Goldair GD190 User manual

Thank you for choosing a Goldair Dehumidifier. This Goldair appliance has been
designed and manufactured to high standards of engineering and with proper
use and care, as described in this booklet, will give you years of useful service.
Please read these instructions carefully and keep for future reference.
YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF
THE INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.
1. WARNING you must not cover this appliance. Covering
this appliance presents fire risk.
2. Use only the voltage specified on the rating label of the
appliance.
3. Keep all objects at least 1 metre from the front, sides
and rear of the appliance.
4. This appliance is intended for household use only and
not for commercial or industrial use.
5. Indoor use only.
6. Do not use abrasive cleaning products on this
appliance. Clean with a damp cloth (not wet) rinsed in
hot soapy water only. Always remove plug from the
mains supply before cleaning.
7. The common cause of overheating is deposits of dust
or fluff in the appliance. Ensure these deposits are
removed regularly by unplugging the appliance and
vacuum cleaning the air vents and grills.
8. Always unplug appliance when not in use.
9. When the appliance has been unpacked, check it for
transport damage and ensure all parts have been
delivered. If parts are missing or the appliance has
been damaged, contact the Goldair Customer Services
Team.
10. If your appliance does not work, or is not working
properly, contact the place of purchase or the Goldair
Customer Services Team.
11. Do not connect the appliance to mains supply until
completely assembled and adjusted.
12. Ensure hands are dry before handling the plug or main
unit.
13. Do not locate the appliance directly below any power
socket outlet.
14. Ensure appliance is on a flat, stable, heat-resistant
surface.
15. Do not operate with cord set coiled up as a heat build
up is likely, which could be sufficient to become a
hazard.
16. Carry out regular checks of the supply cord to ensure
no damage is evident.
17. Do not operate this appliance with a damaged cord,
plug or after the appliance malfunctions or has been
dropped or damaged in any manner. Return to a
qualified electrical person for examination, electrical
service or repair.
18. Do not remove plug from power socket by pulling cord;
always grip plug.
19. Do not twist, kink or wrap the cord around the
appliance, as this may cause the insulation to weaken
and split. Always ensure that all cord has been
removed from any cord storage area and is unrolled
before use.
20. It is recommended that this appliance is plugged
directly into the wall socket. The use of power boards
is not recommended as many power boards are not
designed to supply power to high wattage appliances.
21. A correctly specified, undamaged extension cord may
be used with this appliance provided it is used in a safe
manner.
22. Use this appliance only as described in this manual.
Any other use is not recommended by the
manufacturer and may cause fire, electric shock or
injury.
23. Do not remove plug from power socket until the
appliance has been switched off.
24. Do not place cord under carpet or cover with rugs or
furniture. Arrange the cord so it cannot be tripped over.
25. Do not place appliance on bedding.
26. Switch off and use handle provided when moving.
27. Do not place appliance close to radiant heat source.
28. Never use the appliance to dry clothes.
29. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening, as this may cause an
electric shock, fire or damage to the appliance.
30. Do not sit on the appliance.
31. Do not operate in areas where petrol, paint or other
flammable liquids are used or stored.
32. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge, unless they are supervised or have been
given instruction concerning the use of the appliance
by a person responsible for their safety.
33. Children should be supervised to ensure that they do
not play with the appliance.
34. Do not use this appliance in the immediate surrounds
of a bath, a shower, or a swimming pool or other
liquids. The appliance must not be immersed in any
liquids.
35. There are no user serviceable parts installed in the
unit.
36. Do not place the unit in wardrobes or other enclosed
spaces as this may cause fire hazards.
37. This unit is not supposed to be used in or around
locations where foodstuffs, works of art or delicate
articles of science, etc are stored.
General Care and Safety Guide

Operating your Appliance
CONTROLS
Press or button to set the desired
humidity level in the room, which can be set
from 30%to 90%at 5% intervals or on ‘CO’ for
continuous dehumidification.
Once the room’s humidity is lower than the
selected humidity by 2%, the compressor will
stop and the fan stops working 3 minutes later;
When environmental humidity is equal to or
higher than the selected humidity by 3%, the
compressor will restart.
TIMER
The timer can be set to turn the unit On or Off.
To set to turn on; Press the Timer button when
the unit is turned off. Press again until you reach
the amount of hours you would like to elapse
before the appliance turns on (1-24).
To set the timer to turn off: Press the Timer
button when the unit is turned on. Press again
until you reach the amount of hours you would
like to elapse before the appliance turns off
(1-24).
WARNING: Keep all objects at least 1 metre
from the front, sides and rear of the appliance.
WARNING: In order to avoid overheating or
risk of fire, do not cover the appliance.
WARNING: Never leave this appliance
unattended when in use.
WARNING: Do not use this appliance with a
programmer, remote-control system, separate
timer or any other device that switches the
appliance on automatically.
Note: When the appliance is turned on for the
first time, it may release a slight odour. This
odour is a normal occurrence caused by the
initial starting of the unit and should not occur
again.
Leave the appliance to stand for one hour after
transport or after the unit has been on its side
before connecting it to the mains supply to let the
refrigerant settle.
Ensure that the water container is positioned
correctly.
Ensure all external windows and doors are closed
before turning on the unit.
Plug into power supply and switch on at the
mains. The dehumidifier will display the current
humidity level on the control panel. The POWER
indicator light will illuminate to show power to the
unit.
The louvre to be opened by lifting the louvre at
the opening and pushing it upward.
To turn the Dehumidifier on, press the POWER
button.
Always choose a safe location for your appliance, keeping in mind the safety
precautions outlined. Ensure all packaging has been removed from the unit
before use. This appliance requires no installation, it should be used solely
as a portable appliance.
CONTROL PANEL
Note: This dehumidifier is designed to provide optimum performance at 35°C -15°C but it is still effective down to
5°C. Ultimately the performance of this dehumidifier is dependant on the amount of moisture or water vapour in the
air.

