Goldair GD270 User manual

Operating Instructions
16LDehumidifier
Model: GD270
Attention: This Dehumidifier is rated to extract 16L per day in an environment of 80%
humidity and temperature of 30°C. This is the world-wide standard for rating
dehumidifiers. In New Zealand we do not have climatic conditions with this humidity
and high temperature. Accordingly, the extraction levels may be lower.

General Care and Safety Guide
Thank you for choosing a Goldair Dehumidifier. This Goldair Dehumidifier has
been designed and manufactured to high standards of engineering and with
proper use and care, as described in this leaflet, will give you years of useful
service. Please read these instructions carefully.
TECHNICAL SPECIFICATION
Model No: GD270
Supply: 220-240VAC 50Hz
Wattage: 260W
Unit Capacity: 16.0L/day max (30℃/80%RH)
Tank Capacity: 4.0L
Refrigerant: R134a
1. Use only the voltage specified on the rating label
of the appliance.
2. Keep all objects at least 1 metre from the front,
sides and rear of the appliance. Do not place
appliance close to radiant heat source.
3. Do not operate in areas where petrol, paint or
other flammable liquids are used or stored.
4. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening, as this may cause
an electric shock, fire or damage to the
appliance. Do not sit on the appliance.
5. Do not operate this appliance with a damaged
cord, plug or after the appliance malfunctions or
has been dropped or damaged in any manner.
Return to a qualified electrical person for
examination, electrical service or repair.
6. This appliance is intended for household use
only and not for commercial or industrial use.
7. Use this appliance only as described in this
manual. Any other use is not recommended by
the manufacturer and may cause fire, electrical
shock or injury.
8. The common cause of overheating is deposits of
dust or fluff in the appliance. Ensure these
deposits are removed regularly by unplugging
the appliance and vacuum cleaning the air vents,
grills and filter. Never operate without air filter.
9. Do not use abrasive cleaning products on this
appliance. Clean with a damp cloth (not wet)
rinsed in hot soapy water only. Always remove
plug from the mains supply before cleaning.
10. Do not connect the appliance to mains supply
until completely assembled and adjusted.
11. Switch off and use handle provided when
moving.
12. Do not operate with cord set coiled up as a heat
build up is likely, which could be sufficient to
become a hazard.
13. It is recommended that this Dehumidifier is
plugged directly into the wall socket. Power
boards are not rated to supply power to high
wattage appliances.
14. A correctly specified, undamaged extension cord
may be used with this Dehumidifier provided it is
used in a safe manner.
15. Do not remove plug from power socket until the
appliance has been switched off.
16. Do not remove plug from power socket by pulling
cord; always grip plug.
17. Always unplug appliance when not in use.
18. Do not locate the Dehumidifier directly below any
power socket during operation.
19. Do not twist, kink or wrap the cord around the
appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord has
been removed from any cord storage area and is
unrolled before use.
20. This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities or lack of
experience and knowledge, unless they are
supervised or have been given instruction
concerning the use of the appliance by a person
responsible for their safety.
21. Do not use this appliance in the immediate
surrounds of a bath, a shower, or a swimming
pool or other liquids. The appliance must not be
immersed in any liquids.
22. When the appliance has been unpacked, check it
for transport damage and ensure all parts have
been delivered. If parts are missing or the
appliance has been damaged, contact the
Goldair Customer Services Team.
23. If your appliance does not work, or is not working
properly, contact the place of purchase or the
Goldair Customer Services Team. Repair work
on the appliance by unqualified persons can
cause serious risk to the user.
24. There are no user serviceable parts installed in
the unit.
25. Do not place the unit in wardrobes or other
enclosed spaces as this may cause a fire
hazard.
26. This unit is not supposed to be used in or around
locations where foodstuffs, works of art or
delicate articles of science, etc are stored.
27. Indoor use only.
28. Children should be supervised to ensure that
they do not play with the appliance.
29. Ensure Dehumidifier is on a flat, stable, heat-
resistant surface.
30. It is important that you do not cover this
Dehumidifier.

Components of your Dehumidifier
CONTROL PANEL
1. Control Panel
2. Dry Air Outlet
3. Removable Water Tank
4. Removable Air Filter
5. Carry Handle
6. Permanent Drainage Spout
1
2
3
4
5
6

