS LIST

DIA No. Part Number Description NO Req'd
1 VF81713 BUSHING 2
2 VF14122 WASHER, PLAIN, M10XM20X2 2
3 VF14121 SCREW, M10X65 2
4 VF13502 NUT, LOCK, M6 10
5 GT13032 WASHER, PLAIN, M6 2
6 VF81781 DIODE 400V 3
7 VF81726A SOLENOID, 24V 2
8 VF81734 BREAKER, CIRCUIT, 35 AMP 2
9 VF83149 LABEL, CIRCUIT BREAKER 1
10 VF82108 HOUSING, CONTROL 1
11 VF14078 SCREW, M3X10 6
12 VA50477 WASHER, PLAIN, M3XM10X1 6
13 VF81718 LIGHTS, BATTERY CAPACITY 1
14 VF13495 SCREW, M6X16 4
15 VF82313 GASKET 1
16 VF81719 SPACER 6
17 VF82102A PANEL, SWITCH 1
18 VF82351 LABEL, SWITCH 1
19 VF81721 SWITCH, LIGHTED ROCKER 3
20 VF14200 SCREW, M6X16 12
21 VF81709 PIN, HANDLE LOCK 2
22 VF81716 SPRING 1
23 VF81710 PIN, HANDLE ADJUSTMENT 2
24 VF81744A STRAIN RELIEF, CORD 1
25 VF82312 GASKET 1
26 VF82352 SERIAL TAG (261123) 1
VF82353 SERIAL TAG (261124) 1
27 GV40239 COVER 1
28 VF83148 LABEL, CIRCUIT BREAKER 1
29 VF82303A PANEL, CONTROL HOUSING 1
30 VF81703 BATTERY CAPACITY, CONTROL BOARD 1
31 VF82107BD HANDLE, RIGHT 1
32 VF81711 BOLT, SHOULDER M8XM15XM6 2
33 VF81712 SPRING 1
34 VF13491 SCREW, M4X12 1
35 VF13514A WASHER, PLAIN,M8XM16.5X1 2
36 VF82106BD HANDLE, LEFT 1
37 VF14212 SCREW, M3X25 2
38 VF13511 WASHER, TEETH,M3 2
39 VF44203 SWITCH ASSEMBLY 1
40 VF83141 BRACKET, SWITCH 1
41 VV13652 NUT ,LOCK, M3 2
42 VF81714 TUBE, HANDLE, ADJUSTMENT 1
43 VF82153 SWITCH, KEY 1
44 VF82160 LABEL, KEY SWITCH 1
45 VF99012 BREAKER, CIRCUIT 12 AMP 1
MODEL 261123 & 261124 - CONTROL HOUSING
12

