Retro Pedestal Fan
Owner’s Manual

2
TABLE OF CONTENTS
Introduction ............................................................. 3
Safety and Warnings................................................ 3
Grounding............................................................... 5
Fused Plug............................................................... 6
Unpacking............................................................... 7
Base Assembly......................................................... 7
Operation................................................................ 8
8 noitceleS deepS / ffO
8noitallicsO
Height Adjustment 8
Maintenance............................................................ 9
Technical Support................................................... 10
Trouble shooting.....................................................10
Warranty............................................................... 10
Attaching Motor To Pole........................................... 8
62802-01 20230315

3
INTRODUCTION
Thank you for choosing the Good Housekeeping
Oscillating Stand Fan manufactured by OceanAire
Home Goods Company. This manual gives you complete
instructions for assembling and using your fan. Here are
some of the features you will enjoy with your fan:
An attractive design that enhances any decor
Three speeds to adjust your comfort level
All metal construction
SAFETY AND WARNINGS
READ AND SAVE THESE INSTRUCTIONS! To reduce
When using electrical appliances, basic precautions
shock and personal injury:
Read all instructions before using this fan.
1. Improper installation may result in the risk of
electric shock or personal injury.
2. To prevent the risk of and electric shock, DO
NOT use the unit near windows. Rain and moisture
may create an electrical hazard.
3. The power plug must be removed from the power
socket when not in use, before cleaning, servicing,
maintenance and before moving to another location.
4. DO NOT put fan in a damp place or where humidity
is high, such as a bathroom.
5. The fan should be placed on a stable surface to
avoid overturning.
6. Use fan only for intended use, as described in this
instruction manual.
7. To protect against electrical shock, DO NOT immerse
any part of the unit in water or spray with liquids.
with any solid-state speed control device.
8. Close supervision is necessary when any appliance
is used near children.
62802-01 20230315

4
9. NEVER insert pencils or any other objects
through the grill when the fan is running.
10. DO NOT operate any appliance with a damaged
cord or plug, after the appliance malfunctions or has
been dropped or damaged in any manner. Discard
fan or return to an authorized service facility for
examination and/or repair.
11. To disconnect, grip plug and pull from wall outlet.
NEVER yank on cord.
12. ALWAYS use on a dry surface.
13. This product is intended for household use only and
not for commercial or industrial use.
14. DO NOT operate fan in the presence of explosive
15. DO NOT place fan or any parts near an open
cooking or any other heating appliances.
16. DO NOT use near curtains, plants, window
treatments, etc.
17. This appliance has a grounded three-prong plug
and is suitable for grounded receptacle use only.
An adapter is available for connecting three-blade
grounding-type plugs to two-slot receptacles. The
adapter must be properly grounded. DO NOT
attempt to defeat the purpose of this safely feature.
18. The rubber feet on this product may interact with
wood and cause damage to furniture. Do not place
niture.
19.
20. Children should be supervised to ensure they do not
play with the appliance.
Do not run cord under carpeting. Do not cover cord
with throw rugs, runners, or similar coverings. Do
not route cord under furniture or appliances.
will not be tripped over.
62802-01 20230315

5
Figure 1
Fi 1
This appliance is for household use only and may be
plugged into any 120-volt AC electrical outlet (ordinary
household current). DO NOT use any other type of outlet.
This unit is suitable for grounded receptacle use only.
The power cord has a grounded plug as shown in
Figure 1, and must be used with an electrical outlet that
can accommodate the grounding pin. If your electrical
must purchase an adapter as shown in Figure 2.
NOTE: The adapters ARE NOT supplied with this fan.
Read, follow, and save the instructions that are included
with the adapter you choose. The green grounding lug
extending from the adapter must be connected to a
permanent ground such as a property grounded outlet
accommodate the grounding pin.
LINE CORD SAFETY TIPS
1. NEVER pull or yank on the cord or the appliance.
2.
3. To disconnect the appliance, grasp the plug and
remove it from the outlet.
4. Before each use, inspect the line cord for cuts and/
or abrasion marks. If any are found, the appliance
should be serviced and the line cord replaced. Please
return it to our Service Department or to an authorized
service representative.
5. NEVER wrap the cord tightly around the
appliance, as this could place undue stress on the
cord where it enters the appliance and could cause
it to fray and break.
6. DO NOT operate the appliance if the line cord shows
any damage, if the appliance works intermittently or
stops working entirely.
Grounded
Plug
Grounding Pin Grounded Outlet
Box Cover
WARNING
Figure 2
Fi
2
Grounded Outlet
Box Cover
Metal
Screw
Adapter
Grounding
Means
GROUNDING
outlet cannot accommodate the grounding pin, then you
box. Do not use an adapter if your electrical outlet can
62802-01 20230315

