INTRODUCTION
Thank you for purchasing the FG-3000 series DDS Function Generator.
Based on the latest advances in DDS (Direct Digital Synthesis) technology, the FG-3000 series are
portable high precision sine, square, and triangle waveform function generator. The FG-3000 series
utilize microprocessor control that delivers clean and accurate waveforms up to 20MHz with 12V
peak-to-peak amplitude and DC offset variable up to ±5V in a portable hand-held unit.
The frequency output of the FG-3000 series can be set at 0.2Hz step resolution up to 20MHz. The easy
to use interface features a numerical keypad that allows simple and accurate frequency setting while
the 8-digit LCD displays the frequency value. Internal built-in flash memory allows store/recall of up
to 50 frequency values for various waveforms.
There are two BNC connectors for separate adjustable 12Vp-p sine/triangle/square wave output and
fixed 5V square wave output. The instruments can be power from the included 11V AC.
ITEM CHECKLIST
FG-3000 series DDS function generator
One 11V AC power adapter
One protective rubber boot
One User’s Manual
FEATURES
♦Up to 20MHz output frequency and 12V peak-to-peak amplitude
♦DDS technology with microprocessor control for clean and accurate waveform
♦Multiple output waveforms include sine, triangle, and square wave
♦Numerical keypad for simple and accurate frequency setting up to 0.2Hz step
♦8-digit LCD frequency display
♦Two BNC outputs for simultaneous fixed 5V square waveform and adjustable 12V sine/triangle /square
waveform output
♦Built-in flash memory for store/recall of up to 50 setup parameters
♦AC adaptor power source operation
♦Ideal for on-the-bench and in-the-field testing
♦Easy to use, lightweight, and portable
UNDERSTANDING THE INTERFACE

www.gmetechnology.com 1
1. Power ON/OFF Switch
This Power ON/OFF switch is on the left side of the unit. Slide the switch upward to turn the unit
on and downward to turn the unit off.
2. 11V AC Adaptor Input
Plug in a 11V 300mA 5.5mm x 2.1mm AC adaptor to power the FG-3000 series function
generator.
3. Frequency LCD Display
FRONT PANEL
1
2
4
3
5
6
12
8
7
9
11
13
10
14
15

www.gmetechnology.com 2
This 8-Digit LCD display shows input/output frequency value information.
4. Frequency Unit Display
These indicators will light to show the unit for the frequency value currently displayed on the 8-
Digit LCD screen (i.e. MHz, KHz, Hz).
5. Output Waveform Type Display
These indicators will light to shows the type of waveform being on OUTPUT BNC connector (i.e.
sine wave, triangle wave or square wave). NOTE: The fixed 5V p-p square wave is always being
output on the SQUARE BNC output connector.
6. SQUARE BNC output connector
Outputs the fixed 5V p-p square waveform of selected frequency.
7. OUTPUT BNC output connector
Outputs either sine, triangle or square waveform of selected frequency depending on the output
waveform type selected.
8. Amplitude Control Knob for Sine/Triangle/Square Waveform
The amplitude control knob is on the right side of the unit and is used to adjust the level of the
sine/triangle/square waveform output.
9. DC Offset Control Knob
The offset control knob is on the left side of the unit and is used to adjust the level of the DC offset
on the OUTPUT BNC connector.
10. Modify Keys
Use the left/right modify keys to select the desire digit on the LCD display to modify; use the
up/down modify keys to increment/decrement the value of the selected digit.
11. SHIFT Key Status LED
Press the SHIFT key to turn this LED ON/OFF. When this LED is on, the secondary function of
some keys on the keypad is activated.
12. Input Keypad
Use to key in desire frequency value and the frequency unit (i.e. MHz, KHz, and Hz).
13. Secondary Key Function
Shows the secondary functions of some keys on the keypad; the secondary function is activated by
first pressing the SHIFT key follow by the function key.
14.Offset Switch
Sliding the switch to turn the DC Offset on or off.
15.Output Switch
Sliding the switch to select the output waveform on the OUTPUT BNC connector.