Operating your Dehumidifier
IMPORTANT! NEVER COVER THIS
DEHUMIDIFIER!
TANK FULL INDICATOR
When the water tank is full, the TANK FULL light will
illuminate and the unit will stop working until the water
tank has been emptied and correctly replaced. The
Dehumidifier will continue dehumidifying when the
compressor automatically restarts after approximately
three minutes.
DEFROST
Occasionally the refrigerant around the motor can
become very cool, this will cause the unit to go into
defrost mode. The compressor will turn off and the
fan will continue to run. The DEFROST indicator light
will illuminate on the control panel.
This is a normal function for the dehumidifier and
cannot be controlled by the user.
Once the unit has completed defrosting, the
compressor will turn back on and continue to
dehumidify.
WARNING Keep all objects at least 1 metre from
the front, sides and rear of the appliance.
Leave the appliance to stand for one hour after
transport or after the unit has been on its side before
connecting it to the mains supply to let the refrigerant
settle.
Ensure all external windows and doors are closed
before turning on the unit.
Ensure that the water container is positioned
correctly.
Plug into power supply and switch on at the mains.
To turn the Dehumidifier on, press the ON button.
The unit will start to dehumidify. The operation Light
will flash until the compressor starts to run, the light
will stop flashing and remain on when the compressor
has started.
The compressor will switch off automatically when the
water container is full. THE FAN WILL CONTINUE
TO RUN.
As long as the water container is not full, the
Dehumidifier will continue to operate until it is
switched off manually.
If the Dehumidifier is switched off manually and then
switched back on, the compressor will start to operate
after three minutes.
To turn the Dehumidifier off, press the OFF button.
Wait at least 3 minutes between switching the unit off
and back on again to prevent damage to the
compressor.
If the power supply is cut at the mains without the
dehumidifier being powered Off first, allow at least 10
minutes before switching the unit back on.
If the unit fails to operate after it has been switched
off at the mains before allowing to power Off; switch
off the power at the power supply, leave the unit to
stand for 10 minutes. Switch the power supply back
on then Press the On button again on the unit, the
unit should now operate.
Please note: This Dehumidifier has a pre-set humidity
setting of 50%. If the humidity in the room drops
below 50%, the unit will stop dehumidifying until the
humidity increases to over 50% again.
The recommended operating temperature range is
15℃to 35℃.
Always choose a safe location for the Dehumidifier, keeping in mind the
safety precautions outlined. Ensure all packaging has been removed from
the unit before use. This appliance requires no installation, it should be
used solely as a portable appliance.

Cleaning and Maintenance
CARE AND CLEANING
The dehumidifier requires regular cleaning to ensure
trouble free operation:
Unplug the Dehumidifier from the mains supply
before cleaning.
Ensure that the Dehumidifier has been allowed to
cool down completely before cleaning.
Use a damp cloth (not wet) to wipe the exterior of the
Dehumidifier to remove dust and dirt.
Use a vacuum cleaner to remove dust and fluff from
around the grills.
Never use solutions such as benzene, thinners or
polishing agents.
Ensure the Dehumidifier is dry before plugging back
into the mains supply.
TO CLEAN THE AIR FILTER:
Unplug the Dehumidifier from the mains supply.
Remove the filter. Clean the filter with a vacuum or
with water. Dry the filter.
Ensure the filter is completely dry before placing back
in the unit.
Never use unit without the air filter.
Do not attempt to dismantle the Dehumidifier. There
are no user serviceable parts. For service or repair,
contact an authorised electrical service technician.
Do not use this Dehumidifier with a programmer,
separate timer, separate remote-control system or
any other device that switches the Dehumidifier on
automatically.
STORAGE
To store the unit, remove the plug from the socket
and empty the water container. Allow the container
and the Dehumidifier to dry completely. Clean the air
filter. Store the device in a dust-free location,
preferably covered with a sheet of plastic.
PERMANENT WATER DRAINAGE
It is possible to connect a drainage tube (not
supplied) to the Dehumidifier for permanent water
drainage.
If this option is desired, you will need to purchase a
suitable PVC tube from your local hardware retailer
(Goldair does not hold tubes as spare parts).
Connect the drainage hose to the drain spout.
Ensure that the end of the hose is lower than the
drain opening, otherwise the water will not drain and
flooding may occur.
Also ensure the water tank is in position (in the unit)
otherwise the continuous drainage will not operate.
Place the end of the drainage hose in a drainage
outlet.
When you no longer wish to use the permanent water
drainage, disconnect the drainage tube from the
device.

Trouble Shooting your Dehumidifier
Problem Cause Solution
The Dehumidifier will not
turn on The power is not connected
Insert plug into mains
power supply and turn unit
on
The Dehumidifier is not
extracting water
The water tank is full Remove the water tank
and empty water
The water tank is not in its
correct position Remove water tank and replace it correct position
The air filter is clogged Clean the air filter as per
instructions in user manual
The temperature or
relative humidity in the
room is too low
It is normal for the
Dehumidifier not to
operate in low humidity or
low temperatures
The Dehumidifier
operates, but reduces the
relative humidity in the
room by small amounts
The room which the
Dehumidifier is operating
in is too large
Recommend using a
Dehumidifier with a larger
capacity
There are too many
sources of humidity
Recommend using a
Dehumidifier with a larger
capacity
The room has too much
ventilation
Reduce the number of
ventilation sources (i.e.
close windows, doors, etc.
Goldair Select –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]z
Goldair Select –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[e-mail]
SUPPORT AND TECHNICAL ADVICE
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase. (Refer to back of booklet).

Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in
normal domestic use for a period of two years. In non-domestic use Goldair limits the voluntary warranty to three
months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault
during the warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out
by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in
relation to the goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
Two Year Warranty
Goldair Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
Goldair –New Zealand
CDB Goldair
PO Box 100-707
N.S.M.C
Auckland
Phone [phone]
Phone [phone]
www.goldair.co.nz
Goldair –Australia
CDB Goldair Australia Pty
PO Box 574
South Morang
Victoria, 3752
Phone [phone]
Phone 1300 GOLDAIR (1300 465 324)
www.goldair.com.au
