NSS WRANGLER 26 User manual

OPERATION MANUAL
WRANGLER 26
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Failure to observe these instructions can cause
personal injury to machine operator or bystanders
WARNING: Fire or explosion hazard.
NEVER operate this machine in an
explosive atmosphere (grain dust,
flammable liquids or fumes, etc.).
WARNING: Fire or explosion hazard.
NEVER attempt to pick up flammable or
combustible materials or use such
materials in tank.
INTENDED USE
This machine is intended for commercial use,
scrubbing floors in an indoor environment. NSS
does not recommend using this machine for any
other purpose.
FOR SAFETY:
•ALWAYS read and understand all instructions before
operating or servicing machine.
•ALWAYS use this machine ONLY as described in this
manual.
•NEVER attempt to operate this machine unless you
have been trained in its operation.
•NEVER allow an untrained person to operate this
machine.
•NEVER attempt to operate this machine if it is not
working properly or has been damaged in any manner.
•NEVER disconnect or modify any switches or safety
devices (circuit breaker).
•NEVER drop or insert any object into any machine
opening.
•NEVER operate this machine with any air opening
blocked. Keep all air openings free of dust, lint, hair,
etc.
•NEVER pick up anything that is burning or smoking,
such as cigarettes, matches or hot ashes.
•NEVER spray this machine with water or any liquids.
•NEVER allow the vacuum motor or battery-charging
plug to get wet or a short may occur.
•NEVER operate this machine when the battery charger
is plugged in.
•NEVER operate this machine with the side skirt
removed.
•NEVER allow this machine to be used as a toy. Close
attention is necessary when used by or near children.
•ALWAYS wear clean tennis shoes or “non-slip”
shoes. Leather soled shoes will become extremely
slippery when wet.
•ALWAYS keep face, fingers, hair or any other body
part or loose clothing away from any machine
opening or moving part (revolving brush, pad driver,
or vacuum motor).
•ALWAYS turn the machine off when attaching pads
or brushes.
•ALWAYS remove keys when this machine is left
unattended.
•ALWAYS be sure that the ramp is secured to the
vehicle before attempting to load/unload.
•ALWAYS use extreme caution when operating the
machine on a ramp or loading/unloading this
machine into or out of a truck/trailer. Use extreme
caution if the ramp is wet, oily, or covered with
cleaning chemicals.
•NEVER stop or turn the machine on a ramp or
incline.
•NEVER attempt to climb a grade or operate this
machine on a ramp or incline of more than
8 degrees.
•NEVER park or store the machine near a dock, on
ramps, near a furnace, boiler, open flame, or other
high heat source.
•NEVER allow this machine to freeze.
•NEVER expose the machine to rain, snow, or
extreme temperatures.
•NEVER store any items on this machine.
•ALWAYS store this machine indoors in a dry, cool
area.
ALL REPAIR SERVICE MUST BE PERFORMED BY AN NSS AUTHORIZED DISTRIBUTOR/
SERVICE STATION USING ONLY NSS ORIGINAL EQUIPMENT PARTS.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
BATTERY POWERED EQUIPMENT
WARNING: Failure to observe these instructions can cause
personal injury to machine operator or bystanders
Read and understand all
instructions before installing
or charging batteries.
No smoking, open
flames, or sparks while
working with batteries.
Contains acid.
Avoid contact.
Poison. Causes severe
burns. Avoid contact.
WARNING: Batteries emit hydrogen, which can cause fire or explosion.
NEVER smoke, light a match, or cause a spark during operation or charging.
ALWAYS charge in a well-ventilated area away from open flame.
GENERAL
•ALWAYS read and understand all
instructions before installing or charging
batteries.
•NEVER attempt to install or charge batteries
unless you have been trained to do so.
•NEVER allow an untrained person to install or
charge batteries.
•ALWAYS remove all jewelry when working on
or near the batteries.
•ALWAYS turn off all switches during
installation and service.
•ALWAYS disconnect the battery leads before
performing any service or repair.
•ALWAYS wear eye protection and protective
clothing to avoid contact with battery acid.