1. Remove the
water tank 2. Connect the plastic tube
onto the water
outlet port
Replace the
water tank
Operating your Appliance
WATER TANK FULL
A beep signal will sound 15 times. The WATER
FULL indicator light will illuminate on the control
panel.
The compressor will stop automatically, and the
unit will stop dehumidifying.
Empty the water container and replace it in the
correct position. If the drainage tank is dirty,
wash it with cold or lukewarm water. Do not use
detergent, scouring pads, chemically treated
dust cloths, gasoline, benzene, thinner, or other
solvents, as these can scratch and damage the
tank and cause water leakage.
When replacing the drainage tank, press the
tank firmly into place with both hands.If the tank
is not positioned properly, the “TANK FULL”
sensor will be activated, and the appliance will
not operate.
Do not remove the float from the water tank. The
water full sensor will no longer be able to detect
the water level correctly without the float and
water may leak from the water tank.
The appliance will continue dehumidifying when
the compressor automatically restarts after
approximately three minutes.
PERMANENT WATER DRAINAGE
It is possible to connect a drainage tube (not
supplied) to the unit for permanent water
drainage.
If this option is desired, you will need to
purchase a suitable tube from your local
hardware retailer. (Goldair does not hold tubes
as spare parts).
Ensure that the end of the tube is lower than the
drain opening, otherwise the water will not drain
and flooding may occur. Also ensure the water
tank is in position (in the unit) otherwise the
continuous drainage will not operate.
Place the end of the drainage tube in a drainage
outlet. When you no longer wish to use the
permanent water drainage, disconnect the
drainage tube from the device.

Care and Cleaning
CARE AND CLEANING
The appliance requires regular cleaning to ensure
trouble free operation:
Unplug the appliance from the mains supply
before cleaning.
Ensure that the appliance has been allowed to
cool down completely before cleaning.
Use a damp cloth (not wet) to wipe the exterior of
the appliance to remove dust and dirt.
Never use solutions such as benzene, thinners or
polishing agents.
Use a vacuum cleaner to remove dust and fluff
from around the grills and fins.
Ensure the appliance is dry before plugging back
into the mains supply.
Do not attempt to dismantle the appliance. There
are no user serviceable parts. For service or
repair, contact an authorised electrical service
technician.
PROOF OF PURCHASE
To receive warranty retain receipt as proof of
purchase.
TO CLEAN THE AIR FILTER:
Unplug the appliance from the mains supply.
Remove the filter. Clean the filter with a vacuum
cleaner to remove dust or if it is exceptionally
dirty, wash it with warm water and a mild
detergent. Ensure the filter is completely dry
before placing back in the unit.
Never use unit without the air filter.
STORAGE
To store the unit, remove the plug from the socket
and empty the water tank. Allow the container
and the appliance to dry completely. Clean the air
filter. Store the device in a dust-free location,
preferably covered with a sheet of plastic.
Please note: This appliance is rated to extract
10L per day in an environment of 80% humidity
and temperature of 30°C. This is the world-wide
standard for rating dehumidifiers. In New Zealand
we do not have climatic conditions with this
humidity and high temperature. Accordingly, the
extraction levels may be lower.

Trouble Shooting your Dehumidifier
Problem Possible Cause Solution
The unit doesn't operate
Has the power cord been
disconnected?
Plug the power cord into
the outlet.
Is the tank full indication
lamp blinking? (The tank is
full or in a wrong position.)
Empty the water in the
drainage tank and then
reposition the tank.
Is the temperature of the
room above 35
℃or below
5
℃?
The protection device is
activated and the unit
cannot be started.
The dehumidifying
function doesn't work
Is the air filter clogged?
Clean the air filter as
instructed under
"Cleaning the
dehumidifier".
Is the intake duct or
discharge duct obstructed?
Remove the obstruction
from the discharge duct
or intake duct.
No air is discharged
Is the air filter clogged?
Clean the air filter as
instructed under
"Cleaning the
dehumidifier".
Operation is noisy
Is the unit tilted or
unsteady?
Move the unit to a
stable, sturdy location.
Is the air filter clogged?
Clean the air filter as
instructed under
"Cleaning the
dehumidifier".
TECHNICAL SPECIFICATION
Model No:GD190 Unit Capacity: 10.0L /day max (30℃/80%RH)
Supply:220-240VAC 50Hz Tank Capacity: 2.0L
Wattage: 240W Refrigerant: R134a
SUPPORT AND TECHNICAL ADVICE
Goldair –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
Goldair –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[e-mail]

Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in
normal domestic use for a period of two years. In non-domestic use Goldair limits the voluntary warranty to three
months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault
during the warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out
by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in
relation to the goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
Two Year Warranty
Goldair Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
Goldair –New Zealand
CDB Goldair
PO Box 100-707
N.S.M.C
Auckland
Phone [phone]
Phone [phone]
www.goldair.co.nz
Goldair –Australia
CDB Goldair Australia Pty
PO Box 574
South Morang
Victoria, 3752
Phone [phone]
Phone 1300 GOLDAIR (1300 465 324)
www.goldair.com.au
