GO Elliptical LX-03 User manual

- 1 -
USER’S MANUAL
LX-03
USER WEIGHT LIMITATION: 300lbs(136kgs).
SERIAL NUMBER (found on frame):
USA
For Customer Service
1-267-808-3999
Email: [email protected]

- 2 -
Dear User,
Your GO Elliptical machine - Each machine shipped in Two Boxes Carton No. 1 is the main machine body and
Carton No. 2 is the Per-assembled top post with the whole VST (Variable Stride length system)
Pre-assembled, machine now will be very easy and simple to put together Suggest you get a second partner to
assemble the machine togetherWe are sure you will be able to put the machine together with ease and enjoy The
new World-wide Real VST unit with us.
Read the manual and there is no need to assemble any of the VST Part by you any longer!!

- 3 -
PREASSEMBLY
For future service or related questions:
Please staple your receipt and/or write in the name and phone number of the retail store where you purchased your item.
Name: ______________________________ Phone Number: ___________________ Receipt: ______________________
Open the boxes:
You are now ready to open the boxes of your new equipment. Make sure to inventory all of the parts that are included in the boxes.
Check the Parts List for a full count of the number of parts included for this product to be assembled properly. .
Gather your tools:
Before starting the assembly of your unit, make sure that you have gathered all the necessary tools you may require to assemble the
unit properly. Having all of the necessary equipment at hand will save time and make the assembly quick and hassle-free.
Clear your work area:
Make sure that you have cleared away a large enough space to properly assemble the unit. Make sure the space is free from
anything that may cause injury during assembly. After the unit is fully assembled, make sure there is a comfortable amount of free
area around the unit for unobstructed operation.
Invite a friend:
Some of the assembly steps may require heavy lifting. It is recommended that you obtain the assistance of another person when
assembling this product.
User Weight Limitation:
Please note that there is a weight limitation for this product. If you weigh more than 300lbs. it is not recommended that you use this
product. Serious injury may occur if the user’s weight exceeds the limit shown here. This product is not intended to support users
whose weight exceeds this limit.
For Customer Service
1-267-808-3999
Email: [email protected]

- 4 -
POWER REQUIREMENTS
Power Requirements:
IMPROPER CONNECTION OF THE EQUIPMENT GROUNDING CONNECTOR CAN RESULT IN THE RISK OF AN ELECTRIC
SHOCK. CHECK WITH A QUALIFIED ELECTRICIAN OR SERVICE MAN IF YOU ARE IN DOUBT AS TO WHETHER THE
PRODUCT IS PROPERLY GROUNDED. DO NOT MODIFY THE PLUG PROVIDED WITH THE PRODUCT, IF IT WILL NOT FIT
THE OUTLET; HAVE A PROPER OUTLET INSTALLED BYA QUALIFIED ELECTRICIAN.
This treadmill can be seriously damaged by sudden voltage changes in your home’s electrical power. Voltage spikes, surges and
noise interference can result from weather conditions or from other appliances being turned on or off. To reduce the possibility of
treadmill damage, always use a surge protector (not included) with your treadmill.
Surge protectors can be purchased at most hardware stores. The manufacturer recommends a single outlet surge protector with a
UL 1449 rating as a Transient Voltage Surge Suppressor (TVSS) with a UL suppressed voltage rating of 400V or less and an
electrical rating 120VAC, 15 amps.
This treadmill must be grounded to reduce the risk of electrical shock. Grounding provides a path of least resistance for electric
current, should the treadmill malfunction. This treadmill is equipped with an electrical cord that has an equipment-grounding
conductor and a grounding plug. Always plug the power cord into a surge protector, and plug the surge protector into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
This product is for use on a nominal 120-volt circuit, and has a grounding plug that looks like the plug illustrated in the drawing below.
GFCI outlets and GFCI / AFCI Circuit Breakers are NOT recommended for use on this product. GFCI outlets and GFCI / AFCI Circuit Breakers may cause this
equipment to function improperly.