•NEVER lay anything on top of batteries as
arcing may occur.
•IF CONTACT WITH BATTERY ACID
OCCURS, follow these instructions:
•SKIN –rinse area with water.
•EYES –Flush with water for 15 minutes.
•INTERNAL –Drink water or milk. Follow with
Milk of Magnesia, beaten egg or vegetable
oil. Call a physician immediately.
BATTERY INSTALLATION
•ALWAYS use two people to install, as batteries are heavy.
•ALWAYS turn off all machine switches.
•ALWAYS position batteries as shown on the machine
installation decal to maintain machine balance.
•ALWAYS connect batteries as shown on the machine
installation decal to avoid shorting out the batteries and
the electrical system.
BATTERY CHARGING
•ALWAYS read instructions on charger carefully.
•ALWAYS use the NSS supplied charger with proper
voltage rating.
•ALWAYS check to ensure the battery water level covers
the battery plates before charging.
•ALWAYS check water level after charging and add water
if necessary to bring level to the bottom of the fill hole.
•NEVER overfill batteries as battery
and machine damage may result.
•ALWAYS wipe any acid from the top
of batteries using a soap solution.
•ALWAYS reattach caps to batteries. Do not charge with
caps loose or removed.
•ADD only distilled or treated city water. Not well water.
ALL REPAIR SERVICE MUST BE PERFORMED BY AN NSS AUTHORIZED DISTRIBUTOR/
SERVICE STATION USING ONLY NSS ORIGINAL EQUIPMENT PARTS.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

3
MACHINE INSPECTION
•Now that the machine is unpacked remember to
recycle all packing materials.
•Inspect machine for damage or missing
components. If damage is found, contact the local
freight company to file a freight claim.
MACHINE COMPONENTS
Solution Tank
The solution tank is the lower part of the machine
body. It has a capacity of 25 gallons (95 liters).
•The tank is filled by pouring the water and cleaning
the chemicals through the opening and filter at the
front of the tank.
•The amount of water in the tank is measured by
the solution gage in the clear plastic tube at the
right rear corner of the tank.
•The solution tank is emptied through the clear
plastic tube at the right rear corner of the tank.
Recovery Tank
The recovery tank is the upper part of the machine
body. It has a capacity of 27 gallons (102 liters).
•The recovery tank is closed by a round, clear view
lid assembly.
•The recovery tank has a foam sensitive float shut-
off assembly. As the water level rises, the float ball
will rise into the tube and shut off the airflow of the
vacuum.
•The float shut-off assembly does not shut off the
vacuum motor.
•The recovery tank is emptied through a large
rubber hose at the front of the machine. Remove
the plug and drain the liquids according to your
local EPA regulations.
Operator Control Panel
The operator control panel is located at the upper
rear area of the machine. This panel has components
that control various machine functions.
•In the middle of the panel are two (2) rubber twist
grips. These grips rotate forward and backward to
control the direction and speed of the machine.
The farther the grips are rotated, the faster the
machine will move. These twist grips have a “dead
man” feature that returns the machine to the
neutral position when the handles are released.
•The first toggle switch on the left turns on and off
the brush motor.
•The next toggle switch turns on and off the vacuum
motor.
•The square red button in the center is the master
power switch and it controls the power to all
components. Power ON is indicated by the green
light.
Battery Meter
The battery meter is located on the right side of the
operator control panel and shows the state of charge of
batteries during operation and recharge.
•Work Range -This is the green area in the middle of
the meter. It shows the approximate amount of
“power” available in the batteries. Observe this
reading when operating the Wrangler.
•Recharge Range -This is the red area on the left of
the meter. It shows when the batteries need to be
recharged. Continued machine operation in this area
will cause battery damage and potential machine
damage.
•Charge Range -This is the red area on the right of
the meter. It shows the approximate amount of
recharging the batteries have received. To observe
this reading -turn on the master switch, observe the
meter, turn off the master switch.
Hour Meter
The hour meter is located on the left rear of the
machine. It shows the total working time of the scrub
brushes.