MODEL 261123 & 261124 - RECOVERY TANK ASSEMBLY
13
PARTS LIST

DIA No. Part Number Description NO Req'd
1 VF82010 CLEAR COVER, RECOVERY TANK 1
2 VF82930 DECAL, BATTERY WARNING 1
3 VF82009 ELBOW ADAPTER, FLOAT 1
4 VV13607 WASHER, LOCK, M6 13
5 VF13533 WASHER, PLAIN, M6 X M16 X 2 7
6 VF14233 SCREW, M6 X 20 4
7 VF81504 FLOAT 1
8 VF82002 RECOVERY TANK 1
9 VF13528 WASHER, TOOTH, LOCK, M6 2
10 VF13495 SCREW, M6 X 16 2
11 VF82028 CABLE 1
12 VF81509 PLUG, EXPANSION 1
13 VF81510-9 STRAP, DRAIN HOSE 1
14 VF81510-2 SLEEVE, DRAIN HOSE 1
15 VF81510A DRAIN HOSE ASSEMBLY 1
16 VF82115 DECAL, BATTERY INSTALLATION 1
17 VF82318 HOOK, CABLE 4
18 VF82326 MESH COVER, CABLE 1
19 VV10113 CLAMP, 2" 2
20 VF14225A SCREW, M6 X 40 4
21 VF81723 CONNECTOR 1
22 VF82331 ON BOARD CHARGER, 9AMP, 24V 1
23 VF82332A KIT,CHARGER REPLACEMENT 1
24 VV13601 WASHER, LOCK, M5 4
25 VF13532 WASHER, PLAIN, M5 X M11 X 2 4
26 VV20501 SCREW, M5 X 14 4
27 VF82331A KIT, ON BOARD CHARGER 1
28 VF82332 CLAMP, CHARGER 2
29 VF82320 CLAMP, CABLE 2
30 VF13502 NUT, LOCK, M6 3
31 VF82310 STUD 3
32 ZD53000 MOTOR, VACUUM, 2 STAGE, 24VDC 1
33 VF13521 NUT, M6 3
34 VF81503 SEAT 1
35 VF14200 SCREW, M6 X 16 9
36 GT13032 WASHER, PLAIN, M6 X M16 X 1.5 9
37 VF82011 HINGE, RECOVERY TANK 1
38 VF82929 LOGO 1
39 VA13477 SCREW, SELF-TAPPING, ST, M4 X 16 4
40 VV13664 WASHER, PLAIN, M4 X M12 X 1 4
41 VF82010A RUBBER HINGE 1
42 VF82010B GASKET 1
43 VF82010X KIT, LID 1
MODEL 261123 & 261124 - RECOVERY TANK ASSEMBLY
14

MODEL 261123 & 261124 - SOLUTION TANK ASSEMBLY
15
PARTS LIST

DIA No. Part Number Description NO Req'd
1 VF81405BD GRIP, HANDLE 1
2 VA13477 SCREW, SELF-TAPPING, ST, M4 X 16 3
3 VV13664 WASHER, PLAIN, M4 X M12 X 1 1
4 VF81507 STRAP, PLUG, REAR FILL 1
5 VV13604 SCREW, M8 X 20 6
6 VF13519 WASHER, LOCK, M8 6
7 VF81509 PLUG, EXPANSION 1
8 VF14535 WASHER, PLAIN, M8 X M20 X 2 8
9 VF81406 BUSHING 1
10 VF81404 SUPPORT, RECOVERY TANK 1
11 VF82029A BRACKET, VAC TUBE 1
12 VF82032 SPRING 1
13 VF82030 ADAPTER, TUBE 1
14 VF82031A GASKET, TUBE ADAPTER 1
15 VF82930 DECAL, BATTERY WARNING 1
VF82931 DECAL, CHARGER WARNING 1
16 VF82927 LABEL, LEFT 1
17 VV13652 NUT, LOCK, M3 2
18 VF82114 BRACKET, CHARGE PLUG 1
19 VF82402 WIRE, #6 X 600 1
20 VF82401 WIRE, #6 X 600 1
21 VF81723 CONNECTOR 2
22 VF13511 WASHER, TOOTH, M3 2
23 VF14244 SCREW, M3 X 20 2
24 VF13495 SCREW, M6 X 16 7
25 VV13607 WASHER, LOCK, M6 9
26 GT13032 WASHER, PLAIN, M6 X M16 X 1.5 7
27 VF81715 STANDOFF 2
28 VF82067 BRACKET 1
29 VF14232 SCREW, M6 X 10 2
30 VF82078 SCREEN, FILL 1
31 VF13543 SCREW, SELF-TAPPING, ST, M4 X 16 2
32 VF13544 SCREW, SELF-TAPPING, ST, M4 X 10 6
33 VA13483 WASHER, PLAIN, M4 X M9 X 0.8 7
34 VF82081 PLUG, FILL SCREEN 1
35 VF82079 COVER, FILL SCREEN 1
36 VF82001A SOLUTION TANK 1
37 VF82928 LABEL, RIGHT 1
38 BAT105I BATTERY, 105 A/H, 12V 2
BAT130I BATTERY, 130 A/H, 12V 2
39 VF82076 PLATE 1
40 VF82072 SPACER, BATTERY 1
41 VF81724 CAP, BATTERY, BLACK 2
VF81724R CAP, BATTERY, RED 2
42 VF82403 CABLE, BATTERY 1
43 VF14234 SCREW, M8 X 16 2
44 VF13513 NUT, M8 2
45 VF81408 PLATE, LOCK 2
MODEL 261123 & 261124 - SOLUTION TANK ASSEMBLY
16

