Gomax MS-5005BP User manual

HDMI 2.0a Installation Gear
User Manual
rev: 170810
Made in Taiwan
MS-5005BP

Safety and Notice
The MS-5005BP HDMI 2.0a Installation Gear has been tested for conformance to safety
regulations and requirements, and has been certified for international use. However, like all
electronic equipments, the MS-5005BPshould be used with care. Please read and follow the safety
instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
●Follow all instructions and warnings marked on this unit.
●Do not attempt to service this unit yourself, except where explained in this manual.
●Provide proper ventilation and air circulation and do not use near water.
●Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
●Use only the power adapter and power cords and connection cables designed for this unit.
●Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION.................................................................................................................1
FEATURES.........................................................................................................................1
PACKAGE CONTENTS......................................................................................................1
SPECIFICATIONS..............................................................................................................2
CONNECTION DIAGRAM ..................................................................................................3
PANEL DESCRIPTIONS.....................................................................................................4
MENU OPERATION ...........................................................................................................5
OPERATION APPROACH..................................................................................................6
WARRANTY .......................................................................................................................9

1
INTRODUCTION
The MS-5005BP HDMI 2.0a Installation Gear is a hand-held, pocket size and chargeable battery
supported device which can generate popular HDMI signals, detect important HDMI features, and
examine cable quality. With the help of MS-5005BP, installer can easily and quickly setup up and setup
HDMI equipment in seconds.
In “Source” mode, MS-5005BP provides reliable video patterns up to HDMI 2.0a 4K@60Hz 444 or 4K
HDR, including HDMI 1.4 resolutions such as 1080P and 720P. With adjustable color depth, installer can
instantly test the connected display’s capability and decide if the display under test is a right choice.
In “Sink” mode, MS-5005BP can be treated as a reliable HDMI signal detector to have fundamental
information such as resolution, frame rate, HDCP version. Those important pieces of information can help
installers to deal with tedious HDMI compatibility issues with ease.
In the “Cable” mode, this handy gadget can not only verify the wire condition of HDMI cable, but also
provide a cable quality indicator to help installers understand the cable status before doing any
installation. Especially for HDMI 2.0, the cable quality matters.
FEATURES
Supports video resolution*outputs up to 4K2K@60 4:4:4 8bit, HDR 10bits**, 12bits, 16bits
Built-in 3 video patterns
Both HDMI input and output support up to HDMI 2.0
Fundamental HDMI feature analysis up to 4K2K@60 4:4:4 8bit HDMI 2.0 input
HDCP 1.4 & 2.2 compliant
Tests cable quality
Provides statistics analysis for cable quality or connection stability
Hand-held pocket size
Battery powered for portability, it can extend operation time with full load up to 3 hours
Rechargeable battery design with short charging time about 3 hours
PACKAGE CONTENTS
1x MS-5005BP
1x User Manual
* Not supporting 4K2K60 DVI mode
**4K2K60 (YUV 4:2:0) 10bits is common resolution
Before using the MS-5005BP, please plugging the power adapter to switch off the
shipping mode

2
SPECIFICATIONS
Model Name
MS-5005BP
Technical
Role of usage
HDMI 2.0a Installation Gear
Video bandwidth
Single link 600MHz [18Gbps]
HDMI compliance
HDMI 2.0 and below
HDCP compliance
HDCP 2.2 and below
Video Support
up to 4K60 4:4:4 8bit, 4K2K60 4:2:0 16bit (HDR)
ESD protection
Human body model — ±15kV [air-gap discharge] & ±8kV [contact discharge]
Video Format Support
HDMI
Input
1x HDMI
Output
1x HDMI
Control
Push Button
HDMI connector
Type A [19-pin female]
USB Support
Firmware update / Recharge
USB connector
Micro-USB (Type B)
Mechanical
Enclosure
Metal case
Dimensions
(L x W x H)
Model
130 x 89 x 14mm [5.1" x 3.5" x 0.6"]
Package
198 x 137 x 74mm [7.8" x 5.4" x 2.9"]
Carton
420 x 400 x 300mm [1'4"x 1'3" x 11.8"]
Weight
Model
220g [7.8oz]
Package
320g [11.3oz]
Power supply
Micro-USB / Battery
Power Consumption
5W [MAX]
Operation temperature
0~40°C [32~104°F]
Storage temperature
-20~60°C [-4~140°F]
Relative humidity
20~90% RH [no condensation]

3
CONNECTION DIAGRAM

4
PANEL DESCRIPTIONS
1. Button (ENTER)
2. Button (DOWN)
3. Button (UP)
4. LCD Display: the measured data is shown here
5. OUTPUT: HDMI output
6. Micro-USB: Firmware update / Recharge
7. INPUT: HDMI input
8. Power Switch: Power ON/OFF Switch
MS-5005BP will automatically enter battery saving mode after 1 minute idle. During battery saving
mode, if user would like to get MS-5005BP back to work, please push any button. Notice that when
plugging in an active HDMI input, MS-5005BP will NOT enter battery saving mode.