Solution Control (Valve) Lever
The solution control lever is located in front of the right
hand twist grip. This lever controls the solution valve
and the amount of liquids put on the floor when
cleaning.
•Pull up on the handle to open the valve.
•Push down on the handle to close the valve.
Circuit Breaker and Lift Arm Panel
This is the vertical metal panel located at the rear of the
machine.
•The left circuit breaker is for the drive motor and is
rated at 25 amps.
•The next circuit breaker is for the vacuum motor and
is rated at 20 amps.
•The two circuit breakers on the right are for the brush
motors and each is rated at 25 amps. The right lift
arm is used to raise and lower the brush motor
assembly.
•The left lift arm is used to raise and lower the
squeegee assembly.
Battery Charging Plug
This plug is located below the left twist grip near the
upper left corner of the circuit breaker and lift arm panel.
•The battery charger plug is inserted into the charging
plug to recharge the batteries.
•This plug is red on 24-volt machines. See charging
instructions for more details.
Battery Compartment Drain Hose
This hose is located below the battery-charging plug
and behind the squeegee lift arm. The hose uses a
pinch clamp to hold the hose closed. This hose collects
any spilled liquids from the battery compartment area.
•Inspect hose for liquid level on a weekly basis.
•Dispose of liquids according to local your EPA
regulations.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

4
Solution Filter Assembly
Attached to the intake of the solution solenoid valve
is a filter assembly design to stop debris from
entering the solution valve. The solution solenoid
valve is an automatic valve that turns on the solution
flow when the brushes are on and the machine is
moving. It is located on the frame under the left rear
corner of the machine.
If the water and chemical stops flowing:
•Check the battery charge, a sufficient voltage is
required on order for the solenoid valve to operate.
•There is a metal filter screen inside the plastic
fitting of the solution hose -open the fitting (by
hand), remove and clean the screen.
•Replace the screen and close fitting (by hand).
Check for any liquid leaks.
Drive Motor
This machine is powered forward and reverse by a
24-volt drive motor.
•The speed is electronically controlled for smooth
increase and decrease of speed.
•The motor moves the drive wheels through a
gearbox and transaxle system.
•This motor has carbon brushes that must be
serviced on a regular basis. The carbon brushes
have an expected life of 2,000 operating hours.
Refer to the maintenance section later in this book.
Brush Gear Motor
This machine has two (2) 24-volt brush motors
located at the front of the machine. The motors are
attached to a gearbox to turn the pad drivers or
brushes.
•The left motor rotates clockwise.
•The right motor rotates counterclockwise.
•These motors have carbon brushes that must be
serviced on a regular basis. The carbon brushes
have an expected life of 2,000 operating hours.
Refer to the maintenance section later in this book.
Vacuum Motor
This machine has a 24-volt vacuum motor.
•The vacuum motor is enclosed in the body of the
control panel behind the metal plate.
•This motor has carbon brushes that must be
serviced on a regular basis. The carbon brushes
have a maximum expected life of 700 operating
hours. Refer to the maintenance section later in
this book.
Squeegee Assembly
The squeegee assembly may use a dual (2) urethane
blade system to recover liquids from the floor.
•The squeegee assembly has a wide, flat frame to
help prevent damage, two (2) mounting knobs and
two (2) small wheels to prevent “rollover” in
reverse.
•The squeegee assembly mounts to a metal “U”
shaped bracket at the bottom center of the machine.
The Wrangler 26 may be equipped with an optional
“curved” heavy -duty squeegee assembly. This system
has gum rubber rear and neoprene front blades.
Side Skirt Assemblies
The machine is equipped with left and right side skirt
assemblies.
•The side skirt assemblies are designed to contain the
liquids in the cleaning area under the machine and
channel them toward the squeegee, and prevent
splashing outside of the machine.
•The side skirt assemblies attach to the front of the
machine with retaining pins and are secured with a
retaining latch.
Battery Package
The Wrangler 26 is a 24 volt system and is available
with one battery package:
•Four (4) 6 volt, 225 Amp Hour Batteries. Consult
your local NSS authorized distributor for application
recommendations.