www.gmetechnology.com 3
CAUTION:
OPERATION
The FG-3000 function generator outputs should never be connected to a signal
injection point. Excessive voltage applied to the function generator output can cause
internal damage to the function generator.
I. Setting Up The Instrument
1. Connect the FG-3000 function generator to the main supply with the included 11V AC adaptor.
2. Sliding the power switch to turn on the function generator.
3. The LCD display will turn on to show the current output frequency value. The respective
Frequency Unit Display LED (i.e. MHz, KHz, and Hz) and Output Waveform Type LED (sine
/ triangle/ square wave) will also light to indicate the current signal output waveform status.
II. Frequency Setting
1. With the FG-3000 function generator power up, use the front panel keypad to key in the desire
output frequency value.
NOTE: If the key in frequency is higher than the maximum allowed frequency, the function
generator will automatically set the output frequency to the maximum allowed frequency.
* Example: Key sequence for setting the output frequency to 102.1 KHz
2. The 8-digit LCD will display the value of the key pressed. The output frequency will only
change after one of the three frequency unit keys (i.e. “MHz”, “KHz”, and “Hz”) is pressed at
the end of frequency input sequence.
3. The “modify keys” can be used to change current frequency output.
i. Use the left/right modify key to select the desire digit on the LCD display; selected digit
will flash to indicate it is being selected.
ii. Once a digit has been selected to be modify, use the up/down modify keys to
increment/decrement the value on this digit
iii. Pressing the “SHIFT” key to finish modify.
* Example: Key sequence for changing the output frequency from 102.1000 KHz to 105.1000 KHz
TIPS: While keying in the desire frequency value using the keypad, pressing the “SHIFT” key will
cancel all the keys pressed, allowing the input process to start over. This feature is useful for
correcting any mistake made during the key in process
III. Waveform Type and Amplitude Setting

www.gmetechnology.com 4
1. Sliding the for select the sine/ triangle waveform or sliding the Output switch to right side for
select the square waveform on the OUTPUT BNC connector. The corresponding waveform
LED will light.
2. Output waveform type can be set by pressing the “SHIFT” key (the SHIFT key LED will light)
follow by either “7/SINE” (for sine wave) or “8/TRI” (for triangle wave) key on the keypad.
The corresponding waveform LED will light.
NOTE: The square waveform of selected frequency is always being output on the square wave
BNC output connector. Changing the output waveform will only affect the output on the
“OUTPUT” BNC connector.
* Example: Change the output waveform to sine wave if the “Output switch” on left side.
3. Adjust the waveform output level on “OUTPUT” BNC connector with the amplitude control
knob on the right side of the unit.
4. Adjust the waveform output DC offset on “OUTPUT” BNC connector with the DC offset
control knob on the left side of the unit.
IV. STORE/RECALL Memory Setting
The FG-3000 series can store/recall up to 50 setup parameters (both frequency value and waveform
type) with its built-in nonvolatile memory.
STORE
1. To store the current frequency value and waveform type, press the “SHIFT” key follow by the
“./STORE” key.
2. Key in the memory number from “00” to “49”. This will store the frequency value and
waveform type into this memory number.
* Example: Store current frequency value and waveform type into memory “02”
RECALL
1. To recall a stored frequency value and waveform type from memory, press the “SHIFT” key
follow by the “0/RECALL” key.
2. Key in the memory number from “00” to “49” to recall the frequency value and waveform type
stored in this memory number.
* Example: Recall frequency value and waveform type previously stored in memory “02”
SINE
STORE
RECALL

www.gmetechnology.com 5
Specifications
MODEL
FG-3005
FG-3010
FG-3015
FG-3020
Output Function
Sine, Square,
Triangle
Frequency Range
(For Sine, Square)
0.2 Hz - 5 MHz
0.2 Hz - 10 MHz
0.2 Hz - 15 MHz
0.2 Hz - 20 MHz
(For Triangle)
0.2 Hz - 2 MHz
0.2 Hz - 2 MHz
0.2 Hz - 2 MHz
0.2 Hz - 2 MHz
Frequency Resolution
(Under 10MHz)
0.2 Hz
(Above 10MHz)
1 Hz
Crystal Accuracy
+/- 30ppm
Output Amplitude
OUTPUT BNC Connector
Adjustable 12V peak-to-peak (no load)
SQUARE BNC Connector
Fixed 5V peak-to-peak (no load)
Impedance
50 ohm +/- 5%
DC Offset
±5V
Display
8-digit LCD Display
Store/Recall Memory Size
Store/Recall 50 setup parameters on built-in nonvolatile memory
Power Source
11v AC adaptor (300mA, 5.5mm x 2.1mm)
Operating Temperature
-10 deg ~ 70 deg
Dimension
5.7"(H) x 3.8"(W) x 1.5"(D) (144x96x38mm)
Weight
Approx. 1lb (0.5 kg)
