Goji GDABN14 User manual

Portable DAB radio
Instruction Manual
GDABN14 / GDABR14
GDABN_R14_IB_140529_will.indd 1 29/5/14 12:03 PM

GDABN_R14_IB_140529_will.indd 2 29/5/14 12:03 PM

3
Contents
Contents ............................................................................................................ 3
Safety Warnings .............................................................................................. 5
Unpacking.......................................................................................................10
Product Overview ........................................................................................11
Front & Side View.....................................................................................11
Top View......................................................................................................12
Power Source .................................................................................................13
Battery Power............................................................................................13
Battery Life (Approx. hours) .................................................................13
Knowing When to Replace the Batteries.........................................14
Mains Power ..............................................................................................15
Using Earphones...........................................................................................15
Basic Operation.............................................................................................16
Powering ON/OFF....................................................................................16
Adjusting the Volume.............................................................................16
Setting Equaliser ......................................................................................16
Language....................................................................................................16
Factory Reset.............................................................................................17
Software Version ......................................................................................17
DAB Operation ..............................................................................................18
Display .........................................................................................................18
Showing Signal Strength ......................................................................19
Full Scan ......................................................................................................20
Station Order.............................................................................................20
Station List..................................................................................................20
FM Operation.................................................................................................21
Selecting FM Mode .................................................................................21
Display .........................................................................................................22
Scan Setting...............................................................................................22
Audio Setting ............................................................................................22
GDABN_R14_IB_140529_will.indd 3 29/5/14 12:03 PM

4
Presetting Stations.......................................................................................23
Storing Preset Stations...........................................................................23
Recalling Preset Stations.......................................................................23
AUX IN Mode..................................................................................................24
Maintenance ..................................................................................................25
Cleaning the Unit.....................................................................................25
Hints and Tips ................................................................................................26
Specications.................................................................................................27
GDABN_R14_IB_140529_will.indd 4 29/5/14 12:03 PM

5
Safety Warnings
• Read all the instructions carefully before using the
unit and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
• Check that the voltage marked on the rating label
matches your mains voltage.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any
doubt about it working normally, or if it is damaged
in any way - switch o, unplug from the mains
socket and consult your dealer.
Location of Unit
• The unit must be placed on a at stable surface and
not subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces
as the unit may fall o or tip over.
• The mains socket must be located near the unit and
should be easily accessible.
Temperature
• Avoid extreme degrees of temperature, either hot
or cold. Place the unit well away from heat sources
such as radiators or gas / electric res.
• Avoid exposure to direct sunlight and other sources
of heat.
GDABN_R14_IB_140529_will.indd 5 29/5/14 12:03 PM

Naked Flames
• Never place any type of candle or naked ame on
the top of or near the unit.
Moisture
• To reduce the risk of re, electric shock or product
damage, do not expose this unit to rain, moisture,
dripping or splashing. No objects lled with liquids,
such as vases, should be placed on the unit.
• If you spill any liquid into the unit, it can cause
serious damage. Switch it o at the mains
immediately. Withdraw the mains plug and consult
your dealer.
Ventilation
• To prevent the risk of electric shock or re hazard
due to overheating, ensure that curtains and other
materials do not obstruct the ventilation vents.
• A minimum distance of 5cm around the unit should
be maintained to allow for sucient ventilation.
• Do not install or place this unit in a bookcase, built-
in cabinet or in another conned space. Ensure the
unit is well ventilated.
Safety
• Always disconnect the unit from the mains supply
before connecting / disconnecting other devices or
moving the unit.
• Unplug the unit from the mains socket during a
lightning storm.
GDABN_R14_IB_140529_will.indd 6 29/5/14 12:03 PM

• In the interests of safety and to avoid unnecessary
energy consumption, never leave the unit switched
on while unattended for long periods of time, e.g.
overnight, while on holiday or while out of the
house. Switch it o and disconnect the mains plug
from the mains socket.
Mains Adapter Cable
• Make sure the unit or unit stand is not resting on top
of the mains adapter cable, as the weight of the unit
may damage the cable and create a safety hazard.
Mains Adapter
• The mains adapter will continue to draw electricity
from the mains supply when plugged in the mains
socket. In the interests of safety and to avoid
unnecessary energy consumption, never leave
the adapter plugged in the mains socket while
unattended for long periods of time. Disconnect the
adapter from the power supply.
Interference
• Do not place the unit on or near appliances which
may cause electromagnetic interference. If you do,
it may adversely aect the working performance of
the unit, and cause a distorted sound.
Earphones
• Listening to loud sounds for prolonged
periods of time may permanently damage
your hearing.
GDABN_R14_IB_140529_will.indd 7 29/5/14 12:03 PM