DIA No. Part Number Description NO Req'd
46 VF81416 HOSE BARB 2
47 VF82161 CLAMP (16-25) 1
48 VF82061 TUBING 1
49 VF82306A KIT, LABEL, MARKERS 1
50 VF14230 SCREW, M5 X 15 3
51 VV13601 WASHER, LOCK, M5 3
52 VF13532 WASHER, PLAIN, M5 X M11 X 2 3
53 VF81202 PLATE, SQUEEGEE, LOCK 1
54 VF14235 SCREW, M8 X 35 1
55 VF48216 WASHER, LOCK 1
56 VF82050 HANDLE, SQUEEGEE, LIFT 1
57 VF82050A BUSHING 1
58 VF14248 SCREW, M8 X 100 1
59 VA13516 WASHER, PLAIN, M10 X M30 X 1.5 1
MODEL 261123 & 261124 - SOLUTION TANK ASSEMBLY
17

MODEL 261123 & 261124 - SQUEEGEE ASSEMBLY
18
PARTS LIST

DIA No. Part Number Description NO Req'd
1 VF14247 SCREW, M12 X 25 2
2 VF13538 WASHER, PLAIN, M12 X M26 X 2 2
3 VF82016A BUSHING 2
4 VF82130 MOUNT, PIVOT 1
5 VF13541 WASHER, LOCK, M12 2
6 VF82049 CABLE, SQUEEGEE LIFT 1
7 VF82112 BUSHING 1
8 VF81203A HOSE 1
9 VF83150 HOLDER, "U" HOSE 1
10 VF81207 SPRING 1
11 VF82047 SHAFT 1
12 VF13513 NUT, M8 1
13 VF14236 SCREW, M8 X 40 4
14 VF13514A WASHER, PLAIN, M8 X M16.5 X 1 2
15 VF82055 BUSHING 2
16 VF82013 WHEEL, 3" 2
17 VF82116 HOUSING, SQUEEGEE 1
18 VF82063 BLADE, SQUEEGEE, REAR (PU) 1
VF82119 BLADE, SQUEEGEE, REAR (NEOPRENE ) 1
19 VF81218 LATCH, HOOD 1
20 VF81209 HOOK, REAR SQUEEGEE, BACKUP ADJUSTMENT 1
21 VF14310 SCREW, M5 X 70 1
22 VF81208 RIVET, M4 X 5 2
23 GT13022 NUT, LOCK, M5 1
24 VF81222 BOLT, SHOULDER, M9.5 X 31.5 X 5/16" 3
25 VF81219 WHEEL, 2" 3
26 VF13535 WASHER, PLAIN, M8 X M20 X 2 3
27 VV20203 NUT, LOCK M 5/16" 3
28 VF82120 BACKUP STRIP, SQUEEGEE, REAR 1
29 VF82120A KIT,SQUEEGEE REAR BACKUP STRIP 1
30 VF82062 BLADE, SQUEEGEE, FRONT (PU) 1
VF82117 BLADE, SQUEEGEE, FRONT (NEOPRENE) 1
31 VF82118 BACKUP STRIP, SQUEEGEE, FRONT 1
32 VF82121 KNOB, M6 6
33 VF82084 BOLT, SHOULDER, M12 X 20 2
34 VF13502 NUT, LOCK, M6 1
35 VF82131 BRACKET, SQUEEGEE MOUNT 1
36 VF13521 NUT, M6 1
37 VF13539 WASHER, PLAIN, M12 X M32 X 2 2
38 VF81210 KNOB, M8 2
39 VF14081 NUT, M12 2
40 VF82908A SQUEEGEE ASSEMBLY 1
MODEL 261123 & 261124 - SQUEEGEE ASSEMBLY
19

MODEL 261123 & 261124 - BRUSH LIFT / AXLE ASSEMBLY
20
PARTS LIST