6
Figure 3
Fi 3
This product uses overload protection (fuse). A blown
fuse indicates an overload or short-circuit situation. If the
fuse blows, unplug the product from the outlet. Discard
product if the attachment plug is damaged. To reduce the
remove, replace, repair or tamper with the originally
supplied plug. If the fan does not function properly, it may
be due to the safety device incorporated in this plug.
If the fuse fails, it is generally due to a short circuit or
circuit overload. Replace the fuse as per the instructions
below (follow product marking for proper fuse rating)
and check the product. If the replacement fuse
fails, a short-circuit may be present and
immediately unplug the unit and contact our
technical support department for assistance.
Fuse Replacement:
Grasp plug and remove from the receptacle or other
outlet device. Do not unplug by pulling on cord.
Locate the door on top of the plug. Figure 3.
2. Slide the door on top of the plug towards the blades.
Figure 4.
3. Carefully remove the fuse from the clips holding it on
with 5 Amp, 125 Volt fuse. Figure 5.
Warning! Electrical Hazard! Only replace with a
fuse type and rating matching what was removed from
a safety device (fuse) that should not be removed.
Discard product if the attachment plug is damaged.
the product. If the product fails a second time,
immediately unplug it and contact our technical support
at 1-888-880-3267.
4. Gently push the fuse back into the pins that will hold
it in place.
Note: If the fuse is not seated properly, the unit will not
function.
5.
6. Plug the fan back in and resume use.
Risk of re. Do not replace attachment plug as it contains
FUSED PLUG
Figure 4
Fi
4
Figure 5
Fi 5
Slide the door back over the fuse box in the plug.
62802-01 20230315

7
BASE ASSEMBLY
Figure 7
Figure 6
Figure 8
1.
pole by turning it counter clockwise. Slide the base
trim ring onto the pole. Reinstall the height
adjustment knob Figure 6.
2.
3. Insert the telescopic pole into the top of the base.
Install the metal ring and L-shaped screw into the
threaded hole in the bottom of the pole to secure the
4. Tip the base back upright.
5. Grasp the telescopic pole rmly and twist the
adjustment knob counter clockwise to loosen. Figure 9.
6. Raise the inner pole to maximum height and tighten
the adjustment knob by twisting clockwise until
secure. Figure 9.
Figure 9
UNPACKING
As you unpack the fan, save the carton and packing
materials in case you want to move or ship the unit in the
future. Carefully remove all items from the box.
NOTE: It is best to have someone hold the box while
carton. Make sure all shipping materials are removed
from fan before operating.
NOTE: It is
b
est to
h
ave someone
h
o
ld
t
h
e
b
ox w
h
i
l
e
ca
lifting the fan and protective packaging out of the
rton. Make sure all shipping materials are removed
f
rom
f
an be
f
ore operating.
Base
L
Metal Ring
-shaped
Screw
Telescopic
Pole
Telescopic
Pole
Base Trim
Ring
Height
Adjustment
Knob
Adjustment
Knob
Inner Pole
A
dj
ustme
n
K
no
b
e
r P
o
l
e
L-shaped
Screw
pole to the base. Figure 8.
Remove the height adjustment knob from the telescopic
Remove the L-shaped screw and metal ring from the
telescopic pole by turning it counter clockwise.
Figure 7.
62802-01 20230315

8
Figure 10
Clip Button
1. Press the clip buttons in completely while sliding the
pole from the motor housing assembly into the inner
pole until the clip buttons appear through the hole in
the inner pole. Figure 10.
ATTACHING MOTOR TO POLE
Motor
Figure 12
OPERATION
Turn the fan “ON” or “OFF” by turning the power/speed
control knob. The power should always be OFF before
This appliance is for household use only.
cannot fall or be pulled by the cord.
2. Plug the fan into a grounded 120-volt AC electrical
outlet (ordinary household current). DO NOT use any
other type of outlet. Make sure that the rated voltage of
the fan is the same as the power source before
plugging it into the power source.
unplugging the fan. To select the speed, turn the power/
speed control knob from OFF to the desired speed setting:
O (off), I (low), II (medium), III (high). Figure 11.
Off / Speed Selection
Oscillation
Height Adjustment
To allow the fan to oscillate, push the oscillation knob
down. Pull up on the knob if oscillation is not desired.
Figure 12.
To adjust the height of the fan, turn the adjustment knob
counter-clockwise to loosen the inner p
p
ole. Adjust the
adjustment knob in a clockwise direction. Figure 13.
Figure 13
Adjustment
Knob
Inner Pole
Ajustme
Kn
ob
e
r Pole
High
Medium
Low
Off
Oscillation
Knob
Fi urg e 11
62802-01 20230315