To install the batteries:
•Turn off all switches and tilt open the recovery tank to
expose battery compartment.
•Batteries are heavy -use two people to install.
•Refer to wiring diagram inside the battery
compartment. Align batteries in compartment as
shown on diagram.
•Install battery cables as shown on wiring diagram.
•Tighten bolts and hex nuts with a wrench.
•Caution: Do not touch two terminals with a wrench.
•Loose or improper battery connections will cause
battery or machine damage and possible personal
injury.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

5
MACHINE OPERATION
General Information
The Wrangler 26 is very maneuverable and is
designed to scrub floors as you operate the machine
from behind. Alwaysdust mop the floor before
scrubbing. You may also need to preclean some
types of spills or stains before scrubbing. Plan your
work so that you make long, straight paths with the
fewest amount of turn’s possible. Remove as many
obstacles as possible from the area to be scrubbed.
Consult your local NSS distributor for more complete
procedures and chemical advice.
Preparing the machine for use
Prepare the solution tank:
•Never use water over 140°F (60°C) degrees.
Excessively hot water may damage components
such as the tanks.
•Pour all liquids through the round mesh filter at the
front of the solution tank.
•Put 1 to 2 gallons of clean water into the solution
tank first to help dilute the chemicals and prevent
excess sudsing.
•Consult your local distributor for complete chemical
advice. Dilute the cleaning chemicals according
to the manufacturer’s instructions.
•Add the cleaning chemicals to the solution tank
and fill with water as needed.
Prepare the recovery tank:
•Make sure the drain plug of the recovery tank is
closed tightly and in its holding clip.
•Always use a defoamer to protect the vacuum
motor. Every time you empty the recovery tank,
we recommend that you add at least 4 to 6 ounces
of defoamer chemical into the recovery tank before
resuming work. Vacuum the defoamer into the
empty recovery tank through the squeegee Vac
hose.
To install a pad driver and pad:
•There are a wide range of pads or brushes
available for the many cleaning applications of this
machine. Consult your local NSS authorized
distributor for application recommendations.
•Turn the pad drivers upside down on the floor and
remove the pad holding cup.
•Remove the center cutout of the 13" (33 cm.) pad.
Place the pad on the face of the pad driver.
•The pad must be centered on the driver to prevent
wobbling or bouncing.
•Install and secure the pad holding cup to the pad
driver. Turn the pad driver over so that the pad
faces the floor.
•Raise the brush motors into the transport position.
•Align the lugs of the pad driver with the slots of the
drive casting.
•Turn the lug of the pad driver toward the latch; close
the latch around the lug to lock onto the drive casting.
To install a brush:
•Raise the brush motors into the transport position.
•Align the lugs of the brush with the slots on the drive
casting.
•Turn the lugs of the brush toward the latch, close the
latch around the lug to lock onto the drive casting.
To install the squeegee assembly:
•Place the squeegee lift arm in the storage (up)
position.
•Loosen the two mounting knobs and slide the
squeegee assembly onto the mounting plate.
•The roller wheels must face the operator. Hand
tighten the mounting knobs. Do not use pliers to
tighten knobs as this will defeat the “break-away”
design.
To adjust the squeegee assembly:
As the machine is used, the squeegee blades will wear
or need to be replaced due to damage. Some
adjustment may be needed.
•Turn the vacuum motor ON and open the water valve
slightly.
•Squeegee blades should lay over slightly (like a
window squeegee) when the machine is moving
forward or reverse.
•Adjust the blade angle by turning the wing nut (or
knob) on the pivot arm clockwise or counterclockwise.
•Do not add any weights or other pressure to the
squeegee mechanism, it will not improve the
performance and will shorten service life.
To install the side skirts:
•Position the skirts at the left/right side of the machine.
•Remove the skirt retaining pins from the mount
bracket.
•Align the side skirt holes with mount bracket holes,
insert and secure retaining pins. Close side skirts
around machine and secure with skirt latch.