• Before putting on earphones, turn the volume down
then put the earphones on and slowly increase the
volume until you reach a comfortable listening level.
Batteries
• Batteries used in the unit are easily swallowed by
young children and this is dangerous.
• Keep loose batteries away from young children and
make sure that the battery holder tray is secure in
the unit. Seek medical advice if you believe
a cell has been swallowed.
• Please dispose of batteries correctly by following the
guidance in this manual.
• Do not expose the battery to direct sunlight or
sources of excessive heat.
Supervision
• Children should be supervised to ensure that they
do not play with the unit.
• Never let anyone especially children push anything
into the holes, slots or any other openings in the
case - this could result in a fatal electric shock.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to alert
the user to the presence of uninsulated
“dangerous voltage” within the unit’s enclosure
that may be of sucient magnitude to
constitute a risk of electric shock.
GDABN_R14_IB_140529_will.indd 8 29/5/14 12:03 PM

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
manual accompanying the unit.
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-
serviceable parts. Please leave all maintenance work
to qualied personnel.
• Do not open any xed covers as this may expose
dangerous voltages.
Maintenance
• Ensure to unplug the unit from the power supply
before cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
GDABN_R14_IB_140529_will.indd 9 29/5/14 12:03 PM

10
If items are missing or damaged, please contact
Partmaster (UK only).
Tel: [phone] for assistance.
Thank you for purchasing your new Goji Portable DAB radio.
We recommend that you spend some time reading this instruction manual
in order that you fully understand all the operational features it oered.
You will also nd some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
Unpacking
Remove all the packaging from the unit. Retain the
packaging. If you dispose of it please do so according
to local regulations.
The following items are included:
Instruction
Manual
Main Unit Mains Adapter Instruction
Manual
GDABN_R14_IB_140529_will.indd 10 29/5/14 12:03 PM

11
1. Display
2. Earphones Socket
3. AUX IN Socket
4. DC IN 6V 500mA Socket
5. Aerial
6. Battery Compartment
Product Overview
Front & Side View
AUX IN
DC IN
6V = 500mA
1
2 5
6
3
4
GDABN_R14_IB_140529_will.indd 11 29/5/14 12:03 PM

12
Top View
1. Button
Press to switch radio on or o.
2. MODE Button
Press to switch among DAB, FM and AUX IN
modes.
3. MENU Button
Press to display menu screen of DAB, FM and AUX
IN modes.
4. PRESETS Button
• Press and hold to store preset station.
• Press to recall preset station.
5. VOLUME +/– Buttons
Press to increase/decrease volume.
6. TUNE Buttons
Press to upwards/downwards browse options.
7. SELECT Button
Press to conrm selection.
1 2 3 4 5 6
7
GDABN_R14_IB_140529_will.indd 12 29/5/14 12:03 PM

13
Power Source
Battery Power
Insert 4 x 1.5V AA batteries (not included) correctly by
following the polarity (+ or –) indications in the battery
compartment.
Battery Life (Approx. hours)
When Using FM DAB
Alkaline (Size AA) 4 4
+– +–
–+–+
GDABN_R14_IB_140529_will.indd 13 29/5/14 12:03 PM

14
Knowing When to Replace the Batteries
When the batteries become weak, the sound becomes
weak and distorted.
When the batteries are completely exhausted, the
power is turned o.
Handling the Batteries
• Improper or incorrect use of batteries may
cause corrosion or battery leakage, which
could cause personal injury or damage to
property.
• Install the batteries correctly by following the
polarity (+ and –) indications in the battery
compartment.
• Use only the types of batteries which are
indicated in this manual.
• Do not install new batteries with used ones
and do not mix dierent types of batteries.
• Do not dispose of the used batteries as
domestic waste. Dispose of them in accordance
with local regulations.
• If you are not going to use the unit for a long
time, remove the batteries to avoid damage
from battery leakage and corrosion.
• Due to the short battery life span of some
alkaline batteries, it is recommended to
use rechargeable batteries. You will need to
purchase a charger to charge the rechargeable
batteries. This saves cost and is more
environmental-friendly.
GDABN_R14_IB_140529_will.indd 14 29/5/14 12:03 PM