MAINTENANCE
This fan is permanently lubricated and will not require
additional lubrication (oil) for the life of the fan.
This fan requires little maintenance and contains no user
DO NOT immerse the fan in water or any other liquid.
CLEANING THE GRILL AND BLADE:
1. Turn the fan off and unplug from the electrical outlet.
2. Disassemble the grills by loosening the 6 screws
from the rear grill and remove the front grill with the
grill ring from the rear grill. Figure 14.
3. The blade may be removed by loosening the screw
holding it in place. Grills and blades may be cleaned
with mild soap and water only after they have been
removed from the motor housing.
4.
Use a soft, slightly damp cloth to wipe the remaining
fan parts.
DO NOT allow water or any other liquid to get into
the motor housing or base.
Reassemble the fan after blades and grills have
dried completely.
DO NOT plug the fan into an electrical outlet until it
has been fully reassembled.
the fan.
outlet. Wipe off excess dust with a lint-free cloth. To ensure
adequate air circulation to the motor, keep vents located
at the rear of the motor free from dust accumulation. A
vacuum cleaner hose can be used to clean these vents.
Before cleaning, turn the fan off and unplug from electrical
Use a dry or slightly damp lint-free cloth to clean
9
Figure 14
M3x8mm
screw
62802-01 20230315

TECHNICAL SUPPORT
TROUBLE SHOOTING
1. Problem
Fan will not oscillate.
Solution
Push down on the knob on top of motor housing to
activate oscillation.
WARRANTY
If you need any assistance with setup, operation, or parts
for your new Good Housekeeping Portable Fan, please
call us. Our technical support staff is ready to help! We
are open 24 hours a day, 7 days a week.
You may also reach us online at
OceanAireHomeGoodsCompany.com
An electronic copy of this user manual can also be
obtained online at
OceanAireHomeGoodsCompany.com
OceanAire Home Goods makes the following limited
warranty to the user or consumer purchaser of this
Good Housekeeping Portable fan:
If your Good Housekeeping Portable Fan motor fails at
any time within two years after the date of sale to you
due to a defect in material or workmanship, labor to
repair the defect will be provided free of charge at our
nearest service center or our Service Department in
Kennesaw, Georgia. You will be responsible for labor
costs after this two-year period. The foregoing limited
warranty applies only to the motor itself, and does not
apply to electronic controls such as remote controls,
remote control receivers or transmitters used in
conjunction with the motor. These electronic control items
are included in the one year limited warranty below.
If any part of your Good Housekeeping Portable Fan
other than the motor fails at any time within two year
1-888-880-3267 (FANS)
m
s
Warranty
2 Year
10 62802-01 20230315

after the date of sale to you due to a defect in material
or workmanship, we will repair or, at our option,
replace the defective part free of charge for parts and
labor performed at our nearest service center or at our
Service Department in Kennesaw, Georgia.
IF THE USER OR CONSUMER PURCHASER CEASES TO
OWN THE FAN, THIS WARRANTY AND ANY IMPLIED
WARRANTY WHICH THEN REMAINS IN EFFECT,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE VOIDED. NO
WARRANTY, EXPRESSED OR IMPLIED, INCLUDING ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, IS MADE IN RESPECT TO THE
GLASS GLOBES OR LIGHT BULBS OR THE FINISH ON
ANY METAL PORTION OF THE FAN. THIS WARRANTY
IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. THE
DURATION OF ANY IMPLIED WARRANTY, INCLUDING,
BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, IN RESPECT TO ANY FAN MOTOR OR
OTHER FAN PART, IS EXPRESSLY LIMITED TO THE
PERIOD OF THE EXPRESS WARRANTY SET FORTH
ABOVE FOR SUCH MOTORS AND OTHER PARTS.
This warranty is voided if your Good Housekeeping Fan
is not purchased and used in the USA.
This warranty excludes and does not cover defects,
malfunctions or failures of any Good Housekeeping
Portable fan which were caused by repairs by persons
not authorized by us, use of parts or accessories not
authorized by us, mishandling, improper installation,
modications, or damage to the Good Housekeeping
Portable fan while in your possession, or unreasonable
use, including failure to provide reasonable and
necessary maintenance.
11
To obtain servicing, contact the OceanAire Home Goods
Company Service Department, 980 Cobb Place
Boulevard NW, Suite 100, Kennesaw, GA 30144.
Please contact us before shipping your fan to us. If we
authorize you to ship it to us, you will be responsible for
all insurance and freight or other transportation charges
to our factory service center. We will return your Good
Housekeeping Fan freight prepaid. Your portable fan
should be properly packed to avoid damage in transit
l
r
O
D
R
NY
Warranty
2 Year
62802-01 20230315

980 Cobb Place Boulevard NW, Suite 100,
Kennesaw, GA 30144
GOOD HOUSEKEEPING is a trademark of Hearst
Communications, Inc. 2022 Hearst Communications,
Inc. All Rights Reserved.
since we will not be responsible for any such damage.
Proof of purchase is required when requesting warranty
service. The purchaser must present sales receipt or
other document that establishes proof of purchase.
SOME STATES DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS OR THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.
THE WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS
AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH
VARY FROM STATE TO STATE.
Printed in China
12
IN NO EVENT SHALL OCEANAIRE HOME GOODS BE
LIABLE FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES.
ty
E
Warranty
2 Year
62802-01 20230315