•The side skirt wiper blades will naturally wear with
use and require adjustment or replacement.
To adjust side skirt wiper blades:
•Install the side skirts on the machine.
•Loosen the retaining strip screws.
•Pull down evenly on the entire length of wiper blade
so that it firmly touches the floor.
•Tighten all screws and test run machine for splashing
under the blades.
•DO NOT adjust blades too low, as it will cause
damage and excessive wear to the blades.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

6
To replace side skirt wiper blades:
•Remove the side skirt assembly from the machine.
•Remove the retaining strip and screws.
•Remove the old wiper blade and replace with a
new blade.
•Replace the retaining strip and screws, do not
tighten.
•Pull down evenly on the entire length of wiper
blade so that it firmly touches the floor.
•Tighten all screws and test run machine for liquid
splashing under the blades.
•DO NOT adjust blades too low, as it will cause
damage and excessive wear to the blades.
Operating the Machine
The Wrangler 26 has the brush motors offset to the
right side of the machine. This offset allows you to
clean the edge of the floor or obstructed areas (walls
or shelving) with the right side of the machine.
•Sweep and dust mop the floor to remove dirt and
debris before scrubbing. Accumulations of dirt or
debris on the floor will reduce cleaning
performance.
•Overlap each cleaning path about 2 in. (5 cm.) to
prevent streaking and dirty areas.
Normal Cleaning
•Fill solution tank as directed.
•Put defoamer chemical in recovery tank.
•Install pad drivers / pads or brushes.
•Close and secure side skirts.
•Install squeegee assembly.
•Move machine to area to be cleaned.
•Sweep and dust mop area to be cleaned.
•Place warning signs “Wet Floor” in area.
•Turn on master switch.
•Turn on brush and vacuum motor switches.
•Place brush motors and squeegee assembly in
operating position on floor.
•Twist the handle grips forward (away from you) to
move forward and backward (toward you) to move
backward.
•Lift solution valve handle to adjust liquid flow to
floor. Adjust amount of flow as needed. Close the
solution valve completely 10 ft. (3m.) before you
turn at the end of each cleaning path. This will
reduce the amount of liquid on the floor when you
make the turn. Open the solution valve when you
have started your next cleaning path. Repeat this
procedure on each path.
•Watch the level of liquid in the recovery tank and
listen for the float shut-off to change the sound of the
vacuum motor. When the vacuum airflow stops, you
must turn off the vacuum motor and then empty the
recovery tank.
•Take the machine to an approved disposal drain and
turn off all switches.
•Raise the rubber flap at the front of the
Wrangler and pull out the flexible rubber drain hose.
•Raise the end of the hose above the level of the
recovery tank, loosen and remove the hose drain
plug. Carefully lower and direct the drain hose into
the drain.
•When the recovery tank is empty, replace and tighten
the drain plug. Place the drain hose back into the
machine and secure the plug end in the clamp. Do
not obstruct the lift mechanism or brush motors.
•Resume cleaning operation. Refill solution tank and
empty recovery tank as needed.
•When cleaning is complete, return machine to
storage area and perform daily maintenance.
Special Cleaning
The Wrangler may be used to perform special cleaning
jobs other than “normal” scrubbing.
•Double Scrubbing -This procedure provides deeper
cleaning on heavily soiled floors. One or more
cleaning passes are made before picking up the
chemicals with the squeegee. Best results are
achieved by placing the brush motors in the heavy
scrub position.
•NOTE: The floor surface becomes extremely slippery
in this operation. The Wrangler should be operated
only in low to medium speed and great care should
be taken when walking on this wet surface.
•Stripping -This procedure is used to remove
moderate build-up of floor finish from the floor. The
most aggressive pads or grit brushes are used in this
procedure.
•The stripper solution is applied to the floor with a mop
and then double scrubbed as above. Stripping
solution should not be put into the solution tank.
Clean water from the solution tank is applied to the
floor to keep the chemicals and finish in a “liquid”
condition. The floor surface becomes extremely
slippery in this operation. The Wrangler should be
operated only in low to medium speed and great care
should be taken when walking on this wet surface.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

7
MACHINE MAINTENANCE
Routine maintenance is critical to ensure proper
machine operation and cleaning performance.