15
Long-term exposure to loud music may cause
hearing damage. It is best to avoid extreme
volume when using earphones, especially for
extended periods of time.
Using Earphones
Turn down the volume before
connecting the earphones. Slowly raise
the volume with the earphones on until
you reach your desired volume.
Mains Power
• This unit is designed to operate with the provided
mains adapter.
• Connecting the unit to any
other power source may cause
damage to the unit. Unwind
the mains adapter cable to its
full length. Connect the end
of the cable to the DC IN 6V
500mA Socket at the
rear of the unit and then connect
the mains adapter to the mains
socket. Make sure the mains
adapter is rmly inserted into
the mains socket. The unit is now
connected and ready to use.
AUX IN
DC IN
6V = 500mA
AUX IN
DC IN
GDABN_R14_IB_140529_will.indd 15 29/5/14 12:03 PM

16
Basic Operation
Powering ON/OFF
• Press the button to switch the unit on.
• Press the button again to switch the unit o.
• To switch the unit o completely, unplug the power
adapter from the mains socket.
Adjusting the Volume
Adjust the volume to the desired level by pressing +/–.
Setting Equaliser
1. Press the MENU button and then the buttons
repeatedly to select <System>. Press the button
to conrm.
2. Press the buttons repeatedly to select
<Equaliser>. Press the button to conrm.
3. Press the buttons repeatedly to select between
Treble and Bass. Press the button to conrm.
4. Press the buttons to set the level of Treble and
Bass. Press the button to conrm.
Language
1. Press the MENU button and then the buttons
repeatedly to select <System>. Press the button
to conrm.
2. Press the buttons repeatedly to select
<Language>. Press the button to conrm.
GDABN_R14_IB_140529_will.indd 16 29/5/14 12:03 PM

17
3. Press the buttons repeatedly to select the
desired language. Press the button to conrm.
Factory Reset
1. Press the MENU button and then the buttons
repeatedly to select <System>. Press the button
to conrm.
2. Press the buttons repeatedly to select <Factory
Reset>. Press SELECT to conrm.
3. Press the buttons to select <YES>. Press the
button to conrm.
Software Version
1. Press the MENU button and then the buttons
repeatedly to select <System>. Press the button
to conrm.
2. Press the buttons repeatedly to select <SW
version>. Press the button to conrm.
3. Press MENU to exit.
After the factory reset, all the tuned stations,
DAB/FM preset stations will be erased.
GDABN_R14_IB_140529_will.indd 17 29/5/14 12:03 PM

18
DAB Operation
When you turn on the radio it will automatically search
and store all the available stations. You may conduct an
additional Full Scan to ensure all stations are picked up
and stored. It is also recommended every few months
to run a new scan to pick up any new DAB/DAB+ that
may have begun broadcasting after your radio scanned
last time.
1. For initial use, your radio will conduct a full scan
and store stations list in memory.
2. Once the scanning is completed, the DAB/DAB+
stations will be displayed in alphanumeric order.
The rst station in the list will be selected.
• The DAB/DAB+ stations will be displayed and
stored in alphanumeric order.
• If no DAB/DAB+ signal is found, it may be
necessary for you to relocate your radio.
Display
This feature enables you to select the station
information which shows on the display.
1. Press the MENU button, and then press the
buttons to select <Display>, press the button
to conrm.
GDABN_R14_IB_140529_will.indd 18 29/5/14 12:03 PM

19
BBC 2
Stations with signal strength below the minimum
signal level may not provide a steady stream of
audio.
2. Press the buttons to browse through Scrolling
text, Signal strength, Program Type, Ensemble,
Frequency, Signal quality, Bitrate and Codec,
Format, and then press the button to conrm
your selection.
Showing Signal Strength
While you selected Signal strength, a signal bar with
the strength of the current station will show on the
display.
The indicator on the signal bar shows the minimum
acceptable signal level.
Strength of signal
Minimum signal level
GDABN_R14_IB_140529_will.indd 19 29/5/14 12:03 PM

20
Full Scan
This feature enables your radio to scan for all available
stations.
Press the MENU button, and then the buttons to
select Full scan, press the button to conrm.
Station Order
This feature enables your radio to display the stations in
dierent order.
1. Press the MENU button, and then press the
buttons to select <Station order>, press the
button to conrm.
2. Press the buttons to browse <Alphanumeric>
and <Ensemble>, and then press the button to
conrm your selection.
Alphanumeric Display all stations in alphanumeric
order.
Ensemble List currently broadcasting active
stations before inactive ones.
Station List
This feature enables you to select a station from
available station list.
1. Press the MENU button, and then press the
buttons to select <Station list>, press the
button to conrm.
2. Or, while a program is playing, press the
buttons to show station list.
GDABN_R14_IB_140529_will.indd 20 29/5/14 12:03 PM