- 5 -
SUPPLIED COMPONENTS BOX 1
SUPPLIED COMPONENTS BOX 2
SUPPLIED COMPONENTS BOX 3
Base Frame
Base Frame
Pedal Support Tube (L)
Pedal Support Tube (R)
Console Base
Fan/VST Board
Upright Tube

- 6 -
TOOL included with machine:
Action Handlebar (L)
Power pack
ActionArm Cover Front
Pedal Support Tube Top (L/R)
Pedal Support Tube Bottom (L/R)
ActionArm Cover Rear
Console Base Cover Rear
Water Bottle Holder
Console Base Cover
Rear
Pedal Support Tube (L)
Pedal (L/R)
Console
Pedal Support Tube (R)
Rear Stabilizer
Fixed Handlebar
Front Stabilizer
Action Handlebar (R)
Lower Upright Post Cover (L&R)
MILLIMETERS

- 7 -
General tools prepared by user:
COMPLETE PARTS LIST
Item No.
Description
Qty.
Part No.
1
Handlebar end cap
2
CE90-1
2
Handlebar grip
2
CE90-2
3
T-Bar grip
2
CE90-3
4
Hand pulse grip unit
2
CE90-4
5
Protective cap
4
CE90-5
6
Screw M8*1.25*15
2
CE90-6
7
Locking washer
2
CE90-7
8
Washer ∮25.4
2
CE90-8
9
Sleeve O.D. 25.4MM
4
CE90-9
10
Sleeve
8
CE90-10
11
Washer 10*32*2T
6
CE90-11
12
NY lock nut M10*1.5
9
CE90-12
13
Pedal tube shaft ∮17*70mm
2
CE90-13
14
Pedal tube shaft ∮17*97mm
2
CE90-14
15
Bearing 2203RS
4
CE90-15
16
Retainer R40
4
CE90-16
17
Washer 10*22*3T
2
CE90-17
18
Allen head bolt M8*1.25*15
38
CE90-18
19
Screw M8*1.25*72
4
CE90-19
20
NY lock nut M8*1.25
10
CE90-20
M8 socket
M8/M10
wrench
Screw driver 5mm
M8 wrench
M10 wrench
Screw driver 5mm

- 8 -
21
Plastic cap 5/16
4
CE90-21
22
Large square plastic cap
2
CE90-22
23
Rear foot cover
2
CE90-23
24
Front foot cover (middle)
2
CE90-24
25
Left roller holder
1
CE90-25
26
Right roller holder
1
CE90-26
27
Wheel
2
CE90-27
28
Screw M8*50
2
CE90-28
29
Screw M4*16mm
6
CE90-29
30
Screw M5*0.8*12
16
CE90-30
31
Screw M5*20
29
CE90-31
32
Screw M4*8
8
CE90-32
33
Bearing 6003
2
CE90-33
34
Bearing ∮17mm
4
CE90-34
35
Screw M6*15
1
CE90-35
36
Locking screw M8*1.25*30
1
CE90-36
37
Spacer 17*28*1.0
8
CE90-37
38
Screw M8*1.25*65
6
CE90-38
39
Washer 8*25mm
20
CE90-39
40
Screw M8*1.25*30
1
CE90-40
41
Nut M8
3
CE90-41
42
Spring 3.5mm*21mm
1
CE90-42
43
Console
1
CE90-43
44
P.U.Roller
2
CE90-44
45
Screw M5*15
4
CE90-45
46
Plastic flat round cap
2
CE90-46
47
Flywheel 250
1
CE90-47
48
Speed Sensor Cable
1
CE90-48
49
Belt 550 J6
1
CE90-49
50
Tool storage cover
1
CE90-50
51
Plastic flat round cap
2
CE90-51
52
Pedals
2
CE90-52
53
Pedal bracket
2
CE90-53
54
Adjustable foot
2
CE90-54
55
Small square plastic cap
2
CE90-55
56
End cap (T-Bar)
2
CE90-56
57
Rear cover left
1
CE90-57
58
Rear cover right
1
CE90-58
59
Outer rear cover left
1
CE90-59
60
Outer rear cover right
1
CE90-60
61
Screw M3*10mm
1
CE90-61
62
Motor
1
CE90-62
63
D- Axle ∮15**182mm
1
CE90-63
64
Magnet ∮14.8*7L
1
CE90-64
65
Washer 5/16*16*1.0
4
CE90-65