Perform all maintenance procedures as follows.
Always turn OFF all machine switches before
performing any maintenance.
Daily Maintenance
Battery Charging
The master power switch and all other switches
must be turned OFF.
•You must recharge the batteries at the end of
every work shift or when the battery meter
indicates the “recharge” during the work shift.
•Connect the battery charger plug (red) to the
machine's charging plug.
•Connect the battery charger power cord into a
grounded A.C. outlet of the proper voltage.
•After a few seconds the amp meter (or light) will
indicate the battery charger is operating.
•When the recharge cycle is complete, the battery
charger will turn off automatically. The amp meter
will register “0” or the light will be off.
•If the battery charger will not start operating, check
the charging plug connections, the battery cable
connections and the battery voltage.
•If the batteries have been discharged (used) too
deeply, the battery charger will not start. Consult
your local authorized NSS distributor or service
center for assistance.
Battery Electrolyte (Liquid) Level
Inspect the electrolyte level of at least one cell in
each battery before charging. The liquid must be
visible above the internal plates. Do not charge the
batteries if the liquid is below the plates.
•Add only water to the cell of a battery to adjust the
liquid level. Before charging, add only enough
water to cover the top of the internal plates. After
charging add only enough water to bring the level
to the bottom of the fill tube.
•Do Not overfill the battery liquid level, this will
cause electrolyte (acid) spill. Spilled electrolyte
(acid) can cause machine damage and personal
injury. Clean up and dispose of all spills
immediately. See the battery-warning sheet for
more details.
Solution and Recovery Tanks
•Empty all liquids from both solution and recovery
tanks.
•Rinse both tanks with clean water to prevent
chemical residue build-up. Empty both tanks.
•Remove any residue from screen and float ball to
ensure proper operation. Replace float assembly
on tube in recovery tank.
•Leave recovery tank clear lid open to allow tank to
air dry and prevent odors.
Pad Drivers or Brushes
•Remove both pad drivers (or brushes) from machine.
•Rinse with clean water to prevent chemical residue
build-up.
•Inspect for wear or damage. Repair or replace as
needed.
•Allow to air dry on a shelf or rack.
Squeegee Assembly
•Remove squeegee assembly from machine.
•Rinse with clean water to prevent chemical residue
build-up.
•Inspect for wear or damage. Repair or replace as
needed.
•Allow to air dry on a shelf or rack.
Weekly Maintenance
•Verify all daily maintenance has been performed.
•Inspect battery liquid level, adjust to proper level as
needed.
•Check all battery terminal and cable connections.
Tighten as needed.
•Clean any corrosion from battery terminals and
cables.
•Check solution flow to pad drivers / brushes.
Remove, inspect and clean the solution filter
assembly.
•Flush clean solution tank and hoses with a mixture of
8 oz. (250ml.) white vinegar to one-gallon (4 liter)
warm water.
•Repair or replace any worn or damaged components
as needed.
Monthly Maintenance
•Verify all daily and weekly maintenance has been
performed.
•Inspect vacuum motor exhaust filter behind metal
plate at rear of battery compartment. Clean or
replace as necessary.
•Grease the caster axle and swivel bearing. Use a
hand held grease gun and a high grade ofwater
resistant lithium base grease.
•Inspect all mechanical linkages, pivot points and ball
joints for freedom of movement. Use a penetrating
spray lubricant that is water resistant. Do not use WD
40 lubricant.
•Check return springs of the twist grip (deadman)
handles. If they appear weak or do not return twist
grips to the neutral position, replace both springs.
•Inspect all fasteners (bolts, screws, nuts) at
mechanical linkages, pivot points and ball joints for
tightness. Tighten as needed.
•Repair or replace any worn or damaged components.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

8
Mandatory Periodic Maintenance
It is important for you to read the hour meter for
hours used in order to perform this machine
maintenance.
