GOAL ZERO SHERPA UI User manual

110V
220V
100W
MAX
ON
OFF
Allows you to use AC plugs at
110-220V and 100 Watts.
1. Be sure to ACTIVATE YOUR WARRANTY at www.GOALZERO.com/warranty
2. Attach the SHERPA UI power cord to the chaining port of the SHERPA power pack.
3. Turn the SHERPA power pack on.
4. Turn the SHERPA UI to on.
5. Ensure it is on the right voltage setting and plug in your device.
Get to Know Your Gear
Technical Specs
SECURE IT
POWER IT
The SHERPA UI rests on top of the SHERPA
power pack and plugs into the back.
Make sure to flip the power switch to on before use.
AC multi-standard outlet 110/220VAC, user switchable
100W max
12V port Chaining port
11-14V, 10A max (120W)
Output
Usage
Use with the following:
SHERPA 50 or SHERPA 120
Weight .8 lbs (0.36 kg)
Dimensions 6x4x2 in (15.2x10x5 cm)
Warranty 12 months
Operating usage temp. 32-104°F (0°-40°C)
General
USE IT
Getting Started
Input
How to Use Your Gear
Power switch
Push the rocker switch to the ON position to use the SHERPA UI with
2 or 3 pronged devices.
Plug
The universal outlet accepts all common Western, European, and
Asian plug types.
Voltage
A green light indicates which voltage (110 or 220) is selected.
To change the voltage flick the switch found on the back of the
SHERPA UI under the rubber stopper.
Chain
The SHERPA UI is NOT a battery. It is meant for use with the
GOAL ZERO power packs. Plug it into the chaining cable that
comes with the Sherpa power pack in order to use it.
Cooling
There’s no need to worry about your SHERPA UI over-heating.
It comes with a built-in fan to keep it cool.
Comes With:
SHERPA UI
12V male car adapter

CONTACT US:
Toll Free: 888.794.6250
14864 Pony Express Road
Bluffdale, UT, 84065
WWW.GOALZERO.COM
We proudly support Tifie Humanitarian
WWW.TIFIE.ORG
USER GUIDE
Output Ports
Frequently Asked Questions
Compatible With:
Is the SHERPA UI waterproof?
No. Do not use the SHERPA UI if it is wet. If it gets wet, allow it to dry completely before using it.
What will happen if I select the wrong voltage?
You can SEVERELY damage your devices if you do not select the right voltage. Please verify the voltage requirements
of your device before trying to power it via the SHERPA UI.
Can I use the SHERPA UI with chained GOAL ZERO SHERPA power packs?
Yes, but make sure all SHERPA power packs are turned on.
Can I use the SHERPA UI as a stand-alone source of power?
No. The SHERPA UI is specifically designed to enhance the capabilities of the SHERPA power packs.
It is NOT a battery, and cannot power items on its own.
Do I have to have a SHERPA power pack to use my UI?
The SHERPA UI can be used with SHERPA power packs as well as a 12V car adapter (included).
SHERPA UI
12V male car adapter
Common Western, European, and
Asian plugs.
(Must be 110 or 220V with a maximum of
100 Watts).
GOAL ZERO products:
SHERPA 50
SHERPA 120