5
MENU OPERATION
Menu
Items
Remark
SOURCE MODE
Resolution
Color space
Color depth
HDCP
Pattern provide three test patterns for user to use
(Ramp, Toggle, Color Bar)
SINK MODE
Resolution
read the HDMI information from input
source
Color space
Color depth
HDCP
AUDIO
EDID
CABLE MODE
CED
link quality estimator
*please refer to cable mode section
CEC
HEAC
+5V
HPD
DDC
Menu items subject to change without notification.

6
OPERATION APPROACH
Source Mode
When MS-5005BP is treated as a source, it can generate different test patterns to the display under test.
How to run Source Mode:
Make sure the connection between the MS-5005BP HDMI output port and the display.
Use buttons to select MODE category and enter SOURCE mode.
Use buttons to set up the output signal format and video testing pattern.

7
Sink Mode
When MS-5005BP is in sink mode, it can read the HDMI source’s information and in addition, the input
HDMI can be passed through to HDMI capable display if needed (as shown below).
How to run Sink Mode:
Connect the MS-5005BP between HDMI source and HDMI display.
Use buttons to select MODE category and enter SINK mode.
The source information will be present on the LCD. The process of acquiring HDMI information will
take about 3~5 seconds.

8
Cable Mode
In this mode, MS-5005BP offers a link quality estimator following the Character Error Detection
mechanism from HDMI 2.0 specification. The estimator can provide a basic link quality evaluation
regarding the cable or any other HDMI link connected to MS-5005BP. Please notice that the evaluation
result can provide an insight into the link quality under testing, but not always reflects the real
robustness of HDMI 2.0 full bandwidth connection. The stability of the full bandwidth HDMI 2.0
connection is affected not only by the cable or link quality but also many other factors, such as, the signal
integrity of the source, the ambient temperature, the reception of the display, and so on. Therefore the
testing result is just for a reference.
How to run Cable Mode:
Make sure the tight connection between the MS-5005BP and the cable.
Use buttons to select MODE category and enter CABLE mode.
Keep pressing ENTER button for about 5 seconds to start the link test. The MS-5005BP will evaluate
the HDMI signal quality based on HDMI 2.0 specification and provide a result, PASS or NG. Please
notice that during testing, MS-5005BP will NOT take any commands from buttons except ENTER.
Pressing ENTER continuously for 5 seconds will terminate the evaluation process.
Performance Criteria:
According to HDMI 2.0 specification, the performance criteria is shown ad the following table.
Test Result
Requirement
PASS
The error counts of signal are less than signal clock x 10-6
NG
The error counts of signal are more than signal clock x 10-6
Please be advised that the test result is based on the cable connection and the signal integrity of both
input and output from MS-5005BP. The indicator is usually a good reference for cable quality, but any
other source or display in consideration plays an important role in the final stability of the HDMI 2.0
connection.

9
WARRANTY
The SELLER warrants the MS-5005BP HDMI 2.0a Installation Gear free from defects in the
material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer.
Should this product fail to be in good working order within 1 year warranty period, The SELLER, at its
option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster,
abuse or any unauthorized modifications including static discharge and power surge. This warranty is
offered by the SELLER for its BUYER with direct transaction only. This warranty is void if the warranty
seal on the metal housing is broken.
Unit that fails under conditions other than those covered will be repaired at the current price of parts
and labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of reshipment
to the BUYER. If the unit is delivered by mail, customers agree to insure the unit or assume the risk of loss
or damage in transit. Under no circumstances will a unit be accepted without a return authorization
number.
The warranty is in lieu of all other warranties expressed or implied, including without limitations, any
other implied warranty or fitness or merchantability for any particular purpose, all of which are expressly
disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are responsible
for shipping charges to and from the SELLER. Cables and power adapters are limited to a 30 day
warranty and must be free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate. However, The
SELLER assumes no responsibility for any inaccuracies that may be contained in this manual. The
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting
from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the
technical information contained herein regarding the MS-5005BP features and specifications is
subject to change without further notice.