- 9 -
66
Pulley
2
CE90-66
67A
Base frame
1
CE90-67A
67B
Main frame
1
CE90-67B
68
Upright tube
1
CE90-68
69
Swivel tube, LH
1
CE90-69
70
Swivel tube, RH
1
CE90-70
71
Fixed handle bar
1
CE90-71
72
Handle bar, LH
1
CE90-72
73
Handle bar, RH
1
CE90-73
74A
Left pedal arm front
1
CE90-74A
74B
Left pedal arm rear
1
CE90-74B
75A
Right pedal arm front
1
CE90-75A
75B
Right pedal arm rear
1
CE90-75B
76
Front foot ( Stabilizer )
1
CE90-76
77
Rear foot ( Stabilizer )
1
CE90-77
78
Flywheel holder bracket
1
CE90-78
79
Belt tensioner
1
CE90-79
80
Metal cross, LH
1
CE90-80
81
Metal cross, RH
1
CE90-81
82
NY lock nut M12
6
CE90-82
83
Retainer R12
2
CE90-83
84
Metal plate
2
CE90-84
85
Roller axle ∮12**103mm
2
CE90-85
86
Connecting tube
2
CE90-86
87
Left decorative cover
1
CE90-87
88
Right decorative cover
1
CE90-88
89
Console cable 990MM
1
CE90-89
90A
Cable 1300MM
1
CE90-90A
90B
Main cable top
1
CE90-90B
91
Power wire 750MM
1
CE90-91
92
Power ADAPTOR
1
CE90-92
93
Washer ∮17*∮12*Ｔ1.0
3
CE90-93
94
Washer ∮35*∮12*Ｔ2.0
1
CE90-94
95
Washer ∮35*∮6*Ｔ2.0
1
CE90-95
96
Bearing 6001
6
CE90-96
97A
Toggle switch left
1
CE90-97A
97B
Toggle switch right
1
CE90-97B
98
Square moving arms (L)
1
CE90-98
99
Square moving arms (R)
1
CE90-99
100
Long connecting bar
2
CE90-100
101
Swinging axle plate
2
CE90-101
102
Second pedal support tube left
1
CE90-102
103
Second pedal support tube right
1
CE90-103
104
Step foot cover-Top
2
CE90-104
105
Step foot cover-Bottom
2
CE90-105

