GooBang Doo HDVCB1 User manual

HD VIDEO CAPTURE
USER GUIDE

SAFETY PRECAUTIONS
Before using GooBang Doo HD Video Capture, please ensure that you
read and understand the safety precautions below:
•Do not place heavy objects on GooBang Doo HD video capture.
•Do not attempt to open the case of GooBang Doo HD video capture or
modify it in any way, as this will void the warranty.
•Keep GooBang Doo HD video capture away from water and other liquids,
as this may cause the unit to malfunction.
•GooBang Doo HD video capture will be overheat during working. This
does not indicate malfunction.
•If the exterior of GooBang Doo HD video capture requires cleaning, wipe it
with a soft dry cloth.
•Do not dispose of the unit via conventional domestic waste.

INTRODUCTION
GooBang Doo HD video capture HDVCB1 is widely used in intelligent
communities, traffic management units, medical systems, educational
systems, home video capture and especially in games video producing.
The HD video capture can convert the HDMI signal from vidicon, TV Box,
PLAYSTATION, XBOX and others to recognizable file (MP4) into your USB
flash disk or mobile HDD. It includes USB 2.0 port, HDMI and microphone
input. And it supports capturing maximum resolution 1080P at 60Hz.
SPECIFICATION
Product Name HD Video Capture
Color Black
Capture format MP4 (H.264)
Power supply DC 5V 2.5A
HDMI Version HDMI 1.3
USB Version USB 2.0
Resolution support 480i,480p,576i,576p,720p,720i,1080p,1080i
Audio input LPCM32-192KHz
-20℃~50℃
Working temperature
ESD protect
Human-body Mode
± 8kV (Air-gap discharge)
± 4kV (Contact discharge)
Audio output LPCM 48KHz

PRODUCT DIAGRAM
1.ON/OFF: Press the button to turn on/turn off the power.
2.DC IN: Plug the power adapter into the socket and power on video
capture.
3.HDMI IN & OUT: Connect HDMI cable among the source video player,
TV and video capture.
4.USB: Insert the USB flash drive or mobile HDD to record videos into
the stprage medium.
5.REC/STOP: Press the button to start or stop recording.
6.MIC: Insert the microphone plug into this jack to input voice.
7.1080P/720P: Press the button to switch the output resolution between
1080P & 720P.
8.LED: Power on shows blue indicator, Capturing shows flickering white
indicator.

FEATURE
1.Capturing HDMI audio and video signal and convert to MP4 file.
2.Support maximum resolution both input and output 1080P at 60Hz.
3.HDMI output connect to TV(real capturing while playing).
4.Output video resolution is same as the input acquiescently.
5.Each file maximum volume is 2GB with sequential coding.
6.Output video resolution is same as the input.
CONNECTION GUIDES
1.Plug the power adapter into the power socket and plug the other end
into DC IN port of the video capture.
2.Connect Home game console or TV Box to HDMI In on GooBang Doo
video capture via an HDMI cable.
3.Connect GooBang Doo video capture from HDMI OUT to TV via an
HDMI cable.
4.Connect the USB flash drive or HDD to the USB port of video capture.

OPERATION INSTRUCTION
1.Connect the capture with HDMI source (such as PS4) , TV, flash drive,
microphone and power adaptor as the pictorial view and power on all of
the connected devices.
2.Choose the output resolution you want. The video capture default
setting will output same resolution as the input.
3.Press the capture button, the device will capture video to your flash
drive with white flickering indicator.
4.Press the stop button, the device will stop capturing, and the indicator
will turn to blue.
5.Pull out your flash drive after powering off the video capture, the video
has been captured into your flash drive. The video is 2GB each unit with
sequential coding.
ANNOUNCEMENTS
1.If HDMI source works well, the HDMI source indicator is blue; if not, the
indicator won’t light up, please check your HDMI source machine or the
HDMI cable.
2.Output video resolution is same as the input HDMI source.
3.If input 4K resolution source, the output video maximum is 1080P or
720P, it depends on your choice(Output resolution can not be higher than
input).
4. There’s no problem with the capture when it’s heated while capturing
since our metal case would help dissipate the heat.
5.When the storage space of the USB flash drive or HDD is used up, the
video capture will stop recording.
NOTE:You can switch resolution between 720P & 1080P only with the
input resolution of 1080i/1080P.

PACKAGE CONTENTS
Video Capture X 1
HDMI Cable X 2
Power Adaptor X 1
User Guide X 1
USB STORAGE
Please use an USB flash drive or HDD with the storage format in NTFS
or FAT32.HDD storage capacity should be less than 2TB.Please make
sure the disk boot format is MBR.
MICROPHONE FUNCTION
For best quality voice recording,please use good quality microphone.
Please use a microphone with a 3.5mm audio plug as follow:
