GO2 SKYE User manual

Page 1 of 6
GO2X00013 REV. B | SKYE DESK ASSEMBLY
power drilltape measure #2 Phillips
bit driver
adjustable wrench 6mm allen wrench level
bb
f
a
c
c
c
c
c
c
c
e
e
b
b
c
b
c
c
d
1
2
3
4
56
7
8
g
Components
1. Work Surface (1)
2. Power Cable (1)
3. Handset (1)
4. Control Module (1)
5. Work Surface Cross Supports (2)
6. Work Surface Support Rails (4)
7. Telescoping Leg (2)
8. Feet (2)
Hardware
a. #8 x 25mm Phillips Head Screw (2)
b. #8 x 16mm Phillips Head Screw (18)
c. M8-1.25 x 20mm Step Bolt (10)
d. M8-1.25 Hex Nut (2)
e. M8-1.25 x 20mm Bolt (4)
f. #6 x 16mm Phillips Head Screw (2)
g. Leveling Glide (4)
Tools Required
go2wfh.com
For proper care and
cleaning instructions visit
http://go2wfh.com/resources
Assembly Video

Page 2 of 6
1. Position legs with electrical connectors
facing together. Secure work surface
support rails to the inside hole of both
legs using (4) 20mm step bolts.
x4
2. Fit work surface cross supports to both
ends of base assembly. Align holes and
secure using (4) 20mm step bolts.
x4
go2wfh.com

Page 3 of 6
3. Attach feet using (4) 20mm bolts.
Thread (2) leveling glides to each foot.
4. Place work surface groove-side up on a
soft surface to protect from damage.
Position (2) leg assemblies on work
surface, overlapping as shown, then
slide and click rails together.
x4
x4
go2wfh.com
Click

Page 4 of 6
5. Adjust length of base assembly to align cross
supports holes with the predrilled holes in the
worksurface. Locate aligned holes in front and
back rail sections and insert a 20mm step bolt
through each. Secure with (2) 8mm nuts.
x2
6. Fasten base assembly to work surface
using (12) #8 x 16mm Phillips head
screws on each leg.
x12
Work Surface Damage Warning:
Take precaution to use only
#8 x 16mm Phillips head screws
to attach base assembly.
go2wfh.com
pre-drilled
holes
pre-drilled
holes

Page 5 of 6
go2wfh.com
10. Align handset to marked mounting
location and fasten using the two smallest
diameter #6 x 16mm Phillips head screws.
Route handset cord through rails and plug
into control module.
x2
x2
Handset Damage Warning
Take precaution to use
the smallest diameter
#6 x 16mm Phillips head screws
to attach handset.
Handset
Control Module
9. Determine desired handset mounting
position and orient the control module with
handset connector facing toward handset.
Align control module to pre-drilled holes
between legs and fasten to work surface
using (2) #8 x 25mm Phillips head screws.
Plug power cable and cables from each leg
into the control module.

Page 6 of 6
11. Secure loose wiring by looping
around notches in work surface
support rails or with the twist ties
from the cables.
12. Carefully flip desk upright.
13. Move desk to desired location.
14. Place a level on work surface and adjust for level
both side-to-side and front-to-back. Leveling glides
on both legs can be turned by hand as needed.
15. Plug power cord into outlet
16. Perform reset to syncronize legs by holding both
up and down buttons until both legs move to the
lowest position.
Two
Person
Lift
go2wfh.com