It is mandatory that the following maintenance
procedure be performed at the described interval.
This procedure should be performed by an NSS
authorized distributor or service center. Failure to
perform this procedure may result in poor machine
performance, machine component damage and
failure.
After every 450-500 hours of operation you must
inspect vacuum motor carbon brushes for wear.
After every 650-700 hoursof operation you
must inspect drive motor (transaxle) carbon brushes
for wear.
Replace the drive motor (transaxle) carbon brushes
when they are 3/8in. (9mm) in length. Replace the brush
drive motor carbon brushes when they are 1/2in.
(13mm) in length. Replace the vacuum motor carbon
brushes when they are 7/16in. (11mm) in length.
Authorized Repair Service
Repair service for this machine must be performed by
an NSS authorized service center. Repairs performed
by an unauthorized company will void the machine
warranty. If you require assistance finding an authorized
service center, please contact NSS Enterprises, Inc.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

9
TROUBLE-SHOOTING
PROBLEM CAUSE SOLUTION
No solution flow. Clogged filter. Clean filter.
Low battery charge. Charge the batteries.
The solution valve is closed. Open the solution valve.
Obstruction in the solution hose. Remove the obstruction.
Solution valve or linkage damaged. Repair/replace the valve linkage.
Solution hose kinked. Check for kinks at valve and remove.
Solution tank is empty. Fill the tank.
Solution flow does The solution solenoid valve is dirty Replace solenoid valve.
not stop. or damaged.
Will not pick up any Squeegee is up. Lower squeegee.
water from floor. Squeegee hose is off. Reinstall hose.
Vac motor switch is off. Turn Vac motor switch “on”.
Recovery tank is full. Empty tank.
Vacuum shut-off float is stuck. Open float valve/remove obstruction.
Obstruction/damage in the squeegee, Remove obstruction/repair damage.
squeegee hose or standpipe.
Leaking over gasket. Remove old gasket/replace.
Vac motor is not running. Have an authorized serviceman repair.
Recovery drain hose not plugged properly. Install drain hose plug properly.
Will not pick up all of the Debris on squeegee blades. Clean squeegee.
water from the floor. Squeegee blade is worn/damaged. Reverse/replace squeegee blade.
Obstruction/damage in the squeegee, Remove obstruction/repair damage.
squeegee hose, or standpipe.
Squeegee angle needs adjustment. Adjust angle.
Vacuum motor worn out. Repair / replace the Vac motor.
Recovery tank drain hose damaged. Repair / replace the recovery drain hose.
Batteries do not seem Overcharging batteries (charging.Monitor run time and adjust the charging
to run long enough. too frequently). frequency accordingly.
Tops of batteries are dirty/wet. Clean/dry, charge batteries.
Battery terminals are dirty/damaged. Clean terminals and connectors,
replace damaged cables. Charge.
Electrolyte level is too low. Add distilled water and charge.
Batteries are not fully charged. Charge batteries for 8 hours.
Charger is damaged. Have an authorized serviceman repair.
Battery is defective or worn out. Check cell voltage while discharging.
Cleaning is not even. Brush/pad is worn. Replace brush/pads.
Damage to brush assembly; casters Have an authorized serviceman repair.
or solution valve.
Machine does not run. Circuit breaker tripped. Reset circuit breaker.
Loose battery connection. Tighten battery connection.
NOTE: If any problems remain after taking the above steps, contact your local authorized
distributor/service station for further evaluation and repair.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

10
NOTES:
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

11
NOTES:
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

NSS®Enterprises, Inc.
3115 Frenchmens Road, Toledo, Ohio 43607
PHONE [phone] FAX [phone]
NSS ® Enterprises, Inc. European Distribution Centre
Unit II, Pinfold Trading Estate * 55 Nottingham Road
STAPLEFORD, NOTTINGHAM NG9 8AD ENGLAND U.K.
PHONE: [phone] * FAX: [phone]
WRANGLER 26 VS Orig. 6/98 Rev C 04/03 9092607
https://harrissupplyind.com-ToOrderPartsCall608-268-8080