- 10 -
106
Decorative front cover for left step tube
1
CE90-106
107
Decorative rear cover for left step tube
1
CE90-107
108
Decorative front dover for right step tube
1
CE90-108
109
Decorative rear cover for right step tube
1
CE90-109
110
Roller cover
2
CE90-110
111
Screw M5*8
3
CE90-111
112
Bearing 6002
4
CE90-112
113
Aluminum rail
2
CE90-113
114
Axle for inner adjustor
1
CE90-114
115
Base for inner adjustor
1
CE90-115
116
Outer adjustor
1
CE90-116
117
Connecting axle for lift motor
1
CE90-117
118
Holder for lift motor
2
CE90-118
119
Adjustor connector
2
CE90-119
120
Hex head screw M10×70mm
1
CE90-120
121
Lift motor
1
CE90-121
122
Screw M4*16
24
CE90-122
123
Arm cover front
2
CE90-123
124
Arm cover rear
2
CE90-124
125
Base bracket for lift motor
1
CE90-125
126
Hex head screw M10×40mm
1
CE90-126
127
Bottle holder
1
CE90-127
128
Vest control board
1
CE90-128
90B
Main cable top
1
CE90-90B
129
380 Pulley rim
2
CE90-129
130A
Upright post cover
1
CE90-130A
130B
Upright post cover
1
CE90-130B
131
Console base
1
CE90-131
132B
Right upper upright post cover
1
CE90-132B
133
Front computer cover
1
CE90-133
134
Front cover
1
CE90-134
135
Screw M4*16mm
11
CE90-135
136
Screw M4*16mm
8
CE90-136
137
Adjustor end cap
2
CE90-137
138
Large adjustor screw M10
2
CE90-138
139
Fan network
1
CE90-139
140
FAN
1
CE90-140
141
Cable for Fan
1
CE90-141
142
Fan and vest control board
1
CE90-142
143
Inner small handlebar
2
CE90-143
144A
Handlebar cover front
2
CE90-144A
144B
Handlebar cover rear
2
CE90-144B
145
Rear console base cover
1
CE90-145
146
Adjustor guide cover
2
CE90-146
147
Adjustor fixed cover
2
CE90-147

- 11 -
148
Adjustor rod cover
8
CE90-148
149
Tablet holder
1
CE90-149
150
Screw M8*105
4
CE90-150
#A
Washer M8
4
CE90-#A

- 12 -

- 13 -
ASSE ASSEMBLY
STEP 1: Attach the Front Support (Front Stabilizer)
NOTE: To make attaching the support easier place a large
Styrofoam block under the machine.
(A) Attach the front support to the base frame with the wheels facing
outward.
(B) Align the 2 bolt holes in the front support with the bolt holes in the
main frame.
(C) Secure the front support to the main frame by using 2 x #19 bolts
inserted through the bottom, 2 x # 65 washers 2 x 20 lock nuts and
2 x #21 nut covers
(D) Tighten all bolts now.
#19
4
#65
4
#20
4
#21
4

- 14 -
STEP 2: Attach the Base Frame to the Main Frame
NOTE: Caution: Pinch Point Warning Do Not Pinch the Data Cables
Between the Frames. Keep Hands Clear.
(A) Place the base frame flat on the ground in front of the base frame.
(B) Slide the base frame connecting tube inside the main frame connector
tube
(C) Align the main frame bolt holes with the base frame threaded holes and
hand tighten all eight #18 bolts.
(D) Once all eight #18 bolts are inserted, use the Allen wrench to fully tighten
all the bolts.
(E) Now connect the computer cable extending from the main frame to the
cable extending from the base frame.
(F) Insert any extra cable length back in to the frame.
#18
8
Caution: Pinch Point. Do not pinch the data
cables or fingers between the two frames.

- 15 -
STEP 3:Attach the Upright Tube Assembly to the Base Frame
NOTE: This step is easier to complete with 2 people
! Caution Pinch Point: Do not pinch the wires between the frame!
(A) Hold the upright tube over the round base frame tube so that the data
cable can be connected prior to assembly
(B) After the data cable is connected slide the upright tube onto the round
base frame tube.
(C) Check to make sure the upright tube is facing the correct direction. (See
Fig. 4A)
(D) Secure the upright tube to the base frame by using 6 x #18 Allen head
bolts.
(E) Hand tighten all the bolts first Do not fully tighten these bolts until step 9.
Facing towards the
back of the machine
Fig 4A

- 16 -
STEP 4: Assembling the Pedal Tubes
(A) Place both the left pedal tubes #74Aand #74B on a flat surface.
(B) Secure the two pedal tubes together by using 2x #150 bolts and 2 x #20
Nylock nuts. (See Fig. 7A)
(C) Repeat the process for the right side pedal tube by using the right pedal
tubes #175A and 175B
(D) Tighten all bolts now.
(E) Place the aluminum rail #133 on top of the left pedal tubes and align the
bolt holes on the aluminum rail with the bolt holes on the pedal tube.
(F) Secure the aluminum rail to the pedal tubes by using 4x#30 screws. See
(Fig. 7B)
(G) Tighten all the bolts now.
(H) Repeat the process for the left side pedal tube
(I) Place the front and rear decorative covers #106 and #107 over the
aluminum rail bolts and secure them by using 2x#30 screws
(J) Repeat this process for the right side.
(K) Tighten all bolts now
#150
4
#20
4
#30
12

- 17 -
STEP 5: Attach the Pedal Tube Assembly to the Main Frame
(A) Attach the front pedal covers top and bottom #104/#105 to the left pedal
(this was assembled in the prior step) tube by using 2x #122 screws and 1
x #30 screw. (See Fig.8A)
(B) Repeat the process for the right side pedal tube
(C) Locate the left Pedal tube. NOTE: the left and right pedal tubes are
different and the machine will not function if the wrong pedal tube is
assembled to the wrong side.
(D) Attach the left pedal tube to the base frame pulley axel(See Fig.8B)
(E) Secure the left pedal tube to the base frame crank arm by using 1 x #17
washer and 1 x #12 M10 lock nut. Completely tighten with a wrench
(F) Repeat the process for the right side pedal tube
(G) Insert the front left of the pedal tube #86 in to Action handle bar tube #69
and secure them together by using 2 x #18 Allen head bolts (See Fig. 8C)
Do not fully tighten these bolts. These should be tightened in step 11
(H) Repeat the process for the right side. Do not fully tighten these bolts.
#122
4
#30
2
#12
2
#17
2
#18
4
Make sure both square moving Arm ( 98,and 99) toward the down direction, if
for any reason you have rotated the Swivel tube (l /R ) to occur the 98/99 arms
one of them towards up--just turn the Swivel tube 360 degree to make both
Moving towards to same down direction.
Wrong
Correct

- 18 -
STEP 6:Attach the Second Pedal Support Tube Assembly
(A) Place the left second pedal support tube assembly on top of the pedal
support tube and align the rubber roller on the center of the #113
aluminum rail.
(B) Insert the “U” bracket over the preassembled #98 short square swing
arm
(C) Insert the small axel #14 through the second pedal support tube #102 “U”
bracket and the short square swing arm #98
(D) Secure the small axel #14 by using 2 x #11 washers and 2 x #12 lock nuts.
(E) Completely tighten the large bolts and cover with 2 x #5 protective caps
(F) Repeat the process above for the right side.
NOTE: Due to the tight tolerance of part #102 and #98 it may be
easier to install put part #11 washer and #12 nut on one side of
the # 14 small axel and twist the axel through the part #102 and
#98.
#12
4
#5
4
#14
2
#11
4
Second pedal support tube (left)

- 19 -
STEP 7:Roller Alignment
(A) check with both Alum Rail there are Two of soft PP Bars attach to each
side of each Rail .Set both PU roller To the center of each the soft pp bars
in case any of the Roller will not be able to total set to the center of the
Rails Simply as photo 3 shown hold both of the handlebars (#72 and #73 )
as photo shown move both habdlebars together from side to Side to
make sure the Roller are set in the center of the alignment PP bars with
ease . if not, check with the Screws that suppose to Tightened with finger
tighten if some are tightened too much With assembly steps 3, 4, and
7 , (if not loose them a little ) Make sure all screws are in loose condition
and the Roller Will be set in the center of the pp Bars with ease After
Roller set then tighten up all screws ( #18) in Step 3, 4, and 7, firmly Also
the long Screw (M8 X 90 mm + nut ) tightened up as well.
(B) after all screws tightened up and PU Roller well set , pill off all four
soft PP bars at both side of each PU Roller Will not need these soft
PP bars anymore
12
1
2
4
5
6

- 20 -
